The L-shaped partially encased steel–concrete composite (PEC) stub column, composed of profile steel, concrete, and transverse links, tends to occupy less space than the rectangle-shaped PEC column when used as side or corner columns. In this study, an axial compression test involving three L-shaped PEC stub columns was conducted to investigate the influence of critical factors on axial compression performance. The test results indicated that the axial compression capacity can be effectively enhanced with an increase in material strength. Furthermore, finite element (FE) analysis was carried out with parameters such as material strength, steel thickness, transverse link spacing, transverse link diameter, transverse link distribution, and longitudinal rebar diameter. The results revealed that the primary failure modes of L-shaped PEC columns were concrete spalling and local buckling of the flange. Additionally, it was found that the increase in steel strength, steel thickness, and transverse link diameter, as well as the decrease in transverse link spacing, significantly improved the axial compression capacity and concrete confinement effect. However, an increase in concrete strength diminished the concrete confinement effect. Additionally, the accuracy of the axial compression capacity calculation methods in the Eurocode 4 and T/CECS719-2010 specifications for L-shaped PEC stub columns was verified. Finally, a calculation method based on the superposition principle incorporating the concrete confinement effect was proposed, and validated by comparing with experimental and FE results. Overall, this study could provide a theoretical basis for the engineering application of L-shaped PEC columns. Full article

An experiment was conducted on a prestressed concrete (PC) composite girder bridge with steel truss webs to investigate its flexural performance. The mechanical characteristics and failure modes of a PC composite girder bridge with steel truss webs was clarified. Finite element (FE) analysis was carried out, and the influence of the girder height-to-span ratio and eccentric loading effect on the flexural performance of a composite beam bridge with a steel truss web was discussed. The method for calculating the cracking bending moment, the bending moment at the rebar yield stage, and the ultimate bending moment of a PC composite girder with steel truss webs was proposed. Key findings include that, in both the elastic and cracking elastic stages, the strain of the bottom and top conforms to the plane-section assumption. Throughout the loading process, there was no occurrence of joint failure or local buckling failure in the steel truss webs; the composite girder ultimately fails due to excessive deformation, indicating that the overall mechanical performance of the composite beam is good. The deflection and stress in the mid-span section decrease with an increasing height-to-span ratio, and there are significant impacts of eccentric loading on deflection and stress. Compared with the results of the FE analysis and test, the calculation methods of the cracking moment, reinforcement yield moment, and ultimate moment of PC composite girders with steel truss webs presented in this paper have a high accuracy. Full article

The embedded shear connector with flanges (ESCF) exhibits excellent shear performance in the steel–concrete composite beam. The ESCF consists of embedded corrugated steel web as the shear connector and shape-matched flanges for construction convenience. However, previous research showed that the steel flange of the ESCF was prone to local buckling when subjected to shear force, resulting in insufficient shear strength of the connector. In this paper, head studs were adopted to reinforce the ESCF at the flange with a large width-to-thickness ratio. Nine stud-reinforced embedded shear connectors with flanges (SR-ESCF) were manufactured to conduct the push-out test to investigate the shear performance of SR-ESCF. The effects of the reinforcing studs, thickness of the web, width-to-thickness ratio of the flange, embedding depth of the web, and diameter of the combined rebar on shear strength of the SR-ESCF were revealed and discussed thoroughly. The push-out test results showed that the head studs significantly improved the initial stiffness and load-bearing capacity of the ESCF, which were increased by 17% and 15%, respectively. Moreover, the head studs prevented local buckling of the steel flange. The shear strength of the specimens was greatly influenced by the embedding depth of the web, the width-to-thickness ratio of the flange as well as the reinforcing studs. However, the diameter of the combined rebar and thickness of the web had negligible effects on the shear capacity of the SR-ESCF. According to the test results, the nonlinear finite element model (FEM) and the shear capacity of SR-ESCF prediction formula were created and verified. Furthermore, the layout of the reinforcing studs welded on the flange of the SR-ESCF was optimized by the validated FEM, which indicated that the shear-bearing capacity of the SR-ESCF could be significantly increased by adding studs on the steel flange near the original studs. This research will be of great significance to the design and implementation of the steel–concrete composite beam bridge with corrugated steel web. Full article

FRP-confined concrete core-encased rebar (FCCC-R) is a novel composite structure that has recently been proposed to effectively delay the buckling of ordinary rebar and enhance its mechanical properties by utilizing high-strength mortar or concrete and an FRP strip to confine the core. The purpose of this study was to study the hysteretic behavior of FCCC-R specimens under cyclic loading. Different cyclic loading systems were applied to the specimens and the resulting test data were analyzed and compared, in addition to revealing the mechanism of elongation and mechanical properties of the specimens under the different loading systems. Furthermore, finite-element simulation was performed for different FCCC-Rs using the ABAQUS software. The finite-element model was also used for the expansion parameter studies to analyze the effects of different influencing factors, including the different winding layers, winding angles of the GFRP strips, and the rebar-position eccentricity, on the hysteretic properties of FCCC-R. The test result indicates that FCCC-R exhibits superior hysteretic properties in terms of maximum compressive bearing capacity, maximum strain value, fracture stress, and envelope area of the hysteresis loop when compared to ordinary rebar. The hysteretic performance of FCCC-R increases as the slenderness ratio is increased from 10.9 to 24.5 and the constraint diameter is increased from 30 mm to 50 mm, respectively. Under the two cyclic loading systems, the elongation of the FCCC-R specimens is greater than that of ordinary rebar specimens with the same slenderness ratio. For different slenderness ratios, the range of maximum elongation improvement is about 10% to 25%, though there is still a large discrepancy compared to the elongation of ordinary rebar under monotonic tension. Despite the maximum compressive bearing capacity of FCCC-R is improved under cyclic loading, the internal rebars are more prone to buckling. The results of the finite-element simulation are in good agreement with the experimental results. According to the study of expansion parameters, it is found that the hysteretic properties of FCCC-R increase as the number of winding layers (one, three, and five layers) and winding angles (30°, 45°, and 60°) in the GFRP strips increase, while they decrease as the rebar-position eccentricity (0.15, 0.22, and 0.30) increases. Full article

The construction industry is on the lookout for cost-effective structural members that are also environmentally friendly. Built-up cold-formed steel (CFS) sections with minimal thickness can be used to make beams at a lower cost. Plate buckling in CFS beams with thin webs can be avoided by using thick webs, adding stiffeners, or strengthening the web with diagonal rebars. When CFS beams are designed to carry heavy loads, their depth logically increases, resulting in an increase in building floor height. The experimental and numerical investigation of CFS composite beams reinforced with diagonal web rebars is presented in this paper. A total of twelve built-up CFS beams were used for testing, with the first six designed without web encasement and the remaining six designed with web encasement. The first six were constructed with diagonal rebars in the shear and flexure zones, while the other two with diagonal rebars in the shear zone, and the last two without diagonal rebars. The next set of six beams was constructed in the same manner, but with a concrete encasement of the web, and all the beams were then tested. Fly ash, a pozzolanic waste byproduct of thermal power plants, was used as a 40% replacement for cement in making the test specimens. CFS beam failure characteristics, load–deflection behavior, ductility, load–strain relationship, moment–curvature relationship, and lateral stiffness were all investigated. The results of the experimental tests and the nonlinear finite element analysis performed in ANSYS software were found to be in good agreement. It was discovered that CFS beams with fly ash concrete encased webs have twice the moment resisting capacity of plain CFS beams, resulting in a reduction in building floor height. The results also confirmed that the composite CFS beams have high ductility, making them a reliable choice for earthquake-resistant structures. Full article

The axial compression behaviour of fibre-reinforced polymer (FRP)-confined concrete-core-encased rebar (FCCC-R) was investigated by performing monotonic axial compression tests on seven groups of FCCC-R specimens and three groups of pure rebar specimens. The research parameters considered were the FRP winding angle (0°, ±45°, and 90°), number of layers (2, 4, and 6 layers), and slenderness ratio of specimens (15.45, 20, and 22.73). The test results showed that FCCC-R’s axial compression behaviour improved significantly compared with pure rebar. The axial load–displacement curves of the FCCC-R specimens had a second ascending branch, and their carrying capacity and ductility were enhanced substantially. The best buckling behaviour was observed for the FRP winding angle of 90°. The capacity and ductility of the specimens were positively related to the number of FRP-wrapped layers and inversely related to the slenderness ratio of the specimens. A finite element model of FCCC-R was constructed and agreed well with the test results. The finite element model was used for parametric analysis to reveal the effect of the area ratio, FRP confinement length, internal bar eccentricity, and mortar strength on the axial compression behaviour of FCCC-R. The numerical results showed that the area ratio had the most significant impact on the axial compression behaviour of FCCC-R. The confinement length of the FRP pipe and internal bar eccentricity had similar effects on the axial compression behaviour of FCCC-R. Both of them had a significant impact on the second ascending branch, with the post-peak behaviour exhibiting minimal differences. The influence of mortar strength on the axial compression behaviour of FCCC-R was observed to be minimal. Full article

Steel fibres provide ductility to concrete structures. This, in turn, gives possibility to replace or reduce conventional reinforcement in structural elements. In this study, the focus is on structural walls and the fibres as potential replacements for horizontal reinforcement in areas where vertical rebars are needed. An experimental study was conducted, in which prismatic specimens with longitudinal rebars were subjected to centric loading. Ten samples with 12 specimens in each were tested. The parameters considered were: fibre content, concrete cover for the longitudinal bars, and presence of stirrups. Self-compacting concrete with 30 and 60 kg/m${}^3$ steel fibres was used. Relative and normalised values of the test results were calculated; correlation and analysis of variance was used to estimate the effect of fibres. The results show that the fibres eliminated brittle collapse and spalling of concrete at failure. A strong negative correlation (−0.72 to −0.92) between amount of fibres and load-bearing capacity was found. On average, the reduction of the capacity was 8% to 16% if compared to the specimens with no fibres. However, a positive effect of the fibres on the ductility was observed. Specimens with 30 kg/m${}^3$ fibres showed the same post-peak behaviour as specimens with minimum horizontal reinforcement required by Eurocode 2. The study suggests that combination of steel fibres and conventional rebars can lead to less qualitative compactness of the self-compacting concrete, which in turn may reduce load-bearing capacity and stiffness of the structure. Special attention on concrete cover and distance between rebars should be paid if self-compacting concrete structures with steel fibres are designed. Full article

Aging and corrosion of reinforced concrete structures (RCS) is becoming a global problem, thus proper procedures for simulating the structural performance of corroded RCS should be assessed. Among the main corrosion effects, concrete cover cracking and reinforcement cross-section reduction may influence the materials’ constitutive laws, moreover the confinement contribution and the lateral instability of the longitudinal rebars can be modified. In the present paper, the predictive models available in the scientific literature to assess the materials’ mechanical properties of corroded RCS are recalled and employed into a novel model to derive the theoretical moment–curvature relationships for the cross-section of square and rectangular corroded reinforced concrete elements. The model accounts for cover spalling, buckling of longitudinal reinforcing bars, reduction in confinement pressures, reduction in concrete constitutive law due to the concrete cracking induced by rust formation and decay of mechanical properties for corroded reinforcements. The obtained results are compared with the classical simplified models for corroded RCS, highlighting that buckling and confinement variations cannot be disregarded into a reliable modelling strategy, especially when local ductility plays a key role in the performed investigations. Full article

This study analyzes the buckling behavior of 8-node IsoTruss^® structures with outer longitudinal members. IsoTruss structures are light-weight composite lattice columns with diverse structural applications, including the potential to replace rebar cages in reinforced concrete. In the current work, finite element analyses are used to predict the critical buckling loads of structures with various dimensions. A dimensional analysis is performed by: deriving non-dimensional $\Pi$ variables using Buckingham’s $\Pi$ Theorem; plotting the $\Pi$ variables with respect to critical buckling loads to characterize trends between design parameters and buckling capacity; evaluating the performance of the outer longitudinal configuration with respect to the traditional, internal longitudinal configuration possessing the same bay length, outer diameter, longitudinal radius, helical radius, and mass. The dimensional analysis demonstrates that the buckling capacity of the inner configuration exceeds that of the equivalent outer longitudinal structure for the dimensions that are fixed and tested herein. A gradient-based optimization analysis is performed to minimize the mass of both configurations subject to equivalent load criteria. The optimized outer configuration has about 10.5% less mass than the inner configuration by reducing the outer diameter whilst maintaining the same global moment of inertia. Full article

The purpose of the work was to propose analytical model considering double confinements (provided by both transverse reinforcements and a wide flange steel section), which was verified by the nonlinear finite element analysis considering concrete-damaged plasticity. The scope of the effort and the procedures to achieve the aim of this study included the identification of the concrete confinements provided by both transverse reinforcements and a wide flange steel section based on the elasto-plastic model in tension for both rebar/steel sections and elasto-buckling for rebars in compression. The influence of rebar buckling in the compression zone on flexural moment strength was also investigated with and without considering confining effects offered by steel sections. The analytical approach predicted a post-yield behavior of composite beams based on the confining effect offered by both the shear reinforcement and wide steel flange sections. However, for beams without axial loads, the compressive zones with high and partial confinements for concrete sections at the yield and maximum load limit state were limited when compressive buckling failure was not considered, preventing the confining factors from significantly influencing the flexural load resisting capacity. An accurate flexural capacity of composite beams can be obtained when rebar was modeled with buckling in the compression zone. Full article

To investigate the effect of constructional measures (including horizontal and vertical stiffeners, rebar cages, embedded steel tubes, and cavity welded steel plates) under high axial load ratios on the seismic performance of concrete-filled steel tubular (CFST) columns, quasi-static tests for six large-scale CFST columns with various constructional measures are performed. All specimens are subjected to identical axial forces. The failure mode, hysteresis characteristics, bearing capacity, stiffness degradation, ductility, and energy dissipation of specimens are analyzed. The study shows that the horizontal stiffener delays the occurrence and severity of column base buckling, the vertical stiffener improves the bending resistance capacity and initial stiffness of the member, the rebar cage improves the ductility, and the embedded circular steel tube significantly improves the member’s bearing capacity, ductility, and energy dissipation. When an internal circular steel tube and cavity welded steel plate are applied in tandem, the section steel ratio increases by 4.42% and the bearing capacity improves by 42.72%. A finite element model is created to verify test results, and simulation results match the test results well. Full article

Detection of early-stage corrosion on slender steel members is crucial for preventing buckling failures of steel structures. An active photoacoustic fiber optic sensor (FOS) system is reported herein for the early-stage steel corrosion detection of steel plates and rebars using surface ultrasonic waves. The objective of this study is to investigate a potential method for detecting surface corrosion/rust of steel rods using numerically simulated surface ultrasonic waves. The finite element method (FEM) was applied in the simulation of propagating ultrasonic waves on steel rod models. The pitch-catch mode of damage detection was adopted, in which one source (transmitter) and one sensor (receiver) were considered. In this research, radial displacements at the receiver were simulated and analyzed by short-time Fourier transform (STFT) for detecting, locating, and quantifying surface rust located between the transmitter and the receiver. From our time domain and frequency domain analyses, it was found that the presence, location, and dimensions (length, width, and depth) of surface rust can be estimated by ultrasonic wave propagation. Full article
