Search Results (54)

Determination of nozzle quality ratings based on macroscopic and microscopic parameters generally requires the use of separate measurement methods in research. The guiding idea determining the direction of the conducted research was to use a 2D (two-dimensional) laser analyzer LDA/PDA (laser Doppler anemometry/phase Doppler anemometry) to evaluate the values of selected micro and macro parameters (microstructure characterization with simultaneous evaluation of lateral distribution) of the spray. The research was conducted for variable measurement times. The main issue of the research was an attempt to reduce the measurement cycle time, important in the case of point tests performed with an analyzer. The scope of the conducted research covered three areas. In the first stage of the research, the variability of the coefficients characterizing the spray spectrum as a function of variable measurement time was analyzed. In the next, the value of the coefficient of transverse volume distribution (for a single sprayer) was determined. The results were determined on the basis of the volume diameters obtained from measuring the droplets with a 2D LDA/PDA analyzer. In the third stage, an attempt was made to combine the volume distribution results obtained for single nozzles on the boom. The results obtained were compared with those determined using a groove table. Both measurement methods used a different representativeness in volume measurement (sampling method and significantly different amounts of liquid analyzed); nevertheless, the results of the transverse volume distribution were found to be consistent. Full article

Electrostatic spraying systems can improve the pesticide application efficiency by enhancing droplet deposition and coverage within crop canopies. This study evaluated the droplet size spectra and charge-to-mass ratio (CMR) of five electrostatically charged hollow-cone nozzles and one flat-fan nozzle paired with an electrode. Each nozzle was mounted on a moving boom in a wind tunnel and operated with the electrode and voltage that produced the highest CMR. Their effects on the spray coverage and deposition inside boxwood shrubs at wind speeds of 0 and 2.24 m s⁻¹ were assessed. The nozzles operated with the optimized electrode had average improvements in the canopy deposition and canopy coverage of 1.33 µg cm⁻² and 4.4% at a wind speed of 0 m s⁻¹ and 0.26 µg cm⁻² and 0.9% at a wind speed of 2.24 m s⁻¹. The airborne drift measurements at various heights above the wind tunnel floor showed an average 0.50 µg cm⁻² reduction in the drift at 0.1 m, variable results at 0.35 m, and minimal changes at heights of 0.7 m and above at a downwind distance of 2 m. These findings highlighted the potential of optimized electrostatic spraying systems to enhance pesticide deposition inside the crop canopy under various wind speeds while reducing the spray drift potential. Full article

Unmanned aerial vehicles (UAVs) offer significant advantages in agricultural pest control. The present study investigated the influence of rotor-induced wind fields from multirotor UAVs (six-rotor T30, eight-rotor T40, eight-rotor T50, and four-rotor T60) on pesticide droplet deposition and control efficacy in cotton fields. The results revealed that UAVs with stronger wind fields (e.g., T60) significantly improved droplet deposition in the middle and lower canopy layers, with penetration rates of 54.09–56.04% which were notably higher than the penetration rate observed for the T30 (45.83–44.76%). UAVs exhibited a pesticide utilization efficiency of 75.47–77.86% indicating a 32.2% improvement over the boom sprayers, which achieved a utilization efficiency of 58.88%. While the boom sprayers initially showed a better pest control efficacy, the efficacy gap narrowed after 7 days, with T40 achieving 91.55%, comparable to the efficacy of boom sprayers (93.36%). Following a second spraying, UAVs achieved defoliation rates exceeding 93% and boll opening rates exceeding 90%, similar to that of boom sprayers. This study underscores the critical role of wind field intensity in influencing the spraying performance, with UAVs featuring stronger wind fields exhibiting superior droplet penetration and distribution uniformity. These findings provide valuable scientific insights for optimizing UAV spraying in cotton fields. Full article

Peanut (Arachis hypogea L.) crops in the southeastern U.S. suffer significant yield losses from diseases like leaf spot, southern blight, and stem rot. Traditionally, growers use conventional boom sprayers, which often leads to overuse and wastage of agrochemicals. However, advances in computer technologies have enabled the development of precision or variable-rate sprayers, both ground-based and drone-based, that apply agrochemicals more accurately. Historically, crop disease scouting has been labor-intensive and costly. Recent innovations in computer vision, artificial intelligence (AI), and remote sensing have transformed disease identification and scouting, making the process more efficient and economical. Over the past decade, numerous studies have focused on developing technologies for peanut disease scouting and sprayer technology. The current research trend shows significant advancements in precision spraying technologies, facilitating smart spraying capabilities. These advancements include the use of various platforms, such as ground-based and unmanned aerial vehicle (UAV)-based systems, equipped with sensors like RGB (red–blue–green), multispectral, thermal, hyperspectral, light detection and ranging (LiDAR), and other innovative detection technologies, as highlighted in this review. However, despite the availability of some commercial precision sprayers, their effectiveness is limited in managing certain peanut diseases, such as white mold, because the disease affects the roots, and the chemicals often remain in the canopy, failing to reach the soil where treatment is needed. The review concludes that further advances are necessary to develop more precise sprayers that can meet the needs of large-scale farmers and significantly enhance production outcomes. Overall, this review paper aims to provide a review of smart spraying techniques, estimating the required agrochemicals and applying them precisely in peanut fields. Full article

In the Huang-Huai-Hai region of China, the instability of electric boom sprayers has prompted many farmers to raise the boom height to improve clearance. However, the drift risks associated with these conditions remain poorly assessed. This study investigated two key factors influencing drift: boom height and nozzle type. The standard LI CHENG VP11003 nozzle was compared to the Teejet XR11003 nozzle, and droplet size and velocity were measured at various boom heights. The results showed that, at the same boom height, the LI CHENG nozzle produced droplets with an average D[V, 0.5] 14.6 µm larger (8.13%), an average velocity 0.53 m/s lower (29.26%), and a relative span (RS) value 0.05 higher (4.52%) compared to the Teejet nozzle. Drift tests were performed under field conditions using a spray drift test bench. The results showed that the total drift amount per unit area (TDA) for the LI CHENG nozzle showed minimal variation at boom heights of 0.4–0.6 m (Stage 1), 0.7–0.9 m (Stage 2), and 1.0–1.2 m (Stage 3). The drift potential of the LI CHENG VP11003 nozzle increased by 136.62% in Stage 2 and 282.69% in Stage 3, relative to Stage 1. Similarly, the Teejet XR11003 nozzle showed increases of 30.52% and 165.51% in Stages 2 and 3, respectively. The results showed that the LICHENG nozzle, which is the standard equipment on the sprayer, can only be used to moderately increase the boom height to improve the sprayer’s clearance within the range of the first stage. When the boom height exceeds this range, the drift risk becomes too high. This study provides meaningful insights into enhancing drift control and developing application strategies for growers. Full article

Maize–soybean intercropping can increase soybean yields and stabilize maize yields, and this practice has been widely promoted in China. Fluroxypyr is a recommended herbicide for maize seedlings, and its drift will cause phytotoxicity to neighboring soybean seedlings. A laboratory toxicity test was performed on soybeans by using a mobile bioassay spray tower. It showed that both the carrier volume and the drift deposition rate of fluroxypyr significantly influenced soybean fresh weight. The soybean fresh weight inhibition rate increased with the increase in the drift deposition rate, especially in the range of 1% to 6%, and soybean fresh weight decreased rapidly. The lack of fit R² was 0.6875, with a 9% maximum deviation between experimental values and simulated values. The drift deposition rate upper threshold for mild phytotoxicity (10% fresh weight inhibition rate, ED₁₀) was determined to be 3.35%, while the threshold for no phytotoxicity (0% fresh weight inhibition rate, ED₀) was 1.01%. To ensure soybean safety, isolation devices and anti-drift nozzles were installed on the boom sprayer to maintain drift below ED₀ or, at most, ED₁₀. Maize seedling strip weed control field tests showed that the highest drift deposition rate was 0.689% under the carrier volume of 330 L·ha⁻¹. There was no phytotoxicity observed on soybeans after 21 days of application, which was consistent with laboratory research results. In this study, the phytotoxicity risk and safe thresholds for the fluroxypyr drift on soybean seedlings were established, which provide a theoretical basis for the safe production of soybeans. Full article

Spraying is currently one of the main methods of pesticide application worldwide. It converts the pesticide solution into fine droplets through a sprayer, which then deposit onto target plants. Therefore, in the process of pesticide application, improving the effectiveness of spraying while minimizing or preventing crop damage has become a key issue. Combining the advantages of electrostatic spraying technology with the characteristics of ground boom sprayers, a contact-type electrostatic boom spraying system based on a rod–plate electrode structure was designed and tested on a self-propelled boom sprayer. The charging chamber was designed based on the characteristics of the rod–plate electrode and theoretical analysis. The reliability of the device was verified through COMSOL numerical simulations, charge-to-mass ratio, droplet size, and droplet size spectrum measurements, and a droplet size prediction model was established. The deposition characteristics in soybean fields were analyzed using the Box–Behnken experimental design method. The results showed that the rod–plate electrode structure demonstrated its superiority with a maximum spatial electric field of 2.31 × 10⁶ V/m. When the spray pressure was 0.3 MPa and the charging voltage was 8 kV, the droplet size decreased by 26.6%, and the charge-to-mass ratio reached 2.88 mC/kg. Field experiments showed that when the charging voltage was 8 kV, the spray pressure was 0.3 MPa, the traveling speed was 7 km/h, and the number of deposited droplets was 8517. This study provides some basis for the application of electrostatic spraying technology in large-scale field operations. Full article

The aim of this study was to determine the influence of boom height above a crop stand and the spacing between nozzles and diffusers in an over-row sprayer on the uniformity of the horizontal spray distribution and the uniformity of the air velocity distribution. The experimental setup involved a prototype over-row sprayer equipped with a boom with a working width of 8 m and ten air diffusers with spray nozzles. Air diffusers were connected to one or two nozzles each, and they were installed on the boom at intervals of 60, 80, and 90 cm. Terminal airflow velocity at a canopy is determined by the height of a sprayer boom and the diffuser spacing, ranging from around 2 m s^–1 to around 27 m s^–1. The sprayer boom should be positioned at a height of 50 cm above a crop stand due to the difference between the minimum and maximum airflow velocities. The horizontal spray distribution was more uniform when the sprayer was equipped with hollow-cone nozzles instead of flat-fan nozzles; hollow-cone nozzles should be applied if the distance between nozzles needs to be adjusted to the row width and row spacing. The analyzed coefficients did not exceed 10% when the boom was positioned 50 cm above the crop stand and when the nozzles were spaced 80 cm apart, which suggests that, in this configuration, sprayers equipped with hollow-cone nozzles can also be applied to close-grown crops. Full article

In the dynamic operation of a boom sprayer, the boom oscillation will cause the detection value of the boom height to fluctuate greatly, resulting in failures of the control system. Based on the previously developed static boom height detection model for the entire wheat growth cycle, this study aimed to optimize the model to reduce the impact of boom oscillation on the accuracy of boom height detection. Three ultrasonic sensors were installed on each section boom of a three-section boom sprayer, and dynamic boom height detection tests were conducted at vehicle speeds of 4 to 8 km/h across six growth stages of winter wheat in Beijing, a total detection area within a single fixed operational row of approximately 14 ha. The test results showed that as vehicle speed increased, boom oscillations intensified across all sections. By setting the boom oscillation correction parameters, the detecting value of each section of boom height is corrected. The results show that the fluctuation and deviation degree of the boom height-detecting value are obviously reduced, and the correction effect is obvious. Further analysis of the detecting value of the boom height after the correction shows that the previously established detection model still maintains high detection accuracy under dynamic conditions; that is, the detection position of the ultrasonic sensor does not downward shift. This paper provides a low-cost technical method that can be directly applied to the dynamic detection of boom height. Full article

With recent advances in spray technology and rising interest in site-specific applications, it is imperative to assess the performance of the latest application technologies to ensure effective pesticide applications. Thus, a study was conducted to compare and evaluate the performance of two different flow control systems [rate controller (RC) and pulse width modulation (PWM)] on an agricultural sprayer while simulating different site-specific application scenarios. A custom data acquisition and logging system was developed to record the real-time nozzle flow and pressure across the sprayer boom. The first experiment measured the response time to achieve different target application rates in single-rate site-specific (On/Off) states at varying simulated ground speeds. The second experiment examined the response time for rate transitions in variable-rate application scenarios among different selected target rates at varying simulated ground speeds. Across all the application scenarios, the PWM system consistently outperformed the RC system in terms of response time and rate stabilization. Specifically, the PWM system exhibited significantly lower mean rate stabilization times compared to the RC system during single-rate application states. Similarly, in the variable-rate application states—where the rate transitions were evaluated—the PWM system consistently displayed shorter mean rate transition and stabilization times compared to the RC system. Overall, the findings from this study suggest PWM systems tend to be more responsive and effective, making them the preferred choice for efficient precision site-specific pesticide applications. Future research should evaluate the influence of other operational parameters such as look-ahead time and ground speed variations on the performance of both systems in actual field applications. Full article

Pesticide application equipment (PAE) is the last part of the chain during the plant protection process. The use-phase of plant protection products (PPP) has been addressed in two EU Directives: 128/2009/EC and 127/2009/EC. This last one covers all the mandatory technical requirements to be fulfilled by new sprayers prior to their placement in the market. The objective of this research was to develop a potential decision support system (DSS) to evaluate and quantify the degree of implementation of all the required characteristics of new sprayers, including not only the mandatory requirements but also specifications widely described in the corresponding harmonized standard ISO 16119. It includes 10 independent elements of the sprayer, including a list of technical specifications listed in the applied standards ISO 16119 and ISO 16122. The relative influence of every one of the different elements has been quantified based on previous research. The algorithm enables the establishment of an objective relative classification of the sprayers to differentiate among different machines, mainly based on their quantified environmental contamination risk. The DSS can also discriminate among sprayers that should not reach the market due to their non-compliance with any of the mandatory requirements. Full article

In modern agriculture, which is characterised by dynamic field environments, challenges are faced in maintaining consistent application rates due to varying tractor speeds, field conditions, and certain calibration errors. Conventional control systems, which rely on slower valves, have difficulty adapting to these dynamic field conditions. By contrast, the integration of fast-acting proportional valves improves the precision and flexibility of flow rate adjustment during spraying applications. This research focused on evaluating the accuracy of spraying applications under different tractor speed conditions through field experiments and data analysis. This study involves a field sprayer with boom wings divided into right and left sections, where the flow rate of the liquid to each section is controlled by proportional valves with a 3 s full opening and closing time, dependent on speed information. Using a closed-loop control system consisting of a flow meter, proportional valve, and PLC, the valves are controlled by the PLC’s internal PID blocks. Observations reveal that as the tractor speed increases to a certain level, the system effectively adjusts the application rate close to the target value and maintains control against the changing ground speed during all field tests. The study included five different application tests, with target application rates of 100, 150, 200, 250, and 300 L ha⁻¹, with each repeated three times, resulting in a total of 15 field tests at different ground speeds. During these tests, the data were meticulously recorded every second, covering the tractor speed, flow rate, and pressure values for both right and left boom sections, along with regulator pressure, proportional valve opening rates, and application rates. The durations for each application rate were documented alongside instances within specified periods where error boundaries of ±10% were exceeded. During the total test duration of 9734 s, the actual application rate value exceeded error boundaries during only 209 s. Within the application durations, the speed variation intervals ranged from 5.10 to 10.23 km h⁻¹, 4.64 to 9.91 km h⁻¹, 3.68 to 7.89 km h⁻¹, 4.80 to 8.21 km h⁻¹, and from 4.90 to 8.69 km h⁻¹. The absolute percentage mean application errors were recorded as 2.81%, 2.68%, 2.28%, 2.14%, and 2.51% for respective application rates. Furthermore, statistically significant correlations (p < 0.01) were identified among the variables (speed, valve opening rate, flow rate, pressure) in both the right and left boom sections across all application rates. Full article

A fast spraying speed, wide working area, and easy operation are the operational advantages of high-clearance boom sprayers. To address the issue of spray boom mechanical vibration affecting the spraying effect, a double-link trapezoidal boom suspension is designed for the 3WPYZ sprayer. This suspension can achieve passive vibration reduction, active balance, and ground profiling. The kinematic model of the boom suspension is established based on D’Alembert’s principle and the principle of multi-body dynamics, and the design factors affecting the stability of the boom are determined. Through orthogonal experimental design and virtual kinematics simulation, the influence of the boom length and orifice diameter of each part on the swing angle and the natural frequency of the boom suspension is investigated. Design-Expert 8.0.6 software is used to analyze and optimize the test results. The optimization results show that, when the connecting boom length L_AB is 265 mm, the inner boom suspension boom length L_AD is 840 mm, the outer boom suspension boom length L_BC is 1250 mm, and the throttle hole diameter d is 4 mm; the maximum swing angle of the boom suspension is reduced by 53.02%. In addition, the natural frequency of the boom is reduced from 1.3143 rad/s to 1.1826 rad/s, and the dynamic characteristic optimization effect is remarkable. The modal analysis results show that the first sixth-order vibration test frequency of the boom sprayer suspension designed in this paper meets the requirements and avoids the influence of external factors. Field tests show that, when the sprayer is excited by the environment at 3.5° to 4°, the boom suspension can reduce the vibration transmitted by the body to a reasonable range. The static analysis shows that the structural design of this study reduces the stress at the connection of the end boom suspension, the maximum displacement, and the maximum stress of the inner boom suspension. The test results of the dynamic characteristics of the implement are basically consistent with the virtual model simulation test results, thus achieving the optimization objectives. Full article

Repeated and missed spraying are common problems during the working of boom sprayers, especially in the breakpoint continuous process. Therefore, the present study investigated a breakpoint continuous spraying system for automatic-guidance boom sprayers based on a hysteresis compensation algorithm for spraying. An operational breakpoint identification algorithm, which combines a real-time kinematic global navigation satellite system (RTK-GNSS) and wheel odometer, was proposed; a pre-adjusted proportional-integral-derivative (PID) control algorithm for the opening degree of the proportional control valve was designed in thus study. Tests were conducted to establish equations correlating the opening degree of the proportional control valve, pump output flow rate, and main pipeline flow rate, with an R² ≥ 0.9525. The time to adjust to the target flow rate was experimentally tested. The breakpoint identification accuracy of the RTK-GNSS and RTK-GNSS + wheel odometer was experimentally assessed. A field spraying deposition variation experiment was conducted. According to the results, the system effectively eliminated missed spraying, with a maximum repeated spraying distance of ≤3.3 m, and it achieved a flow control error within 3%. This system also reduced the repeated spraying area and enhanced the pesticide spraying quality of breakpoint continuous spraying for automatic-guidance boom sprayers. Full article

Under soybean–corn intercropping in China, quizalofop-p-ethyl is recommended as a herbicide for stem and leaf treatment after soybean seedling. Nonetheless, herbicide drift during spraying may lead to environmental contamination and damage to the corn plants. In order to clearly show the threshold of the drift deposition amount of quizalofop-p-ethyl that causes herbicide damage to corn, we used a bioassay spray tower to spray quizalofop-p-ethyl herbicide on corn in the laboratory and a boom sprayer to spray quizalofop-p-ethyl herbicide, which drifts to corn in the field, to study and evaluate the damage quizalofop-p-ethyl herbicide causes to corn under different spray volumes and drift deposition rates. The results showed that under a drift deposition rate of 1% of three spray volumes, the corn showed no symptoms of herbicide damage and their plant height was not inhibited 14 days after spray; under a spray volume of 150 L/ha and a drift deposition rate of 5%, the corn showed symptoms of mild herbicide damage but their plant height was not inhibited 14 days after spray, while the corn showed symptoms of moderate herbicide damage and their plant height was slightly and moderately inhibited, respectively, under the spray volumes of 300 L/ha and 450 L/ha; under drift deposition rates of 10% and 30% of three spray volumes, half or more of the corn in each treatment withered and their plant height was severely inhibited or completely inhibited. Under the same spray volume, the symptoms of herbicide damage and the inhibition rate of plant height increased with the increase in the drift deposition rate; under the same drift deposition amount, the symptoms of herbicide damage and the inhibition rate of plant height increased with a decrease in the spray volume. The effect of the drift deposition rate on the symptoms of herbicide damage and plant height was extremely significant, but the spray volume was not significant. The drift deposition rates for 10% inhibition and no inhibition of corn plant height were 5.70% (R₁₀) and 5.05% (R₀) under spray volume of 150 L/ha, 4.56% (R₁₀) and 1.23% (R₀) under 300 L/ha, and 3.31% (R₁₀) and 1.86% (R₀) under 450 L/ha, respectively. When the herbicide was sprayed in the field using a soybean–corn-dedicated plant protection machine under the spray volume of 450 L/ha, the drift deposition rate ranged from 1.22% to 1.69%, and the corn did not produce symptoms of herbicide damage and plant height was not inhibited 14 days after the spray. In actual weeding operations, it is better to ensure that the drift deposition rate of quizalofop-p-ethyl is below R₀ by setting reasonable operational parameters, using anti-drift nozzles or additives, and so on, and, at most, not more than R₁₀. This study clarified the drift hazard of quizalofop-p-ethyl herbicide on corn and the safety value of the herbicide drift deposition amount, which provided data support for the standardized use of quizalofop-p-ethyl herbicide under soybean–corn intercropping and guidance for the safe production of field corn. Full article
