A novel configuration for a polarimetric fiber ring laser incorporating a coupled optoelectronic oscillator (COEO) is proposed and experimentally demonstrated, and its application to magnetic field sensing is studied. The COEO-based polarimetric fiber ring laser has two mutually coupled loops: the fiber ring laser loop and the OEO loop. In the fiber ring laser loop, longitudinal modes break up into orthogonal polarization modes because of birefringence. The frequency of the polarization mode beat (PMB) signals is determined by the cavity birefringence. In the OEO loop, a microwave signal with its frequency equal to the PMB signal is generated. By feeding the oscillation mode to modulate the optical loop, mode-locking can be achieved, rendering the mode spacing of the laser equal to the frequency of the oscillating OEO mode. We can estimate the birefringence variation by measuring the oscillating frequency of the COEO. To validate the proposed sensing system, a circular birefringence change is introduced in a magneto-optic crystal via the Faraday rotation effect. Then, the magnetic field sensing is implemented. Such configuration can achieve single longitudinal oscillation and realize high-speed and high-precision measurements. Full article

An optical fiber ring laser (FRL) cavity-based sensitive temperature and salinity sensor is proposed and experimentally demonstrated. The sensor consists of a Sagnac loop with a waist of 15 µm and a total length of 30 cm made of tapered polarization-maintaining fiber (PMF). Sagnac loop dual parameter sensing was theoretically modeled and presented. The salinity sensitivity of 0.173 nm/‰ was made possible by the efficient interaction between the tapered PMF cladding mode and the external refractive index. In addition, temperature sensitivity of 0.306 nm/°C was achieved through ultrahigh birefringence of PMF. Apart from that, the previous sensing system used a broadband light source (BBS) as the input light, resulting in a wide bandwidth and a poor signal-to-noise ratio (SNR). The Sagnac loop integrated into the FRL system can achieve a high SNR of approximately 50 dB and a narrow bandwidth of 0.15 nm while serving as the filter and sensor head. Additionally, the developed sensor has the advantages of simple design, low cost, and easy fabrication. It can also extend sensing distance indefinitely within a given range, which is anticipated to have positive effects on the testing of marine environments in laboratories. Full article

Reducing the dimensions of optical gyroscopes is a crucial task and resonant fiber optic gyroscopes are promising candidates for its solution. The paper presents a prototype of a miniature resonant interferometric gyroscope of a strategic accuracy class. Due to the use of passive optical elements in this gyroscope, it has a great potential for miniaturization, alongside a low production cost and ease of implementation, since it does not require many feedback loops. The presented prototype shows results on a zero instability of 20°/h and an angle random walk of 0.16°/√h. A theoretical model explaining the nature of the multipath interference of resonant spectra and establishing the relationship between the resonator parameters and the output parameters of the presented prototype is proposed. The results predicted are in agreement with the experimental data. The prototype gyroscope demonstrates a scale factor instability and a change in the average signal level, which is due to the presence of polarization non-reciprocity, occurring due to the induced birefringence in the single-mode fiber of the contour. This problem requires further investigation to be performed. Full article

In this paper, a different Fiber Loop Mirror (FLM) configuration with two circulators is presented. This configuration is demonstrated and characterized for sensing applications. This new design concept was used for strain and torsion discrimination. For strain measurement, the interference fringe displacement has a sensitivity of (0.576 ± 0.009) pm‧με⁻¹. When the FFT (Fast Fourier Transformer) is calculated and the frequency shift and signal amplitude are monitored, the sensitivities are (−2.1 ± 0.3) × 10⁻⁴ nm⁻¹ με⁻¹ and (4.9 ± 0.3) × 10⁻⁷ με⁻¹, respectively. For the characterization in torsion, an FFT peaks variation of (−2.177 ± 0.002) × 10⁻¹² nm⁻¹/° and an amplitude variation of (1.02 ± 0.06) × 10⁻³/° are achieved. This configuration allows the use of a wide range of fiber lengths and with different refractive indices for controlling the free spectral range (FSR) and achieving refractive index differences, i.e., birefringence, higher than 10⁻², which is essential for the development of high sensitivity physical parameter sensors, such as operating on the Vernier effect. Furthermore, this FLM configuration allows the system to be balanced, which is not possible with traditional FLMs. Full article

We have demonstrated the use of a flat multi-wavelength Brillouin erbium-doped fiber laser (MWBEFL) based on a Sagnac loop with an unpumped erbium-doped fiber (Un-EDF) as a high-sensitivity sensor. A Sagnac loop with a Un-EDF was used as power equalizer to achieve multi-wavelength power flatness by adjusting the birefringence beat length properly. In the experiments, the best result obtained in terms of Brillouin Stokes lines and output power flatness was ±0.315 dB and the optical signal-to-noise ratio (OSNR) was 18.97 dB within a 33 nm bandwidth range from 1532.0 nm to 1565.0 nm. The flatness of the 33 nm bandwidth range varied from ±0.315 dB to ±1.38 dB and the average OSNR was about 17.51 dB. The peak power values of Brillouin Stokes lines observed under different wavelengths were extremely close and their range of fluctuation was about ±0.37 dB. These experimental results were close to our previous experimental values obtained using a passive Sagnac loop with a Un-EDF. The flat range covering almost the entire C-band has broad application prospects in high-sensitivity distributed optical fiber sensing and wavelength-division multiplexing. Full article

Reflective semiconductor optical amplifiers (RSOAs) are key elements for modern optical communications. Despite their widespread deployment, their performance when intended for ultrafast data amplification is limited by their inherently slow gain dynamics. In this paper, we propose to employ a birefringent fiber loop (BFL) to compensate for the RSOA pattern-dependent behavior and extend its operation well beyond that allowed by its nominal optical modulation bandwidth. We apply a reduced model to describe the RSOA response and quantify the RSOA output distortion by means of a non-return-to-zero data pulse overshoot. We validate the outcomes of this model in the time domain both for the RSOA alone and with the assistance of the BFL by an extensive comparison to available measurements. The excellent matching between simulation and experimental results allows us to further investigate the impact of critical operating parameters and derive specifications for them so that the performance of the scheme against the overshoot is made acceptable. The theoretical predictions confirm the ability of the BFL to enhance the RSOA direct amplification capability and hence establish it as a frequency discriminator for complementing RSOAs’ versatile and scalable operation. Full article

Reflective Semiconductor Optical Amplifiers (RSOAs) are essential devices for the development of new generation networks that rely on the convergence of optical and RF communications. Despite their proven potential for direct modulation, RSOAs’ electro-optic response is limited by their finite bandwidth, which hinders their employment both for signal amplification and modulation at the data rates envisioned by the target applications. In this paper, we elaborate on exploiting a Birefringent Fiber Loop (BFL) to enhance the operation of RSOAs as intensity modulators. We apply a mathematically and computationally reduced model to simulate the RSOA response in the time domain, and correlate it with that of the BFL in the frequency domain. We validate the model’s predictions by an extensive comparison of the simulation against experimental results. The reasonable theoretical findings allow us to establish the employed model as an efficient tool for describing electrically driven RSOA operation and its improvement by means of optical notch filtering. Furthermore, we evaluate and quantify the performance of the scheme and the potential range of RSOA direct modulation capability extension enabled by the BFL, which complies with the experimentally observed trends. The outcomes of this thorough study highlight the BFL supportive role in rendering feasible RSOAs’ direct modulation at data rates beyond those deemed possible by their nominal modulation bandwidth. Full article

Here, by harnessing a composite combination of wave retarders, we propose and experimentally demonstrate a first-order narrowband fiber comb filter capable of continuously tuning its wavelength, of which the filter structure is on the fundamental basis of a polarization–diversity loop structure. The demonstrated comb filter consists of a polarizing beam splitter (PBS), two high birefringence fiber (HBF) segments of the same length, an ordered wave retarder combination (WRC) of a quarter-wave retarder (QWR) and a half-wave retarder (HWR) before the first HBF segment, and an ordered WRC of an HWR and a QWR before the second HBF segment. The second HBF segment is butt-coupled to one port of the PBS so that its principal axis should be 22.5° away from the horizontal axis of the PBS. Taking the filter transmittance obtained by Jones calculus into consideration, we found the azimuth orientation angle (AOA) sets of the four wave retarders, which could allow extra phase shifts (ψ’s) ranging from 0° to 360° to be induced in the narrowband transmittance function. From filter transmission spectra calculated according to the AOA sets found above, it is confirmed that the first-order narrowband comb spectrum can be continuously tuned by properly controlling the AOA’s, clearly indicating the continuous wavelength tunability based on a composite combination of ordered wave retarders. This theoretical prediction was verified by actually constructing the proposed filter. Then, it is concluded that our filter employing the composite combination of wave retarders can be continuously frequency-tuned by properly controlling the AOA’s of the wave retarders. Full article

The feasibility of employing a birefringent fiber loop to enhance the performance of a directly modulated reflective semiconductor optical amplifier is experimentally demonstrated for the first time. The birefringent fiber loop acts as an optical filter of opposite slope than that of the reflective semiconductor optical amplifier electro-optical response and counteracts the finite reflective semiconductor optical amplifier modulation bandwidth of only 0.89 GHz. By proper adjustment of its detuning, the birefringent fiber loop tailors the spectral components that physically manifest due to the reflective semiconductor optical amplifier dynamic perturbation subject to direct modulation in the saturated gain regime, and suppresses the pattern-dependent distortions in the time domain. In this manner, the birefringent fiber loop manages to significantly improve the quality characteristics of the encoded signal at higher data rates than those enabled by the reflective semiconductor optical amplifier limited modulation capability. Owing to the birefringent fiber loop, the reflective semiconductor optical amplifier modulation range is extended to 4 Gb/s at the raw bit error rate of $1.0\times {10}^{-9}$, and to 11 Gb/s at the forward error correction limit of $3.8\times {10}^{-3}$. These results, which are unique against the evaluation criterion adopted in the first case, and the modulation speed achieved with post-filtering schemes in the second, highlight the beneficial role that the birefringent fiber loop can play in supporting reflective semiconductor optical amplifier operation for intensity amplification and modulation purposes. Full article

We propose a high-sensitive Sagnac-interferometer biosensor based on theVernier effect (VE) with a high-birefringence microfiber. The sensitivity enhancement is achieved by utilizing two cascaded Sagnac interferometers. One of the two interference loops consists of a panda polarization-maintaining fiber as a filter, whilst the other is comprised of high-birefringent microfiber coated Graphene oxide (GO) as a sensing channel. We theoretically analyzed the sensitivity of the sensor and verified it with experiments. The results of the simulation show that the refractive index sensitivity is more than five times that of the fiber sensor based on a single Sagnac loop. The sensitivity of the refractive index in the experiments can reach 2429 nm/refractive index unit (RIU), which is basically in accordance with the simulation. We also use electrostatic adsorption to coat GO on the surface of the sensing channel. GO is employed to adsorb bovine serum albumin (BSA) molecules to achieve the desired detection results, which has good biocompatibility and large specific surface area. The sensitivity to detect BSA can reach 9.097 nm/(mg×mL⁻¹). Full article

In this paper, a double-clad Er/Yb fiber laser with self-Q-switched and continuous wave operation depending on the pump power range is experimentally demonstrated. The linear cavity is formed on one side by a pair of cascaded tunable fiber Bragg gratings used for the selection and tuning of the generated laser lines. On the opposite side, a fiber optical loop mirror with high birefringence fiber in the loop is used to adjust the intra-cavity losses to obtain dual-wavelength emission by temperature changes on the fiber loop. Continuous wave dual-wavelength laser operation is obtained for tunable separation of the generated laser lines in a range from 1 to 7 nm, maximum output power of 3.6Wwith a pump power of 10Wand laser wavelengths linewidth of ~0.2 nm. Self-Q-switched laser pulses are obtained with low pump power in a range from 322 to 890 mW. Q-switched pulses with minimum pulse duration of ~1.5 _s and maximum pulse energy of ~3.5 _J are obtained. Full article

An optical fiber temperature and torsion sensor has been proposed by employing the Lyot-Sagnac interferometer, which was composed by inserting two sections of high-birefringence (HiBi) fiber into the Sagnac loop. The two inserted sections of HiBi fiber have different functions; while one section acts as the temperature sensitive region, the other can be used as reference fiber. The temperature and twist sensor based on the proposed interferometer structure have been experimentally demonstrated. The experimental results show that the envelope of the output spectrum will shift with the temperature evolution. The temperature sensitivity is calculated to be −17.99 nm/°C, which is enlarged over 12 times compared to that of the single Sagnac interferometer. Additionally, the fringe visibility of the spectrum will change due to the fiber twist, and the test results reveal that the fringe visibility and twist angle perfectly conform to a Sine relationship over a 360° twist angle. Consequently, simultaneous torsion and temperature measurement could be realized by detecting the envelope shift and fringe visibility of the spectrum. Full article

Recent advances in devices and applications of high-birefringence fiber loopmirror sensors are addressed. In optical sensing, these devices may be used as strain andtemperature sensors, in a separate or in a simultaneous measurement. Other describedapplications include: refractive index measurement, optical filters for interrogate gratingsstructures and chemical etching control. The paper analyses and compares different types ofhigh-birefringence fiber loop mirror sensors using conventional and microstructured opticalfibers. Some configurations are presented for simultaneous measurement of physicalparameters when combined with others optical devices, for example with a long periodgrating. Full article
