Biomimetic design for engineering applications may suggest the optimal performance of engineering devices. In this work the passive/pure pitching characteristics of a hydrofoil are investigated experimentally with and without a pair of biomimetic fin strips placed symmetrically on the two sides of the foil leading edge. The work is performed in a recirculating water channel at low Reynolds numbers (Re) with a range of 1300 ≤ Re ≤ 3200. Using high-speed videography and Particle Image Velocimetry (PIV), the pitching characteristics and wakes are visualized. Passive pitching characteristics, i.e., the pitching amplitude and pitching frequency of the hydrofoils, are investigated based on their trailing edge movement. Significant improvement in both pitching frequency and amplitudes are observed for the foil with fin strips compared to the baseline simple foil. Comparing the pitching characteristics of the two foils, it is observed that the hydrofoil with biomimetic fin strips exhibits 25% and 21% higher pitching amplitude and pitching frequency, respectively, compared to that of the baseline at comparable Reynolds numbers. The initiation of pitching for the finned foil is also observed at comparatively low Reynolds numbers. The wake is also studied using time mean and fluctuating velocity profiles obtained using PIV. Full article

In recent years, leading-edge tubercles have gained significant attention as an innovative biomimetic flow control technique. This paper explores their impact on the aerodynamic performance and flow patterns of an airfoil through wind tunnel experiments, utilizing force measurements and tuft visualization at Reynolds numbers between 2.7 × 10⁵ and 6.3 × 10⁵. The baseline airfoil exhibits a hysteresis loop near the stall angle, with sharp changes in lift coefficient during variations in the angle of attack (AOA). In contrast, the airfoil with leading-edge tubercles demonstrates a smoother stall process and enhanced post-stall performance, though its pre-stall performance is slightly reduced. The study identifies four distinct flow regimes on the modified airfoil, corresponding to different segments of the lift coefficient curve. As the AOA increases, the flow transitions through stages of full attachment, trailing-edge separation, and local leading-edge separation across some or all valley sections. Additionally, the study suggests that normalizing aerodynamic performance based on the valley section chord length is more effective, supporting the idea that leading-edge tubercles function like a series of delta wings in front of a straight-leading-edge wing. These insights provide valuable guidance for the design of blades with leading-edge tubercles in applications such as wind and tidal turbines. Full article

Previous studies on the clap–fling mechanism have predominantly focused on the initial downward and forward phases of flight in miniature insects, either during hovering or forward flight. However, this study presents the first comprehensive kinematic data of Coccinella septempunctata during climbing flight. It reveals, for the first time, that a clap-and-fling mechanism occurs during the initial upward and backward phase of the hind wings’ motion. This discovery addresses the previously limited understanding of the clap-and-fling mechanism by demonstrating that, during the clap motion, the leading edges of beetle’s wings come into proximity to form a figure-eight shape before rotating around their trailing edge to open into a “V” shape. By employing numerical solutions to solve Navier–Stokes (N-S) equations, we simulated both single hind wings’ and double hind wings’ aerodynamic conditions. Our findings demonstrate that this fling mechanism not only significantly enhances the lift coefficient by approximately 9.65% but also reduces the drag coefficient by about 1.7%, indicating an extension of the applicability range of this clap-and-fling mechanism beyond minute insect flight. Consequently, these insights into insect flight mechanics deepen our understanding of their biological characteristics and inspire advancements in robotics and biomimetics. Full article

Surface engineering of nanoparticles has been widely used in biosensing and assays, where sensitivity was mainly limited by plasmonic colour change or electrochemical responses. Here, we report a novel biomimetic sensing strategy involving protein-modified gold nanoparticles (AuNPs), where the modulation strategy was inspired by gastropods in inhibition of coffee-ring effects in their trail-followings. The so-called coffee-ring effect presents the molecular behaviour of AuNPs to a macroscopic ring through aggregation, and thus greatly improves sensitivity. The assay relies upon the different assembly patterns of AuNPs against analytes, resulting in the formation or suppression of coffee-ring effects by the different surface engineering of AuNPs by proteins and peptides. The mechanism of the coffee-ring formation process is examined through experimental characterizations and computational simulations. A practical coffee-ring effect assay is developed for a proof-of-concept target, amyloid β (1–42), which is a typical biomarker of Alzheimer’s disease. A novel quasi-titrimetric protocol is constructed for quantitative determination of the target molecule. The assay shows excellent selectivity and sensitivity for the amyloid β monomer, with a low detection limit of 20 pM. Combined with a fluorescent staining technique, the assay is designed as a smart sensor for amyloid β detection and fibrillation evaluation in rat cerebrospinal fluids, which is a potential point-of-care test for Alzheimer’s disease. Connections between amyloid fibrillation and different courses of brain ischaemia are also studied, with improved sensitivity, lower sample volumes that are required, convenience for rapid detection, and point-of-care testing. Full article

The first botanical gardens in Europe were established for the study of medicinal, poisonous, and herbal plants by students of medicine or pharmacy at universities. As the natural sciences became increasingly important in the 19th Century, botanical gardens additionally took on the role of public educational institutions. Since then, learning from living nature with the aim of developing technical applications, namely biomimetics, has played a special role in botanical gardens. Sir Joseph Paxton designed rainwater drainage channels in the roof of the Crystal Palace for the London World’s Fair in 1881, having been inspired by the South American giant water lily (Victoria amazonica). The development of the Lotus-Effect^® at the Botanical Garden Bonn was inspired by the self-cleaning leaf surfaces of the sacred lotus (Nelumbo nucifera). At the Botanic Garden Freiburg, a self-sealing foam coating for pneumatic systems was developed based on the self-sealing of the liana stems of the genus Aristolochia. Currently, botanical gardens are both research institutions and places of lifelong learning. Numerous botanical gardens provide biomimetics trails with information panels at each station for self-study and guided biomimetics tours with simple experiments to demonstrate the functional principles transferred from the biological model to the technical application. We present eight information panels suitable for setting up education about biomimetics and simple experiments to support guided garden tours about biomimetics. Full article

The airfoil structure and folding pattern of the hindwings of a beetle provide new transformation paths for improvements in the aerodynamic performance and structural optimization of flapping-wing flying robots. However, the explanation for the aerodynamic mechanism of the asymmetrical bending of a real beetle’s hindwings under aerodynamic loads originating from the ventral and dorsal sides is unclear. To address this gap in our understanding, a computational investigation into the aerodynamic characteristics of the flight ability of C. buqueti and the large folding ratio of their hindwings when hovering is carried out in this article. A three-dimensional (3D) pressure-based SST k-ω turbulence model with a biomimetic structure was used for the detailed analysis, and a refined polyhedral mesh was used for the simulations. The results show that the fluid around the hindwings forms a vortex ring consisting of a leading-edge vortex (LEV), wing-tip vortex (TV) and trailing-edge vortex (TEV). Approximately 61% of the total lift is generated during the downstroke, which may be closely related to the asymmetric bending of the hindwings when they are subjected to pressure load. Full article

High efficiency thrust generating foils are extensively being researched for potential use as thrusters in micro air vehicles and biomimetic autonomous underwater vehicles. Here, we propose a simple reduced order model for prediction of thrust generation attributes of foils that are pitched either continuously or intermittently in a periodic and possibly asymmetric fashion. Our model accounts for the distinct thrust contributions from added mass, leading edge suction, quasi steady and wake terms, all deduced from a rigorous generalization of linearized potential theory to foils undergoing small amplitude multimodal flapping motion. Additionally, the model relies on Bone-Lighthill boundary layer thinning hypothesis to account for the pitching motion induced increase in the drag force exerted on the foil. We derive generic forms of the thrust coefficient for prescribed multimodal pitching motions and specifically in the limit of large reduced frequencies, demonstrate a convergence to rather simplified scaling laws that are functions of just the Reynolds number and Strouhal number based on root mean square of the foil’s trailing edge velocity. Comparisons with previously reported experimental and simulation-based investigations demonstrate that the scaling laws capture the influence of imposed pitch on thrust generation characteristics over a range of pitching waveforms ranging from sinusoidal to square or triangular-shaped waveforms and also waveforms corresponding to intermittent pitching. The generalized relations derived in our work and the asymptotic scaling laws deduced from them are applicable to a wide spectrum of self-propulsion enabling and thrust producing waveforms including the ones that can potentially be employed in burst and coast swimming. Full article

The aim of the paper is to present the parameters of new biomimetic folding fins measured using image processing. Tests were carried out for different types of folding biomimetic fins and compared to the most popular fins on the market. A noninvasive image processing method was used to estimate divers’ velocities in the vertical and horizontal directions and the frequency and the amplitude of the fin trailing edge, and as a result, the Strouhal number was calculated. These tests are a continuation of studies conducted in a water tunnel, where fin efficiency was measured as the ratio of generated thrust to electrical energy consumption, taking into account the mechanical efficiency of the leg manipulator as well as the water velocity. The Strouhal number helped us to analyse the parameters of the fin–diver–water system taking into account the properties of the fins, in particular the newly designed biomimetic folding fins. Full article

Loud hydrodynamic noise is not only potentially harmful to the health of organisms in the ocean, but it is also a threat to the survival of underwater vehicles. Different from the general noise reduction technologies at present, a new idea for a flow-induced noise reduction design with spanwise microgrooved surfaces inspired by sharkskin is introduced in this paper. Large eddy simulations (LES) combined with the Ffowcs Williams and Hawkings (FW-H) equation are adopted to simulate the hydrodynamic noise of the three-dimensional (3D) hydrofoil. The accuracy of the numerical predictions is checked against existing experimental data, achieving good agreement. With the increase of observing distance, the noise reduction effect at the trailing edge direction is gradually apparent, and a maximum noise reduction of up to 7.28 dB can be observed. It is seen from the noise spectra of the biomimetic hydrofoil that the main peaks are eliminated, and the noise level at high frequency is also decreased. The cause of noise reduction lies in the secondary vortex generated in the microgrooves, which hinder the process of turbulence, consume the energy of the flow, and weaken the intensity of turbulent burst. The results of this study provide a new way to design low-noise underwater structures with hydrofoils. Full article
