Search Results (52)

With growing demands for improved blast resistance in concrete protective structures, developing new concrete materials that combine high toughness, impact resistance, and efficient energy dissipation is essential. This study replaces conventional aggregates with titanium slag and prepares three specimen groups: pure cement mortar (control), cement mortar with large titanium slag particles, and an optimized mix with titanium slag aggregates. Using Split Hopkinson Pressure Bar (SHPB) tests and AUTODYN finite difference simulations, stress-wave absorption and attenuation performance were systematically investigated. Results show that, under identical impact loading rates, the large-particle titanium slag group increased energy absorption by 23.5% compared with the control, while the optimized mix improved by 19.2%. Both groups maintained stable absorption efficiencies across different loading rates. Numerical simulations reveal that the porous titanium slag model attenuated stress waves by approximately 67.9% after passing through three slag layers, significantly higher than the 51.4% attenuation in the non-porous model. This improvement is attributed to multiple wave reflections and interferences caused by a two-order-magnitude difference in the elastic modulus between the slag and air interfaces, creating ring-shaped stress concentrations that disrupt wave propagation and dissipate impact energy. This research provides experimental support and mechanistic insights for titanium slag application in novel blast-resistant concrete. Full article

This study examines the behaviour of reinforced concrete (RC) slabs subjected to contact explosions through experimental investigations and numerical simulations. A contact explosive charge field experiment was conducted on a bi-directionally reinforced RC slab to characterise the resulting damage patterns. The experimental findings revealed localised perforation and substantial deformation of the reinforcement bars without bar rupture. A numerical model employing the RHT concrete and Johnson–Cook steel material models was implemented in Ansys Autodyn (v 2023 R2) to replicate the observed responses. Initial verification was carried out against data from the literature, and calibration was performed using the instantaneous geometric strain (IGS) as the erosion parameter. An optimal IGS value of 0.375 was found to reproduce the experimental damage most accurately. Subsequent parametric analyses of the validated models investigated the influence of slab thickness and reinforcement ratios on blast resistance. The results demonstrated that increasing the slab thickness substantially mitigates perforation, while higher reinforcement ratios improve overall structural integrity. This work confirms the reliability of the calibrated numerical models for predicting the response of RC slabs to contact explosions, and it offers valuable insight into the design of blast-resistant structures. Full article

Given the significantly large deformation and high strain exhibited by explosively formed projectiles (EFP) in penetration, their penetration performance into multi-layer targets differs from that of ordinary bullets or rigid projectiles. Therefore, it is necessary to investigate the ballistic performance and the damage mechanism of target deformation when an EFP penetrates a multi-layer target. This study conducted high-velocity impact tests of EFPs on four types of multi-layer steel targets, analyzing the damage morphology and deformation characteristics of multi-layer steel targets subjected to EFP penetration from both macro and micro levels. To investigate the anti-penetration performance of more target combinations at different EFP velocities, an accurate symmetrical finite element model of EFP penetration into multi-layer targets was established using Autodyn 16.0 finite element software and the SPH-FEM algorithm based on the symmetrical characteristics of the EFP and target structure. The experimental and simulation results showed that for a three-layer composite target, when the thickness of the middle layer remained constant, using the target layers with a front–rear target thickness ratio of less than one was beneficial for enhancing the anti-penetration performance of the targets against EFPs; when the EFP velocity was low and the residual velocity for penetrating a single-layer target was no more than 200 m/s, the anti-penetration performance of the two-layer target was optimal. When the EFP velocity exceeded 1500 m/s, the single-layer target exhibited the best anti-penetration performance to the EFP, and the more layers, the smaller the ballistic resistance. When the number of layers was more than six, the ballistic resistance of the multi-layer targets gradually tended to remain constant. Full article

To comprehensively understand the explosion risk in underground energy transportation tunnels, this study employed computational fluid dynamics technology and finite element simulation to numerically analyze the potential impact of an accidental explosion for a specific oil and gas pipeline in China and the potential damage risk to nearby buildings. Furthermore, the study investigated the effects of tunnel inner diameter (d = 4.25 m, 6.5 m), tunnel length (L = 4 km, 8 km, 16 km), and soil depth (primarily L_soil = 20 m, 30 m, 40 m) on explosion dynamics and on structural response characteristics. The findings indicated that as the tunnel length and inner diameter increased, the maximum explosion overpressure gradually rose and the peak arrival time was delayed, especially when d = 4.25 m; with the increase in L, the maximum explosion overpressure rapidly increased from 1.03 MPa to 2.12 MPa. However, when d = 6.5 m, the maximum explosion overpressure increased significantly by 72.8% from 1.25 MPa. Evidently, compared to the change in tunnel inner diameter, tunnel length has a more significant effect on the increase in explosion risk. According to the principle of maximum explosion risk, based on the peak explosion overpressure of 2.16 MPa under various conditions and the TNT equivalent calculation formula, the TNT explosion equivalent of a single section of the tunnel was determined to be 1.52 kg. This theoretical result is further supported by the AUTODYN 15.0 software simulation result of 2.39 MPa (error < 10%). As the soil depth increased, the distance between the building and the explosion source also increased. Consequently, the vibration peak acceleration and velocity gradually decreased, and the peak arrival time was delayed. In comparison to a soil depth of 10 m, the vibration acceleration at soil depths of 20 m and 30 m decreased by 81.3% and 91.7%, respectively. When the soil depth was 10 m, the building was at critical risk of vibration damage. Full article

Shear thickening fluids (STFs) have garnered attention as potential enhancers of protective capabilities and for the optimization of Kevlar^® armor design. To assess the possible shear thickening properties and potential application in ballistic protection, ten formulations were developed by employing polyethylene glycol (PEG) or polypropylene glycol (PPG), along with fumed silica or Aerosil HDK^®. Rheological characterization facilitated the identification of formulations displaying shear thickening behavior. The potential integration of the selected shear thickening fluids (STFs) into Kevlar^®-based composites was investigated by studying the impact resistance of Kevlar^® soft armor structures. Also, high-velocity impact testing revealed that the distance between aramid layers plays a crucial role in the impact resistance effectiveness of Kevlar^®–STF composite structures and that there is a very narrow domain between optimal and undesired scenarios in which STF could facilitate the penetration of Kevlar. The introduction of STF between the Kevlar sheets disrupted this packing and the energy absorption capacity of the material was not improved. Only one formulation (PEG400, Aerosil 27 wt.%) led to a less profound traumatic imprint and stopped the bullet when it was placed between layers no.1 and no.2 from a total of 11 layers of Kevlar XP. These experimental findings align with the modeling and simulation of Kevlar^®–STF composites using Ansys simulation software (Ansys® AutoDyn 2022 R2). Full article

The main applications of civil explosives in soils are soil compaction, mass excavation, and in situ pile creation. The suitability of explosives for each of these applications strongly depends upon the explosive properties and the soil properties. For those reasons, a reliable estimation or process simulation regarding cost efficiency and explosive work ability in the soil with known soil parameters is relevant. This paper presents a numerical simulation study of different types of soil (different amounts of gravel, sand, silt, and clay) under a blast load modeled using Ansys 2020 R1 Autodyn 2D hydrocode, with different types of explosives. The calculated results from the Ansys 2020 R1 Autodyn 2D and the experimental results obtained from the in situ cavity formation caused by blasting are presented. The Jones–Wilkins–Lee (JWL) equation of state parameters was calculated using EXPLO5 V7.01.01 supported by experimental data, while the soil and explosive properties were measured in laboratory and in situ. Full article

Rubble-pile asteroids may be the type of near-Earth object most likely to threaten Earth in a future collision event. Small-scale impact experiments and numerical simulations for large-scale impacts were conducted to clarify the size ratio of the boulder/projectile diameter effects on ejecta size–velocity distribution. A series of small-scale impact cratering experiments were performed on porous gypsum–basalt targets at velocities of 2.3 to 5.5 km·s⁻¹. Three successive ejection processes were observed by high-speed and ultra-high-speed cameras. The momentum transfer coefficient and cratering size were measured. A three-dimensional numerical model reflecting the random distribution of the interior boulders of the rubble-pile structure asteroid is established. The size ratio (length to diameter) of the boulder size inside the asteroid to the projectile diameter changed from 0.25 to 1.7. We conducted a smoothed particle hydrodynamics numerical simulation in the AUTODYN software to study the boulder size effect on the ejecta size–velocity distribution. Simulation results suggest that the microscopic porosity on regolith affects the propagation of shock waves and reduces the velocity of ejecta. Experiments and numerical simulation results suggest that both excavation flow and spalling ejection mechanism can eject boulders (0.12–0.72 m) out of the rubble-pile asteroid. These experiments and simulation results help us select the potential impact site in a planetary defense scenario and reduce deflection risk. are comprised primarily of boulders of a range of sizes. Full article

This study was conducted on a linear shaped charge with a double-angle liner. The double-angle liner has a large inner apex angle and a small outer liner angle. Experiments and numerical analysis were performed in a penetration performance study, and it was confirmed that the experimental results and numerical analysis results matched well. As a result of the numerical analysis, at the standoff distance of 1.5 CD, the penetration performance of the double-angle linear shaped charge was improved by 14.5% compared to the conventional linear shaped charge, and at the standoff distance of 2.5 CD, the penetration performance was improved by 12.5%. For miniaturization, numerical analysis was performed by reducing the height of the explosive and the standoff distance. As a result of the numerical analysis, the penetration performance of the double-angle linear shaped charge was improved by 14.6% compared to the conventional linear shaped charge. Double-angle liners are effective in improving the penetration performance of linear shaped charges. Full article

In order to study the impact initiation process and mechanism of hypervelocity PTFE/Al composite structure reactive fragments on a shielded charge, first, an existing PTFE/Al reactive fragment hypervelocity collision experiment was numerically simulated using the SPH algorithm in ANSYS/AUTODYN 17.0 software. Then, the Lee–Tarver model was verified to describe the detonation reaction behavior and explosion damage effect of reactive materials. A numerical simulation analysis of the impact of two kinds of ultra-high-speed PTFE/Al composite-structure reactive fragments on a shielded charge was carried out using the SPH algorithm. These were steel-coated PTFE/Al and steel-semi-coated PTFE/Al fragments, and they were compared with the impact of steel fragments. The results indicate that the threshold velocities of the impact initiation of the two composite-structure reactive fragments on the shielded charge were both 2.6 km/s, while the threshold velocity of the steel fragment was 2.7 km/s. Under the threshold velocity condition, the two composite-structure reactive fragments increase the time and intensity of the compressed shock wave pulse in the explosive due to the impact energy release effect of the reactive materials, causing the shielded charge to detonate under the continuous long-term pulse loads. However, the mechanism of the steel fragment on the shielded charge belongs to the shock–detonation transition. The research results can provide scientific references for the design of hypervelocity reactive fragments and the study of their damage mechanism. Full article

Composite concrete structures, commonly found in urban infrastructures, such as highways and runways, are pivotal research object in the protection field. To study the dynamic response of composite concrete structures subjected to reactive jet penetration coupled with an explosive effect, a full-scale damage experiment of composite structures under the action of 150 mm caliber shaped charges was performed, to derive the dynamic damage modes of different concrete thicknesses under the combined kinetic and chemical energy damage effects. The results indicated that under aluminum jet penetration, concrete layers exhibited minor funnel craters and penetration holes. However, concrete layers displayed a variety of damage modes, including central penetration holes, funnel craters, bulges, and radial/circumferential cracks when subjected to the PTFE/Al jet. The area of the funnel crater expanded as the thickness of the concrete increased, while the height of the bulge and the number of radial cracks decreased. The diameter of penetration holes increased by 76.9% and the area of funnel crater increased by 578% in comparison to Al jet penetration damage. A modified-RHT concrete model that reflected concrete tensile failure was established, utilizing AUTODYN. Segmented numerical simulations of damage behavior were performed using the FEM-SPH algorithm and a restart approach combined with reactive jet characteristics. The spatial distribution characteristic of the reactive jet and the relationship between kinetic penetration and explosion-enhanced damage were obtained by the simulation, which showed good concordance with the experimental results. This study provides important reference data and a theoretical basis for the design of composite concrete structures to resist penetration and explosion. Full article

Space launch vehicles are usually loaded with a large amount of propellant, and the destructive power caused by their explosion is significant. The altitude of an accidental explosion will lead to differences in the destructive power, because the environmental parameters of different altitudes are different, and the explosion shock wave parameters are closely related to the environmental parameters. Therefore, it was necessary to establish a set of analytical methods to rapidly analyze the relationship between altitude and the explosion shock wave parameters. A large number of simulation conditions were tested at 0~10 km altitude using the nonlinear dynamics software AUTODYN. The relationship between the explosion shock wave pressure P, the proportional distance z, and the altitude h was obtained, which could be used to rapidly characterize the explosion shock wave pressures at different altitudes. A comparative analysis was conducted with the experimental results to verify the scientificity of the fitting formula. The results indicate that the error between the experimental and calculated values is less than 5.80%, indicating that the rapid evaluation formula established in this paper is reasonable. These findings not only enrich the theory related to explosion shock waves, but also provide a rapid analysis basis for the accidental explosion of space launch vehicles. Full article

In this paper, the AUTODYN/Smoothed Particle Hydrodynamics (SPH) method was used to study the impact of reactive fragments on three-layer equidistant steel plates. The perforation characteristics of equidistant three-layer steel plates were investigated along with the parameters of combustion energy release from reactive fragments under varied impact velocities and shape conditions. The modification of the steel plates’ perforation diameter was investigated using the dimensional analysis approach. The shock wave pressure and chemical reaction characteristics were examined using the shock wave theory. The results show that within the examined impact velocity range, the perforation diameter initially increased and then decreased as the impact velocity of the reactive fragment rose. In addition, the perforation diameter was approximately 1.5–3 times the diameter of the reactive fragment. As the impact speed increased, the active reaction generated by the reactive fragments became more sufficient. The energy released contributed to the impact’s pressure rise; in addition, the temperature of the steel plate was raised in part by the reactive fragment impact, making the steel plate more prone to melting. The results of this investigation provide important support for a detailed understanding of the rules governing the failure of steel plates under the impact of reactive fragments as well as the combustion of reactive fragments under impact. Full article

To study the influences of an explosion-proof wall on shock wave parameters, an air explosion protection experiment was performed, the time history of shock wave pressure at different positions before and after the explosion-proof wall was established, and the characteristics of shock wave impulse and dynamic pressure were analyzed. The explosion-proof working conditions of five different diffraction angles were simulated and analyzed using Autodyn software(2019R3). Results indicated the following findings. The explosion-proof wall exerted an evident attenuation effect on the explosion shock wave, but considerable pressure still existed at the top of the explosion-proof wall. Overpressure behind the wall initially increased and then decreased. The larger the diffraction angle, the faster the attenuation speed of the diffraction overpressure of the shock wave in the air behind the wall. The history curve of shock wave pressure exhibited an evident bimodal structure. The shock wave diffraction of the wall made the shock wave bimodal structure behind the wall more prominent. The characteristics of the bimodal structure behind the wall (the interval time of overpressure peak Δt was less than the normal phase time of the diffracted shock wave T⁺) caused the shock wave impulse to stack rapidly, significantly improving its damage capability. The peak value of dynamic pressure on the oncoming surface was approximately two times the peak value of overpressure, and the inertia of air molecules resulted in a longer positive duration of dynamic pressure than overpressure. The maximum overpressure on the ground behind the explosion-proof wall appeared at approximately two times the height of the explosion-proof wall, while the maximum overpressure in the air behind the explosion-proof wall appeared at approximately one times the height of the explosion-proof wall. The relatively safe areas on the ground and in the air behind the wall were approximately 4–4.5 times and 3.5–4 times the height of the explosion-proof wall, respectively. Full article

A dynamic disturbance will induce cracks around the tunnel in tunnel blasting or shield construction. To investigate the overall stability of cracks with various angles during a fixed borehole (round hole explosion) blasting, models containing an individual crack with different angles were introduced for simulation research. The research set up a thin sheet model with a length of 350 mm and a width of 150 mm, with a 7 mm diameter hole and a pre-existing crack of 75 mm and 5 mm in the middle. The evolution of the stress wave propagation model and the crack propagation model were simulated using the AUTODYN software. And in this study, the theory of stress wave is used to creatively explain the dynamic load under the action of formation and reasons for the danger zone. The results indicate that pre-existing cracks from different angles will have an impact on the blast hole and the new cracks generated around itself. At 45–90°, pre-existing cracks will direct reflected stress waves to promote some cracks around the hole to have faster growth rates than others, and these special cracks with faster growths and longer lengths will more easily connect with the free surface or other cracks, resulting in overall instability. And these conditions are consistent with the prediction made by the stress wave propagation simulation study. The research results have certain guiding significance for the stability analysis and hazardous area prediction of tunnel blasting with existing cracks. Full article

Based on the analysis of existing collective shockwave protection methods worldwide, this paper addresses the mitigation of shock waves by means of passive methods, namely the use of perforated plates. Employing specialized software for numerical analysis, such as ANSYS-AUTODYN 2022R1^®, the interaction of shock waves with a protection structure has been studied. By using this cost-free approach, several configurations with different opening ratios were investigated, pointing out the peculiarities of the real phenomenon. The FEM-based numerical model was calibrated by employing live explosive tests. The experimental assessments were performed for two configurations, with and without a perforated plate. The numerical results were expressed in terms of force acting on an armor plate placed behind a perforated plate at a relevant distance for ballistic protection in engineering applications. By investigating the force/impulse acting on a witness plate instead of the pressure measured at a single point, a realistic scenario can be considered. For the total impulse attenuation factor, the numerical results suggest a power law dependence, with the opening ratio as a variable. Full article
