Search Results (43)

Search Parameters:
Keywords = artificial magnetic conductor (AMC)

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
12 pages, 8325 KiB
Article
Co-Design of Single-Layer RCS-Reducing Surface and Antenna Array Based on AMC Technique
by Rongyu Yang, Xiaoyi Liao, Yujie Wang, Xiangcheng Qian, Minxing Wang, Hongfei Zhang and Xiaoxing Fang
Electronics 2025, 14(12), 2392; https://doi.org/10.3390/electronics14122392 - 11 Jun 2025
Viewed by 349
Abstract
A co-design of radar cross section (RCS) reducing surface and array antenna on a single-layer printed board is presented in this paper. To achieve this goal, two kinds of artificial magnetic conductors (AMCs) are designed and optimized. The first kind of AMC shares [...] Read more.
A co-design of radar cross section (RCS) reducing surface and array antenna on a single-layer printed board is presented in this paper. To achieve this goal, two kinds of artificial magnetic conductors (AMCs) are designed and optimized. The first kind of AMC shares the same geometry with the array element and thus is simultaneously used as the array element. The other kind of AMC generates opposed-phased reflections for a normal incident wave, and when they are in a checkerboard configuration, the RCS is reduced via phase cancellation of opposed-phased reflections. In the range of 10 GHz to 16 GHz, the designed bi-functional surface achieves an 8 dB decline in monostatic RCS, while the array antenna obtains a gain of 15 dBi, a side-lobe less than −10 dB, and a cross-polarization less than −20 dB at 13.5 GHz. To validate the calculation results, a prototype is fabricated and measured. To feed the array antenna, a T-type power divider network is etched under the ground and the array is fed via coupling slots on the ground. The measured results agree with the simulation results. Full article
(This article belongs to the Special Issue Broadband High-Power Millimeter-Wave and Terahertz Devices)
Show Figures

Figure 1

19 pages, 8477 KiB
Article
Wideband Dual-Polarized PRGW Antenna Array with High Isolation for Millimeter-Wave IoT Applications
by Zahra Mousavirazi, Mohamed Mamdouh M. Ali, Abdel R. Sebak and Tayeb A. Denidni
Sensors 2025, 25(11), 3387; https://doi.org/10.3390/s25113387 - 28 May 2025
Viewed by 651
Abstract
This work presents a novel dual-polarized antenna array tailored for Internet of Things (IoT) applications, specifically designed to operate in the millimeter-wave (mm-wave) spectrum within the frequency range of 30–60 GHz. Leveraging printed ridge gap waveguide (PRGW) technology, the antenna ensures robust performance [...] Read more.
This work presents a novel dual-polarized antenna array tailored for Internet of Things (IoT) applications, specifically designed to operate in the millimeter-wave (mm-wave) spectrum within the frequency range of 30–60 GHz. Leveraging printed ridge gap waveguide (PRGW) technology, the antenna ensures robust performance by eliminating parasitic radiation from the feed network, thus significantly enhancing the reliability and efficiency required by IoT communication systems, particularly for smart cities, autonomous vehicles, and high-speed sensor networks. The proposed antenna achieves superior radiation characteristics through a cross-shaped magneto-electric (ME) dipole backed by an artificial magnetic conductor (AMC) cavity and electromagnetic bandgap (EBG) structures. These features suppress surface waves, reduce edge diffraction, and minimize back-lobe emissions, enabling stable, high-quality IoT connectivity. The antenna demonstrates a wide impedance bandwidth of 24% centered at 30 GHz and exceptional isolation exceeding 40 dB, ensuring interference-free dual-polarized operation crucial for densely populated IoT environments. Fabrication and testing validate the design, consistently achieving a gain of approximately 13.88 dBi across the operational bandwidth. The antenna’s performance effectively addresses the critical requirements of emerging IoT systems, including ultra-high data throughput, reduced latency, and robust wireless connectivity, essential for real-time applications such as healthcare monitoring, vehicular communication, and smart infrastructure. Full article
(This article belongs to the Special Issue Design and Measurement of Millimeter-Wave Antennas)
Show Figures

Figure 1

16 pages, 4519 KiB
Article
A High-Gain and Dual-Band Compact Metasurface Antenna for Wi-Fi/WLAN Applications
by Yunhao Zhou and Yilin Zheng
Materials 2025, 18(11), 2538; https://doi.org/10.3390/ma18112538 - 28 May 2025
Viewed by 589
Abstract
With the rapid development of Wi-Fi 6/6E and dual-band wireless systems, there is an increasing demand for compact antennas with balanced high-gain performance across both 2.4 GHz and 5 GHz bands. However, most existing dual-band metasurface antennas face challenges in uneven gain distribution [...] Read more.
With the rapid development of Wi-Fi 6/6E and dual-band wireless systems, there is an increasing demand for compact antennas with balanced high-gain performance across both 2.4 GHz and 5 GHz bands. However, most existing dual-band metasurface antennas face challenges in uneven gain distribution between lower/higher-frequency bands and structural miniaturization. This paper proposes a high-gain dual-band metasurface antenna based on an artificial magnetic conductor (AMC) array, which has a significant advantage in miniaturization and improving antenna performance. Two types of dual-band AMC structures are applied to design the metasurface antenna. The optimal antenna with dual-slot AMC array operates in the 2.42–2.48 GHz and 5.16–5.53 GHz frequency bands, with a 25% size reduction compared to the reference dual-band U-slot antenna. Meanwhile, high gains of 7.65 dBi and 8 dBi are achieved at 2.4 GHz and 5 GHz frequency bands, respectively. Experimental results verify stable radiation gains across the operation bands, where the total efficiency remains above 90%, agreeing well with the simulation results. This research provides an effective strategy for high-gain and dual-band metasurface antennas, offering a promising solution for integrated modern wireless systems such as Wi-Fi 6, Bluetooth, and MIMO technology. Full article
(This article belongs to the Special Issue Metamaterials and Metasurfaces: From Materials to Applications)
Show Figures

Figure 1

16 pages, 4503 KiB
Article
A Single-Field Finite Difference Time-Domain Method Verified Using a Novel Antenna Design with an Artificial Magnetic Conductor Enhanced Structure
by Yongjun Qi, Weibo Liang, Yilan Hu, Liang Zhang, Cheng You, Yuxiang Zhang, Tianrun Yan and Hongxing Zheng
Micromachines 2025, 16(4), 489; https://doi.org/10.3390/mi16040489 - 21 Apr 2025
Viewed by 613
Abstract
The Finite Difference Time-Domain (FDTD) method is a powerful tool for electromagnetic field analysis. In this work, we develop a variation of the algorithm to accurately calculate antenna, microwave circuit, and target scattering problems. To improve efficiency, a single-field (SF) FDTD method is [...] Read more.
The Finite Difference Time-Domain (FDTD) method is a powerful tool for electromagnetic field analysis. In this work, we develop a variation of the algorithm to accurately calculate antenna, microwave circuit, and target scattering problems. To improve efficiency, a single-field (SF) FDTD method is proposed as a numerical solution to the time-domain Helmholtz equations. New formulas incorporating resistors and voltage sources are derived for the SF-FDTD algorithm, including hybrid implicit–explicit and weakly conditionally stable SF-FDTD methods. The correctness of these formulas is verified through numerical simulations of a newly designed dual-band wearable antenna with an artificial magnetic conductor (AMC) structure. A novel antenna fed by a coplanar waveguide with a compact size of 15.6 × 20 mm2 has been obtained after being optimized through an artificial intelligent method. A double-layer, dual-frequency AMC structure is designed to improve the isolation between the antenna and the human body. The simulation and experiment results with different bending degrees show that the antenna with the AMC structure can cover two frequency bands, 2.4 GHz–2.48 GHz and 5.725 GHz–5.875 GHz. The gain at 2.45 GHz and 5.8 GHz reaches 5.3 dBi and 8.9 dBi, respectively. The specific absorption rate has been reduced to the international standard range. In particular, this proposed SF-FDTD method can be extended to analyze other electromagnetic problems with fine details in one or two directions. Full article
Show Figures

Figure 1

15 pages, 3949 KiB
Article
A Simple AMC Antenna for Liquid Monitoring in an Infusion Bag
by Boyu Zhang and Zhijiao Chen
Sensors 2025, 25(6), 1675; https://doi.org/10.3390/s25061675 - 8 Mar 2025
Viewed by 839
Abstract
Running-out detection of the liquids in an infusion bag is important for medical treatment. This paper proposed a simple low-cost sensing scheme with an artificial magnetic conductor (AMC) antenna for liquid-running-out detection in infusion bags. The proposed antenna consists of a dipole antenna [...] Read more.
Running-out detection of the liquids in an infusion bag is important for medical treatment. This paper proposed a simple low-cost sensing scheme with an artificial magnetic conductor (AMC) antenna for liquid-running-out detection in infusion bags. The proposed antenna consists of a dipole antenna supported by an AMC layer. It operates in the 2.4 GHz ISM band in the without-liquid state, in the 2.0 GHz ISM band in the with-liquid state, and can be used for liquid sensing. The AMC layer isolates interference from the surrounding environment such as the standing pole. It also enhances antenna performance and improves monitoring sensitivity. This gives a peak gain of 6.45 dBi and a radiation efficiency of 98% in the without-liquid state. Meanwhile, the with-liquid state can achieve a peak gain of 4.5 dBi and a radiation efficiency of 93%. The proposed antenna is fabricated and measured, verifying its sensing performance of the liquid in the infusion bag. This antenna’s design is flexible, compact, precise, and suitable for biomedical wireless sensing. Full article
(This article belongs to the Section Communications)
Show Figures

Figure 1

15 pages, 8329 KiB
Article
Inverse Design of Broadband Artificial Magnetic Conductor Metasurface for Radar Cross Section Reduction Using Simulated Annealing
by Haoda Xia, Xiaoyu Liang, Bowen Jia, Pei Shi, Zhihong Chen, Shi Pu and Ning Xu
Appl. Sci. 2025, 15(6), 2883; https://doi.org/10.3390/app15062883 - 7 Mar 2025
Viewed by 939
Abstract
In this study, we present a novel design methodology for unit cells in chessboard metasurfaces with the aim of reducing the radar cross-section (RCS) for linearly polarized waves. The design employs rotational symmetry and incorporates ten continuous parameters to define the metasurface units, [...] Read more.
In this study, we present a novel design methodology for unit cells in chessboard metasurfaces with the aim of reducing the radar cross-section (RCS) for linearly polarized waves. The design employs rotational symmetry and incorporates ten continuous parameters to define the metasurface units, enabling the creation of flexible 2D structures. The geometrical parameters of the two units are then optimized using a simulated annealing (SA) algorithm to achieve a low RCS chessboard metasurface. Following optimization, the properties of the metasurface were experimentally verified. The experimental results show a significant RCS reduction of 10 dB within the 7.6–15.5 GHz range, with the peak reduction reaching-28 dB at normal incidence. For a bistatic RCS, the metasurface effectively scatters incident waves into four distinct lobes. The proposed method offers an alternative strategy for the inverse design of low RCS metasurfaces and can be extended to applications in polarization control, phase gradient manipulation, and transmissive metasurfaces. Full article
(This article belongs to the Special Issue Recent Advances in AI-Enabled Wireless Communications and Networks)
Show Figures

Figure 1

29 pages, 20951 KiB
Article
Design and SAR Analysis of an AMC-Integrated Wearable Cavity-Backed SIW Antenna
by Yathavi Thangavelu, Balakumaran Thangaraju and Rajagopal Maheswar
Micromachines 2024, 15(12), 1530; https://doi.org/10.3390/mi15121530 - 23 Dec 2024
Cited by 1 | Viewed by 1467
Abstract
Wearable communication technologies necessitate antenna designs that harmonize ergonomic compatibility, reliable performance, and minimal interaction with human tissues. However, high specific absorption rate (SAR) levels, limited radiation efficiency, and challenges in integration with flexible materials have significantly constrained widespread deployment. To address these [...] Read more.
Wearable communication technologies necessitate antenna designs that harmonize ergonomic compatibility, reliable performance, and minimal interaction with human tissues. However, high specific absorption rate (SAR) levels, limited radiation efficiency, and challenges in integration with flexible materials have significantly constrained widespread deployment. To address these limitations, this manuscript introduces a novel wearable cavity-backed substrate-integrated waveguide (SIW) antenna augmented with artificial magnetic conductor (AMC) structures. The proposed architecture is meticulously engineered using diverse textile substrates, including cotton, jeans, and jute, to synergistically integrate SIW and AMC technologies, mitigating body-induced performance degradation while ensuring safety and high radiation efficiency. The proposed design demonstrates significant performance enhancements, achieving SAR reductions to 0.672 W/kg on the spine and 0.341 W/kg on the forelimb for the cotton substrate. Furthermore, the AMC-backed implementation attains ultra-low reflection coefficients, as low as −26.56 dB, alongside a gain improvement of up to 1.37 dB, culminating in a total gain of 7.09 dBi. The impedance bandwidth exceeds the ISM band specifications, spanning 150 MHz (2.3–2.45 GHz). The design maintains remarkable resilience and operational stability under varying conditions, including dynamic bending and proximity to human body models. By substantially suppressing back radiation, enhancing directional gain, and preserving impedance matching, the AMC integration optimally adapts the antenna to body-centric communication scenarios. This study uniquely investigates the dielectric and mechanical properties of textile substrates within the AMC-SIW configuration, emphasizing their practicality for wearable applications. This research sets a precedent for wearable antenna innovation, achieving an unprecedented balance of flexibility, safety, and electromagnetic performance while establishing a foundation for next-generation wearable systems. Full article
(This article belongs to the Topic Innovation, Communication and Engineering)
Show Figures

Figure 1

11 pages, 2775 KiB
Communication
Dual-Polarized Dipole Antenna with Wideband Stable Radiation Patterns Using Artificial Magnetic Conductor Reflector
by Xianjing Lin, Jielin Mai, Hongjun He and Yao Zhang
Sensors 2024, 24(12), 3911; https://doi.org/10.3390/s24123911 - 17 Jun 2024
Cited by 1 | Viewed by 2338
Abstract
This paper presents a wideband dual-polarized dipole antenna structure operating at 1.7–3.8 GHz (76.4%). For a traditional 4G dipole antenna that covers the band 1.71–2.69 GHz, it is difficult to maintain the satisfactory impedance matching and normal stable radiation patterns within the 5G [...] Read more.
This paper presents a wideband dual-polarized dipole antenna structure operating at 1.7–3.8 GHz (76.4%). For a traditional 4G dipole antenna that covers the band 1.71–2.69 GHz, it is difficult to maintain the satisfactory impedance matching and normal stable radiation patterns within the 5G sub-6 GHz band 3.3–3.8 GHz, mainly due to the fixed antenna height no longer being a quarter-wavelength. To solve this, a connected-ring-shaped metasurface structure is proposed and deployed to operate as an artificial magnetic conductor (AMC). As a result, stable antenna radiation patterns are obtained within the whole band 1.7–3.8 GHz. For verification, this wideband dipole antenna using AMC is implemented and tested. The measured results show that the proposed antenna has an impedance bandwidth of 80.7% (1.7–4.0 GHz). It has an average measured in-band realized gain of 7.0±1.0 dBi and a stable 70±5 half power beam width (HPBW) within the 4G/5G-sub 6GHz bands 1.71–2.69 GHz and 3.3–3.8 GHz. Full article
(This article belongs to the Special Issue Antenna Design and Optimization for 5G, 6G, and IoT)
Show Figures

Figure 1

12 pages, 4174 KiB
Article
A Compact and Robust RFID Tag Based on an AMC Structure
by Giovanni Andrea Casula, Giacomo Muntoni, Paolo Maxia and Giorgio Montisci
Sensors 2024, 24(5), 1468; https://doi.org/10.3390/s24051468 - 24 Feb 2024
Viewed by 1692
Abstract
A platform-tolerant RFID (Radio-Frequency Identification) tag is presented, designed to operate across the entire RFID band. This tag utilizes a small Artificial Magnetic Conductor (AMC) structure as a shielding element for an ungrounded RFID tag antenna. It can be easily mounted on various [...] Read more.
A platform-tolerant RFID (Radio-Frequency Identification) tag is presented, designed to operate across the entire RFID band. This tag utilizes a small Artificial Magnetic Conductor (AMC) structure as a shielding element for an ungrounded RFID tag antenna. It can be easily mounted on various surfaces, including low permittivity dielectric materials, metal objects, or even attached to the human body for wearable applications. The key features of this RFID tag include its ability to be tuned within the worldwide RFID band, achieving a maximum theoretical read range of over 11 m. Despite its advanced capabilities, the design emphasizes simplicity and cost-effective manufacturing. The design and simulations were conducted using CST Studio Suite. Full article
(This article belongs to the Special Issue Wearable Antennas and Sensors for Microwave Applications)
Show Figures

Figure 1

10 pages, 17890 KiB
Communication
A Wideband Low-Profile Dual-Polarized Antenna Based on a Metasurface
by Rui Wu, Shuai Cao, Yuan Liu and Shuting Cai
Electronics 2023, 12(23), 4739; https://doi.org/10.3390/electronics12234739 - 22 Nov 2023
Cited by 5 | Viewed by 2330
Abstract
A wideband, low-profile, dual-polarized antenna using a metasurface (MS) is proposed in this paper. This design consists of a pair of crossed dipoles, an MS, a metal cavity and two baluns. The proposed MS acts as an artificial magnetic conductor (AMC), which is [...] Read more.
A wideband, low-profile, dual-polarized antenna using a metasurface (MS) is proposed in this paper. This design consists of a pair of crossed dipoles, an MS, a metal cavity and two baluns. The proposed MS acts as an artificial magnetic conductor (AMC), which is designed for the ±90° reflection-phase bandwidth of 1.4–2.9 GHz. Compared with the 0.25λ0 profile of the traditional crossed dipoles, the profile is reduced to 0.15λ0 by using the in-phase reflection characteristics of the MS, which realizes the utilization of space. The measured results show that the antenna has a 10 dB return loss of 68.2% with isolation of more than 30 dB (1.45–2.95 GHz). The realized gain is 9 dBi with ±1 dBi variation, especially exceeding 10 dBi from 2.1 to 2.8 GHz. Full article
(This article belongs to the Special Issue Broadband Antennas and Antenna Arrays)
Show Figures

Figure 1

12 pages, 4795 KiB
Article
Ferrite-Loaded Inverted Microstrip Line-Based Artificial Magnetic Conductor for the Magnetic Shielding Applications of a Wireless Power Transfer System
by Sonapreetha Mohan Radha, Seong Hoon Choi, Jae Ho Lee, Jung Hoon Oh, In-Kui Cho and Ick-Jae Yoon
Appl. Sci. 2023, 13(18), 10523; https://doi.org/10.3390/app131810523 - 21 Sep 2023
Cited by 2 | Viewed by 1513
Abstract
In this paper, we propose a ferrite-loaded inverted microstrip line (IML)-based artificial magnetic conductor (AMC) with a novel design that can provide complete magnetic shielding at the backside of the transmitting (Tx) coil while slightly improving the power transfer efficiency (PTE) of a [...] Read more.
In this paper, we propose a ferrite-loaded inverted microstrip line (IML)-based artificial magnetic conductor (AMC) with a novel design that can provide complete magnetic shielding at the backside of the transmitting (Tx) coil while slightly improving the power transfer efficiency (PTE) of a wireless power transfer system (WPTS). The target frequency of the WPTS application is approximately 6.78 MHz. In the proposed design, the AMC is placed behind the Tx coil, and its magnetic shielding capability and PTE performance were verified through simulations and measurements. The size of the proposed AMC is 528 × 528 × 6.6 mm3. The measurement results verified that, compared with the Tx coil without an AMC surface, the proposed ferrite-loaded IML-based AMC can provide complete magnetic shielding while improving the PTE of the WPTS by approximately 8.05%. Full article
Show Figures

Figure 1

11 pages, 7232 KiB
Article
Circularly Polarized High-Gain Fabry-Perot Cavity Antenna with High Sidelobe Suppression
by Muhammad Hussain, Kyung-Geun Lee and Dongho Kim
Appl. Sci. 2023, 13(14), 8222; https://doi.org/10.3390/app13148222 - 15 Jul 2023
Cited by 2 | Viewed by 2426
Abstract
The proposed design approach improves the circularly polarized Fabry-Perot cavity antenna (CP-FPCA) by increasing gain and sidelobe suppression (SLS) while reducing the axial ratio (AR) and cross-polarization levels. Conventional CP-FPC antennas have a high AR due to the lack of independent control over [...] Read more.
The proposed design approach improves the circularly polarized Fabry-Perot cavity antenna (CP-FPCA) by increasing gain and sidelobe suppression (SLS) while reducing the axial ratio (AR) and cross-polarization levels. Conventional CP-FPC antennas have a high AR due to the lack of independent control over circular polarization conditions. The solution proposes a double-layered circularly polarized partially reflecting surface (CP-PRS) that independently controls the circular polarization conditions at the design frequency f0 (10 GHz) for equal magnitudes and at a ±90° phase difference between orthogonal components of the transmitted waves. The PRS and artificial magnetic conductor (AMC) unit cells are employed to satisfy Trentini’s beamforming condition, leading to increased gain and SLS and lowered AR and cross-polarization levels. Consequently, the proposed CP-FPCA provides a 15.4 dBi high gain with 25.3% aperture efficiency and more than 23.5 dB high SLS in each plane. Moreover, it achieves an AR lowered by 0.12 dB and a cross-polarization level below −42 dB. A strong correlation between the simulations and experiments proves the practicality of our proposal. Full article
(This article belongs to the Section Electrical, Electronics and Communications Engineering)
Show Figures

Figure 1

14 pages, 8880 KiB
Article
Low-Profile Broadband Dual-Polarized Dipole Antenna for Base Station Applications
by Hao Feng, Mengyuan Li, Zhiyi Zhang, Jiahui Fu, Qunhao Zhang and Yulin Zhao
Sensors 2023, 23(12), 5647; https://doi.org/10.3390/s23125647 - 16 Jun 2023
Cited by 1 | Viewed by 4152
Abstract
A low-profile broadband dual-polarized antenna is investigated for base station applications. It consists of two orthogonal dipoles, fork-shaped feeding lines, an artificial magnetic conductor (AMC), and parasitic strips. By utilizing the Brillouin dispersion diagram, the AMC is designed as the antenna reflector. It [...] Read more.
A low-profile broadband dual-polarized antenna is investigated for base station applications. It consists of two orthogonal dipoles, fork-shaped feeding lines, an artificial magnetic conductor (AMC), and parasitic strips. By utilizing the Brillouin dispersion diagram, the AMC is designed as the antenna reflector. It has a wide in-phase reflection bandwidth of 54.7% (1.54–2.70 GHz) and a surface-wave bound range of 0–2.65 GHz. This design effectively reduces the antenna profile by over 50% compared to traditional antennas without an AMC. For demonstration, a prototype is fabricated for 2G/3G/LTE base station applications. Good agreement between the simulations and measurements is observed. The measured −10-dB impedance bandwidth of our antenna is 55.4% (1.58–2.79 GHz), with a stable gain of 9.5 dBi and a high isolation of more than 30 dB across the impedance passband. As a result, this antenna is an excellent candidate for miniaturized base station antenna applications. Full article
Show Figures

Figure 1

12 pages, 9277 KiB
Article
Transmission-Reflection-Integrated Multifunctional Passive Metasurface for Entire-Space Electromagnetic Wave Manipulation
by Shunlan Zhang, Weiping Cao, Tiesheng Wu, Jiao Wang, Heng Li, Yanliang Duan, Haoyu Rong and Yulong Zhang
Materials 2023, 16(12), 4242; https://doi.org/10.3390/ma16124242 - 8 Jun 2023
Cited by 4 | Viewed by 1860
Abstract
In recent years, many intriguing electromagnetic (EM) phenomena have come into being utilizing metasurfaces (MSs). However, most of them operate in either transmission or reflection mode, leaving the other half of the EM space completely unmodulated. Here, a kind of transmission-reflection-integrated multifunctional passive [...] Read more.
In recent years, many intriguing electromagnetic (EM) phenomena have come into being utilizing metasurfaces (MSs). However, most of them operate in either transmission or reflection mode, leaving the other half of the EM space completely unmodulated. Here, a kind of transmission-reflection-integrated multifunctional passive MS is proposed for entire-space electromagnetic wave manipulation, which can transmit the x-polarized EM wave and reflect the y-polarized EM wave from the upper and lower space, respectively. By introducing an H-shaped chiral grating-like micro-structure and open square patches into the unit, the MS acts not only as an efficient converter of linear-to-left-hand circular (LP-to-LHCP), linear-to-orthogonal (LP-to-XP), and linear-to-right-hand circular (LP-to-RHCP) polarization within the frequency bands of 3.05–3.25, 3.45–3.8, and 6.45–6.85 GHz, respectively, under the x-polarized EM wave, but also as an artificial magnetic conductor (AMC) within the frequency band of 12.6–13.5 GHz under the y-polarized EM wave. Additionally, the LP-to-XP polarization conversion ratio (PCR) is up to −0.52 dB at 3.8 GHz. To discuss the multiple functions of the elements to manipulate EM waves, the MS operating in transmission and reflection modes is designed and simulated. Furthermore, the proposed multifunctional passive MS is fabricated and experimentally measured. Both measured and simulated results confirm the prominent properties of the proposed MS, which validates the design’s viability. This design offers an efficient way to achieve multifunctional meta-devices, which may have latent applications in modern integrated systems. Full article
(This article belongs to the Section Catalytic Materials)
Show Figures

Figure 1

15 pages, 15327 KiB
Article
A 0.18 μm CMOS Millimeter Wave Antenna-on-Chip with Artificial Magnetic Conductor Design
by Ming-An Chung, Chia-Chun Hsu, Siao-Rong Huang and Pin-Rui Huang
Inventions 2023, 8(3), 78; https://doi.org/10.3390/inventions8030078 - 2 Jun 2023
Cited by 2 | Viewed by 2500
Abstract
This paper presents a small-size broadband slot monopole chip antenna for millimeter wave application. Using a 0.18 μm CMOS process, through metal_1, the artificial magnetic conductor (AMC) of the metal layer increased the impedance bandwidth of the chip antenna. The additional inverted C [...] Read more.
This paper presents a small-size broadband slot monopole chip antenna for millimeter wave application. Using a 0.18 μm CMOS process, through metal_1, the artificial magnetic conductor (AMC) of the metal layer increased the impedance bandwidth of the chip antenna. The additional inverted C branch was used to achieve a better reflection coefficient. By adding an AMC and inverted C branch, the operating frequency of the chip antenna went to 33.8–110 GHz below the reflection coefficient of −10 dB, and its fractional bandwidth was 103.4%. The maximum gain was −6.3 dBi at 72 GHz. The overall chip size was 1.2 × 1.2 (mm2). Through measurement and verification, the proposed antenna reflection coefficient was close to the simulation trend and had better resonance. The frequency range of the chip antenna proposed in this paper covered the 5G NR FR2 band (24.2 GHz–52.6 GHz) and W-band (75 GHz–110 GHz). The proposed chip antenna can be applied to the Internet of Things, Industry 4.0, biomedical electronics, near field sensing and other related fields. Full article
Show Figures

Figure 1
