Search Results (68)

In this study, we propose a novel wideband aperture-coupled magneto-electric (ME) dipole antenna that achieves enhanced bandwidth by simultaneously leveraging ME resonance and aperture-coupled excitation. Building upon the conventional ME dipole architecture, the antenna integrates a pair of horizontal metal patches forming the electric dipole and a pair of vertical metal patches forming the magnetic dipole. A key innovation is the aperture-coupled feeding mechanism, where electromagnetic energy is transferred from a tapered microstrip line to the dipole structure through a slot etched in the ground plane. This design not only excites the characteristic ME resonances effectively but also significantly improves impedance matching, delivering a markedly broader impedance bandwidth. To validate the proposed concept, a prototype antenna was fabricated and experimentally characterized. Measurements show an impedance bandwidth of 84.48% (3.61–8.89 GHz) for $S_{11}$ ≤ −10 dB and a maximum in-band gain of 7.88 dBi. The antenna also maintains a stable, unidirectional radiation pattern across the operating band, confirming its potential for wideband applications such as 5G wireless communications. Full article

Deployable thin-film antennas deliver large aperture gains and high stowage efficiency for spaceborne phased arrays but suffer wrinkling-induced planarity loss and radiation distortion. To bridge the lack of electromechanical coupling models for tensioned thin-film patch antennas, we present a unified framework combining structural deformation and electromagnetic simulation. We derive a coupling model capturing the increased bending stiffness of stepped-thickness membranes, formulate a wrinkling analysis algorithm to compute tension-induced displacements, and fit representative unit-cell deformations to a dual-domain displacement model. Parametric studies across stiffness ratios confirm the framework’s ability to predict shifts in pattern, gain, and impedance due to wrinkling. This tool supports the optimized design of wrinkle-resistant thin-film phased arrays for reliable, high-performance space communications. Full article

A low-profile dual-polarized shared-aperture phased array antenna is proposed for Ku-band satellite communications in this paper. The stacked octagonal patches loaded with Via-rings are proposed as dual-polarized shared-aperture radiation elements, with the characteristics of wide impedance bandwidth, high gain, and weak coupling. Furthermore, innovative minimized three-port ring couplers are utilized for the differential-fed antenna array, further suppressing the cross-polarization component. Substrate integrated coaxial line (SICL) and microstrip line (MS) feed networks are employed for the excitation of transmitting band (Tx) horizontal polarization and receiving band (Rx) vertical polarization, respectively. The non-uniform subarray architecture is optimized to minimize the sidelobe levels with the reduced number of transmitter and receiver (T/R) radio frequency phase-shifting modules. As proof-of-concept examples, 16 × 24 and 32 × 24 array antennas are demonstrated and fabricated. The measured impedance bandwidths of the proposed phased array antennas are around 21.1%, while the in-band isolations are above 36.7 dB. Gains up to 29 dBi and 32.4 dBi are performed by two prototypes separately. In addition, the T/R phase-shifting modules are utilized to validate the beam-scanning characteristic, which is of value for dynamic satellite communications. Full article

In this paper, we establish criteria for the design of small aperture antenna arrays for Direction of Arrival (DOA) estimation. We define a small aperture antenna array as one consisting of a few elements with an average interelement spacing less than or equal to half a wavelength. We use the spatial covariance matrix of the antenna array to derive the design criterion. It is well known that the DOA estimation performance of an antenna array is strongly related to the amount of information in this matrix. Also, the Cramer-Rao Bound of the estimated DOA is closely related to this matrix. We establish and demonstrate that, for optimal DOA estimation performance, a small aperture antenna array should have non-uniformly spaced and dissimilar antenna elements. Since mutual coupling between antenna elements makes their in situ responses dissimilar, instead of mitigating mutual coupling, one should include mutual coupling in the DOA estimation process to enhance the DOA estimation performance of antenna arrays. Full article

In this paper, a broad-angle low-scattering microstrip antenna for dual-polarization is designed based on characteristic mode analysis (CMA). The modal analysis of the reference antenna under dual-polarization incident plane waves is first carried out to guide radar cross section (RCS) reduction (RCSR) design in broad-angle range. Then, through the modifications on the radiation patch and ground, the modal currents of the important scattering modes in broad-angle range are cut off. Hence, a broad-angle low-RCS aperture-coupled microstrip antenna for dual-polarization is obtained. However, the radiation performance decreases due to the ground modification. A frequency selective surface (FSS) structure is designed and fills in the ground modification areas. With the FSS structure, the proposed antenna shows a good radiation and scattering performance. A low-RCS antenna prototype is fabricated and tested. The antenna works from 2.79 GHz to 2.87 GHz (2.82%), and the gain is 6 dBi at 2.84 GHz. For the co-polarization, it can realize RCSR from 0° to 90°, and the average and peak RCSRs are 9.0 dB and 17 dB, respectively. For the cross-polarization, it can realize RCSR from 0° to 18° and 22° to 90°, and the average and peak RCSRs are 5.0 dB and 20 dB, respectively. In the meantime, its transmission and radiation performance keeps well. The measured and simulated results are in good agreement, which validates the design. Full article

High-precision two-dimensional direction of arrival (2D-DOA) estimation is an important mean of millimeter-wave radar for accurate target location. Aiming at the problems such as limited antenna aperture, signal coherence, and a few snapshots in millimeter-wave radar target detection, this paper proposes a 2D-DOA estimation method by using a joint iterative adaptive approach and rotational invariance technique (IAA-RIT) based on the double-parallel linear array. This method first constructs an iterative adaptive approach spectrum based on subarray 1 in the double-parallel linear array and then calculates the coupling angle estimate with the azimuth and the elevation. Secondly, based on the rotational invariance relationship between the two subarrays, the extended covariance matrices are respectively constructed, and the spatial smoothing technique is employed to decorrelate the signals. Then, the signal direction matrix is reconstructed based on the coupling angle estimate, and the rotational invariance relationship between the two subarrays is calculated to obtain another set of coupling angle estimates. Finally, the azimuth and the elevation are decoupled based on two sets of estimated coupling angles and the spatial geometry relation. Our experimental results show that IAA-RIT can estimate the coherent signal with high-precision 2D-DOA with a few snapshots and no additional angle matching. Full article

The synthetic aperture passive positioning (SAPP) method has attracted the attention of researchers due to its high positioning resolution. However, there are still key technical issues regarding SAPP methods, such as residual frequency offset (RFO) coupling at Doppler frequency leading to decreased positioning accuracy, and non-periodic discontinuous signals emitted by unknown radiation sources (NRSs) causing positioning algorithm failure. Therefore, this paper proposes an ultra-short baseline SAPP method based on interferometer assistance. Firstly, conjugate multiplication is applied to the received signals of the interferometer’s dual antennas to obtain a single frequency received signal corresponding to the straight-line distance. Subsequently, the proposed step search (SS) algorithm based on cross-correlation analysis is used to obtain the receiving frequency of the single frequency signal, and the initial positioning distance is calculated using the corresponding mapping relationship based on this frequency. Finally, NRS positioning is completed in the two-dimensional coordinates of azimuth and range by combining with the signal arrival angle. The positioning results of this method are insensitive to RFO, and even if NRS emits non-periodic discontinuous signals, the proposed method can successfully locate them. In addition, the Cramer–Rao lower bound (CRLB) of the localization for this method is derived. The simulation and unmanned aerial vehicle (UAV) experimental results demonstrate the effectiveness and feasibility of this method. Full article

The rise of artificial intelligence (AI) necessitates ultra-fast computing, with on-chip terahertz (THz) communication emerging as a key enabler. It offers high bandwidth, low power consumption, dense interconnects, support for multi-core architectures, and 3D circuit integration. However, transitioning between different waveguides remains a major challenge in THz systems. In this paper, we propose a THz band mode converter that converts from a rectangular waveguide (RWG) (WR-0.43) in ${\mathrm{TE}}_{10}$ mode to a substrate-integrated waveguide (SIW) in ${\mathrm{TE}}_{20}$ mode. The converter comprises a tapered waveguide, a widened waveguide, a zigzag antenna, and an aperture coupling slot. The zigzag antenna effectively captures the electromagnetic (EM) energy from the RWG, which is then coupled to the aperture slot. This coupling generates a quasi-slotline mode for the electric field (E-field) along the longitudinal side of the aperture, exhibiting odd symmetry akin to the SIW’s ${\mathrm{TE}}_{20}$ mode. Consequently, the ${\mathrm{TE}}_{20}$ mode is excited in the symmetrical plane of the SIW and propagates transversely. Our work details the mode transition principle through simulations of the EM field distribution and model optimization. A back-to-back RWG ${\mathrm{TE}}_{10}{\mathrm{-to-TE}}_{10}$ mode converter is designed, demonstrating an insertion loss of approximately 5 dB over the wide frequency range band of 2.15–2.36 THz, showing a return loss of 10 dB. An on-chip antenna is proposed which is fed by a single higher-order mode of the SIW, achieving a maximum gain of 4.49 dB. Furthermore, a balun based on the proposed converter is designed, confirming the presence of the ${\mathrm{TE}}_{20}$ mode in the SIW. The proposed mode converter demonstrates its feasibility for integration into a THz-band high-speed circuit due to its efficient mode conversion and compact planar design. Full article

Aiming at solving the problem of radiation pattern distortion caused by coupling between antennas in different frequency bands in traditional shared-aperture base station array antennas, a new shared-aperture array antenna integrating high-frequency filtering units and medium-frequency electromagnetic transparent antenna units is proposed. Without adding additional decoupling structures, it is possible to effectively reduce the coupling of different frequencies, while weakening common-mode and scattering interferences, making the radiation pattern conformal. The array consists of an electromagnetic transparent antenna unit in the medium-frequency (1.71–2.70 GHz) band and four filtering antenna units in the high-frequency (3.30–3.70 GHz) band. The four high-frequency antenna units form two 2 × 1 linear arrays arranged on both sides of the medium-frequency antenna unit and share a reflector. The simulation and measurement results show that the voltage standing wave ratio (VSWR) in the working frequency band is less than 1.50, the average gain in the medium-frequency band is 8.80 dBi, the average gain in the high-frequency band is 12.20 dBi, and the radiation pattern is normal. It is suitable for the field of shared-aperture base station antennas. Full article

Multiple input multiple output (MIMO) antennas have recently received attention for improving wireless communication data rates in rich scattering environments. Despite this, the challenge of isolation persists prominently in compact MIMO-based electronics. Various techniques have recently emerged to address the isolation issues, among which the defected ground structure (DGS) stands out as a cost-effective solution. Additionally, selecting the appropriate feed mechanism is crucial for enhancing the key performance indicators of MIMO antennas. However, there has been minimal focus on how different feed methods impact the operation of MIMO antennas integrated with DGS. This paper begins with a comprehensive review of diverse antenna design, feeding strategies, and DGS architectures. Subsequently, the causal relationships between various feed networks and DGSs has been established through modeling, simulation, fabrication, and measurement of MIMO antennas operating within the sub-6 GHz spectrum. Particularly, dual elements of MIMO antennas grounded by a slotted complementary split ring resonator (SCSRR)-based DGS were excited using four standard feed methods: coaxial probe, microstrip line, proximity coupled, and aperture coupled feed. The influence of each feed network on the performance of MIMO antennas integrated with SCSRR-based DGSs has been thoroughly investigated and compared, leading to guidelines for feed network selection. The coaxial probe feed network provided improved isolation performance, ranging from 16.5 dB to 46 dB in experiments.The aperture and proximity-coupled feed network provided improvements in bandwidth of 38.7% and 15.6%, respectively. Furthermore, reasonable values for envelope correlation coefficient (ECC), diversity gain (DG), channel capacity loss (CCL), and mean effective gain (MEG) have been ascertained. Full article

This paper proposes a dual-band patch antenna with combined self-decoupling and filtering properties, designed to suppress mutual coupling between two antenna elements both within the same dual-band and across different dual-bands. Initially, a dual-band aperture-coupled filtering patch antenna is designed, featuring a forked short-circuited SIR feedline with a quarter-wavelength open-ended stub and a U-shaped patch with two U-slots, which generate three controllable radiation nulls while introducing two additional resonant modes. The design steps are also provided in detail. Subsequently, the low mutual coupling phenomenon of two vertically placed aperture-coupled patch antennas is investigated, successfully developing a high-isolated dual-band two-element MIMO array I. Furthermore, the other quad-band two-element MIMO array II is designed, which utilizes the filtering response to significantly reduce mutual coupling across four bands. Finally, a dual-band filtering patch antenna element and two two-element MIMO arrays are fabricated and measured. The measurements and simulations validate the antenna’s low mutual coupling performance in multi-band MIMO arrays and demonstrate its strong potential for future wireless communication applications. Full article

A comprehensive design framework is proposed for optimizing sparse MIMO (multiple-input, multiple-output) arrays to enhance multi-target detection. The framework emphasizes efficient utilization of antenna resources, including strategies for minimizing inter-element mutual coupling and exploring alternative grid-based sparse array (GBSA) configurations by efficiently separating interacting elements. Alternative strategies are explored to enhance angular beamforming metrics, including beamwidth (BW), peak-to-sidelobe ratio (PSLR), and grating lobe limited field of view. Additionally, a set of performance metrics is introduced to evaluate virtual aperture effectiveness and beamwidth loss factors. The framework explores optimization strategies for the partial sharing of antenna elements, specifically tailored for multi-mode radar applications, utilizing the desirability function to enhance performance across various operational modes. A novel machine learning initialization approach is introduced for rapid convergence. Key observations include the potential for peak-to-sidelobe ratio (PSLR) reduction in dense arrays and insights into GBSA feasibility and performance compared to uniform arrays. The study validates the efficacy of the proposed framework through simulated and measured results. The study emphasizes the importance of effective sparse array processing in multi-target scenarios and highlights the advantages of the proposed design framework. The proposed design framework for grid-spaced sparse arrays stands out for its superior efficiency and applicability in processing hardware compared to both uniform and non-uniform arrays. Full article

This paper presents a novel 3 × 3 phased array antenna optimized for 4 GHz operation, achieving a realized gain of 13.2 dBi and enabling 30-degree beam steering with a minimal capacitance variation of 1.5 pF. The design features a series aperture-coupled feeding mechanism that not only reduces the antenna’s size but also simplifies the fabrication process, making the device both cost-effective and compact. Integrating cost-efficient quadrature-hybrid phase shifters and novel power splitters with cascaded quadrature hybrids ensures uniform power distribution and precise beam steering. The innovative use of these components addresses common challenges in phased array systems, such as space constraints, high costs, and complex power distribution. Full article

For target detection and recognition in a complicated electromagnetic environment, the two-dimensional direction-of-arrival and polarization estimation using a polarization-sensitive array has been receiving increased attention. To efficiently improve the performance of such multi-parameter estimation in practice, this paper proposes a parallel synthetic coprime array with reduced mutual coupling and hardware cost saving and then presents a dimension-reduction compressive sensing-based estimation method. For the proposed array, the polarization types, numbers, and positions of antennas in each subarray are jointly considered to effectively mitigate mutual coupling in the physical array domain and to both enhance degrees of freedom and extend the aperture in the difference coarray domain with the limited physical antennas. By exploring the array configuration, the parameter estimation can be formulated as a block-sparse signal reconstruction problem, and then the one-dimensional sparse reconstruction algorithm is only used once to achieve multi-parameter estimation with automatic pair-matching. The theoretical analysis and simulation results are provided to demonstrate the superior performance of the proposed array and method over the existing techniques. Full article

Pointing accuracy is a crucial performance index for a fully steerable large-aperture radio telescope and is subject to external and internal disturbances. Improvement of the antenna’s servo control performance is meaningful for pointing, especially for blind pointing of the antenna. This paper firstly establishes a multi-motor-driving four-degrees-of-freedom (DOF) model of an antenna servo system, then optimizes the original design consisting of the active disturbance rejection (ADR)-based velocity controller and lead–lag-based position controller, making the velocity controller a novel linear ADR-based controller coupled with a disturbance-velocity compensation (DLADRC) and the position controller the simplest proportional (P) controller. Simulation results based on a 100 m class radio telescope servo model indicate that the new control system’s velocity-loop response is smoother, the position-loop peak disturbance response is reduced by 17.8%, the position-loop dynamic performance with the short settling time and slight overshoot remains the same as the former PD-LADRC system, and the RMS pointing/tracking error is 2.16 arcsec under a mean wind of 3 m/s, less than the design specification of 2.5 arcsec RMS required. Full article
