Search Results (69)

Pneumatic artificial muscles (PAMs) are inherently compliant and relatively safe. They are widely used in applications where human beings and robots interact closely, such as service robots or medical robots. However, PAMs are constrained by bulky pumps and valve control systems, limiting their mobility, portability, and practical applications. In this research, a novel type of artificial muscle, namely Twisting Tube Artificial Muscle (TTAM), is presented. In a TTAM design, fluid (pressurized air in this research) is contained inside an elastic tube (constrained by a braiding). By twisting the tube from one end, the fluid inside the twisted part will be extruded to the untwisted part, resulting in a pressure increase inside the untwisted part. Both the twisted and untwisted parts will thus contract. Modeling and experimental characterization of the TTAM are conducted. In an experimental test at 100 kPa initial air pressure, after a 6π twisting angle, the internal pressure of a prototype TTAM is increased to 219 kPa, and the largest contraction force of the TTAM was up to 200 N. A novel antagonistic robotic joint actuated by two TTAMs is developed as a sample application. Full article

Soft robotics has emerged as a promising approach for safe human–machine interaction, adaptive manipulation, and bioinspired motion, yet its progress relies on accurate material characterization and structural analysis of actuators. This study presents the mechanical behavior and stress analysis of a stereolithography-printed pneumatic actuator with antagonistic architecture, fabricated using Elastic 50A resin V2. Uniaxial tensile tests were performed according to ASTM D412 to derive material parameters, which were fitted to hyperelastic constitutive models. The Yeoh model was identified as the most accurate and implemented in finite element simulations to predict actuator deformation under multiple pressurization modes. Results revealed critical stress zones and established operational pressure limits of 110–130 kPa, beyond which the material approaches its tensile strength. Experimental testing with a controlled pneumatic system validated the numerical predictions, confirming both bending and multidirectional actuation as well as structural failure thresholds. The integration of material characterization, numerical modeling, and experimental validation provides a robust workflow for the design of SLA-fabricated antagonistic actuators. These findings highlight the advantages of combining digital fabrication with antagonistic actuation and material modeling to expand the understanding of soft robots’ behavior. Full article

This paper presents the design, implementation, and experimental results of a six-degree-of-freedom Delta-type parallel manipulator, in which all actuators were realized using proprietary pneumatic muscles. The objective of the study was to evaluate the suitability of this type of actuator for applications in parallel robotics, with particular attention to their dynamic properties, nonlinearities, and potential limitations. In the first part of the article, the details of the manipulator’s construction and the kinematic model, covering both the forward and inverse kinematics, are presented. The control system was based on antagonistic pairs of pneumatic muscles forming servo drives responsible for the motion of individual arms. The experimental investigations were focused on analyzing trajectory-tracking accuracy and positioning repeatability, both in unloaded conditions and under additional payload applied to the end-effector. The results indicate that positioning errors for simple trajectories were generally below 1 mm, whereas for complex trajectories and under load, they increased, particularly during changes in motion direction, which can be attributed to friction and hysteresis phenomena in the muscles. Repeatability tests confirmed the ability of the manipulator to repeatedly reach the desired positions with small deviations. The analysis carried out confirms that pneumatic muscles can be effectively applied to drive parallel manipulators, offering advantageous features such as high power density and low mass. At the same time, the need for further research on nonlinearity compensation and durability enhancement was demonstrated. Full article

In this study, a novel shape memory alloy actuated bearing active preload system (SMA-BAPS) was proposed and experimentally demonstrated. SMA actuators placed in a single or antagonistic configuration were employed to drive the screw pair and thus fulfill one-way or bidirectional preload adjustment. Moreover, the self-locking screw pair was used to maintain the bearing preload without external energy input. To determine the parameters of screw pair and SMA actuators, a detailed design process was conducted based on analytical models of the proposed system. Finally, a screw pair with a lead of 3 mm and SMA actuators with a diameter of 0.5 mm and a length of 130 mm were adopted. Prototype tests were conducted to validate and evaluate the performance of the preload adjustment with the SMA-BAPS. The resistive torque and the natural frequency of spindles were recorded to represent the preload level of the bearing. Through the performance tests, the SMA-BAPS induced a maximum 47% variation in the resistive torque and a 20% variation in the spindle’s natural frequency. The response time of the SMA-BAPS was less than 5 s when the heating current of 5 A was applied on the SMA actuator. This design highlighted the compact size, quick response, as well as the bidirectional preload adjustment, representing its potential use in aerospace mechanisms and advanced motors. Full article

Bio-inspired joints play a pivotal role in legged robots, directly determining their motion capabilities and overall system performance. While shape memory alloy (SMA) actuators present superior power density and silent operation compared to conventional electromechanical drives, their inherent nonlinear hysteresis and restricted strain capacity (typically less than 5%) limit actuation range and control precision. This study proposes a bio-inspired joint integrating an antagonistic actuator configuration and differential dual-diameter pulley collaboration, achieving amplified joint stroke (±60°) and bidirectional active controllability. Leveraging a comprehensive experimental platform, precise reference input tracking is realized through adaptive fuzzy control. Furthermore, an SMA-driven bio-inspired leg is developed based on this joint, along with a motion retargeting framework to map human motions onto the robotic leg. Human gait tracking experiments conducted on the leg platform validate its motion performance and explore practical applications of SMA in robotics. Full article

Wrist movements play a crucial role in upper-limb motor tasks. As prosthetic and robotic hand technologies have evolved, increasing attention has been focused on replicating the anatomy and functionality of the wrist. Closely imitating the biomechanics and movement mechanisms of human limbs is expected to enhance the overall performance of bionic robotic hands. This study presents the design of a tendon-driven bionic spherical robot wrist, utilizing two pairs of cables that mimic antagonist muscle pairs. The cables are actuated by pulleys driven by servo motors, allowing for two primary wrist motions: flexion–extension and ulnar–radial deviation. The performance Please confirm if the “1583 Iiyama” is necessary. Same as belowof the proposed robot wrist is validated through manipulation experiments using a prototype, demonstrating its capability to achieve a full range of motion for both ulnar and radial deviation. This wrist mechanism is expected to be integrated into robotic systems, enabling greater flexibility and more human-like movement capabilities. Full article

This paper addresses the design, development, control, and experimental evaluation of a soft robot arm whose actuation is inspired by the muscular structure of the octopus arm, one of the most agile biological manipulators. The robot arm is made of soft silicone and thus possesses enhanced compliance, which is beneficial in a variety of applications where the arm may come into contact with delicate features of its environment. The arm is composed of three elongated segments arranged in series, each one of which contains several pneumatically actuated chambers embedded in its silicone body, which may induce various types of deformations of the segment. By combining the segment deformations, and by imitating the antagonistic muscle group functionality of the octopus, the robot arm can bend in various directions, increase or decrease its length, as well as twist around its central axis. This is one of the few octopus-inspired soft robotic arms where twisting is replicated in its motion characteristics, thus greatly expanding the arm’s potential applications. We present the design process and the development steps of the soft arm, where the molding of two-part silicone of low hardness in 3d-printed molds is employed. In addition, we present the control methodology and the experimental evaluation of both a standalone segment and the entire three-segment arm. This experimental evaluation involves model-free closed-loop control schemes, exploiting visual feedback from a pair of external cameras in order to reconstruct in real time the shape of the soft arm and the pose of its tip. Full article

The antagonistic system of two shape memory alloy wires is a great inspiration for the robotics field where it is applied as a linear actuator due to its shape memory effect. However, its control is still a challenge due to its hysteresis behavior. For that reason, a new controller is proposed in this paper for the displacement of the system’s effector. It is based on a Long Short-Term Memory neural network model. The aim is achieved by combining temperature-deformation data from an analytical model with voltage-temperature-deformation data from real experiments. Hence, these datasets are studied to overcome the nonlinearity obstacle of this system in order to be able to integrate it into robotic applications. Full article

An exoskeleton is a wearable device with human–machine interaction characteristics. An ideal exoskeleton should have kinematic and kinetic characteristics similar to those of the wearer. Most traditional exoskeletons are driven by rigid actuators based on joint torque or position control algorithms. In order to achieve better human–robot interaction, flexible actuators have been introduced into exoskeletons. However, exoskeletons with fixed stiffness cannot adapt to changing stiffness requirements during assistance. In order to achieve collaborative control of stiffness and torque, a bionic variable stiffness hip joint exoskeleton (BVS-HJE) is designed in this article. The exoskeleton proposed in this article is inspired by the muscles that come in agonist–antagonist pairs, whose actuators are arranged in an antagonistic form on both sides of the hip joint. Compared with other exoskeletons, it has antagonistic actuators with variable stiffness mechanisms, which allow the stiffness control of the exoskeleton joint independent of force (or position) control. A BVS-HJE model was established to study its variable stiffness and static characteristics. Based on the characteristics of the BVS-HJE, a control strategy is proposed that can achieve independent adjustment of joint torque and joint stiffness. In addition, the variable stiffness mechanism can estimate the output force based on the established mathematical model through an encoder, thus eliminating the additional force sensors in the control process. Finally, the variable stiffness properties of the actuator and the controllability of joint stiffness and joint torque were verified through experiments. Full article

The agonist–antagonist myoneural interface (AMI), a surgical method to reinnervate physiologically-relevant proprioceptive feedback for control of limb prostheses, has demonstrated the ability to provide natural afferent sensations for limb amputees when actuating their prostheses. Following AMI surgery, one potential challenge is atrophy of the disused muscles, which would weaken the reinnervation efficacy of AMI. It is well known that electrical muscle stimulus (EMS) can reduce muscle atrophy. In this study, we conducted an animal investigation to explore whether the EMS can significantly improve the electrophysiological performance of AMI. AMI surgery was performed in 14 rats, in which the distal tendons of bilateral solei donors were connected and positioned on the surface of the left biceps femoris. Subsequently, the left tibial nerve and the common peroneus nerve were sutured onto the ends of the connected donor solei. Two stimulation electrodes were affixed onto the ends of the donor solei for EMS delivery. The AMI rats were randomly divided into two groups. One group received the EMS treatment (designated as EMS_on) regularly for eight weeks and another received no EMS (designated as EMS_off). Two physiological parameters, nerve conduction velocity (NCV) and motor unit number, were derived from the electrically evoked compound action potential (CAP) signals to assess the electrophysiological performance of AMI. Our experimental results demonstrated that the reinnervated muscles of the EMS_on group generated higher CAP signals in comparison to the EMS_off group. Both NCV and motor unit number were significantly elevated in the EMS_on group. Moreover, the EMS_on group displayed statistically higher CAP signals on the indirectly activated proprioceptive afferents than the EMS_off group. These findings suggested that EMS treatment would be promising in enhancing the electrophysiological performance and facilitating the reinnervation process of AMI. Full article

This paper designs a two-degrees-of-freedom (DOF) compliant positioning stage with antagonistic piezoelectric actuation. Two pairs of PEAs are arranged in an antagonistic configuration to generate reciprocating motions. Flexure mechanisms are intentionally adopted to construct the fixtures for PEAs, whose elastic deformations can help to reduce the stress concentration on the PEA caused by the extension of the PEA in the other direction. Subsequently, the parameter and performance of the 2-DOF compliant positioning stage is optimized and verified by finite element analysis. Finally, a prototype is fabricated and tested. The experimental results show that the developed positioning stage achieves a working stroke of 28.27 μm × 27.62 μm. Motion resolutions of both axes are 8 nm and natural frequencies in the working directions are up to 2018 Hz, which is promising for high-precision positioning control. Full article

The idle air control actuator is an important device in automotive engine management systems to reduce fuel consumption by controlling the engine’s idling operation. This research proposes an innovative idle air control (IAC) actuator for vehicle applications utilizing shape memory alloy (SMA) technology. The proposed actuator leverages the unique properties of SMAs, such as the ability to undergo large deformations upon thermal activation, to achieve precise and rapid controls in the air intake of automotive engines during idle conditions. The actuator structure mechanism consists of an SMA spring and an antagonistic spring made from steel. The design process utilizes both numerical and analytical approaches. The SMA spring is electrically supplied to activate the opening process of the actuator, and its closing state does not need electricity. However, the PID controller is used to control the applied current, which reduces the time taken by the actuator to achieve the actuation strokes. It shows good operability within multiple numbers of operation cycles. Additionally, the performance of the designed actuator is evaluated through mathematical algorithms by integrating it into the engine’s air intake system during idle operating conditions. The results demonstrate the effectiveness of the SMA-based actuator in achieving rapid control of the air intake through bypass, thereby improving engine idle conditions. Full article

This article presents a study on the neurobiological control of voluntary movements for anthropomorphic robotic systems. A corticospinal neural network model has been developed to control joint trajectories in multi-fingered robotic hands. The proposed neural network simulates cortical and spinal areas, as well as the connectivity between them, during the execution of voluntary movements similar to those performed by humans or monkeys. Furthermore, this neural connection allows for the interpretation of functional roles in the motor areas of the brain. The proposed neural control system is tested on the fingers of a robotic hand, which is driven by agonist–antagonist tendons and actuators designed to accurately emulate complex muscular functionality. The experimental results show that the corticospinal controller produces key properties of biological movement control, such as bell-shaped asymmetric velocity profiles and the ability to compensate for disturbances. Movements are dynamically compensated for through sensory feedback. Based on the experimental results, it is concluded that the proposed biologically inspired adaptive neural control system is robust, reliable, and adaptable to robotic platforms with diverse biomechanics and degrees of freedom. The corticospinal network successfully integrates biological concepts with engineering control theory for the generation of functional movement. This research significantly contributes to improving our understanding of neuromotor control in both animals and humans, thus paving the way towards a new frontier in the field of neurobiological control of anthropomorphic robotic systems. Full article

In this paper, an optimal PID controller is introduced for an antagonistic variable stiffness actuator (AVSA) based on Hammerstein models. A set of Hammerstein models is developed for the AVSA using the voltage difference method. For each stiffness level, linear and nonlinear Hammerstein models are identified using the least squares method. Experimental results confirm that the outputs of the Hammerstein models fit the measured data better than linear models, as Hammerstein models can incorporate nonlinear effects such as friction. A genetic algorithm is utilized to find optimal PID gains for different stiffness levels and reference position amplitudes. The final gains are obtained by linearly interpolating the optimal gains obtained. To demonstrate the effectiveness of the proposed design, several scenarios with different reference positions and stiffness profiles are provided. Specifically, square, sinusoidal, and sawtooth waves are used for reference positions and stiffness values. The robustness of the proposed approach is further analyzed by applying a disturbance force on the actuator link. The results are compared with the linear method, showing that the proposed design can handle soft transitions in stiffness variation and ensure perfect tracking. Full article

Endoscopy has made a significant and noteworthy contribution to the field of medical science and technology. Nevertheless, its potential remains constrained due to the limited availability of rigid or flexible endoscopes. This paper introduces a novel hydraulic actuator based on electrorheological fluid (ERF) as a pivotal advancement in bridging the existing gap within the realm of endoscopy. Following a comprehensive introduction that briefly outlines the electrorheological effect, the subsequent section is dedicated to the elucidation of the actuator’s development process. Challenges arise, particularly in terms of miniaturization and the realization of a hydraulically sealed system with integrated valve electrodes. An internal electrorheological valve system consisting of four valves that are controlled using a pulse-width modulated high voltage was suitable for position control of the antagonistic hydraulic actuators. High-precision stereolithography (SLA) printing has proven practical for manufacturing actuator components. For functional testing, a test bench was set up in which the actuator follows a setpoint through a PI control loop. The control deviation ranged from 0.6 to 1 degree, with a response time between 6 and 8 s. The experiments have demonstrated that through the use of ERF and integrated valve electrodes, a miniaturized functional actuator can be constructed. Full article
