Search Results (19)

To address the issues of low permeability, clogging susceptibility, and insufficient circumferential bearing capacity of traditional drainage blind pipes behind tunnel linings in water-rich areas, this study proposes a novel curved-mesh circumferential drainage blind pipe specifically designed for such environments. First, through engineering surveys and comparative analysis, the limitations and application demands of conventional circumferential annular drainage blind pipes in highway tunnels were identified. Based on this, the key parameters of the new blind pipe—including material, wall thickness, and aperture size—were determined. Laboratory tests were then conducted to evaluate the performance of the newly developed pipe. Subsequently, the pipe was applied in a real-world tunnel project, where a construction process and an in-service blockage inspection method for circumferential drainage pipes were proposed. Field application results indicate that, compared to commonly used FH50 soft permeable pipes and F100 semi-split spring pipes, the novel curved-mesh drainage blind pipe exhibits superior circumferential load-bearing capacity, anti-clogging performance, and deformation resistance. The proposed structure provides a total permeable area exceeding 17,500 mm², three to four times larger than that of conventional drainage pipes, effectively meeting the drainage requirements behind tunnel linings in high-water-content zones. The use of four-way connectors enhanced integration with other drainage systems, and inspection of the internal conditions confirmed that the pipe remained free of clogging and deformation. Furthermore, the curved-mesh design offers better conformity with the primary support and demonstrates stronger adaptability to complex installation conditions. Full article

The implementation of a decentralized blue–green infrastructure (BGI) is a key strategy in climate adaptation and stormwater management. However, the integration of urban trees into the multifunctional infrastructure remains insufficiently addressed, particularly regarding rooting space in dense urban environments. Addressing this gap, the BoRSiS project developed the soil-pipe system (SPS), which repurposes the existing underground pipe trenches and roadway space to provide trees with significantly larger root zones without competing for additional urban space. This enhances tree-related ecosystem services, such as cooling, air purification, and runoff reduction. The SPS serves as a stormwater retention system by capturing excess rainwater during heavy precipitation events of up to 180 min, reducing the pressure on drainage systems. System evaluations show that, on average, each SPS module (20 m trench length) can store 1028–1285 L of water, enabling a moisture supply to trees for 3.4 to 25.7 days depending on the species and site conditions. This capacity allows the system to buffer short-term drought periods, which, according to climate data, recur with frequencies of 9 (7-day) and 2 (14-day) events per year. Geotechnical and economic assessments confirm the system stability and cost-efficiency. These findings position the SPS as a scalable, multifunctional solution for urban climate adaptation, tree vitality, and a resilient infrastructure. Full article

The underground pipeline is a critical component of urban water supply and drainage infrastructure. However, the absence of accurate pipe information frequently leads to construction delays and cost overruns, adversely impacting urban management and economic development. To address these challenges, the digital management of underground pipelines has become essential. Despite its importance, research on the structural analysis and reconstruction of underground pipelines remains limited, primarily due to the complexity of underground environments and the technical constraints of LiDAR technology. This study proposes a framework for reconstructing underground pipelines based on unstructured point cloud data, aiming to accurately identify and reconstruct pipe structures from complex scenes. The Random Sample Consensus (RANSAC) algorithm, enhanced with parameter-adaptive adjustments and subset-independent fitting strategies, is employed to fit centerline segments from the set of center points. These segments were used to reconstruct topological connections, and a Building Information Model (BIM) of the underground pipeline was generated based on the structural analysis. Experiments on actual underground scenes evaluated the method using recall rate, radius error, and deviation between point clouds and models. Results showed an 88.8% recall rate, an average relative radius error below 3%, and a deviation of 3.79 cm, demonstrating the framework’s accuracy. This research provides crucial support for pipeline management and planning in smart city development. Full article

Crystallization-induced blockages in tunnel drainage systems pose significant challenges to their functionality and longevity. To address this issue, this study proposes a novel adaptive drainage pipe designed to prevent crystallization. By constructing an indoor experimental model for anti-crystallization tests, combined with scanning electron microscopy (SEM) and molecular dynamics simulations, this study investigates the mechanism and effectiveness of the proposed system. The findings reveal that flexible PVC pipes in dynamic flow and expansion states significantly reduce crystallization compared to conventional PVC pipes. Among tested materials, EVA and TPU demonstrate superior crystallization resistance, with EVA exhibiting the lowest crystallization accumulation (7.13 g/m). Molecular dynamics simulations further elucidated the influence of material properties on the diffusion coefficient and binding energy of calcium carbonate crystals, with EVA showing the lowest binding energy with calcium carbonate at 135.11 kcal/mol, ultimately confirming EVA as the optimal material for crystallization prevention. These results offer new strategies and valuable references for managing crystallization in tunnel drainage systems. Full article

Advancements in smart sensing and control technologies enable urban drainage engineers to retrofit stormwater storage facilities with real-time control devices for mitigating stormwater in-site overflow, downstream flooding, and overloaded total suspended solids (TSS) in drainage pipes. While the smart technology can improve the performance of the static drainage systems, coordinatively controlling multiple valve and gate operations poses a significant challenge, especially at a large-scale watershed. Using a benchmark stormwater model located at Ann Arbor, Michigan, USA, we assessed the impact of different real-time control strategies (local individual downstream control and system-level multiple control) on balancing flooding mitigation at downstream outlets and TSS reduction at upstream storage units, such as detention ponds. We examined changes in peak water depth, outflow, and TSS as indicators to assess changes in water quantity and quality. The results indicate that system-level control can reduce peak water depth by up to 7.3%, reduce flood duration by up to 34%, and remove up to 67% of total suspended solids compared with a baseline uncontrolled system, with the outflow from upstream detention ponds being the most important hydraulic indicator for control strategy rule set-up. We find that system-level control does not always outperform the individual downstream controls, particularly in alleviating flooding duration at some downstream outlets. With urban growth and a changing climate, this research provides a foundation for quantifying the benefits of real-time control methods as an adaptive stormwater management solution that addresses both water quantity and quality challenges. Full article

Drainage pipes are a critical component of urban infrastructure, and their safety and proper functioning are vital. However, haze problems caused by humid environments and temperature differences seriously affect the quality and detection accuracy of drainage pipe images. Traditional repair methods are difficult to meet the requirements when dealing with complex underground environments. To solve this problem, we researched and proposed a dehazing method for drainage pipe images based on multi-attention multi-scale adaptive feature networks. By designing multiple attention and adaptive modules, the network is able to capture global features with multi-scale resolution in complex underground environments, thereby achieving end-to-end dehazing processing. In addition, we also constructed a large drainage pipe dataset containing tens of thousands of clear/hazy image pairs of drainage pipes for network training and testing. Experimental results show that our network exhibits excellent dehazing performance in various complex underground environments, especially in the real scene of urban underground drainage pipes. The contributions of this paper are mainly reflected in the following aspects: first, a novel multi-scale adaptive feature network based on multiple attention is proposed to effectively solve the problem of dehazing drainage pipe images; second, a large-scale drainage pipe data is constructed. The collection provides valuable resources for related research work; finally, the effectiveness and superiority of the proposed method are verified through experiments, and it provides an efficient solution for dehazing work in scenes such as urban underground drainage pipes. Full article

Extreme rainfall events cause immense damage in cities where drainage networks are nonexistent or deficient and thus unable to transport rainwater. Infrastructure adaptations can reduce flooding and help the population avoid the associated negative consequences. Consequently, it is imperative to develop suitable mathematical models rooted in a thorough understanding of the system. Additionally, the utilization of efficient computational search techniques is crucial when applying these methods to real-world problems. In this study, we propose a novel iterative search space reduction methodology coupled with a multiobjective algorithm (NSGA-II) for urban drainage network rehabilitation and flood mitigation. This approach considers the replacement of pipes and the installation of storm tanks (STs) in drainage networks. Additionally, NSGA-II is integrated with the Storm Water Management Model (SWMM) to achieve multiobjective optimization. To demonstrate the advantages of using this technique, two case study networks are presented. After three iterations, 90% of the decision variables are eliminated from the process in the E-Chicó case, and 76% are eliminated in the Ayurá case. The primary outcome of this study is that the proposed methodology yields reductions in rehabilitation costs and flood levels. Additionally, the application of NSGA-II to the reduced-dimension model of the network yields a superior Pareto front compared to that of the original network. Full article

There is currently a context of climate change due to the way modern cities are developed, and they are made up mainly of impermeable surfaces and concrete buildings that change the hydrological cycle, causing (i) an increase in temperatures, (ii) the accumulation of stormwater on different surfaces, (iii) overflow in drainage systems, and (iv) the alteration of ventilation patterns, among others. This article presents a case study on the implementation of a permeable interlocking concrete paving (PICP) system, and it develops physical–mathematical modeling using software for the design of a parking lot that currently does not have adequate paving and urban drainage, resulting in sporadic flooding due to heavy rainfall in the city of Temuco, La Araucanía region, Chile. This article’s contribution highlights the application of new technology in Chile, discussing road infrastructure solutions based on sustainable urban drainage systems (SUDSs), which seek to implement feasible alternatives in urban sectors to improve human livelihood. The factors studied include structural and hydrological properties, along with the infiltration analysis of the system according to historical rainfall records in the area. This research concludes that the permeable pavement system with a drainage pipe and smooth roughness coefficient performs satisfactorily for an extreme hydrometeorological event corresponding to 140 mm considering 24 h of rainfall with a return period of 100 years equivalent to an inflow of 673 m³/day. Finally, the results indicate that, at least in the conditions of the city of Temuco, the use of permeable interlocking concrete pavement (PICP) proves to be a sustainable and feasible alternative to implementing measures of adaptation and mitigation against climate change, reducing the city’s flooding zones and allowing the irrigation of urban green areas. Full article

Sponge city is a method of managing rain floods, proposed by China to deal with urban waterlogging and the overflow pollution of drainage pipe networks, which indicates a more effective strategy to promote urban sustainable development. Due to the diversity of sponge city construction objectives and the complexity of the developmental system, a unified and effective sustainability evaluation method has not yet been formed. Based on the emergy analysis method, the indicators of ecosystem service, the construction cost, the runoff regulation, and the pollutant reduction of sponge city construction are thus included in the evaluation system, and the sustainable evaluation model of a sponge city is fully constructed. Taking the core area in the south of Haicang in Xiamen City as the studying object, the runoff regulation, and the pollutant reduction indicators, are carefully obtained by using Info Works simulation software. The results showed that: ① the quality of COD (Chemical Oxygen Demand) of pollutants discharged from the research object is 409.8t/a, the total runoff is 3.579 million m³/a, the current annual total runoff control rate is 37.15%, and the current emergy index ESI of sponge city system is 0.05 < 1, which is in an unsustainable state, It is necessary to upgrade and transform the urban underlying surface; ② The transformation intensity of three LID (Low Impact Development) facilities, i.e., concave green space, permeable pavement and green roof, is carefully selected as different construction schemes. When the construction intensity of LID is 25%, the emergy index ESI (Emergy Sustainable Index) = 1.08, which meets the basic requirements of sustainable development; As long as the reconstruction construction intensity is 30%, the growth value of ESI, ΔESI, is the largest, the sustainable growth effect of sponge city construction is the most obvious, and the marginal benefit is the largest; ③ As long as the total annual runoff control rate of the research object is 69–82%, its sustainable energy index ESI should be within the range of 1.39–1.83. If ESI is less than 1.39, this indicates that the total annual runoff control rate of the research area cannot adapt to the planning requirements of 69%. Full article

For a long time, the serious mismatch between negative pressure and drainage parameters of underground gas drainage has been the main reason for the standing engineering problems in coal mines, such as low gas drainage concentration, fast decay, and low-utilization rate. Aiming at these problems, an innovative method by adding micro-frequency conversion drainage pumps and electronically controlled valves at the key nodes of the conventional pipe network system of gas drainage and the joint quantitative regulation of underground regulation facilities and surface drainage pumps based on the intrinsic correlation between the drainage parameters and negative pressure is proposed in this paper to solve the difficulty of how to regulate increasing pressure or resistance in the on-site gas-drainage system and to realize energy matching in the whole drainage system on demand. For this method, the study further defines the safety and efficiency criteria of gas drainage, proposes the adaptive control strategy of gas-drainage parameters, and establishes the adaptive control model based on particle swarm optimization. The model took the safety and efficiency criteria of gas drainage as the constraint conditions and the maximum gas-drainage flow or concentration as the objective function to adaptively adjust the operating conditions of drainage pumps, micro-frequency conversion drainage pumps, and electric control valves to realize the adaptive regulation of gas-drainage parameters. Finally, based on the adaptive control strategy and model of gas-drainage parameters, the numerical simulation research was carried out through Comsol with Matlab. The results show that the gas-drainage concentration and high-concentration drainage period can be increased many times, and the adaptive drainage parameters of valves and micro pumps can be adjusted intelligently, which provides a theoretical basis for the intelligent field implementation of gas. Full article

Sustainability evaluation of wastewater treatment helps to reduce greenhouse gas emissions, as it emphasizes the development of green technologies and optimum resource use rather than the end-of-pipe treatment. The conventional approaches for treating acid mine drainages (AMDs) are efficient; however, they need enormous amounts of energy, making them less sustainable and causing greater environmental concern. We recently demonstrated the potential of immobilized acid-adapted microalgal technology for AMD remediation. Here, this novel approach has been evaluated following emergy and carbon footprint analysis for its sustainability in AMD treatment. Our results showed that imported energy inputs contributed significantly (>90%) to the overall emergy and were much lower than in passive and active treatment systems. The microalgal treatment required 2–15 times more renewable inputs than the other two treatment systems. Additionally, the emergy indices indicated higher environmental loading ratio and lower per cent renewability, suggesting the need for adequate renewable inputs in the immobilized microalgal system. The emergy yield ratio for biodiesel production from the microalgal biomass after AMD treatment was >1.0, which indicates a better emergy return on total emergy spent. Based on greenhouse gas emissions, carbon footprint analysis (CFA), was performed using default emission factors, in accordance with the IPCC standards and the National Greenhouse Energy Reporting (NGER) program of Australia. Interestingly, CFA of acid-adapted microalgal technology revealed significant greenhouse gas emissions due to usage of various construction materials as per IPCC, while SCOPE 2 emissions from purchased electricity were evident as per NGER. Our findings indicate that the immobilized microalgal technology is highly sustainable in AMD treatment, and its potential could be realized further by including solar energy into the overall treatment system. Full article

A problem for drainage systems managers is the increase in extreme rain events that are increasing in various parts of the world. Their occurrence produces hydraulic overload in the drainage system and consequently floods. Adapting the existing infrastructure to be able to receive extreme rains without generating consequences for cities’ inhabitants has become a necessity. This research shows a new way to improve drainage systems with minimal investment costs, using for this purpose a novel methodology that considers the inclusion of hydraulic control elements in the network, the installation of storm tanks and the replacement of pipes. The presented methodology uses the Storm Water Management Model for the hydraulic analysis of the network and a modified Genetic Algorithm to optimize the network. In this algorithm, called the Pseudo-Genetic Algorithm, the coding of the chromosomes is integral and has been used in previous studies of hydraulic optimization. This work evaluates the cost of the required infrastructure and the damage caused by floods to find the optimal solution. The main conclusion of this study is that the inclusion of hydraulic controls can reduce the cost of network rehabilitation and decrease flood levels. Full article

The increasing population and urban sprawl will continue to add significant pressure to natural resources in arid and semi-arid zones. This study evaluates the theoretical effectiveness of adapting resilient strategies such as water conservation and green infrastructure to mitigate the water scarcity faced by the inhabitants of a residential area with a semi-arid climate. Three scenarios were analyzed at a micro-basin level to determine the mitigation of surface runoff and the volume that can be theoretically intercepted for further use: (a) unaltered natural watershed (scenario 1), (b) currently urbanized watershed (scenario 2), and (c) watershed adapted with resilient strategies (scenario 3). For this last scenario, the annual usable volume of rainwater intercepted on the dwelling rooftops was obtained. The runoff and peak flow in the natural watershed were lower than in the other two scenarios. In contrast, a decrease in the runoff was observed in scenario 3 concerning scenario 2, which indicates that the interception of rainwater on house roofs and the adoption of green infrastructure solutions would significantly reduce the diameter of urban drainage pipes required in new developments, as well as the dependency of inhabitants on potable water services. In sites with semi-arid climates, it is possible to take advantage of the rainwater harvested on rooftops and the runoff intercepted through green infrastructure to mitigate local water scarcity problems, which should be considered and adopted in new residential developments. Full article

The Fifth Assessment Report (AR5) of the Intergovernmental Panel on Climate Change (IPCC) of the United Nations mentions that extreme rainfalls might increase their intensity and frequency in most mid-latitude locations and tropical regions by the end of this century, as a consequence of the rise of the average global surface temperature. Human action has given way to global warming which manifests with an increase in extreme rainfall. If these climatic conditions are added to the waterproofing that cities have been experiencing as a result of urban development, a scenario of growing concern for the managers of drainage systems is generated. The objective of drainage networks is preventing the accumulation of rainwater on the surface. Under the new conditions of climate change, these need to be modified and adapted to provide cities with the security they demand. The following article describes a method for flood control by using a rehabilitation model that connects the Storm Water Management Model (SWMM) 5 model with a genetic algorithm to find the best solutions to the flood problem. The final analysis is performed using the Pareto efficiency criteria. The innovation of this method is the inclusion of a local head loss in the drainage network, allowing the upstream flow to be retained by decreasing the downstream concentration time. These elements called hydraulic controls improve system performance and are installed in the initial part of some pipes coming out of storm tanks. As a case study, the developed method has been applied in a section of the drainage network of the city of Bogotá. Full article

The traditional engineering approach to manage urban drainage is by combined or separated sewers. In urban catchments, drainage systems may include different types of storage and detention facilities to avoid flooding from heavy rainfall. However, during recent decades, alternative ways to manage floods have evolved since traditional methods often harm the riverine ecosystems by pollution and erosion and increase the flood risk in the downstream extent of a catchment. Green spaces are important in urban areas for many different reasons: recreation, maintenance of biodiversity, city structure, cultural identity, environmental quality of the urban area, and as biological solutions to technical problems in urban areas. However, plans for urban green spaces often do not take into consideration the multiple purposes of green spaces and the relation between urban green spaces and water is only to a limited degree mentioned and discussed in such plans. Densification has become a dominating urban planning strategy, as many cities strive to reduce their negative, environmental impact. As a consequence of urban densification, the need for solid strategies to preserve, build, develop and ideally simultaneously increase the quantity (area) and quality of green and blue spaces (vegetation and surface water) in urban areas in a multifunctional manner increases. The combination of climate change adaptation, densification, pollution, the call for more green spaces, and a need to restore aging sewers, leads to strong interest in retrofitting of urban areas with nature-based solutions (NBS). Incorporation of NBS into decision-making and ways to handle integrative and multi-criteria aspects in the legal and organisational system are still to a great extent not done. The current regime for stormwater management, through piped drainage, is dominating and many cities face a lack of green spaces. Introducing more nature-based solutions is faced with barriers that are largely socio-institutional rather than technical. In this keynote session such barriers, as well as drivers, for wide-spread implementation of NBS, as well as data management strategies to help the implementation, are discussed. Based on transition theory, socio-technical transition towards wide-spread implementation of such measures were examined through interviews with municipal and water utility officials. Legal, organisational and financial changes are suggested. This keynote session also discusses urban, pluvial flooding and if NBS can be used as a strategy for resilient flood risk management. Spatial analyses of flood claims from insurance companies and the water utility company of Malmö are used to study how NBS impact flood risk. Full article
