Search Results (27)

In this paper, a compact multi-split-ring resonator-based antenna is presented for wireless applications. The proposed antenna integrates multiple resonators to achieve multiband operation, where each resonator corresponds to a specific frequency band. A theoretical analysis is conducted to model the equivalent circuit of the proposed antenna, followed by an analytical study to calculate the resonant frequency of each resonator. By integrating these resonators, the proposed antenna achieves a compact size of 23 × 24 × 1.6 mm³ (0.19 × 0.2 × 0.01λ³), resulting in a size reduction of 81.6% compared to a conventional patch antenna, while maintaining gain, improving bandwidth, and providing excellent impedance matching. The proposed antenna covers the 2.4–2.8 GHz (14.55%), 3.25–3.75 GHz (14.28%) and 4.5–7.84 GHz (54.13%) frequency bands, providing acceptable gains of 1.5 dBi, 2 dBi and 3.2 dBi, respectively. The antenna was designed with CST, its performance was verified with HFSS simulations and it was validated with an equivalent circuit in ADS. Finally, the antenna was fabricated to confirm the accuracy and reliability of the simulation results, and it was found that the measurements agreed well with the simulations. This multiband functionality, combined with a compact form factor and simple feed line, makes the antenna cost-effective, easy to manufacture and suitable for various wireless communication applications, including 5G sub-6 GHz mid-band (2.5/3.5/5/5 GHz), RFID (2.45/5.8 GHz), WiMAX (2.4/3.5/5.8 GHz), Wi-Fi 5/6/6E (2.4/5/6 GHz) and WLAN (5.2/5.8 GHz). Full article

The fifth generation of wireless communication (5G) technology is becoming more innovative with the increasing need for high data rates because of the incremental rapidity of mobile data growth. In 5G systems, enhancing device-to-device communication, ultra-low latency (1 ms), outstanding dependability, significant flexibility, and data throughput (up to 20 Gbps) is considered one of the most essential factors for wireless networks. To meet these objectives, a sub-6 5G wideband multiple-input multiple-output (MIMO) array microstrip antenna for 5G Worldwide Interoperability for Microwave Access (WiMAX) applications on hotspot devices has been proposed in this research. The 1 × 4 MIMO array radiating element antenna with a partial ground proposed in this research complies with the 5G application standard set out by the Federal Communications Commission. The planned antenna configuration consists of a hollow, regular circular stub patch antenna shaped like a crescent with a rectangular defect at the top of the patch. The suggested structure is mounted on an FR-4 substrate with a thickness “h” of 1.6, a permittivity “${\epsilon }_r$” of 4.4, and a tangential loss of 0.02. The proposed antenna achieves a high radiation gain and offers a frequency spectrum bandwidth of 3.01 GHz to 6.5 GHz, covering two 5G resonant frequencies “$f_r$” of 3.5 and 5.8 GHz as the mid-band, which yields a gain of 7.66 dBi and 7.84 dBi, respectively. MIMO antenna parameters are examined and introduced to assess the system’s performance. Beneficial results are obtained, with the channel capacity loss (CCL) tending to 0.2 bit/s/Hz throughout the operating frequency band, the envelope correlation coefficient (ECC) yielding 0.02, a mean effective gain (MEG) of less than −6 dB over the operating frequency band, and a total active reflection coefficient (TARC) of less than −10 dB; the radiation efficiency is equal to 71.5%, maintaining impedance matching as well as good mutual coupling among the adjacent parameters. The suggested antenna has been implemented and experimentally tested using the 5G system Open Air Interface (OAI) platform, which operates at sub-6 GHz, yielding −67 dBm for the received signal strength indicator (RSSI), and superior frequency stability, precision, and reproducibility for the signal-to-interference-plus-noise ratio (SINR) and a high level of positivity in the power headroom report (PHR) 5G system performance report, confirming its operational effectiveness in 5G WiMAX (Worldwide Interoperability for Microwave Access) application. Full article

This article analyses & describes a trapezoidal dual-band monopole antenna. The notch band monopole disables 4.4–5.7 GHz commercial communication equipment. The basic type operates at 2.5–4.4 GHz with a 500 MHz marginal bandwidth and 5.7–7 GHz with a 1000 MHz bandwidth. Present research optimises multiband trapezoidal antennas. Trapezoidal antennas improve multi-band wireless antennas. GSM, LTE, Wi-Fi, and 5G frequency bands start design. Inefficient and space-wasting, traditional antennas lack frequency range. Benefits of trapezoids: changing trapezoidal element sizes and angles enables the antenna to transmit many frequencies, sloping trapezium sides allow impedance changes without networks or tuning, numerical calculation and electromagnetic modelling optimise the trapezoidal antenna’s performance throughout the communication band, impedance matching, gain, and radiation efficiency provide transmission reliability, and broadband trapezoidal forms eliminate band-specific antennas & switches. Simplified antenna integration makes modern devices cheaper and simpler. In multiband applications, trapezoidal antennas outperform normal antennas. The antenna fits numerous wireless communication devices and systems due to its modest size and wide band coverage. The redesigned structure with notch increases operating band bandwidth and notches application bands between 4.4–5.7 GHz. By modifying trapezoidal geometry, we generate selective impedance transition notches to target crucial interference frequencies. Modern wireless communication systems with complicated interference situations can trust its careful engineering to provide good efficiency and radiation patterns across a wide frequency band while actively rejecting interfering signal. The peak realized gains obtained at 2.5 GHz is 2.4 dB, at 3.4 GHz it is 3.5 GHz and at 5.8 GHz it is 4.7 dB. Full article

This article describes the development of a compact microstrip bandpass filter (BPF) for multiple wireless communication utilizations. The proposed bandpass filter consists of metamaterial unit cells that are symmetrical in shape. The design process involves the placement of four symmetrical split-ring resonators (SRRs) on the top plane of the BPF. It exhibits improved filter characteristics through the implementation of these SRRs. The filter was modeled and fabricated and its performance was evaluated using a Vector Network Analyzer. The designed bandpass filter shows a 5 GHz bandwidth covering the frequency band spanning from 1 to 5.2 GHz, with a quality factor value of 1.85 across 1.9 GHz, 3.3 across 3.3 GHz and 5.1 across 5.1 GHz. The metamaterial analysis was carried out using ANSYS ELECTRONIC DESKTOP. The proposed filter measures 20 × 18 × 1.6 mm³, which is significantly smaller than current filters. The designed bandpass filter occupies 50% of the space of a conventional filter. The designed bandpass filter exhibits a distributed surface current of 84 A/m, and 94 A/m across the wide- and narrow-band operating frequency. The simulated and measured results indicate that the suggested metamaterial filter is well-suited for multiband wireless applications like GPS (1.57 GHz), WLAN (2.4, 3.6, and 5.2 GHz), Wi-MAX (2.3, 2.5, and 3.5 GHz), and ISM (2.5 GHz). Full article

This article presents a quad-element MIMO antenna designed for multiband operation. The prototype of the design is fabricated and utilizes a vector network analyzer (VNA-AV3672D) to measure the S-parameters. The proposed antenna is capable of operating across three broad frequency bands: 3–15.5 GHz, encompassing the C band (4–8 GHz), X band (8–12.4 GHz), and a significant portion of the Ku band (12.4–15.5 GHz). Additionally, it covers two mm-wave bands, specifically 26.4–34.3 GHz and 36.1–48.9 GHz, which corresponds to 86% of the Ka-band (27–40 GHz). To enhance its performance, the design incorporates a partial ground plane and a top patch featuring a dual-sided reverse 3-stage stair and a straight stick symmetrically placed at the bottom. The introduction of a defected ground structure (DGS) on the ground plane serves to provide a wideband response. The DGS on the ground plane plays a crucial role in improving the electromagnetic interaction between the grounding surface and the top patch, contributing to the wideband characteristics of the antenna. The dimensions of the proposed MIMO antenna are 31.7 mm × 31.7 mm × 1.6 mm. Furthermore, the article delves into the assessment of various performance metrics related to antenna diversity, such as ECC, DG, TARC, MEG, CCL, and channel capacity, with corresponding values of 0.11, 8.87 dB, −6.6 dB, ±3 dB, 0.32 bits/sec/Hz, and 18.44 bits/sec/Hz, respectively. Additionally, the equivalent circuit analysis of the MIMO system is explored in the article. It’s worth noting that the measured results exhibit a strong level of agreement with the simulated results, indicating the reliability of the proposed design. The MIMO antenna’s ability to exhibit multiband response, good diversity performance, and consistent channel capacity across various frequency bands renders it highly suitable for integration into multi-band wireless devices. The developed MIMO system should be applicable on n77/n78/n79 5G NR (3.3–5 GHz); WLAN (4.9–5.725 GHz); Wi-Fi (5.15–5.85 GHz); LTE5537.5 (5.15–5.925 GHz); WiMAX (5.25–5.85 GHz); WLAN (5.725–5.875 GHz); long-distance radio telecommunication (4–8 GHz; C-band); satellite, radar, space communications and terrestrial broadband (8–12 GHz; X-band); and various satellite communications (27–40 GHz; Ka-band). Full article

Ultra-wideband (UWB) technology is widely used in many communication scenarios. However, narrowband systems can easily interfere with the UWB system, which generates multipath fading. In order to solve these interferences and meet the design requirements of high isolation of multiple-input multiple-output (MIMO) antennas, two MIMO antennas with double-notch structures are designed. Firstly, two U-shaped slots are etched on the radiating patch and feeder to achieve notch characteristics in WiMAX and ITU bands. Using this antenna element, a two-element antenna is put symmetrically in parallel, and two rectangular branches are loaded to improve the isolation. The size is 0.57λ × 0.32λ × 0.013λ (at 2.5 GHz). Then, a four-element antenna is designed to meet the requirements for another application; here, each element is placed orthogonally to each other, and the isolation is improved through loading a cross-shaped branch in the middle of these elements. The size is 0.57λ × 0.57λ × 0.013λ. Both antenna samples are tested to verify the design. Measurement results show that the working bandwidth is 2.45–14.88 GHz and 2.14–14.95 GHz, the isolation is greater than 17 and 20 dB, and the peak gain is 5.7 and 5.9 dBi for the two- and four-element MIMO antenna, respectively. Compared to the references, the designed antennas have a wider bandwidth and a higher gain and radiation efficiency. They are well-suited for diverse wireless applications. Full article

A wideband low-profile radiating G-shaped strip on a flexible substrate is proposed to operate as biomedical antenna for off-body communication. The antenna is designed to produce circular polarization over the frequency range 5–6 GHz to communicate with WiMAX/WLAN antennas. Furthermore, it is designed to produce linear polarization over the frequency range 6–19 GHz for communication with the on-body biosensor antennas. It is shown that an inverted G-shaped strip produces circular polarization (CP) of the opposite sense to that produced by G-shaped strip over the frequency range 5–6 GHz. The antenna design is explained and its performance is investigated through simulation, as well as experimental measurements. This antenna can be viewed as composed of a semicircular strip terminated with a horizontal extension at its lower end and terminated with a small circular patch through a corner-shaped strip extension at its upper end to form the shape of “G” or inverted “G”. The purpose of the corner-shaped extension and the circular patch termination is to match the antenna impedance to 50 $\mathsf{\Omega }$ over the entire frequency band (5–19 GHz) and to improve the circular polarization over the frequency band (5–6 GHz). To be fabricated on only one face of the flexible dielectric substrate, the antenna is fed through a co-planar waveguide (CPW). The antenna and the CPW dimensions are optimized to obtain the most optimal performance regarding the impedance matching bandwidth, 3dB Axial Ratio (AR) bandwidth, radiation efficiency, and maximum gain. The results show that the achieved 3dB-AR bandwidth is 18% (5–6 GHz). Thus, the proposed antenna covers the 5 GHz frequency band of the WiMAX/WLAN applications within its 3dB-AR frequency band. Furthermore, the impedance matching bandwidth is 117% (5–19 GHz) which enables low-power communication with the on-body sensors over this wide range of the frequency. The maximum gain and radiation efficiency are 5.37 dBi and 98%, respectively. The overall antenna dimensions are 25 × 27 × 0.13 mm${}^3$ and the bandwidth-dimension ratio (BDR) is 1733. Full article

We proposed a novel approach based on a complementary split-ring resonator metamaterial in a two-port MIMO antenna, giving high gain, multiband results with miniature size. We have also analyzed a circular disk metasurface design. The designs are also defected using ground structure by reducing the width of the ground plane to 8 mm and etching all other parts of the ground plane. The electric length of the proposed design is 0.5λ × 0.35λ × 0.02λ. The design results are also investigated for a different variation of complementary split-ring resonator ring sizes. The inner and outer ring diameters are varied to find the optimized solution for enhanced output performance parameters. Good isolation is also achieved for both bands. The gain and directivity results are also presented. The results are compared for isolation, gain, structure size, and the number of ports. The compact, multiband, high gain and high isolation design can apply to WiMAX, WLAN, and satellite communication applications. Full article

This paper introduces a new tri-wideband fractal antenna for use in wireless communication applications. The fractal manufactured antenna developed has a Sierpinski hexagonal-shaped radiating element and a partial ground plane loaded with three rectangular stubs and three rectangular slits. The investigated antenna has a small footprint of 0.19λ₀ × 0.24 λ₀ × 0.0128 λ₀ and improved bandwidth and gain. According to the measurements, the designed antenna resonates throughout the frequency ranges of 2.19–4.43 GHz, 4.8–7.76 GHz, and 8.04–11.32 GHz. These frequency ranges are compatible with a variety of wireless technologies, including WLAN, WiMAX, ISM, LTE, RFID, Bluetooth, 5G spectrum band, C-band, and X-band. The investigated antenna exhibited good gain with almost omnidirectional radiation patterns. Utilizing CST MWS, the performance of the suggested Sierpinski hexagonal-shaped fractal antenna was achieved. The findings were then compared to the experimental results, which were found to be in strong agreement. Full article

Next generation mobile networks are expected to integrate multiple drones organized in Flying Ad Hoc Networks (FANETs) to support demanding and diverse services. The highly mobile drones should always be connected to the network in order to satisfy the strict requirements of upcoming applications. As the number of drones increases, they burden the network with the management of signaling and continuous monitoring of the drones during data transmission. Therefore, designing transmission mechanisms for fifth-generation (5G) drone-aided networks and using clustering algorithms for their grouping is of paramount importance. In this paper, a clustering and selection algorithm of the cluster head is proposed together with an efficient Group Handover (GHO) scheme that details how the respective Point of Access (PoA) groups will be clustered. Subsequently, for each cluster, the PoA elects a Cluster Head (CH), which is responsible for manipulating the mobility of the cluster by orchestrating the handover initiation (HO initiation), the network selection, and the handover execution (HO execution) processes. Moreover, the members of the cluster are informed about the impending HO from the CH. As a result, they establish new uplink and downlink communication channels to exchange data packets. In order to evaluate the proposed HO scheme, extensive simulations are carried out for a next-generation drone network architecture that supports Internet of Things (IoT) and multimedia services. This architecture relies on IEEE 802.11p Wireless Access for Vehicular Environment (WAVE) Road Side Units (RSUs) as well as Long-Term Evolution Advanced (LTE-A) and IEEE 802.16 Worldwide Interoperability for Microwave Access (WiMAX). Furthermore, the proposed scheme is also evaluated in a real-world scenario using a testbed deployed in a controlled laboratory environment. Both simulation and real-world experimental results verify that the proposed scheme outperforms existing HO algorithms. Full article

In this manuscript, we proposed the split ring resonator loaded multiple-input multiple-output (MIMO) antenna design for the frequency range of 1 and 25 GHz. The proposed antenna is numerically investigated and fabricated to analyze the different antenna parameters. We provided statistics on a wide range of antenna parameters for five different designs, including a simple circular patch antenna, a single-split-ring antenna, and a double-split-ring antenna. Reflectance, gain, directivity, efficiency, peak gain, and electric field distribution are all analyzed for all proposed antennas. The maximum achievable bandwidth is 5.28 GHz, and the double-split-ring resonator structure achieves this with a return loss of −20.84 dB. The radiation patterns of all the antenna with different port excitation conditions are presented to identify the behavior of the antenna radiation. We found the effect of the split-ring resonators to form radiation beams in different directions. We found the maximum and minimum half-power beam widths of 75° and 2°, respectively, among the different antenna designs. It was found that the split-ring resonator geometries in patch antenna convert wide-beam antenna radiation patterns to several narrow-beam radiation patterns. We found that each antenna’s bandwidth, gain, and return loss performance significantly differs from the others. Overall, the proposed results of the antenna may apply to a wide range of communication applications, including those for Wi-Fi, WiMAX, and 5G. Full article

A novel ultra-wideband (UWB) KAYI-shaped and common KITE-shaped ground plane tri-port antenna is proposed. The proposed research work has a small size of (30 × 30 × 1.6 mm${}^3$). The MIMO antenna elements are placed in a KAYI-shaped (Y-shaped) with a symmetric phase shift of ${120}^{\circ }$ between the nearby MIMO antennas element improving the isolation. The antenna’s gain is more than 5 dBi for the entire bands of WiMax, WLAN, and X-band satellite communication. The suggested work includes notches at $3.2$ GHz, $5.2$ GHz, and $8.9$ GHz, respectively. The notching characteristics are made possible by L-shaped slits for the WiMax band, the inverted U-shaped slot for WLAN, while the third is created by the interaction between the L-shaped and U-shaped notching elements. Results were measured after making the prototype antenna on the FR-4 substrate. The proposed antenna has good impedance matching for 2–20 GHz and three notching characteristics with high isolation among the MIMO elements. Mean effective gain (MEG), envelope correlation coefficient (ECC), and total active reflection coefficient (TARC) are the diversity metrics of MIMO antennas which are in good comparison to the proposed antenna. The antenna is a good candidate for deployment in wireless communication and MIMO applications. Full article

A four-port dielectric resonator (DR)-based multiple-input multiple-output (MIMO) antenna is presented for sub-6 GHz MIMO communication. The dielectric resonator was fed through aperture feeding to achieve dual-band resonance. The DRA has the operating modes of $T{E}_{01\delta }$ and $T{E}_{10\delta }$at 3.3 GHz and 3.9 GHz, respectively. The engineered antenna has port isolation of higher than 20 dB at the target frequencies without the employment of an extra isolation mechanism. Full-wave high-frequency simulation software was employed for the simulation computation. The antenna has a peak gain of 5.8 dBi and 6.2 dBi, and an efficiency of 88.6% and 90.2% at 3.3 GHz and 3.9 GHz, respectively. The proposed resonator has good MIMO diversity parameters. The optimal envelope correlation coefficient (ECC) is 0.01, channel capacity loss (CCL) is 0.1 bits/sec/Hz, and the total active reflection coefficient (TARC) is −22.46. The DRA elements are aligned orthogonally with adequate displacement for achieving polarization diversity and spatial diversity. The antenna delivers its applications in Sub-6 GHz 5G and WiMAX communications. Full article

The excessive use of digital platforms with rapidly increasing users in the wireless domain enforces communication systems to provide information with high data rates, high reliability and strong transmission connection quality. Wireless systems with single antenna elements are not able to accomplish the desired needs. Therefore, multiple-input multiple-output (MIMO) antennas are getting more attention in modern high-speed communication systems and play an essential part in the current generation of wireless technology. However, along with their ability to significantly increase channel capacity, it is a challenge to achieve an optimal isolation in a compact size for fifth-generation (5G) terminals. Portable devices, automobiles, handheld gadgets, smart phones, wireless sensors, radio frequency identification and other applications use MIMO antenna systems. In this review paper, the fundamentals of MIMO antennas, the performance parameters of MIMO antennas, and different design approaches and methodologies are discussed to realize the three most commonly used MIMO antennas, i.e., ultra-wideband (UWB), dual-band and circularly polarized antennas. The recent MIMO antenna design approaches with UWB, dual band and circularly polarized characteristics are compared in terms of their isolation techniques, gain, efficiency, envelope correlation coefficient (ECC) and channel capacity loss (CCL). This paper is very helpful to design suitable MIMO antennas applicable in UWB systems, satellite communication systems, GSM, Bluetooth, WiMAX, WLAN and many more. The issues with MIMO antenna systems in the indoor environment along with possible solutions to improve their performance are discussed. The paper also focuses on the applications of MIMO characteristics for future sixth-generation (6G) technology. Full article

In this article, a novel quad-band fractal PIFA antenna design for DCS, PCS, UMTS, and WiMAX wireless communications systems is presented. The proposed antenna is a PIFA antenna where a slot having a Hilbert fractal shape at the third iteration has been inserted at the center of the radiating patch. The fractal shape of the implanted slot on the PIFA antenna was used in order to make the antenna operational at four frequency bands, according the required applications. The proposed antenna with the fractal shape of the slot offers quad-band operation with a miniaturized size compared to the initial PIFA antenna, such that the dimensions of the radiating patch become equal to 28 mm × 28 mm. This structure is operational in the following frequency bands: (1.73–2.08) GHz, (2.46–2.59) GHz, (3.39–3.47) GHz, and the band (4.56–5.02) GHz covering DCS, PCS, UMTS, and WiMAX mobile communications systems, respectively, with a gain ranging from 2 dB to 6 dB at the desired frequency bands. The fractal PIFA antenna design was carried out under CST MWs software with validation of the results made using HFSS software. There is good agreement between the obtained results by the two simulation software. Full article
