Search Results (19)

Underwater acoustic imaging is essential in marine science and engineering, enabling high-resolution detection and characterization of underwater structures and targets. However, conventional deconvolution beamforming methods using broadband signals often suffer from model mismatch, inter-frequency interference, and limited noise robustness. To overcome these challenges, this study rigorously analyzes the point spread function of the imaging system and introduces Acoustic Frequency Comb (AFC) excitations to enhance resolution. By exploiting the autocorrelation characteristics of AFC signals and optimizing key parameters, imaging artifacts are effectively suppressed and the main-lobe width is narrowed, resulting in a 50% improvement in range resolution. Comparative analyses identify the Richardson–Lucy algorithm as the most effective in enhancing azimuthal resolution and maintaining robustness under array perturbations and low signal-to-noise ratios. Parametric studies further demonstrate that AFC excitation outperforms conventional linear frequency modulated pulses, achieving a 30% main-lobe width reduction, 10 dB sidelobe suppression, and a 14 dB noise decrease. Finally, tank experiments confirm the simulation results, showing that accurate PSF modeling enabled by AFC ensures high angular resolution. The discrete spectral structure facilitates more effective separation of signal and noise during iterative deconvolution, while excellent autocorrelation characteristics guarantee high range resolution, yielding superior overall imaging performance. Full article

A horizontal towed linear coherent hydrophone array is often employed to estimate the spatial intensity distribution of incident plane waves scattered from the geological and biological features in an ocean acoustic waveguide using conventional beamforming. However, due to the physical limitations of the array aperture, the spatial resolution after conventional beamforming is often limited by the fat main lobe and the high sidelobes. Here, we propose a method originated from computer vision deblurring based on deep learning to enhance the spatial resolution of beamformed images. The effect of image blurring after conventional beamforming can be considered a convolution of beam pattern, which acts as a point spread function (PSF), and the original spatial intensity distributions of incident plane waves. A modified U-Net-like network is trained on a simulated dataset. The instantaneous acoustic complex amplitude is assumed following circular complex Gaussian random (CCGR) statistics. Both synthetic data and experimental data collected from the South China Sea Experiment in 2021 are used to illustrate the effectiveness of this approach, showing a maximum 700% reduction in a 3 dB width over conventional beamforming. A lower normalized mean square error (NMSE) is provided compared with other deconvolution-based algorithms, such as the Richardson–Lucy algorithm and the approximate likelihood model-based deconvolution algorithm. The method is applicable in various acoustic imaging applications that employ linear coherent hydrophone arrays with one-dimensional conventional beamforming, such as ocean acoustic waveguide remote sensing (OAWRS). Full article

In ground-based astronomical observations or artificial space target detections, images obtained from a ground-based telescope are severely distorted due to atmospheric turbulence. The distortion can be partially compensated by employing adaptive optics (pre-detection compensation), image restoration techniques (post-detection compensation), or a combination of both (hybrid compensation). This paper focuses on the improvement of the most commonly used practical post-processing techniques, Richardson–Lucy (R–L) iteration blind deconvolution, which is studied in detail and improved as follows: First, the total variation (TV) norm is redefined using the Gaussian gradient magnitude and a set scheme for regularization parameter selection is proposed. Second, the Gaussian TV constraint is proposed to impose to the R–L algorithm. Last, the Gaussian TV R–L (GRL) iterative blind deconvolution method is finally presented, in which the restoration precision is visually increased and the convergence property is considerably improved. The performance of the proposed GRL method is tested by both simulation experiments and observed field data. Full article

The frequency–azimuth (FRAZ) spectrum is a critical characteristic in passive target detection and tracking, as it encapsulates information regarding the signal’s frequency and azimuth. However, due to the inherent limitations in the sonar array’s physical aperture and the analysis time of the system, the signal often suffers from undersampling in both spatial and temporal dimensions. This undersampling leads to energy leakage across the azimuth and frequency domains, adversely affecting the resolution of the FRAZ spectrum. Such a reduction in resolution hampers multitarget resolution and feature extraction. To address these challenges, this study introduces a deconvolution-based FRAZ spectrum estimation method tailored for uniform linear arrays. The proposed method initiates by decoupling the azimuth and frequency in the FRAZ spectrum, forming a two-dimensional point scattering function that possesses shift-invariance. Subsequent to this, the power spectrum and the two-dimensional point scattering function undergo deconvolution using the Richardson–Lucy (R–L) iterative algorithm. The final stage involves calculating the signal azimuths and frequencies based on the deconvolution results from the preceding step. Comparative analyses involving simulations and sea test results reveal that the proposed method achieves a narrower main lobe width and diminished background noise in contrast to traditional FRAZ spectrum estimation techniques. This improvement is instrumental in minimizing the target’s energy leakage in both the azimuth and frequency domains. Full article

The retrieval of tree height percentiles from satellite lidar waveforms observed over mountainous areas is greatly challenging due to the broadening and overlapping of the ground return and vegetation return. To accurately represent the shape distributions of the vegetation and ground returns, the target response waveform (TRW) is resolved using a Richardson–Lucy deconvolution algorithm with adaptive iteration. Meanwhile, the ground return is identified as the TRW component within a 4.6 m ground signal extent above the end point of the TRW. Based on the cumulative TRW distribution, the height metrics of the energy percentiles of 25%, 50%, 75%, and 95% are determined using their vertical distances relative to the ground elevation in this study. To validate the proposed algorithm, we select the received waveforms of the Global Ecosystem Dynamics Investigation (GEDI) lidar over the Pahvant Mountains of central Utah, USA. The results reveal that the resolved TRWs closely resemble the actual target response waveforms from the coincident airborne lidar data, with the mean values of the coefficient of correlation, total bias, and root-mean-square error (RMSE) taking values of 0.92, 0.0813, and 0.0016, respectively. In addition, the accuracies of the derived height percentiles from the proposed algorithm are greatly improved compared with the conventional Gaussian decomposition method and the slope-adaptive waveform metrics method. The mean bias and RMSE values decrease by the mean values of 1.68 m and 2.32 m and 1.96 m and 2.72 m, respectively. This demonstrates that the proposed algorithm can eliminate the broadening and overlapping of the ground return and vegetation return and presents good potential in the extraction of forest structure parameters over rugged mountainous areas. Full article

Contrast-enhanced μCT imaging has been used to provide non-destructive 3D images of microdamage, but at a lower quality than found in histology and 2D backscatter electron (BSE) imaging. This study aimed to quantify potential improvements in microdamage characterization by enhancing µCT scanning parameters. Eleven slides from 9 rat vertebrae (healthy = 3, osteolytic metastases = 3, mixed metastases = 3) previously stained for microdamage with BaSO₄ and analyzed with BSE imaging (2μm voxel spacing) were used in this study. μCT imaging conducted under varying protocols (x-ray voltage, tube current, frame averaging) demonstrated enhanced scan parameters at 90 kVp, 44 µA, 0.5 mm aluminum filter, 8 times frame averaging, and 4.9 µm voxel spacing. Post-processing with Richardson-Lucy deconvolution further deblurred the μCT images. Labeled microdamage in the baseline, enhanced and deblurred μCT images were segmented and spatially quantified vs. BSE-labeled microdamage using a probability-based correlation metric at six inflation radii. Enhanced μCT scan parameters improved damage visualization and increased spatial correlation probability with BSE images. Deblurring improved the sharpness of stain boundaries but did not significantly improve spatial correlation probabilities in comparison to the enhanced scans. This enhanced μCT protocol facilitates 3D visualization of microdamage, an indicator of bone quality important to bone damage mechanics. Full article

Three-dimensional reconstruction in brightfield microscopy is challenging since a 2D image includes from in-focus and out-of-focus light which removes the details of the specimen’s structures. To overcome this problem, many techniques exist, but these generally require an appropriate model of Point Spread Function (PSF). Here, we propose a new images restoration method based on the application of Multivariate Curve Resolution (MCR) algorithms to a stack of brightfield microscopy images to achieve 3D reconstruction without the need for PSF. The method is based on a statistical reconstruction approach using a self-modelling mixture analysis. The MCR-ALS (ALS for Alternating Least Square) algorithm under non-negativity constraints, Wiener, Richardson–Lucy, and blind deconvolution algorithms were applied to silica microbeads and red blood cells images. The MCR analysis produces restored images that show informative structures which are not noticeable in the initial images, and this demonstrates its capability for the multiplane reconstruction of the amplitude of 3D objects. In comparison with 3D deconvolution methods based on a set of No Reference Images Quality Metrics (NR-IQMs) that are Standard Deviation, ENTROPY Average Gradient, and Auto Correlation, our method presents better values of these metrics, showing that it can be used as an alternative to 3D deconvolution methods. Full article

A refractive lens is one of the simplest, most cost-effective and easily available imaging elements. Given a spatially incoherent illumination, a refractive lens can faithfully map every object point to an image point in the sensor plane, when the object and image distances satisfy the imaging conditions. However, static imaging is limited to the depth of focus, beyond which the point-to-point mapping can only be obtained by changing either the location of the lens, object or the imaging sensor. In this study, the depth of focus of a refractive lens in static mode has been expanded using a recently developed computational reconstruction method, Lucy-Richardson-Rosen algorithm (LRRA). The imaging process consists of three steps. In the first step, point spread functions (PSFs) were recorded along different depths and stored in the computer as PSF library. In the next step, the object intensity distribution was recorded. The LRRA was then applied to deconvolve the object information from the recorded intensity distributions during the final step. The results of LRRA were compared with two well-known reconstruction methods, namely the Lucy-Richardson algorithm and non-linear reconstruction. Full article

Accompanied by the increasing requirements of the probing micro/nanoscopic structures of biological samples, various image-processing algorithms have been developed for visualization or to facilitate data analysis. However, it remains challenging to enhance both the signal-to-noise ratio and image resolution using a single algorithm. In this investigation, we propose a composite image processing method by combining discrete wavelet transform (DWT) and the Lucy–Richardson (LR) deconvolution method, termed the DWDC method. Our results demonstrate that the signal-to-noise ratio and resolution of live cells’ microtubule networks are considerably improved, allowing the recognition of features as small as 120 nm. The method shows robustness in processing the high-noise images of filament-like biological structures, e.g., the cytoskeleton networks captured by fluorescent microscopes. Full article

Digital image devices have been widely applied in many fields, such as individual recognition and remote sensing. The captured image is a degraded image from the latent observation, where the degradation processing is affected by some factors, such as lighting and noise corruption. Specifically, noise is generated in the processing of transmission and compression from the unknown latent observation. Thus, it is essential to use image denoising techniques to remove noise and recover the latent observation from the given degraded image. In this research, a supervised encoder–decoder convolution neural network was used to fix image distortion stemming from the limited accuracy of inverse filter methods (Wiener filter, Lucy–Richardson deconvolution, etc.). Particularly, we will correct image degradation that mainly stems from duplications arising from multiple-pinhole array imaging. Full article

The optical quality of an image depends on both the optical properties of the imaging system and the physical properties of the medium in which the light travels from the object to the final imaging sensor. The analysis of the point spread function of the optical system is an objective way to quantify the image degradation. In retinal imaging, the presence of corneal or cristalline lens opacifications spread the light at wide angular distributions. If the mathematical operator that degrades the image is known, the image can be restored through deconvolution methods. In the particular case of retinal imaging, this operator may be unknown (or partially) due to the presence of cataracts, corneal edema, or vitreous opacification. In those cases, blind deconvolution theory provides useful results to restore important spatial information of the image. In this work, a new semi-blind deconvolution method has been developed by training an iterative process with the Glare Spread Function kernel based on the Richardson-Lucy deconvolution algorithm to compensate a veiling glare effect in retinal images due to intraocular straylight. The method was first tested with simulated retinal images generated from a straylight eye model and applied to a real retinal image dataset composed of healthy subjects and patients with glaucoma and diabetic retinopathy. Results showed the capacity of the algorithm to detect and compensate the veiling glare degradation and improving the image sharpness up to 1000% in the case of healthy subjects and up to 700% in the pathological retinal images. This image quality improvement allows performing image segmentation processing with restored hidden spatial information after deconvolution. Full article

This paper proposes an implementation of a Richardson-Lucy (RL) deconvolution method to reduce the spatial degradation in hyperspectral images during the image acquisition process. The degradation, modeled by convolution with a point spread function (PSF), is reduced by applying both standard and accelerated RLdeconvolution algorithms on the individual images in spectral bands. Boundary conditions are introduced to maintain a constant image size without distorting the estimated image boundaries. The RL deconvolution algorithm is implemented on a field-programmable gate array (FPGA)-based Xilinx Zynq-7020 System-on-Chip (SoC). The proposed architecture is parameterized with respect to the image size and configurable with respect to the algorithm variant, the number of iterations, and the kernel size by setting the dedicated configuration registers. A speed-up by factors of 61 and 21 are reported compared to software-only and FPGA-based state-of-the-art implementations, respectively. Full article

Deconvolution methods can be used to improve the azimuth resolution in airborne radar imaging. Due to the sparsity of targets in airborne radar imaging, an $L_1$ regularization problem usually needs to be solved. Recently, the Split Bregman algorithm (SBA) has been widely used to solve $L_1$ regularization problems. However, due to the high computational complexity of matrix inversion, the efficiency of the traditional SBA is low, which seriously restricts its real-time performance in airborne radar imaging. To overcome this disadvantage, a fast split Bregman algorithm (FSBA) is proposed in this paper to achieve real-time imaging with an airborne radar. Firstly, under the regularization framework, the problem of azimuth resolution improvement can be converted into an $L_1$ regularization problem. Then, the $L_1$ regularization problem can be solved with the proposed FSBA. By utilizing the low displacement rank features of Toeplitz matrix, the proposed FSBA is able to realize fast matrix inversion by using a Gohberg–Semencul (GS) representation. Through simulated and real data processing experiments, we prove that the proposed FSBA significantly improves the resolution, compared with the Wiener filtering (WF), truncated singular value decomposition (TSVD), Tikhonov regularization (REGU), Richardson–Lucy (RL), iterative adaptive approach (IAA) algorithms. The computational advantage of FSBA increases with the increase of echo dimension. Its computational efficiency is 51 times and 77 times of the traditional SBA, respectively, for echoes with dimensions of $218\times 400$ and $400\times 400$ , optimizing both the image quality and computing time. In addition, for a specific hardware platform, the proposed FSBA can process echo of greater dimensions than traditional SBA. Furthermore, the proposed FSBA causes little performance degradation, when compared with the traditional SBA. Full article

Matched filtering is widely used in active sonar because of its simplicity and ease of implementation. However, the resolution performance generally depends on the transmitted waveform. Moreover, its detection performance is limited by the high-level sidelobes and seriously degraded in a shallow water environment due to time spread induced by multipath propagation. This paper proposed a method named iterative deconvolution-time reversal (ID-TR), on which the energy of the cross-ambiguity function is modeled, as a convolution of the energy of the auto-ambiguity function of the transmitted signal with the generalized target reflectivity density. Similarly, the generalized target reflectivity density is a convolution of the spread function of channel with the reflectivity density of target as well. The ambiguity caused by the transmitted signal and the spread function of channel are removed by Richardson-Lucy iterative deconvolution and the time reversal processing, respectively. Moreover, this is a special case of the Richardson-Lucy algorithm that the blur function is one-dimensional and time-invariant. Therefore, the iteration deconvolution is actually implemented by the iterative temporal time reversal processing. Due to the iterative time reversal method can focus more and more energy on the strongest target with the iterative number increasing and then the peak-signal power increases, the simulated result shows that the noise reduction can achieve 250 dB in the “ideal” free field environment and 100 dB in a strong multipaths waveguide environment if a 1-ms linear frequency modulation with a 4-kHz frequency bandwidth is transmitted and the number of iteration is 10. Moreover, the range resolution is approximately a delta function. The results of the experiment in a tank show that the noise level is suppressed by more than 70 dB and the reverberation level is suppressed by 3 dB in the case of a single target and the iteration number being 8. Full article

In computed tomography (CT), artifacts due to patient rigid motion often significantly degrade image quality. This paper suggests a method based on iterative blind deconvolution to eliminate motion artifacts. The proposed method alternately reconstructs the image and reduces motion artifacts in an iterative scheme until the difference measure between two successive iterations is smaller than a threshold. In this iterative process, Richardson–Lucy (RL) deconvolution with spatially adaptive total variation (SATV) regularization is inserted into the iterative process of the ordered subsets expectation maximization (OSEM) reconstruction algorithm. The proposed method is evaluated on a numerical phantom, a head phantom, and patient scan. The reconstructed images indicate that the proposed method can reduce motion artifacts and provide high-quality images. Quantitative evaluations also show the proposed method yielded an appreciable improvement on all metrics, reducing root-mean-square error (RMSE) by about 30% and increasing Pearson correlation coefficient (CC) and mean structural similarity (MSSIM) by about 15% and 20%, respectively, compared to the RL-OSEM method. Furthermore, the proposed method only needs measured raw data and no additional measurements are needed. Compared with the previous work, it can be applied to any scanning mode and can realize six degrees of freedom motion artifact reduction, so the artifact reduction effect is better in clinical experiments. Full article
