Existing methods for selecting the number of teeth in complex planetary gear systems are often methodologically demanding. They do not always ensure all conditions required for proper operation and assembly. This paper presents an analytical methodology for determining gear tooth numbers. The method is demonstrated on a Ravigneaux planetary gear set with seven kinematic links and two degrees of freedom. It ensures the simultaneous satisfaction of all meshing and assembly conditions. Starting from the known transmission ratios, the number of teeth of one central gear, and the selected angular displacement of the outer planet gear, analytical relationships are derived. These allow the determination of the tooth numbers of all remaining gear elements. The procedure is implemented in Python 3.13. This enables a systematic evaluation of predefined input ranges and an automatic verification of geometric constraints, including interference and undercutting conditions. The proposed method yields six feasible configurations. Compared with the Borg-Warner M85 automatic transmission, deviations in individual gear ratios reach up to 10%. Significantly lower tooth numbers are achieved for several gears. These results suggest that the proposed methodology can achieve comparable kinematic performance while offering more compact gear designs and a potential weight reduction. The developed model also provides a basis for extension to more complex configurations and integration with optimisation and dynamic criteria in planetary gear synthesis. Full article

Thirty-two novel hybrid transmissions consisting of a Ravigneaux gear train and a single planetary gear train are synthesized using a creative design methodology based on graph-theory and the lever analogy method. The design process commences by identifying an existing transmission configuration which meets all of the design requirements. The chosen design is then used to synthesize all possible mechanism permutations which satisfy the design constraints. The feasible mechanisms which satisfy both the design requirements and the design constraints are converted into analogous levers. The levers which fail to provide the required operation modes of the hybrid transmission are eliminated and the remaining levers are assigned brakes and clutches in order to realize the final designs. The responsiveness of the new hybrid transmissions and the feasibility of the proposed design methodology are confirmed by analyzing the power flow and kinematics of one of the designs in all of the operation modes. Full article

A highly integrated electric drivetrain module with 157 kW peak power is presented, which incorporates novel technologies in the field of electric machines, power electronics and transmissions: 1. High-speed electric machine with six phases and injection mould polymer-bonded magnets; 2. High-ratio dual-speed transmission with double planetary gear set (Ravigneaux gear set); 3. Gallium nitride (GaN) power electronics with winding reconfiguration feature.The combination of these components in one single housing makes the drive module flexible to integrate and to combine with conventional or alternative propulsion technologies, thus allowing various hybrid and electric drivetrain topologies. All technologies are selected in accordance with mass production potential and can therefore have a high impact on the automotive market in the future. Currently, the drive module is under development; the first models will be assembled in winter 2019. The integration into a demonstrator vehicle in 2020 will prove the potential of many new technologies and the suitability for the automotive market. Full article

The purpose of this research is to develop a new torque vectoring differential (TVD) for vehicle applications and investigate its effect on vehicle dynamic control. TVD is a technology that is able to distribute the engine torque to the left and right driving wheels at different ratios so that the yaw motion control can be realized. Attention has been paid to this technology in recent years because of its potential to improve the vehicle performance and driving safety. In this study, a new TVD design with a Ravigneaux gearset was developed. This new design is able to use only one pair of gearsets to generate two different speed ratios, and the weight and volume of the system can be reduced. To execute the research, current TVD designs were analyzed and their design principles were clarified. Next, a new TVD design with Ravigneaux gearset was proposed. Then the connecting manner and the gear ratio of the Ravigneaux gearset were discussed. The dynamic equation of the system was then derived and the operation of the system was simulated in a MATLAB program. Further simulation was performed with a vehicle dynamic model in SimulationX to demonstrate the effect of the new system. The results of this study show the potential of building a new TVD with a Ravigneaux gearset and can be helpful for further system development. Full article

In order to extend the product applications into plug-in hybrid electric vehicle field, a high capacity lithium-ion battery is configured and matched to the previous compound power-split hybrid transmission which is based on a modified ravigneaux gear set with two additional brake clutches. The equivalent lever diagrams are used to investigate the operating modes for the hybrid system, and its dynamic and kinematic characteristics in equations are derived. To evaluate the economy and power performance of the plug-in hybrid vehicle, a forward-looking simulation platform and components model are established. In addition, the simulating results of key power and economy tests are demonstrated. Results show that the proposed powertrain configuration can be well used for plug-in applications, and the economy and power performance can be further improved. Full article
