Search Results (24)

In this study, the global land surface albedo namely GAC43 was retrieved for the years 1979 to 2020 using Advanced Very High Resolution Radiometer (AVHRR) global area coverage (GAC) data onboard National Oceanic and Atmospheric Administration (NOAA) and Meteorological Operational (MetOp) satellites. We provide a comprehensive retrieval process of the GAC43 albedo, followed by a comprehensive assessment against in situ measurements and three widely used satellite-based albedo products, the third edition of the CM SAF cLoud, Albedo and surface RAdiation (CLARA-A3), the Copernicus Climate Change Service (C3S) albedo product, and MODIS BRDF/albedo product (MCD43). Our quantitative evaluations indicate that GAC43 demonstrates the best stability, with a linear trend of ±0.002 per decade at nearly all pseudo invariant calibration sites (PICS) from 1982 to 2020. In contrast, CLARA-A3 exhibits significant noise before the 2000s due to the limited availability of observations, while C3S shows substantial biases during the same period due to imperfect sensors intercalibrations. Extensive validation at globally distributed homogeneous sites shows that GAC43 has comparable accuracy to C3S, with an overall RMSE of approximately 0.03, but a smaller positive bias of 0.012. Comparatively, MCD43C3 shows the lowest RMSE (~0.023) and minimal bias, while CLARA-A3 displays the highest RMSE (~0.042) and bias (0.02). Furthermore, GAC43, CLARA-A3, and C3S exhibit overestimation in forests, with positive biases exceeding 0.023 and RMSEs of at least 0.028. In contrast, MCD43C3 shows negligible bias and a smaller RMSE of 0.015. For grasslands and shrublands, GAC43 and MCD43C3 demonstrate comparable estimation uncertainties of approximately 0.023, with close positive biases near 0.09, whereas C3S and CLARA-A3 exhibit higher RMSEs and biases exceeding 0.032 and 0.022, respectively. All four albedo products show significant RMSEs around 0.035 over croplands but achieve the highest estimation accuracy better than 0.020 over deserts. It is worth noting that significant biases are typically attributed to insufficient spatial representativeness of the measurement sites. Globally, GAC43 and C3S exhibit similar spatial distribution patterns across most land surface conditions, including an overestimation compared to MCD43C3 and an underestimation compared to CLARA-A3 in forested areas. In addition, GAC43, C3S, and CLARA-A3 estimate higher albedo values than MCD43C3 in low-vegetation regions, such as croplands, grasslands, savannas, and woody savannas. Besides the fact that the new GAC43 product shows the best stability covering the last 40 years, one has to consider the higher proportion of backup inversions before 2000. Overall, GAC43 offers a promising long-term and consistent albedo with good accuracy for future studies such as global climate change, energy balance, and land management policy. Full article

This study introduces a global land cover clustering using an unsupervised algorithm, incorporating the novel step of filtering data to retain only temporally stable pixels before applying K-means clustering. Unlike previous approaches that did not assess the pixel-level temporal stability, this method provides more reliable clustering results. The K-means identified 160 distinct clusters, with Cluster 13 Global Temporally Stable (Cluster 13-GTS) showing significant improvements in temporal stability. Compared to Cluster 13 Global (Cluster 13-G) from earlier research, Cluster 13-GTS reduced the coefficient of variation by up to 1% and increased the number of calibration locations from 23 to over 50. This study also validated these clusters using TOA reflectance from ground-truth measurements collected at the Radiometric Calibration Network (RadCalNet) Gobabeb (RCN-GONA) site, incorporating data from Landsat 8, Landsat 9, Sentinel-2A, and Sentinel-2B. The GONA Extended Pseudo Invariant Calibration Sites (EPICS) GONA-EPICS cluster used for the validation provided statistically comparable mean TOA reflectance to RCN-GONA, with a reduced chi-square test indicating minimal differences within the cluster’s uncertainty range. Notably, the difference in reflectance between RCN-GONA and GONA-EPICS was less than 0.023 units across all the bands. Although GONA-EPICS exhibited slightly higher uncertainty (6.4% to 10.3%) compared to RCN-GONA site (<5%), it offered advantages such as 80 potential calibration points per Landsat cycle and reduced temporal instability, and it provided alternatives to reduce the reliance on single sites like traditional PICS or RCN-GONA, making it a valuable tool for calibration efforts. These findings highlight the potential of the newly developed EPICS for radiometric calibration and stability monitoring of optical satellite sensors. Distributed across diverse regions, these global targets increase the number of calibration points available for any sensor in any orbital cycle, reducing the reliance on traditional PICS and offering more robust targets for radiometric calibration efforts. Full article

Calibrating optical sensors has become a priority to maintain data quality and ensure consistency among sensors from different agencies. Achieving and monitoring radiometric calibration often involves the identification of temporally stable targets on the Earth’s surface. Although some locations across North Africa have traditionally been used as primary targets for calibration purposes, it is crucial to explore alternative options to account for potential changes in these sites over time. This study conducted a global assessment of pixel-level temporal stability using Landsat 8 OLI data, with the primary goal of identifying regions suitable for global radiometric calibration efforts. This work followed a two-stage approach, including the testing and selection of an effective combination of statistical tests to differentiate between temporally stable and unstable pixels and the generation of a worldwide mosaic of temporally stable pixels through a per-pixel statistical analysis employing a combination of Spearman’s rho and Pettitt’s test for assessing long-term trends and detecting change points. Notably, comparing the temporal mean top-of-atmosphere (TOA) reflectance before and after applying the generated temporal filter to a site with documented unstable pixels revealed a substantial reduction in mean variation, up to 6%. In addition, slopes observed in the pre-filter mean TOA reflectance, ranging between −0.002 and −0.005, became zero or near-zero and statistically insignificant after the temporal filter was applied, demonstrating a reduction in total uncertainties by 3 to 4%. These findings evidence the potential of this work, placing it as a potential foundation in the continuous search to identify additional targets for global radiometric calibration efforts. Full article

The radiometric calibration network (RadCalNet) comprises four pseudo-invariant calibration sites (PICS): Gobabeb, Baotou, Railroad Valley Playa, and La Crau. Due to its site stability characteristics, it is widely used for sensor performance monitoring and radiometric calibration, which require high spatiotemporal stability. However, some studies have found that PICS are not invariable. Previous studies used top-of-atmosphere (TOA) data without verifying site data, which could affect the accuracy of their results. In this study, we analyzed the short- and long-term radiometric trends of RadCalNet sites using bottom-of-atmosphere (BOA) data, and verified the trends revealed by the TOA data from Landsat 7, 8, and Sentinel-2. Besides the commonly used methods (e.g., nonparametric Mann–Kendall and sequential Mann–Kendall tests), a more robust Sen’s slope method was used to estimate the magnitude of the change. We found that (1) the trends based on TOA reflectance contrasted with those based on BOA reflectance in certain cases, e.g., the reflectance trends in the red band of BOA data for La Crau in summer and autumn and Baotou were not significant, while the TOA data showed a significant downward trend; (2) the temporal trends showed statistically significant and abrupt changes in all PICS, e.g., the SWIR2 band of La Crau in winter and spring changed by 1.803% per year, and the SWIR1 band of Railroad Valley Playa changed by >0.282% per year, indicating that the real changes in sensor performance are hard to detect using these sites; (3) spatial homogeneity was verified using the coefficient of variation (CV) and Getis statistic (Gi*) for each PICS (CV < 3% and Gi* > 0). Overall, the RadCalNet remains a highly reliable tool for vicarious calibration; however, the temporal stability should be noted for radiometric performance monitoring of sensors. Full article

Historically stable areas across North Africa, known as pseudo invariant calibration sites (PICS), have been used as targets for the calibration and monitoring of optical satellite sensors. However, two major drawbacks exist for these sites: first is the dependency on a single location to be always invariant, and second is the limited amount of observation achieved using these sites. As a result, longer time periods are necessary to construct a dense dataset to assess the radiometric performance of on-orbit optical sensors and confirm that the change detected is sensor-specific rather than site-specific. This work presents a global land cover classification to obtain an extended pseudo invariant calibration site (EPICS) on a global scale using Landsat-8 Operational Land Imager (OLI) data. This technique provides multiple calibration sites across the globe, allowing for the building of richer datasets in a shorter time frame compared to the traditional approach (PICS), with the advantage of assessing the calibration and stability of the sensors faster, detecting possible changes sooner and correcting them accordingly. This work identified 23 World Reference System two (WRS-2) path/row locations around the globe as part of the global EPICS. These EPICS have the advantage of achieving multiple observations per day, with similar spectral characteristics compared to traditional PICS, while still producing a temporal coefficient of variation (ratio of temporal standard deviation and temporal mean) less than 4% for all bands, with some as low as 2.7%. Full article

The remote sensing community has extensively used Pseudo-Invariant Calibration Sites (PICS) to monitor the long-term in-flight radiometric calibration of Earth-observing satellites. The use of the PICS has an underlying assumption that these sites are invariant over time. However, the site’s temporal stability has not been assured in the past. This work evaluates the temporal stability of PICS by not only detecting the trend but also locating significant shifts (change points) lying behind the time series. A single time series was formed using the virtual constellation approach in which multiple sensors data were combined for each site to achieve denser temporal coverage and overcome the limitation of dependence related to a specific sensor. The sensors used for this work were selected based on radiometric calibration uncertainty and availability of the data: operational land imager (Landsat-8), enhanced thematic mapper (Landsat-7), moderate resolution imaging spectroradiometer (Terra and Aqua), and multispectral instrument (Sentinel-2A). An inverse variance weighting method was applied to the Top-of-Atmosphere (TOA) reflectance time series to reveal the underlying trend. The sequential Mann–Kendall test was employed upon the weighted TOA reflectance time-series recorded over 20 years to detect abrupt changes for six reflective bands. Statistically significant trends and abrupt changes have been detected for all sites, but the magnitude of the trends (maximum of 0.215% change in TOA reflectance per year) suggest that these sites are not changing substantially over time. Hence, it can be stated that despite minor changes in all evaluated PICS, they can be used for radiometric calibration of optical remote sensing sensors. The new approach provides useful results by revealing underlying trends and providing a better understanding of PICS’ stability. Full article

Satellite sensors have been extremely useful and are in massive demand in the understanding of the Earth’s surface and monitoring of changes. For quantitative analysis and acquiring consistent measurements, absolute radiometric calibration is necessary. The most common vicarious approach of radiometric calibration is cross-calibration, which helps to tie all the sensors to a common radiometric scale for consistent measurement. One of the traditional methods of cross-calibration is performed using temporally and spectrally stable pseudo-invariant calibration sites (PICS). This technique is limited by adequate cloud-free acquisitions for cross-calibration which would require a longer time to study the differences in sensor measurements. To address the limitation of traditional PICS-based approaches and to increase the cross-calibration opportunity for quickly achieving high-quality results, the approach presented here is based on using extended pseudo invariant calibration sites (EPICS) over North Africa. With the EPICS-based approach, the area of extent of the cross-calibration site covers a large portion of the North African continent. With targets this large, many sensors should image some portion of EPICS nearlydaily, allowing for evaluation of performance with much greater frequency. By using these near-daily measurements, trends of the sensor’s performance are then used to evaluate sensor-to-sensor daily cross-calibration. With the use of the proposed methodology, the dataset for cross-calibration is increased by an order of magnitude compared to traditional approaches, resulting in the differences between any two sensors being detected within a much shorter time. Using this new trend in trend cross-calibration approaches, gains were evaluated for Landsat 7/8 and Sentinel 2A/B, with the results showing that the sensors are calibrated within 2.5% (within less than 8% uncertainty) or better for all sensor pairs, which is consistent with what the traditional PICS-based approach detects. The proposed cross-calibration technique is useful to cross-calibrate any two sensors without the requirement of any coincident or near-coincident scene pairs, while still achieving results similar to traditional approaches in a short time. Full article

The objective of this paper is to find an empirical hyperspectral absolute calibration model using Libya 4 pseudo invariant calibration site (PICS). The approach involves using the Landsat 8 (L8) Operational Land Imager (OLI) as the reference radiometer and using Earth Observing One (EO-1) Hyperion, with a spectral resolution of 10 nm as a hyperspectral source. This model utilizes data from a region of interest (ROI) in an “optimal region” of 3% temporal, spatial, and spectral stability within the Libya 4 PICS. It uses an improved, simple, empirical, hyperspectral Bidirectional Reflectance Distribution function (BRDF) model accounting for four angles: solar zenith and azimuth, and view zenith and azimuth angles. This model can perform absolute calibration in 1 nm spectral resolution by predicting TOA reflectance in all existing spectral bands of the sensors. The resultant model was validated with image data acquired from satellite sensors such as Landsat 7, Sentinel 2A, and Sentinel 2B, Terra MODIS, Aqua MODIS, from their launch date to 2020. These satellite sensors differ in terms of the width of their spectral bandpass, overpass time, off-nadir viewing capabilities, spatial resolution, and temporal revisit time, etc. The result demonstrates the efficacy of the proposed model has an accuracy of the order of 3% with a precision of about 3% for the nadir viewing sensors (with view zenith angle up to 5$°$) used in the study. For the off-nadir viewing satellites with view zenith angle up to 20$°$, it can have an estimated accuracy of 6% and precision of 4%. Full article

The Simultaneous Nadir Overpass (SNO) method was developed by the NOAA/NESDIS to improve the consistency and quality of climate data acquired by different meteorological satellites. Taking advantage of the reduced impact induced by the Bidirectional Reflectance Distribution Function (BRDF), atmospheric effects, illumination and viewing geometries during an SNO, we created a sensor comparison methodology for all spectral targets. The method is illustrated by applying it to the assessment of data acquired by the Landsat 8 (L8), Sentinel-2A (S2A), and Sentinel-2B (S2B) optical sensors. Multiple SNOs were identified and selected without the need for orbit propagators. Then, by locating spatially homogeneous areas, it was possible to assess, for a wide range of Top-of-Atmosphere reflectance values, the relationship between the L8 bands and the corresponding ones of S2A and S2B. The results yield high coefficients of determination for S2 A/B with respect to L8. All are higher than 0.980 for S2A and 0.984 for S2B. If the S2 band 8 (wide near-infrared, NIR) is excluded then the lowest coefficients of determination become 0.997 and 0.999 from S2A and S2B, respectively. This methodology can be complementary to those based on Pseudo-Invariant Calibration Sites (PICS) due to its simplicity, highly correlated results and the wide range of compared reflectances and spectral targets. Full article

Pseudo-invariant calibration sites (PICS) have been used for the radiometric calibration and stability monitoring of satellite optical sensors. Several stable PICS, such as those in the Sahara Desert in North Africa, were selected for the vicarious calibration of earth remote sensing satellites. However, the selection procedure of PICSs in the whole of Northwest China has not been fully explored before. This paper presents a novel technique for selecting PICS in Northwest China by combined using the coefficient of variation (CV) and the iteratively reweighted multivariate alteration detection (IR-MAD) technique. IR-MAD, which calculates the differences between two multispectral N-band images from the same scene acquired at different times, is used to identify no-change pixels (NCPs) of the scene through one image pair. The NCPs from IR-MAD using the long-term data of FY-3 visible infrared radiometer (VIRR) and aqua Moderate Resolution Imaging Spectroradiometer (MODIS) were aggregated into the contiguously stable sites. The traditional spatial uniformity and temporal stability from MODIS surface products were used to select the potential PICS. By combining the results of both methods, over thirty PICSs with a wider brightness range of the scene types were selected. To confirm and characterize these PICSs over Northwest China, Landsat operational land imager (OLI) high-spatial-resolution images were used to check the spatial uniformity of the selected site to determine the specific location and the size of these sites. Additionally, the surface spectral reflectance and bidirectional reflectance distribution function (BRDF) were obtained from the field campaign at Chaidamu Basin, 2018. To demonstrate the practical utilization and usability of these PICSs, they were employed in the multi-site top of atmosphere (TOA) reflectance simulation to validate the operational calibration performance of Aqua/MODIS and FY-3D/MERSI-II (Medium Resolution Spectral Imager II). The simulation results showed good consistency compared with the observations from both MODIS and MERSI-II, with a relative bias and root mean square error (RMSE) of <5% and <0.05%, respectively. These sites provide prospects for multi-site vicarious calibrations of solar reflective bands, which may help to evaluate or characterize instrumental nonlinear responses using a wider signal dynamic from the sites in different seasons. Full article

One of the biggest changes in the world of optical remote sensing over the last several years is the sheer increase in the number of sensors that are imaging the Earth in moderate to high spatial resolution. With respect to the calibration of these sensors, they are broadly classified into two types, namely government systems and commercial systems. Because of the differences in the design and mission of these sensor types, calibration approaches are often substantially different. Thus, an opportunity exists to foster discussion between calibration teams for these sensors with the goal of improving overall sensor calibration and data interoperability. The approach used to accomplish this task was a one-day workshop where team members from both government and commercial sensors could share best practices, discuss methods for collaboration and improvement, and make recommendations for continuing activities. Five major recommendations were developed from the event that focused on coordinated activities using pseudo invariant calibration sites (PICS), broader and more consistent communication, collaboration on specific cross-calibration opportunities, developing a reference sensor for all optical systems, and encouraging the coordinated development of surface reflectance products. Workshop participants concluded that regular interactions between these teams could foster a better calibration of all sensor systems and accelerate the improved interoperability of surface products. Full article

In recent years, Korea has sustained consistent access to remote sensed data by launching Korea Multi-Purpose Satellite-3A (KOMPSAT-3A, K3A)—an updated version of the high-resolution KOMPSAT series. This KOMPSAT-3A required calibration and validation (Cal/Val) before and after its launch to enable proper functional characterization and to maintain the veracity of data collected. The Korea Aerospace Research Institute (KARI) executed the initial prelaunch calibration in the laboratory and we performed the Cal/Val of KOMPSAT-3A during the Launch and Early Operation Phase (LEOP) in the field. Two suitable sites in Korea and Mongolia with stable weather, almost uniform terrain, and near Lambertian diffusion, provided the necessary tarp reflectance to calculate the absolute radiometric calibration coefficients. The surface reflectance was determined using 12 and four well-calibrated reference reflectance tarps employing the FieldSpec^® 3(Analytical Spectral Devices Inc., Boulder, CO, USA) Spectroradiometer. Subsequently, the top of atmosphere (TOA) radiance was estimated using radiative transfer code (RTC) software based on the Atmospheric and Topographic Correction (ATCOR). In addition, cross calibration was simultaneously performed at the Libya-4 pseudo invariant calibration site (PICS) for KOMPSAT-3A TOA radiance, using the spectral band adjustment factor (SBAF) compensated Landsat 8 reflectance and the Second Simulation of Satellite Signal in the Solar Spectrum (6S) to compute cross calibration coefficients. The results of the KOMPSAT-3A absolute calibration coefficient show that the R² values were over 0.99, implying a significant correlation for almost all bands between the TOA radiance and the KOMPSAT-3A spectral band response at both campaign sites. However, this study reveals a difference of less than 5% calibration gains for all bands compared to the prelaunch values, while the cross calibration gain is below 5% in visible bands and above 5% in the near infrared band. An effort to optimize the reliability of the absolute calibration coefficients resorted to the rigorous quantification of uncertainties amongst atmospheric conditions, the digital number (DN), the reflectance tarp, the bidirectional reflectance distribution function (BRDF), and ozone levels. Therefore, we presumed that the total uncertainty was 4.27%, which conforms to some published results. Full article

Pseudo-Invariant Calibration Sites (PICS) have been widely used by the remote sensing community in recent decades for post-launch absolute calibration, cross-calibration, and the monitoring of radiometric stability. The Committee on Earth Observation Satellites (CEOS) has established several official PICS for these purposes. Of these, Libya-4 is the most commonly used, due to its high uniformity and stability. The site was chosen as a large-area site for medium resolution sensors, and with high-resolution sensors now common, smaller sites are being identified. This work has identified an improved area of interest (AOI) within Libya-4 by using combined Landsat 8 and Sentinel 2 data. The Optimized Ground Target (OGT) was determined by calculating the coefficient of variation along with the use of a quasi-Newton optimization algorithm combined with the Basin–Hopping global optimization technique to constrain a search area small enough to perform a final brute-force refinement. The Coefficient of Variation CV of the proposed OGT is significantly lower than that in the original CEOS area, with differences between the CV of both zones in the order of 1% in the visible near-infrared (VNIR) bands. This new AOI has the potential to improve the cross-calibration between high-resolution sensors using the PICS methodology through an OGT with more homogeneous and stable characteristics. Full article

The characterization of sands detailed in this paper has been performed in order to support the in-flight radiometric performance assessment of space-borne optical sensors over the so-called Pseudo-Invariant Calibration Sites (PICS). Although the physical properties of PICS surface are fairly stable in time, the signal measured from space varies with the illumination and the viewing geometries. Thus, there is a need to characterize the spectro-directional properties of PICS. This could be done on a broad scale, thanks to multi-spectral multi-directional space-borne sensors such as the POLDER instrument (with old data). However, interpolating or extrapolating the spectro-directional reflectance measured from space to spectral bands of another sensor is not straightforward. The hyperspectral characterization of sand samples collected within or nearby PICS could contribute to a solution. In this context, a set of 31 sand samples was compiled. The BiConical Reflectance Factor (BCRF), linked to Bidirectional Reflectance Distribution Function (BRDF), was measured between 0.4 and 2.5 µm, over a half hemisphere when the amount of sand in the sample was large enough and for only a single fixed angular configuration for small samples. These optical measurements were complemented by grain size distribution measurements and mineralogical analysis and compiled together with previously published measurements in the so-called PICSAND database, freely available online. Full article

Reference of Earth-observing satellite sensor data to a common, consistent radiometric scale is an increasingly critical issue as more of these sensors are launched; such consistency can be achieved through radiometric cross-calibration of the sensors. A common cross-calibration approach uses a small set of regions of interest (ROIs) in established Pseudo-Invariant Calibration Sites (PICS) mainly located throughout North Africa. The number of available cloud-free coincident scene pairs available for these regions limits the usefulness of this approach; furthermore, the temporal stability of most regions throughout North Africa is not known, and limited hyperspectral information exists for these regions. As a result, it takes more time to construct an appropriate cross-calibration dataset. In a previous work, Shrestha et al. presented an analysis identifying 19 distinct “clusters” of spectrally similar surface cover that are widely distributed across North Africa, with the potential to provide near-daily cloud-free imaging for most sensors. This paper proposes a technique to generate a representative hyperspectral profile for these clusters. The technique was used to generate the profile for the cluster containing the largest number of aggregated pixels. The resulting profile was found to have temporal uncertainties within 5% across all the spectral regions. Overall, this technique shows great potential for generation of representative hyperspectral profiles for any North African cluster, which could allow the use of the entire North Africa Saharan region as an extended PICS (EPICS) dataset for sensor cross-calibration. This should result in the increased temporal resolution of cross-calibration datasets and should help to achieve a cross-calibration quality similar to that of individual PICS in a significantly shorter time interval. It also facilitates the development of an EPICS based absolute calibration model, which can improve the accuracy and consistency in simulating any sensor’s top of atmosphere (TOA) reflectance. Full article
