Search Results (12)

Distributed renewable energy sources with significant output fluctuations can negatively impact the power grid stability when it is connected to the power grid. Therefore, it is necessary to develop a capacity configuration method that improves the output stability of highly uncertain energy sources such as wind and photovoltaic (PV) power by integrating pumped storage units. In response, this study proposes a capacity configuration method for a cascade small hydropower-pumped storage–wind–PV complementary system. The method utilizes the regulation capacity of cascade small hydropower plants and pumped storage units, in conjunction with the fluctuating characteristics of local distributed wind and PV, to perform power and energy time-series matching and determine the optimal capacity allocation for each type of renewable energy. Furthermore, an optimization and scheduling model for the cascade small hydropower-pumped storage–wind–PV complementary system is constructed to verify the effectiveness of the configuration under multiple scenarios. The results demonstrate that the proposed method reduces system energy deviation, improves the stability of power output and generation efficiency, and enhances the operational stability and economic performance of the system. Full article

This paper conducts an in-depth study on the application of inductor-capacitor-inductor (LCL) filters in grid-connected photovoltaic (PV) inverters. First, the resonance issues associated with LCL filters are analyzed, and solutions are discussed, with a focus on the implementation of passive damping strategies. Various passive damping schemes, based on the placement of resistors (R), are compared and analyzed, ultimately selecting the capacitor branch series resistor as the optimal solution. During the design process, multiple parameters, such as total inductance, inverter-side inductance, grid-side inductance, capacitance, and damping resistors, are considered in light of their mutual constraints. Detailed analysis and optimization of these parameters are performed based on steady-state operation, current ripple, and power loss limitations. Finally, it is concluded that the passive damping solution using a series resistor in the capacitor branch meets the requirements for stable operation and efficient filtering. The optimal solutions are identified as R₁ = 0, R₂ = ∞, R₃ ≠ 0, and R₄ = ∞, providing a reliable and effective filtering solution for grid-connected PV inverter systems. Full article

Photovoltaic (PV) arrays are often affected by partial shading (PS), which can significantly reduce their power output. Dynamic reconfiguration is a promising technique for mitigating the negative effects of PS by adjusting the electrical connections of the PV modules in real-time. This paper introduces a hierarchical-based switching block scheme for the dynamic reconfiguration of PV arrays under PS conditions. With the aim of mitigating the negative impact of PS on PV arrays, the proposed system employs a low complexity and easily scalable architecture, making it well-suited for practical applications. Comparative assessments against conventional configurations such as bridge-linked (BL), total-cross-tied (TCT), and series–parallel (SP) reveal superior energy harvesting efficiency for the proposed system under various shading conditions. The hierarchical switching block architecture, featuring multiple levels of switching blocks, enables efficient and flexible reconfiguration of the PV array, even in the presence of complex shading patterns. Through extensive simulations, the system consistently outperforms conventional configurations by adapting effectively to changing shading patterns and optimizing the PV array’s output. The proposed switching block (SB) reconfiguration technique significantly outperforms existing methods like TCT, Sudoku, dynamic proposals, and Magic Square in terms of both power generation (up to 42.52% increase) and efficiency (up to 42.13% improvement) under diverse partial shading conditions. The proposed hierarchical-based switching block scheme thus presents a promising solution for enhancing the dynamic reconfiguration of PV arrays under PS conditions, offering a balance between low complexity, scalability, and superior energy harvesting efficiency for practical applications in the realm of solar energy. Full article

In this paper, we propose a photovoltaic emulator (PVE) composed of a series of connected power diodes with a single constant current source, rather than a power converter-based PVE. Accordingly, this enables readily verifying the operation because a the simple hardware structure and lack of a complex control algorithm. The proposed PVE can be intuitively implemented using the proposed selection criteria for the power diode and equivalent resistances. Since there is no feedback control based on complex analog/digital controls and sensors, the control response can be very fast. In addition, the proposed PVE can be easily integrated with a PV power system such as a power optimizer, to allow testing in a simple and flexible manner. Spice simulation was performed based on the electrical characteristics provided by the solar panel manufacturer, and this was utilized to validate the applied emulator circuit model, the Norton Equivalent Circuit. During the design process, the simulation helped to manufacture the PVE within error ranges satisfying the desired I–V and P–V curves, as well as the maximum power point (MPP). Partial shading could be easily implemented through use of the multiple series connection of individual PVEs, demonstrating local MPP and global MPP. A 400 W class PVE was built through appropriate power diode selection, with a thermal design to increase the output power. Moreover, its performance and feasibility were verified through intensive experiments. The measured efficiency, transient response time, and maximum transient error of the partial shading tests were 91%, 22 μs, and 5.8%, respectively. Full article

In recent years, to increase the fuel efficiency of environment-friendly vehicles, a large volume of research is ongoing regarding applying photovoltaic (PV) systems. However, in PV systems, a power imbalance between submodules is common due to shading or pollution, and this degrades the power generation efficiency of the system. To solve this problem, various differential power processing (DPP) converters have been developed. In order to adopt the DPP converter to environment-friendly vehicles, the DPP converter must have a small volume, high efficiency, and high price competitiveness. In this regard, we propose a DPP converter with a single multi-winding transformer by integrating multiple transformers and secondary sides of the conventional flyback DPP converter. Since the proposed DPP converter can be applied to battery balancing circuits as well as photovoltaic systems, the proposed circuit is a valuable converter. In the PV system, the maximum output power of each submodule is 60 W, and the total PV system is 240 W by connecting four submodules in series. To verify the validity of the proposed DPP converter, a prototype with 8 V input and 60 W/30 V output specification was built and tested, and the effectiveness of the proposed converter is supported by the experimental results. Full article

The photovoltaic (PV) system center inverter architecture comprises various conventional array topologies such as simple-series (S-S), parallel (P), series-parallel (S-P), total-cross-tied (T-C-T), bridge-linked (B-L), and honey-comb (H-C). The conventional PV array topologies under non-uniform operating conditions (NUOCs) produce a higher amount of mismatching power loss and represent multiple maximum-power-points (M-P-Ps) in the output characteristics. The performance of T-C-T topology is found superior among the conventional topologies under NUOCs. However, T-C-T topology’s main limitations are higher redundancy, more number of electrical connections, higher cabling loss, poor performance during row-wise shading patterns, and more number of switches and sensors for the re-configuration of PV modules. This paper proposes the various optimal hybrid PV array topologies to overcome the limitations of conventional T-C-T array topology. The proposed hybrid topologies are such as series-parallel-cross-tied (S-P-C-T), bridge-link-cross-tied (B-L-C-T), honey-comb-cross-tied (H-C-C-T), series-parallel-total-cross-tied (S-P-T-C-T), bridge-link-total-cross-tied (B-L-T-C-T), honey-comb-total-cross-tied (H-C-T-C-T), and bridge-link-honey-comb (B-L-H-C). The proposed hybrid topologies performance is evaluated and compared with the conventional topologies under various NUOCs. The parameters used for the comparative study are open-circuit voltage, short-circuit current, global-maximum-power-point (GMPP), local-maximum-power-point (LMPP), number of LMPPs, and fill factor (FF). Furthermore, the mismatched power loss and the conversion efficiency of conventional and hybrid array topologies are also determined. Based on the results, it is found that the hybrid array topologies maximize the power output by mitigating the effect of NUOCs and reducing the number of LMPPs. Full article

Vegetation phenology is an integrative indicator of environmental change, and remotely–sensed data provide a powerful way to monitor land surface vegetation responses to climatic fluctuations across various spatiotemporal scales. In this study, we synthesize the local climate, mainly temperature and precipitation, and large-scale atmospheric anomalies, El Niño-Southern Oscillation (ENSO)-connected dynamics, on a vegetative surface in a subtropical mountainous island, the northwest Pacific of Taiwan. We used two decadal photosynthetically active vegetation cover (PV) data (2001–2020) from Moderate Resolution Imaging Spectroradiometer (MODIS) reflectance data to portray vegetation dynamics at monthly, seasonal, and annual scales. Results show that PV is positively related to both temperature and precipitation at a monthly timescale across various land cover types, and the log-linear with one-month lagged of precipitation reveals the accumulation of seasonal rainfall having a significant effect on vegetation growth. Using TIMESAT, three annual phenological metrics, SOS (start of growing season), EOS (end of growing season), and LOS (length of growing season), have been derived from PV time series and been related to seasonal rainfall. The delayed SOS was manifestly influenced by a spring drought, <40 mm during February–March. The later SOS led to a ramification on following late EOS, shorter LOS, and reduction of annual NPP. Nevertheless, the summer rainfall (August–October) and EOS had no significant effects on vegetation growth owing to abundant rainfall. Therefore, the SOS associated with spring rainfall, instead of EOS, played an advantageous role in regulating vegetation development in this subtropical island. The PCA (principal component analysis) was applied for PV time series and explored the spatiotemporal patterns connected to local climate and climatic fluctuations for entire Taiwan, North Taiwan, and South Taiwan. The first two components, PC1 and PC2, explained most of data variance (94–95%) linked to temporal dynamics of land cover (r > 0.90) which was also regulated by local climate. While the subtle signals of PC3 and PC4 explained 0.1–0.4% of the data variance, related to regional drought (r = 0.35–0.40) especially in central and southwest Taiwan and ENSO-associated rainfall variation (r = −0.40–−0.37). Through synthesizing the relationships between vegetation dynamics and climate based on multiple timescales, there will be a comprehensive picture of vegetation growth and its cascading effects on ecosystem productivity. Full article

To satisfy the grid-connected voltage level, both photovoltaic modules and energy storage modules are connected in series. However, the multiple photovoltaic modules often fall into local maximum power point under partial shading conditions during practical operation, and the multiple energy storage modules may suffer from a reduction in the effective capacity caused by characteristic differences among modules. To solve this problem, a novel cascaded modular photovoltaic-energy storage system is proposed in this paper. In the proposed topology, the energy storage modules achieve maximum power point tracking of the corresponding distributed photovoltaic module, and the proposed energy optimization strategy based on particle swarm optimization can ensure the efficient constant active power transmission from a photovoltaic energy storage (PV/ES) system to the grid in a certain time period under capacity constraints. Compared with conventional photovoltaic systems, the proposed scheme can avoid hot spots or the hot strings phenomena for PV modules and the large current and voltage stresses for DC/DC converters. Furthermore, the proposed energy optimization strategy for the coordination of all ES modules can realize the independent MPPT of each PV module and the constant active power between the PV/ES system and the grid under inconsistency of the light intensity under partial shading conditions. A hardware-in-loop photovoltaic-energy platform is established to verify the feasibility and effectiveness of the proposed topology and control strategy, and the proposed system achieves efficiency of about 97% under partial shading conditions, thus providing an effective and practical solution for power generation system. Full article

The hardware in the loop (HIL) technique allows you to reproduce the behavior of a dynamic system or part of it in real time. This quality makes HIL a useful tool in the controller validation process and is widely used in multiple areas including photovoltaic systems (PVSs). This study presents the development of an HIL system to emulate the behavior of a PVS that includes a photovoltaic panel (PVP) and a DC-DC boost converter connected in series. The emulator was embedded into an NI-myRIO development board that operates with an integration time of 10 µs and reproduces the behavior of the real system with a mean percent error of 2.0478%, compared to simulation results. The implemented emulator is proposed as a platform for the validation of control systems. With it, the experimental stage is carried out on two controllers connected to the PVS without having the real system and allowing to emulate different operating conditions. The first controller is based on the Hill Climbing algorithm for the maximum power point tracking (MPPT), the second is a proportional integral (PI) controller for voltage control. Both controllers generate settling times of less than 3 s; the MPPT controller generates variations in the output in steady state inherent to the algorithm used. For both cases, the comparison of the experimental results with those obtained through software simulation show that the platform fulfills its usefulness when evaluating control systems. Full article

Herein we discuss polymer electrolyte membrane (PEM) electrolysis stacks and systems we developed that are optimized for direct coupling to a photovoltaic (PV) panel. One advantage of PEM systems is their use of non-corrosive and non-toxic media. Thus, safe outdoor operation can be guaranteed, even in the case of a leakage. The system design was adapted to reduce the number of connection tubes, allowing for a series connection of multiple stacks at low cost and high reliability. One coupled PEM/PV system was tested under various temperature and irradiance conditions. All system components were also thoroughly characterized. The characterization was used to calibrate simple models of the individual components. Finally, the models were used to predict the system’s solar-to-hydrogen efficiency under different operating conditions and to find an optimal configuration for real-world outdoor operation. Full article

Partial shading on photovoltaic (PV) strings consisting of multiple panels connected in series is known to trigger severe issues, such as reduced energy yield and the occurrence of multiple power point maxima. Various kinds of differential power processing (DPP) converters have been proposed and developed to prevent partial shading issues. Voltage stresses of switches and capacitors in conventional DPP converters, however, are prone to soar with the number of panels connected in series, likely resulting in impaired converter performance and increased circuit volume. This paper proposes a DPP converter using an LLC resonant voltage multiplier (VM) with a voltage divider (VD) to reduce voltage stresses of switches and capacitors. The VD can be arbitrarily extended by adding switches and capacitors, and the voltage stresses can be further reduced by extending the VD. Experimental verification tests for four PV panels connected in series were performed emulating partial shading conditions in a laboratory and outdoor. The results demonstrated the proposed DPP converter successfully precluded the negative impacts of partial shading with mitigating the voltage stress issues. Full article

A recent approach to mitigate the adverse effects of photovoltaic (PV) arrays operating under mismatching conditions is the dynamic electrical reconfiguration of the PV panels. This paper introduces a procedure to determine the best configuration of a PV array connected in a series-parallel structure without using complex mathematical models. Such a procedure uses the experimental current vs. voltage curves of the PV panels, which are composed of multiple PV modules, to construct the power vs. voltage curves of all of the possible configurations to identify the optimal one. The main advantage of this method is the low computational effort required to reconstruct the power vs. voltage curves of the array. This characteristic enables one to implement the proposed solution using inexpensive embedded devices, which are widely adopted in industrial applications. The proposed method, and its embedded implementation, were tested using a hardware-in-the-loop simulation of the PV system. Finally, the real-time operation and benefits of the proposed solution are illustrated using a practical example based on commercial devices. Full article
