Search Results (9)

In this paper, we experimentally investigated the excitation of spoof surface plasmon polaritons (SSPPs) supported by a 1D subwavelength grating with a rectangular profile in the terahertz (THz) frequency range. Using the attenuated total reflection technique and the THz radiation of the Novosibirsk free electron laser, we carried out detailed studies of both angular and gap spectra at several wavelengths. A shallow grating supporting a fundamental mode was fabricated by means of multibeam X-ray lithography and used as a test sample. The results indicated that we achieved 1-THz tunability of resonance in the frequency range from 1.51 to 2.54 THz on a single grating, which cannot be obtained with active tunable metamaterials. The Q factors of the resonances in the angular spectra were within the range of 19.4–37.6, while the resonances of the gap spectra had a Q factor lying within the 1.17–2.03 range. The gap adjustment capability of the setup shown in the work has great potential in modulation of the absorption efficiency, whereas the angular tuning and recording data from each point of the grating will enable real-time monitoring of changes in the surrounding medium. All of this is highly important for enhanced terahertz real-time absorption spectroscopy and imaging. Full article

In this paper, we theoretically investigated the low-threshold and controllable optical bistability (OB) of a graphene-based Otto configuration with a nonlinear three-dimensional Dirac semimetal (3D DSM) as the substrate. The combined effect of the excitation of surface plasmon polaritons (SPPs) in graphene and the very high third-order nonlinear conductivity of the 3D DSM enabled this scheme to achieve a relatively low optical bistability threshold. At the same time, this simple multilayer structure showed the tunability of OB due to the fact that the reflectance could be modulated by regulating the Fermi energy of the 3D DSM. Furthermore, we also found that the OB hysteresis curve was closely related to the relaxation time of the 3D DSM and the thickness of the air layer. We believe that this multilayer configuration could provide a reference idea for devising a bistable device. Full article

We have demonstrated the wide-field amplitude surface plasmon resonance (SPR) microscopy technique in the terahertz (THz) range. A Zeonex polymer prism was utilized to excite surface plasmon polaritons (SPPs) through attenuated total reflection (ATR) in an Otto configuration. Coherent quasimonochromatic radiation with a wavelength of approximately 197 μm, generated by the Novosibirsk free electron laser, was employed. Our results indicate that the SPR microscopy method is applicable for investigating the planar surfaces of semiconductors at THz frequencies, provided that the SPPs’ cutoff frequency is close to the probing radiation frequency. This condition ensures that the propagation length of the SPPs is comparable to the radiation wavelength. By varying the air gap between the prism and the surface under examination, we acquired images of a polypropylene coating 20 µm thick and a graphene coating 35 nm thick on a flat indium antimonide substrate. The boundary between the coated and uncoated regions can be precisely localized through determination of the kink in the reflection coefficient of the THz radiation beam that illuminates the boundary between the regions if the optimal conditions for the generation of the SPPs in the uncoated region are met. Full article

Highly sensitive detection of enhanced terahertz (THz) fingerprint absorption spectrum of trace-amount tiny molecules is essential for biosensing. THz surface plasmon resonance (SPR) sensors based on Otto prism-coupled attenuated total reflection (OPC-ATR) configuration have been recognized as a promising technology in biomedical detection applications. However, THz-SPR sensors based on the traditional OPC-ATR configuration have long been associated with low sensitivity, poor tunability, low refractive index resolution, large sample consumption, and lack of fingerprint analysis. Here, we propose an enhanced tunable high-sensitivity and trace-amount THz-SPR biosensor based on a composite periodic groove structure (CPGS). The elaborate geometric design of the spoof surface plasmon polaritons (SSPPs) metasurface increases the number of electromagnetic hot spots on the surface of the CPGS, improves the near-field enhancement effect of SSPPs, and enhances the interaction between THz wave and the sample. The results show that the sensitivity (S), figure of merit (FOM) and Q-factor (Q) can be increased to 6.55 THz/RIU, 4234.06 1/RIU and 629.28, respectively, when the refractive index range of the sample to measure is between 1 and 1.05 with the resolution $1.54\times {10}^{-5}$ RIU. Moreover, by making use of the high structural tunability of CPGS, the best sensitivity (SPR frequency shift) can be obtained when the resonant frequency of the metamaterial approaches the biological molecule oscillation. These advantages make CPGS a strong candidate for the high-sensitivity detection of trace-amount biochemical samples. Full article

The conventional approach to optimising plasmonic sensors is typically based entirely on ensuring phase matching between the excitation wave and the surface plasmon supported by the metallic structure. However, this leads to suboptimal performance, even in the simplest sensor configuration based on the Otto geometry. We present a simplified coupled mode theory approach for evaluating and optimizing the sensing properties of plasmonic waveguide refractive index sensors. It only requires the calculation of propagation constants, without the need for calculating mode overlap integrals. We apply our method by evaluating the wavelength-, device length- and refractive index-dependent transmission spectra for an example silicon-on-insulator-based sensor of finite length. This reveals all salient spectral features which are consistent with full-field finite element calculations. This work provides a rapid and convenient framework for designing dielectric-plasmonic sensor prototypes—its applicability to the case of fibre plasmonic sensors is also discussed. Full article

In this study, an electrostatically driven vertical MEMS actuator was designed using a hollow square electrode. To attain vertical actuation, a hollow square-shaped electrode was designed on the glass substrate. The silicon proof mass, containing a step, was utilized to realize analogue actuation without pull-in. The vertical MEMS actuator was fabricated using the SiOG (Silicon on Glass) process and the total actuator size was 8.3 mm × 8.3 mm. The fabricated proof mass was freestanding due to eight serpentine springs with 30 μm width. The vertical movement of the MEMS actuator was successfully controlled electrostatically. The measured vertical movement was 5.6 µm for a voltage of 40 V, applied between the top silicon structure and the hollow square electrode. The results shown here confirm that the proposed MEMS actuator was able to control the vertical displacement using an applied voltage. Full article

In this study, a micromachined chip in Otto configuration with multiple air-gaps (1.86 μm, 2.42 μm, 3.01 μm, 3.43 μm) was fabricated, and the resonance characteristics for each air-gap was measured with a 980 nm laser source. To verify the variability of the reflectance characteristics of the Otto configuration and its applicability to multiple gas detection, the air-gap between the prism and metal film was adjusted by using a commercial piezoactuator. We experimentally verified that the SPR characteristics of the Otto chip configuration have a dependence on the air-gap distance and wavelength of the incident light. When a light source having a wavelength of 977 nm is used, the minimum reflectance becomes 0.22 when the displacement of the piezoactuator is about 9.3 μm. Full article

The mobility industry has experienced a fast evolution towards electric-based transport in recent years. Recently, hybrid electric vehicles, which combine electric and conventional combustion systems, have become the most popular alternative by far. This is due to longer autonomy and more extended refueling networks in comparison with the recharging points system, which is still quite limited in some countries. This paper aims to conduct a literature review on thermodynamic models of heat engines used in hybrid electric vehicles and their respective configurations for series, parallel and mixed powertrain. It will discuss the most important models of thermal energy in combustion engines such as the Otto, Atkinson and Miller cycles which are widely used in commercial hybrid electric vehicle models. In short, this work aims at serving as an illustrative but descriptive document, which may be valuable for multiple research and academic purposes. Full article

Liquefied natural gas began to attract attention as a ship fuel to reduce environmental pollution and increase energy efficiency. During this period, highly efficient internal combustion engines emerged as the new propulsion system instead of steam turbines. However, Otto-cycle engines must use fuel that meets the methane number that was given by the engine makers. The purpose of this study was to develop a system configuration and a control method of methane number adjustment using combined cascade/feed-forward controllers for marine Otto-cycle engines to improve reference tracking and the disturbance rejection. The main principle involves controlling the downstream gas temperature of the fuel gas supply system to meet the required methane number. Three controllers are used in the combined cascade/feed-forward control for adjusting the downstream of the gas temperature: the cascade loop has two controllers and the feed-forward has one controller. The two controllers in the cascade loop are designed with proportional–integral (PI) controllers. The remaining controller is based on feed-forward control theory. A simulation was conducted to verify the efficacy of the proposed method, focusing on the disturbance rejection and set-point tracking, in comparison with a single PI controller, a single PI controller with feed-forward, and cascade control. Full article
