Search Results (19)

Water vapor is an active trace component in the troposphere and has a significant impact on meteorology and the atmospheric environment. In order to meet demands for high-precision water vapor and aerosol observations for numerical weather prediction (NWP), the China Meteorological Administration (CMA) deployed 49 Raman aerosol lidar systems and established the first Raman–Mie scattering lidar network in China (CARLNET) for routine measurements. In this paper, we focus on the water vapor measurement capabilities of the CARLNET. The uncertainty of the water vapor Raman channel calibration coefficient (Cw) is determined using an error propagation formula. The theoretical relationship between the uncertainty of the calibration coefficient and the water vapor mixing ratio (WVMR) is constructed based on least squares fitting. Based on the distribution of lidar in regions with different humidity conditions, the method of real-time calibration and quality control based on radiosonde data is established for the first time. Based on the uncertainty requirements of the World Meteorological Organization for water vapor in data assimilation, the calibration and quality control thresholds of the WVMR in regions with different humidity conditions are determined by fitting real-time lidar and radiosonde data. Lastly, based on the radiosonde results, the calibration algorithm established in this study is used to calibrate CARLNET data from October to December 2023. Compared with traditional calibration results, the results show that the stability and detection accuracy of the CARLNET significantly improved after calibration in regions with different humidity conditions. The deviation of the Cw decreased from 12.84~18.47% to 5.41~11.54%. The inversion error of the WVMR compared to radiosonde decreased from 1.05~0.46 g/kg to 0.82~0.34 g/kg. The reliability of the improved calibration algorithm and the CARLNET’s performance have been verified, enabling them to provide high-precision water vapor products for NWP. Full article

This study aims to achieve the classification of the cirrus clouds over the Observatory of Haute-Provence (OHP) in France. Rayleigh–Mie–Raman lidar measurements, in conjunction with the ERA5 dataset, are analyzed to provide geometrical morphology and optical cirrus properties over the site. The method of cirrus cloud climatology presented here is based on a threefold classification scheme based on the cirrus geometrical and optical properties and their formation history. Principal component analysis (PCA) and subsequent clustering provide four morphological cirrus classes, three optical groups, and two origin-related categories. Cirrus clouds occur approximately 37% of the time, with most being single-layered (66.7%). The mean cloud optical depth (COD) is 0.39 ± 0.46, and the mean heights range around 10.8 ± 1.35 km. Thicker tropospheric cirrus are observed under higher temperature and humidity conditions than cirrus observed in the vicinity of the tropopause level. Monthly cirrus occurrences fluctuate irregularly, whereas seasonal patterns peak in spring. Concerning the mechanism of the formation, it is found that the majority of cirrus clouds are of in situ origin. The liquid-origin cirrus category consists nearly entirely of thick cirrus. Overall results suggest that in situ origin thin cirrus, located in the upper tropospheric and tropopause regions, have the most noteworthy occurrence over the site. Full article

The diel vertical variations of chlorophyll a (Chl-a) concentration are thought of primarily as an external manifestation of regulating phytoplankton’s biomass, which is essential for dynamically estimating the biogeochemical cycle in inland waters. However, information on these variations is limited due to insufficient measurements. Undersampled observations lead to delayed responses in phytoplankton assessment, impacting accurate evaluations of carbon export and water quality in dynamic inland waters. Here, we report the first lidar-observed diel vertical variations of inland Chl-a concentration. Strong agreement with r² of 0.83 and a root mean square relative difference (RMSRD) of 9.0% between the lidar-retrieved and in situ measured Chl-a concentration verified the feasibility of the Mie–fluorescence–Raman lidar (MFRL). An experiment conducted at a fixed observatory demonstrated the lidar-observed diel Chl-a concentration variations. The results showed that diel variations of Chl-a and the formation of subsurface phytoplankton layers were driven by light availability and variations in water temperature. Furthermore, the facilitation from solar radiation-regulated water temperature on the phytoplankton growth rate was revealed by the high correlation between water temperature and Chl-a concentration anomalies. Lidar technology is expected to provide new insights into continuous three-dimension observations and be of great importance in dynamic inland water ecosystems. Full article

Haze aerosols have a profound impact on air quality and pose serious health risks to the public. Due to its geographical location, Beijing experienced haze events in the spring of 2024. Lidar is an active remote sensing technology with a high spatiotemporal resolution and the ability to classify aerosols, and it is essential for effective haze monitoring. This study utilizes fluorescence–Raman–Mie polarization lidar with an emission wavelength of 355 nm, employing the ${\delta }_p$-$G_f$ method based on the particle depolarization ratio at 355 nm (${\delta }_{p355}$) and the fluorescence capacity ($G_f$), and combines meteorological data and backward-trajectory analysis to observe and classify low-altitude haze aerosols in Beijing during the spring of 2024. Notably, a mining dust event with strong fluorescence backscatter was detected. The haze aerosols were categorized into three types: pollution aerosols, desert dust, and mining dust. Their optical properties were summarized and compared. Desert dust showed a particle depolarization ratio range of 0.23–0.39 and a fluorescence capacity range from 0.18 × 10⁻⁴ to 0.63 × 10⁻⁴. Pollution aerosols had a larger fluorescence capacity but a lower depolarization ratio compared to desert dust, with a fluorescence capacity ranging from 0.55 × 10⁻⁴ to 1.10 × 10⁻⁴ and a depolarization ratio ranging from 0.10 to 0.17. Mining dust shared similar depolarization characteristics with desert dust but had a larger fluorescence capacity, ranging from 0.71 × 10⁻⁴ to 1.23 × 10⁻⁴, with a depolarization ratio range of 0.30–0.39. This study validates the effectiveness of the ${\delta }_{p355}$-$G_f$ method in classifying low-altitude haze aerosols in Beijing. Additionally, it offers a new perspective for more detailed dust classification using lidar. Furthermore, utilizing the ${\delta }_{p355}$-$G_f$ classification method and the ${\delta }_{p355}$-$G_f$ distributions of three typical aerosol samples, we developed a set of equations for the analysis of mixed aerosols. This method facilitates the separation and fraction analysis of aerosol components under various mixing scenarios. It enables the characterization of variations in the three types of haze aerosols at different altitudes and times, offering valuable insights into the interactions between desert dust, mining dust, and pollution aerosols in Beijing. Full article

This study presents the hygroscopic properties of aerosols from the Arctic free troposphere by means of contemporary lidar and radiosonde observations only. It investigates the period from the Arctic Haze in spring towards the summer season in 2021. Therefore, a one-parameter growth curve model is applied to lidar data from the Koldewey Aerosol Raman Lidar (AWIPEV in Ny-Ålesund, Svalbard) and simultaneous radiosonde measurements. Hygroscopic growth depends on different factors like aerosol diameter and chemical composition. To detangle this dependency, three trends in hygroscopicity are additionally investigated by classifying the aerosol first by its dry color ratio, and then by its season and altitude. Generally, we found a complex altitude dependence with the least hygroscopic particles in the middle of the troposphere. The most hygroscopic aerosol is located in the upper free troposphere. A hypothesis based on prior lifting of the particles is given. The expected trend with aerosol diameter is not observed, which draws attention to the complex dependence of hygroscopic growth on geographical region and altitude, and to the development of backscatter with the aerosol size itself. In a seasonal overview, two different modes of stronger or weaker hygroscopic particles are additionally observed. Furthermore, two special days are discussed using the Mie theory. They show, on the one hand, the complexity of analyzing hygroscopic growth by means of lidar data, but on the other hand, they demonstrate that it is in fact measurable with this approach. For these two case studies, we calculated that the aerosol effective radius increased from $0.16\mathsf{\mu }\mathrm{m}$ (dry) to $0.18\mathsf{\mu }\mathrm{m}$ (wet) and from $0.28\mathsf{\mu }\mathrm{m}$ to $0.32\mathsf{\mu }\mathrm{m}$ for the second case. Full article

Due to the influence of geometric factors, the temperature and humidity profile of lidar’s near-field signal was warped when sensing the air environment. In order to perform geometric factor correction on near-field signals, this article proposes different correction solutions for the Mie and Raman scattering channels. Here, the Mie scattering channel used the Raman method to invert the aerosol backscatter coefficient and correct the extinction coefficient in the transition zone. The geometric factor was the ratio of the measured signal to the forward-computed vibration Raman scattering signal. The aerosol optical characteristics were reversed using the corrected echo signal, and the US standard atmospheric model was added to the missing signal in the blind zone, reflecting the aerosol evolution process. The stability and dependability of the proposed algorithm were validated by the consistency between the visibility provided by the Environmental Protection Agency and the visibility acquired via lidar retrieval data. The near-field humidity data were supplemented by the interpolation method in the Raman scattering channel to reflect the water vapor transfer process in the temporal dimension. The measured transmittance curve of the filter, the theoretical normalized spectrum, and the sounding data were used to compute the delay geometric factor. The temperature was retrieved and the near-field signal distortion issue was resolved by applying the corrected quotient of the temperature channel. The proposed algorithm exhibited robustness and universality, enhancing the system’s detection accuracy compared to the temperature and humidity data constantly recorded by the probes in the meteorological gradient tower, which have a high correlation with the lidar observation data. The comparison between lidar data and instrument monitoring data showed that the proposed algorithm could effectively correct distorted echo signals in the transition zone, which was of great value for promoting the application of lidar in the meteorological monitoring of the urban canopy layer. Full article

To better calibrate the aerosol lidar network constructed by the China Meteorological Administration, and ensure the data quality observed by the network, the Meteorological Observation Center (China Meteorological Administration) and the University of Naples (Italy) jointly developed a “high quality 532 nm Raman aerosol lidar” (REAL lidar) in 2018. The ability to detect Raman–Mie scattering signals was improved through signal detection in a large dynamic range. This study compared the REAL lidar with the reference lidar (European ACTRIS aerosol lidar network) considering three wavelengths and eight channels. The results show that both the original signals and data products of the two radars exhibited good consistency. In the calibration application of China’s domestic lidar network, after REAL calibration, the relative average and standard deviations of the backscattering coefficient of the in-station lidar decreased from 55.4% to 7.9% and from 64% to 9.9%, respectively. The effect was significant, which indicates that REAL is an aerosol lidar with a high-performance index. The results satisfy the demand for calibration of the aerosol lidar network, and the REAL was successfully applied to the calibration of the aerosol lidar network. Full article

Characterization of aerosol transportation is important in order to understand regional and global climatic changes. To obtain accurate aerosol profiles and wind profiles, aerosol lidar and Doppler wind lidar are generally combined in atmospheric measurements. In this work, a method for calibration and quantitative aerosol properties using coherent Doppler wind lidar (CDWL) is adopted, and data retrieval is verified by contrasting the process with synchronous Rayleigh–Mie–Raman lidar (RMRL). The comparison was applied to field measurements in the Taklimakan desert, from 16 to 21 February 2023. Good agreements between the two lidars was found, with the determination coefficients of 0.90 and 0.89 and the root-mean-square error (RMSE) values of 0.012 and 0.013. The comparative results of continuous experiments demonstrate the ability of the CDWL to retrieve aerosol properties accurately. Full article

LIDAR is an atmospheric sounding instrument based on the use of high-power lasers. The use of these lasers involves fulfilling obligations with respect to air safety. In this article, we present a low-cost air traffic surveillance solution integrated into an automated operating system for the Rayleigh-Mie-Raman LIDAR of Clermont Ferrand and the statistical elements of its application over more than two years of operation from September 2019 to March 2022. Air traffic surveillance that includes the possibility of shutting off lasers is required by international regulations because LIDAR is equipped with a class four laser that presents potential dangers to aircraft flying overhead. The original system presented in this article is based on software-defined radio. ADS-B transponder frames are analyzed in real-time, and laser emission is stopped during LIDAR operation when an aircraft is detected within a 2 km radius around the LIDAR. The system was accredited in 2019 by the French air traffic authorities. Laser shutdowns due to the detection of aircraft near the Clermont Ferrand LIDAR caused a data loss rate of less than 2% during the period of application. Full article

The vertical aerosol layering of the troposphere is poorly documented in mountainous regions, particularly in the Alpine valleys, which are influenced by valley and mountain winds. To improve our knowledge of particulate matter trapped in the Annecy valley, synergetic measurements performed by a ground-based meteorological Raman lidar and a Rayleigh-Mie lidar aboard an ultralight aircraft were implemented as part of the Lacustrine-Water vApor Isotope inVentory Experiment (L-WAIVE) over Lake Annecy. These observations were complemented by satellite observations and Lagrangian modeling. The vertical profiles of aerosol optical properties (e.g., aerosol extinction coefficient (AEC), lidar ratio (LR), particle linear depolarization ratio (PDR)) are derived from lidar measurements at 355 nm during the period between 13 and 22 June 2019. The background aerosol content with an aerosol optical thickness (AOT) of 0.10 ± 0.05, corresponding to local–regional conditions influenced by anthropogenic pollution, has been characterized over the entirety of Lake Annecy thanks to the mobile ultralight payload. The aerosol optical properties are shown to be particularly variable over time in the atmospheric column, with mean LRs (PDRs) varying between 40 ± 8 and 115 ± 15 sr (2 ± 1 and 35 ± 2%). Those conditions can be disturbed by air masses that have recirculated over the valley, as well as by contributions from neighboring valleys. We have observed an important disruption in the atmospheric aerosol profiles by the arrival of an exceptionally dry air mass (RH ~ 30%), containing aerosols identified as coming from the Great Western Erg (AOT ~ 0.5, LR = 65 ± 10 sr, PDR = 20–35%) in the Sahara. These desert dust particles are shown to influence the entire atmospheric column in the Annecy valley. Such an experimental approach, coupling upward and downward lidar and spaceborne observation/Lagrangian modelling, was shown to be of significant interest for the long-term monitoring of the evolution of aerosol loads over deep valleys. It allows a better understanding of the influence of dust storms in the presence of severe convective weather processes. Full article

Seasonal and diurnal characteristics of the vertical profiles of aerosol properties are essential for detecting the regional transport and the climatic radiative effects of aerosol particles. We have studied the seasonal and diurnal characteristics of the vertical distribution of aerosols in urban Beijing from 2017 to 2021 based on long-term Raman–Mie LiDAR observations. The influence of the vertical distribution of aerosols, the meteorological conditions within the boundary layer, the optical–radiometric properties of aerosols, and their interconnections, were investigated during a heavy haze pollution event in Beijing from 8 to 15 February 2020 using both meteorological and sun photometer data. The aerosol extinction coefficient was highest in summer (0.4 km⁻¹), followed by winter (0.35 km⁻¹), and roughly equal in spring and autumn (0.3 km⁻¹). The aerosol extinction coefficient showed clear daily variations and was different in different seasons as a result of the variation in the height of the boundary layer. During the haze pollution event, the particulate matter mainly consisted of scattered spherical fine particles and the accumulation time of pollutants measured via the AOD_440nm and PM_2.5 mass concentration was different as a result of the hygroscopic growth of the aerosol particles. This growth increased scattering and led to an increase in the aerosol optical depth. The vertical transport of particulate matter also contributed to the increase in the aerosol optical depth. Full article

Lidar plays an essential role in monitoring the vertical variation of atmospheric aerosols. However, due to the limited information that lidar measurements provide, ill-posedness still remains a big challenge in quantitative lidar remote sensing. In this study, we describe the Basic algOrithm for REtrieval of Aerosol with Lidar (BOREAL), which is based on maximum likelihood estimation (MLE), and retrieve aerosol microphysical properties from extinction and backscattering measurements of multi-wavelength Mie–Raman lidar systems. The algorithm utilizes different types of a priori constraints to better constrain the solution space and suppress the influence of the ill-posedness. Sensitivity test demonstrates that BOREAL could retrieve particle volume size distribution (VSD), total volume concentration (V_t), effective radius (R_eff), and complex refractive index (CRI = n − ik) of simulated aerosol models with satisfying accuracy. The application of the algorithm to real aerosol events measured by LIlle Lidar AtmosphereS (LILAS) shows it is able to realize fast and reliable retrievals of different aerosol scenarios (dust, aged-transported smoke, and urban aerosols) with almost uniform and simple pre-settings. Furthermore, the algorithmic principle allows BOREAL to incorporate measurements with different and non-linearly related errors to the retrieved parameters, which makes it a flexible and generalized algorithm for lidar retrieval. Full article

Lidar networks are essential to study the three-dimensional distribution of aerosols on a regional scale. At present, both Mie-scattering lidar (ML) and advanced lidars are being used in lidar networks. The latter can retrieve extinction coefficients without strict assumptions of the lidar ratio, such as Raman lidar (RL) or high-spectral-resolution lidar (HSRL). In order to balance the data quality and instrument costs for the lidar network, the lidar ratio regional transfer method in a lidar network is proposed in this paper. We developed a Lidar Ratio and Aerosol Fraction Non-linear Regression (LR-AFNR) model between the lidar ratio and corresponding absorbing aerosol fraction (this paper studied two types of absorbing aerosols: dust and carbonaceous). The aerosol fraction of the sun photometer retrieval was used as a medium to transfer the lidar ratio of HSRL retrieval to a certain range of MLs. This lidar ratio can be the input parameter for ML retrieval and enables the improvement of the extinction coefficient accuracy. The results show that the LR-APNR model is applicable to atmospheric conditions with high mineral dust or carbonaceous aerosol loading, and the maximum relative error of the ML extinction coefficient can be reduced from 46% (dust) and 64% (carbonaceous aerosol) to 20%. Full article

A method to calibrate the overlap factor of Lidar is proposed, named unmanned aerial vehicle correction (UAVC), which uses unmanned aerial vehicles (UAVs) to detect the vertical distribution of particle concentrations. The conversion relationship between the particulate matter concentration and the aerosol extinction coefficient is inverted by the high-altitude coincidence of the vertical detection profiles of the UAV and Lidar. Using this conversion relationship, the Lidar signal without the influence of the overlap factor can be inverted. Then, the overlap factor profile is obtained by comparing the signal with the original Lidar signal. A 355 nm Raman-Mie Lidar and UAV were used to measure overlap factors under different weather conditions. After comparison with the Raman method, it is found that the overlap factors calculated by the two methods are in good agreement. The changing trend of the extinction coefficient at each height is relatively consistent, after comparing the inversion result of the corrected Lidar signal with the ground data. The results show that after the continuously measured Lidar signal is corrected by the overlap factor measured by this method, low-altitude aerosol information can be effectively obtained. Full article

Previous studies have identified finely laminated, or layered, features within Arctic clouds. This study focuses on quasi-horizontal layers that are 7.5 to 30 m thick, within clouds from 0 to 5 km altitude. No pre-selection for any particular cloud types was made prior to the identification of laminations. We capitalize on the 4-year measurement record available from Eureka, Nunavut (79.6${}^{\circ }$ N, 85.6${}^{\circ }$ W), using the Canadian Network for the Detection of Atmospheric Composition Change (CANDAC) Rayleigh–Mie–Raman Lidar (CRL; 1 min, 7.5 m resolution). Laminated features are identified on 18% of all days, from 2016–2019. Their presence is conclusively excluded on 12% of days. March, April, and May have a higher measurement cadence and show laminations on 41% of days. Individual months show laminations on up to 50% of days. Our results suggest that laminations are not rare phenomena at Eureka. To determine laminations’ likely contribution to Arctic weather and climate, local weather reports were obtained from the nearby Environment and Climate Change Canada (ECCC) weather station. Days with laminated clouds are strongly correlated with precipitating snow (r = 0.63), while days with non-laminated clouds (r = −0.40) and clear sky days (r = −0.43) are moderately anti-correlated with snow precipitation. Full article
