In recent years, research on light-matter interactions in silicon-based micro/nano cavity optomechanical systems demonstrates high-resolution sensing capabilities (e.g., sub-fm-level displacement sensitivity). Conventional 2D photonic crystal (PhC) cavity optomechanical sensors face inherent limitations: thin silicon layers (200–300 nm) restrict both the mass block (critical for thermal noise suppression) and optical Q-factor. Enlarging the detection mass in such thin layers exacerbates in-plane height nonuniformity, severely limiting high-precision sensing. This study proposes a 500 nm thick silicon-based 2D slot-type PhC cavity design for advanced sensing applications, fabricated on a silicon-on-insulator (SOI) substrate with optimized air slot structures. Systematic parameter optimization via finite element simulations defines structural parameters for the 1550 nm band, followed by 6 × 6 × 6 combinatorial experiments on lattice constant, air hole radius, and line-defect waveguide width. Experimental results demonstrate a loaded Q-factor of 57,000 at 510 nm lattice constant, 175 nm air hole radius, and 883 nm line-defect waveguide width (measured sidewall angle: 88.4°). The thickened silicon layer delivers dual advantages: enhanced mass block for thermal noise reduction and high Q-factor for optomechanical coupling efficiency, alongside improved ridge waveguide compatibility. This work advances the practical development of CMOS-compatible micro-opto-electromechanical systems (MOEMS). Full article

Scanning micromirrors represent a crucial component in micro-opto-electro-mechanical systems (MOEMS), with a broad range of applications across diverse fields. However, in practical applications, several factors inherent to the fabrication process and the surrounding usage environment exert a considerable influence on the accuracy of measurements obtained with the micromirror. Therefore, it is essential to calibrate the scanning micromirror and its measurement system. This paper presents a novel scanning micromirror calibration method based on the prediction of a particle swarm optimization-least squares support vector machine (PSO-LSSVM). The objective is to establish a correspondence between the actual deflection angle of the micromirror and the output of the measurement system employing a regression algorithm, thereby enabling the prediction of the tilt angle of the micromirror. The decision factor ($R^2$) for this model at the x-axis reaches a value of 0.9947. Full article

High-precision displacement sensing has been widely used across both scientific research and industrial applications. The recent interests in developing micro-opto-electro-mechanical systems (MOEMS) have given rise to an excellent platform for miniaturized displacement sensors. Advancement in this field during past years is now yielding integrated high-precision sensors which show great potential in applications ranging from photoacoustic spectroscopy to high-precision positioning and automation. In this review, we briefly summarize different techniques for high-precision displacement sensing based on MOEMS and discuss the challenges for future improvement. Full article

Accurately classifying and identifying non-cooperative targets is paramount for modern space missions. This paper proposes an efficient method for classifying and recognizing non-cooperative targets using deep learning, based on the principles of the micro-Doppler effect and laser coherence detection. The theoretical simulations and experimental verification demonstrate that the accuracy of target classification for different targets can reach 100% after just one round of training. Furthermore, after 10 rounds of training, the accuracy of target recognition for different attitude angles can stabilize at 100%. Full article

Highly integrated and stable devices are appealing in optical communication and sensing. This appeal arises from the presence of high refractive index contrast and high-quality waveguides. In this study, we improved the vapor proton exchange (VPE) process, enabling large-scale waveguide fabrication and addressing the issue of liquid exchange during cooling. Additionally, we have prepared and characterized planar waveguides on X-cut lithium niobate (LN) crystals. The exchanged samples exhibit α and k1 phases, refractive index contrasts as high as 0.082, and exceptional refractive index uniformity. Furthermore, we utilized the same process to fabricate channel waveguides and Y-branch waveguides. We achieved low propagation losses in channel waveguides, accompanied by small mode sizes, and low-loss Y-branch waveguides with a highly uniform beam splitting ratio. All waveguides exhibited consistent performance across multiple preparations and tests, remaining free from aging effects for three months. Our results underscore the promising potential of VPE for creating Y-branch splitters and modulators in LN crystals. Full article

An erbium-doped Lu₃Ga₅O₁₂(LuGG) single crystal was grown by the Czochralski method. The crystalline phase in the grown crystal was analyzed by powder X-ray diffraction. The erbium-ion emission spectra of the crystal were acquired. The erbium-ion emission cross-section (ECS) spectrum was computed from the acquired emission spectrum. The erbium-ion absorption cross-section (ACS) spectrum was computed using the McCumber relationship. The results are discussed in contrast to those computed from the acquired absorption spectrum, and the comparison shows that both methods give consistent results. The temporal characteristics of the emissions were also studied based on 0.98 μm pulse pumping. The study shows that the infrared emissions at 1.0, 1.5, and 2.8 μm show mono-exponentially temporal behavior. Instead, the decays of two visible emissions at 0.56 and 0.67 μm show considerable non-exponential features; each trace can be fitted double-exponentially. The non-exponential behavior is associated with those erbium ions that are present in the form of clusters, which enables non-radiative upconversion depopulation and hence additional contribution to the decay through cross relaxation between the erbium ions in clusters. The study also shows that about half of the erbium ions are present in the cluster state in the studied crystal. Full article

A mid-infrared difference frequency generator (DFG) based on a periodically poled thin-film lithium niobate rib waveguide on a sapphire substrate is theoretically studied. A mode analysis is carried out at the mid-infrared region, and the analysis focuses on the effects of waveguide geometry on effective refractive indices of a few lower-order modes. A complete theory suitable for modeling a DFG based on a waveguide structure is described. Its validity is confirmed by comparing the theoretical results with previously reported experimental data. Explicit expressions are presented for nonlinear conversion efficiency, thermal tunability and quasi-phase matching (QPM) bandwidth. The effects of waveguide geometry and mode hybridization on the effective mode field area and mode overlap factor, which are either inversely or linearly proportional to nonlinear conversion efficiency, are studied in detail. In this article, an optimized mid-infrared DFG with improved geometry that exhibits excellent performance, including a higher nonlinear conversion efficiency of 230–273% W⁻¹cm⁻² in the temperature range of 20–120 °C; a larger temperature tunability of 2.2 nm/°C; a larger QPM bandwidth of ~130 nm; and a higher idler wave output power, as much as −2 dBm when P_p = 20 dBm and P_s = 11.5 dBm, is suggested. Full article

Micro-opto-electro-mechanical (MOEM) accelerometers that can measure small accelerations are attracting growing attention thanks to their considerable advantages—such as high sensitivity and immunity to electromagnetic noise—over their rivals. In this treatise, we analyze 12 schemes of MOEM-accelerometers, which include a spring mass and a tunneling-effect-based optical sensing system containing an optical directional coupler consisting of a fixed and a movable waveguide separated by an air gap. The movable waveguide can perform linear and angular movement. In addition, the waveguides can lie in single or different planes. Under acceleration, the schemes feature the following changes to the optical system: gap, coupling length, overlapping area between the movable and fixed waveguides. The schemes with altering coupling lengths feature the lowest sensitivity, yet possess a virtually unlimited dynamic range, which makes them comparable to capacitive transducers. The sensitivity of the scheme depends on the coupling length and amounts to 11.25 × 10³ m⁻¹ for a coupling length of 44 μm and 30 × 10³ m⁻¹ for a coupling length of 15 μm. The schemes with changing overlapping areas possess moderate sensitivity (1.25 × 10⁶ m⁻¹). The highest sensitivity (above 6.25 × 10⁶ m⁻¹) belongs to the schemes with an altering gap between the waveguides. Full article

The micro-electromechanical system (MEMS) sensors are suitable devices for vibrational analysis in complex systems. The Fabry–Pérot interferometer (FPI) is used due to its high sensitivity and immunity to electromagnetic interference (EMI). Here, we present the design, fabrication, and characterization of a silicon-on-insulator (SOI) MEMS device, which is embedded in a metallic package and connected to an optical fiber. This integrated micro-opto-electro-mechanical system (MOEMS) sensor contains a mass structure and handle layers coupled with four designed springs built on the device layer. An optical reading system using an FPI is used for displacement interrogation with a demodulation technique implemented in LabVIEW^®. The results indicate that our designed MOEMS sensor exhibits a main resonant frequency of 1274 Hz with damping ratio of 0.0173 under running conditions up to 7 g, in agreement with the analytical model. Our experimental findings show that our designed and fabricated MOEMS sensor has the potential for engineering application to monitor vibrations under high-electromagnetic environmental conditions. Full article

The ongoing miniaturization of spectrometers creates a perfect synergy with the common advantages of near-infrared (NIR) spectroscopy, which together provide particularly significant benefits in the field of food analysis. The combination of portability and direct onsite application with high throughput and a noninvasive way of analysis is a decisive advantage in the food industry, which features a diverse production and supply chain. A miniaturized NIR analytical framework is readily applicable to combat various food safety risks, where compromised quality may result from an accidental or intentional (i.e., food fraud) origin. In this review, the characteristics of miniaturized NIR sensors are discussed in comparison to benchtop laboratory spectrometers regarding their performance, applicability, and optimization of methodology. Miniaturized NIR spectrometers remarkably increase the flexibility of analysis; however, various factors affect the performance of these devices in different analytical scenarios. Currently, it is a focused research direction to perform systematic evaluation studies of the accuracy and reliability of various miniaturized spectrometers that are based on different technologies; e.g., Fourier transform (FT)-NIR, micro-optoelectro-mechanical system (MOEMS)-based Hadamard mask, or linear variable filter (LVF) coupled with an array detector, among others. Progressing technology has been accompanied by innovative data-analysis methods integrated into the package of a micro-NIR analytical framework to improve its accuracy, reliability, and applicability. Advanced calibration methods (e.g., artificial neural networks (ANN) and nonlinear regression) directly improve the performance of miniaturized instruments in challenging analyses, and balance the accuracy of these instruments toward laboratory spectrometers. The quantum-mechanical simulation of NIR spectra reveals the wavenumber regions where the best-correlated spectral information resides and unveils the interactions of the target analyte with the surrounding matrix, ultimately enhancing the information gathered from the NIR spectra. A data-fusion framework offers a combination of spectral information from sensors that operate in different wavelength regions and enables parallelization of spectral pretreatments. This set of methods enables the intelligent design of future NIR analyses using miniaturized instruments, which is critically important for samples with a complex matrix typical of food raw material and shelf products. Full article

The paper proposes a technology based on UV-LIGA process for microoptoelectromechanical systems (MOEMS) manufacturing. We used the original combination of materials and technological steps, in which any of the materials does not enter chemical reactions with each other, while all of them are weakly sensitive to the effects of oxygen plasma. This made it suitable for long-term etching in the oxygen plasma at low discharge power with the complete preservation of the original geometry, including small parts. The micromembranes were formed by thermal evaporation of Al. This simplified the technique compared to the classic UV-LIGA and guaranteed high quality and uniformity of the resulting structure. To demonstrate the complete process, a test MOEMS with electrostatic control was manufactured. On one chip, a set of micromembranes was created with different stiffness from 10 nm/V to 100 nm/V and various working ranges from 100 to 300 nm. All membranes have a flat frequency response without resonant peaks in the frequency range 0–200 kHz. The proposed technology potentially enables the manufacture of wide low-height membranes of complex geometry to create microoptic fiber sensors. Full article

The Micro-Opto-Electro-Mechanical Systems (MOEMS) accelerometer is a new type of accelerometer that combines the merits of optical measurement and Micro-Electro-Mechanical Systems (MEMS) to enable high precision, small volume, and anti-electromagnetism disturbance measurement of acceleration, which makes it a promising candidate for inertial navigation and seismic monitoring. This paper proposes a modified micro-grating-based accelerometer and introduces a new design method to characterize the grating interferometer. A MEMS sensor chip with high sensitivity was designed and fabricated, and the processing circuit was modified. The micro-grating interference measurement system was modeled, and the response sensitivity was analyzed. The accelerometer was then built and benchmarked with a commercial seismometer in detail. Compared to the previous prototype in the experiment, the results indicate that the noise floor has an ultra-low self-noise of 15 ng/Hz^1/2. Full article

A simple, easy, inexpensive, and quick nonsilicon-based micromachining method was developed to manufacture a microlens array. The spherical surface of the microlens was machined using a microshaper mounted on a three-axis vertical computer numerical control (CNC) machine with cutter-path-planning. The results show the machined profiles of microlens agree well with designed profiles. The focus ability of the machined microlens array was verified. The designed and measured focal lengths have average 1.5% error. The results revealed that the focal lengths of micro lens agreed with the designed values. A moderate roughness of microlens surface is obtained by simply polishing. The roughness of the lens surface is 43 nm in feed direction (x-direction) and 56 nm in path interval direction (y-direction). It shows the simple, scalable, and reproducible method to manufacture microlenses by microshaper with cutter-path-planning is feasible. Full article

In this paper we present a detailed evaluation of a micro-opto-electromechanical system (MOEMS) for active focusing which is realized using an electrostatically deformed thin silicon membrane. The evaluation is done using finite element methods and experimental characterization of the device behavior. The devices are realized in silicon on insulator technology. The influence of internal stress especially resulting from the high compressive buried oxide (BOX) layer is evaluated. Additionally, the effect of stress gradients in the crystalline device layer and of high reflective coatings such as aluminum is discussed. The influence of variations of some important process steps on the device performance is quantified. Finally, practical properties such as focal length control, long-term stability, hysteresis and dynamical response are presented and evaluated. The evaluation proves that the proposed membrane focusing device is suitable for high performance imaging (wavefront errors between λ/5–λ/10) with a large aperture (5 mm). Full article

In this paper, the characterization of a whispering gallery mode (WGM) resonator applied in a novel micro-opto-electro-mechanical system (MOEMS) gyroscope was investigated. The WGM optical transmission coupling model was analyzed and compared by adjusting key parameters, such as the cavity radius, the waveguide width, and the gap between them for silicon and silicon nitride materials in simulations, which will greatly affect the quality factor (Q) of the WGM resonator. Furthermore, the structural parameters of the disk resonant gyroscope were also optimized. Then, the fabrication process was optimized to overcome the difficulties in the realization of micro-optical devices. Finally, a gyroscope prototype with the integrated WGM resonator was verified experimentally. The scale factor and bias instability performance of the MOEMS gyroscope was 2.63 mv/°/s and 4.0339°/h, respectively. Full article
