This paper investigates Direction-of-Arrival (DOA) estimation of Long-Range Navigation-C (Loran-C) signals using an Ultra-Short Baseline (USBL) receiving array. Two least-squares angle estimation approaches based on inter-element delay measurements are examined, including Correlation-based Least-Squares (Corr-LS) and a Zero-Crossing-based Least Squares (ZC-LS). In both methods, relative delays are extracted only within the local array and subsequently mapped to azimuth through a geometric least squares formulation; the approach is, therefore, distinct from distributed time difference-of-arrival (TDOA) localization. For comparison, the Multiple Signal Classification (MUSIC) algorithm is implemented as a covariance-based DOA estimator that operates without explicit delay extraction. Experiments were conducted using Loran-C transmissions from the Xuancheng, Xi’an, and Rongcheng stations, with 100 valid pulse groups collected for each station. Statistical analysis using boxplots shows that Corr-LS exhibits the largest variance due to broadened or shifted correlation peaks, particularly under skywave–groundwave interference. ZC-LS reduces both variance and bias by exploiting the deterministic zero-crossing structure of the Loran-C waveform. MUSIC produces the most concentrated azimuth estimates but requires a well-conditioned covariance matrix and substantially higher computational costs. The results demonstrate that ZC-LS achieves a favorable balance among angular accuracy, robustness, and real-time feasibility, making it suited for compact Loran-C receivers and complementary navigation applications in GNSS-challenged environments. Full article

The Loran-C system employs the spherical hyperbola positioning (SHP) method. However, SHP has three drawbacks in inland regions: first, approximating the Earth’s ellipsoid as a sphere introduces positioning errors; second, hyperbola positioning inherently suffers from a high geometric dilution of precision (GDOP) value; third, it is not easy to simultaneously receive long-wave signals from an entire chain of stations under complex propagation paths, which, to some extent, limits the application and development of the Loran-C system in inland areas. This paper addresses the limitations of the SHP algorithm and introduces the ellipsoidal pseudorange positioning (EPP) method, which eliminates the need to approximate the Earth’s ellipsoid as a sphere. This pseudorange positioning algorithm reduces the GDOP value, enabling navigation and positioning with signals from just three stations, thereby breaking through the restriction of requiring signals from a single chain. Simulation analyses were conducted for various Loran-C chains in China. Due to differences in the geometric layout of the chains, the EPP algorithm improved the positioning coverage area by 129.1% to 284.6% compared to the SHP algorithm. In field test data from the Maoming region of Guangdong Province, China (a typical inland mountainous environment), the EPP algorithm significantly reduced the root mean square error (RMSE), from 417.2 m with the SHP algorithm to 43.1 m, representing an improvement of 89.7%. Both the simulation and experimental results demonstrate that the EPP method effectively addresses errors in Earth ellipsoid modeling, significantly reduces the GDOP, and substantially improves the positioning accuracy and usable area of the Loran-C system in complex inland terrain. This provides more reliable technical support for Loran-C applications in inland navigation, timing, and timing backup. Full article

Precise timing synchronization remains a fundamental requirement for modern navigation and communication systems, where the miniaturization of Loran-C infrastructure presents both technical challenges and practical significance. Conventional miniaturized loop antennas cannot simultaneously meet the requirements of the Loran-C signal for both radiation intensity and bandwidth due to inherent quality factor (Q) limitations. A sub-cubic-meter impedance matching (IM) antenna is proposed, featuring a −20 dB bandwidth of 18 kHz and over 7-fold radiation enhancement. The proposed design leverages a planar-transformer-based impedance matching network to enable efficient 100 kHz operation in a compact form factor, while a resonant coil structure is adopted at the receiver side to enhance the system’s sensitivity. The miniaturized Loran-C timing system incorporating the IM antenna achieves an extended decoding range of >100 m with merely 100 W input power, exceeding conventional loop antennas limited to 30 m operation. This design successfully achieves overall miniaturization of the Loran-C timing system while breaking through the current transmission distance limitations of compact antennas, extending the effective transmission range to the hundred-meter scale. The design provides a case for developing compact yet high-performance Loran-C systems. Full article

Loran is a crucial maritime navigation system and is also considered a key backup for satellite navigation systems. To enhance positioning and timing services, improving the accuracy of the Loran system is essential. This paper discusses the factors affecting Loran’s positioning and timing performance, with a focus on ASF (additional secondary factor) measurement techniques and filtering methods. This study specifically addresses challenges in maritime navigation and employs a first-order Gauss–Markov process to simulate ASF+SF values. This approach eliminates the need for precise geodetic distances or real-time GNSS corrections. The research included experimental tests conducted along the eastern coast of China, evaluating environmental conditions and the positioning station’s location data. Positioning calculations were performed under maritime navigation conditions. The experimental results demonstrate that when satellite navigation systems are unavailable, the proposed model significantly enhances navigation accuracy. The accuracy, previously at the level of several hundred meters, was improved to approximately 40 m, making Loran a more reliable alternative for maritime applications. Full article

This paper explores effective methods for taming rubidium atomic clocks with longwave timing signals. In an in-depth analysis of the time-difference data between the 1PPS timing signal output from the ground-wave signal received by a long-wave receiver and the 1PPS signal from UTC, we observe that the time-difference data has significant short-term jitter and long-term periodicity effects. To meet this challenge, we adopt several innovative strategies. First, we use the Fourier transform algorithm to analyse the time-frequency characteristics of the time-difference data in detail and accordingly propose a de-jittering correction algorithm for the long-wave timing data, which is aimed at improving the stability of the long-wave timing signals. Secondly, the time difference model of the rubidium clock is innovatively modified, and a quadratic polynomial superimposed with a periodic fluctuation term is constructed, which can accurately solve and eliminate the periodic components and obtain smoother time difference data. Finally, the parameters of the rubidium clock are accurately estimated by the least-squares method using the corrected smoother time difference data, and the output frequency of the rubidium clock is adjusted accordingly so that the rubidium clock is tamed effectively by the long-wave timing signal successfully. The experimental results show that the long-term stability of the tamed rubidium clock is significantly improved to 3.52 × 10⁻¹³/100,000 s; meanwhile, the phase deviation of the output 1PPS from the UTC of the tamed rubidium clock after entering the stabilisation period is kept within 25 ns. Full article

With the widespread use of the Global Navigation Satellite System (GNSS), its signal vulnerabilities and security issues have become increasingly exposed. Enhanced Long-Range Navigation (eLoran), as a backup system for the GNSS, has gradually attracted widespread attention. This paper investigates and optimizes the eLoran/GNSS combined positioning algorithm. The main research contributions are as follows: (a) Correcting the incorrect application of spatial coordinate transformation relations in the existing literature and re-deriving the eLoran/GNSS combined positioning algorithm based on the Andoyer–Lambert formula. (b) Correcting the eLoran pseudorange positioning equation for altitude in the combined positioning algorithm, compensating for the lack of altitude parameters in eLoran to improve positioning accuracy. (c) Verifying the correctness of the algorithm through simulation analysis, exploring the impact of errors on the algorithm, and evaluating whether the correction of altitude contributes to improving positioning accuracy. (d) Verifying the simulation results through actual measurement analysis. Full article

To improve the positioning accuracy of the Loran system and meet the requirements of Loran/BDS integrated positioning and timing, it is necessary to enhance the traditional Loran hyperbolic positioning method, making its pseudorange calculation consistent with the BDS positioning and timing solution. The existing pseudorange algorithm based on the Andoyer-Lambert formula has issues such as strict initial value selection range and susceptibility to singularities during calculations. This study proposes a new Loran pseudorange calculation method based on the Vincenty distance formula and conducts a simulation analysis of it. The results show that, in the absence of noise interference, the positioning and timing errors of this pseudorange algorithm are close to zero, demonstrating high accuracy. When subjected to random noise with a standard deviation of less than 100 ns, the latitude and longitude errors are both less than 10 m, and the timing error is less than 10⁻⁴ ns, meeting the requirements of Loran positioning and timing. Compared to the pseudorange algorithm based on the Andoyer-Lambert formula, the one based on the Vincenty formula has comparable positioning longitude accuracy but superior timing accuracy. Moreover, the latter offers a wider range of initial value selection and can avoid more singularity issues during calculations. Full article

In this study, Loran-C signals were collected throughout the day, and the characteristics of the received signals at different propagation distances were analyzed. Because the signal amplitude is small and difficult to recognize at a long distance and there is mutual interference between stations, a linear average method is used to process the received signal. At locations closer to the receiver, clear observations of the time delay and amplitude variation in the one-hop sky wave can be made by using the ground wave as a reference, which can be applied to studying the characteristics and parameter inversion of the lower ionosphere. When the distance is further, the significant enhancement of the sky-wave signal during the night may lead to decreased accuracy in timing and positioning. When the distance is much larger than the propagation range of the ground wave, only the sky-wave signal can be received, and the signal is more stable than when the distance is closer. During the night, multiple amplitude-comparable multi-path signals may appear in the sky wave, making the identification of the one-hop sky wave more difficult. Full article

This article introduces the eLoran timing system principle, the characteristics of the eLoran and GNSS systems, and the current development status of eLoran in China. This article elaborates on the significance and scale of this high-precision ground time service system currently being constructed in China and describes the technical methods used in the high-precision ground time service system. Finally, it analyzes and elaborates on the signal and data channels of the eLoran time service system. Full article

Loran-C is the most essential backup and supplementary system for the global navigation satellite system (GNSS). Continuous wave interference (CWI) is one of the main interferences in the Loran-C system, which will cause errors in the measurement of the time of arrival, thereby affecting positioning performance. The traditional adaptive notch filter method needs to know the frequency of CWI when removing it, and the number is limited. This paper presents a method based on sparseness to suppress the CWI in the Loran-C signal. According to the different morphological characteristics of the Loran-C signal and the CWI, we construct dictionaries suitable for the two components, respectively. We use the tunable Q-factor wavelet transform and the discrete cosine transform to make the two components obtain a good sparse representation in their respective dictionaries. Then, the two components are separated using the morphological component analysis theory. We illustrate this method using both synthetic data and actual data. A huge advantage of the proposed method is that there is no need to know the frequencies of the CWI for it can better cope with frequency changes of the CWI in the actual environments. Compared with the adaptive notch filter method, the results of the proposed method show that our approach is more effective and convenient. Full article

Satellite-based navigation techniques have revolutionized modern-day surveying with unprecedented accuracies along with the traditional and terrestrial-based navigation techniques. However, the satellite-based techniques gain popularity due to their ease and availability. The position and attitude sensors mounted on satellites, aerial, and ground-based platforms as well as different types of equipment play a vital role in remote sensing providing navigation and data. The presented review in this paper describes the terrestrial (LORAN-C, Omega, Alpha, Chayka) and satellite-based systems with their major features and peculiar applications. The regional and global navigation satellite systems (GNSS) can provide the position of a static object or a moving object i.e., in Kinematic mode. The GNSS systems include the NAVigation Satellite Timing And Ranging Global Positioning System (NAVSTAR GPS), of the United States of America (USA); the Globalnaya navigatsionnaya sputnikovaya sistema (GLObal NAvigation Satellite System, GLONASS), of Russia; BEIDOU, of China; and GALILEO, of the European Union (EU). Among the initial satellite-based regional navigation systems included are the TRANSIT of the US and TSYKLON of what was then the USSR which became operational in the 1960s. Regional systems developed in the last decade include the Quasi-Zenith Satellite System (QZSS) and the Indian Regional Navigation Satellite System (IRNSS). Currently, these global and regional satellite-based systems provide their services with accuracies of the order of 10–20 m using the trilateration method of surveying for civil use. The terrestrial and satellite-based augmented systems (SBAS) were further developed along with different surveying techniques to improve the accuracies up to centimeters or millimeter levels for precise applications. Full article

There are mainly two types of data modulation methods used for enhanced LOng-RAnge Navigation (eLORAN) systems: pulse position modulation (PPM) and supernumerary interpulse modulation (SIM). The typical application for PPM is tri-state PPM (3S-PPM), also known as Eurofix. The typical application for SIM is ninth pulse modulation. Both of these methods are phase modulation methods. Phase modulation coding, a very mature technology, is used at present. To achieve a better demodulation success rate of eLORAN digital modulation signals at longer distances, a method of using the transmitting station duplex mode to transmit a digital modulation pulse group after LORAN-C transmitting a pulse group is proposed to realize modulation pulse on–off modulation. In this method, a broadcasting experiment was performed on the BPL (The call sign of eLORAN time service system in China) broadcaster station. After monitoring, a good receiving demodulation effect was initially obtained. Full article

Loran-C is the most important backup and supplement system for the global navigation satellite system (GNSS). However, existing Loran-C demodulation methods are easily affected by noise and skywave interference (SWI). Therefore, this article proposes a demodulation method based on Loran-C pulse envelope correlation–phase detection (EC–PD), in which EC has two implementation schemes, namely moving average-cross correlation and matched correlation, to reduce the effects of noise and SWI. The mathematical models of the EC, calculation of the signal-to-noise ratio (SNR) gain, and selection of the EC schemes are given. The simulation results show that compared with an existing method, the proposed method has clear advantages: (1) The demodulation SNR threshold under Gaussian channel is only −2 dB, a reduction of 12.5 dB; (2) The probability of the demodulated SNR threshold, being less than zero under the SWI environment, can reach 0.78, a 26-fold increase. The test results show that the average data availability of the proposed method is 3.3 times higher than that of the existing method. Thus, our demodulation method has higher engineering application value. This will improve the performance of the modern Loran-C system, making it a more reliable backup for the GNSS. Full article

The Loran-C system is an internationally standardized positioning, navigation, and timing service system. It is the most important backup and supplement for the global navigation satellite system (GNSS). However, the existing Loran-C signal acquisition methods are easily affected by noise and cross-rate interference (CRI). Therefore, this article proposes an envelope delay correlation acquisition method that, when combined with linear digital averaging (LDA) technology, can effectively suppress noise and CRI. The selection of key parameters and the performance of the acquisition method are analyzed through a simulation. When the signal-to-noise ratio (SNR) is −16 dB, the acquisition probability is more than 90% and the acquisition error is less than 1 μs. When the signal-to-interference ratio (SIR) of the CRI is −5 dB, the CRI can also be suppressed and the acquisition error is less than 5 μs. These results show that our acquisition method is accurate. The performance of the method is also verified by actual signals emitted by a Loran-C system. These test results show that our method can reliably detect Loran-C pulse group signals over distances up to 1500 km, even at low SNR. This will enable the modern Loran-C system to be a more reliable backup for the GNSS system. Full article

To avoid degradation of navigation performance in the navigation warfare environment, the multi-radio integrated navigation system can be used, in which all available radio navigation systems are integrated to back up Global Navigation Satellite System (GNSS) when the GNSS is not available. Before real-time multi-radio integrated navigation systems are deployed, time and cost can be saved when the modeling and simulation (M&S) software is used in the performance evaluation. When the multi-radio integrated navigation system M&S is comprised of independent function modules, it is easy to modify and/or to replace the function modules. In this paper, the M&S software design method was proposed for multi-radio integrated navigation systems as a GNSS backup under the navigation warfare. The M&S software in the proposed design method consists of a message broker and function modules. All the messages were transferred through the message broker in order to be exchanged between the function modules. The function modules in the M&S software were independently operated due to the message broker. A message broker-based M&S software was designed for a multi-radio integrated navigation system. In order to show the feasibility of the proposed design method, the M&S software was implemented for Global Positioning System (GPS), Korean Navigation Satellite System (KNSS), enhanced Long range navigation (eLoran), Loran-C, and Distance Measuring Equipment/Very high-frequency Omnidirectional Radio range (DME/VOR). The usefulness of the proposed design method was shown by checking the accuracy and availability of the GPS only navigation and the multi-radio integrated navigation system under the attack of jamming to GPS. Full article
