Search Results (102)

The integration of Building Information Modeling (BIM) and 3D Geographic Information System (3D GIS) models provides high-precision spatial data for digital twin watersheds. To tackle the challenges of large data volumes and rendering latency in integrated models, this study proposes a three-step framework that uses Industry Foundation Classes (IFCs) as the base model and Open Scene Graph Binary (OSGB) as the target model: (1) geometric optimization through an angular weighting (AW)-controlled Quadric Error Metrics (QEM) algorithm; (2) Level of Detail (LOD) hierarchical mapping to establish associations between the IFC and OSGB models, and redesign scene paging logic; (3) coordinate registration by converting the IFC model’s local coordinate system to the global coordinate system and achieving spatial alignment via the seven-parameter method. Applied to the Santun River Basin digital twin project, experiments with 10 water gate models show that the AW-QEM algorithm reduces average loading time by 15% compared to traditional QEM, while maintaining 97% geometric accuracy, demonstrating the method’s efficiency in balancing precision and rendering performance. Full article

Large-scale scene rendering faces challenges in managing massive scene data and mitigating rendering latency caused by suboptimal loading sequences. Although current approaches utilize Level of Detail (LOD) for dynamic resource loading, two limitations remain. One is loading priority, which does not adequately consider the factors affecting visual effects such as LOD selection and visible area. The other is the insufficient trade-off between rendering quality and loading latency. To this end, we propose a loading prioritization metric called Vision Degree (VD), derived from LOD selection, loading time, and the trade-off between rendering quality and loading latency. During rendering, VDs are sorted in descending order to achieve an optimized loading and unloading sequence. At the same time, a compensation factor is proposed to further compensate for the visual loss caused by the reduced LOD level and to optimize the rendering effect. Finally, we optimize the initial viewpoint selection by minimizing the average model-to-viewpoint distance, thereby reducing the initial scene loading time. Experimental results demonstrate that our method reduces the rendering latency by 24–29% compared with the existing Area-of-Interest (AOI)-based loading strategy, while maintaining comparable visual quality. Full article

This study presents a comprehensive framework for evaluating urban heat resilience, incorporating urban climatology models, their characteristics, and simulation programs. Utilizing the local climate zone (LCZ) classification method, this research explores how urban geomorphology influences the thermal characteristics of the area. This study integrates spatial data at different “levels of detail” (LOD), from the meso- to building scales, emphasizing the significance of detailed LOD 3 models acquired through 3D laser scanning. The results demonstrate the ability of these models to identify urban heat islands (UHIs) and to simulate urban planning scenarios, such as increasing green spaces and optimizing building density, to mitigate the UHI effect. The ST3D 3D model of the city of Split, represented using an LOD 2 object model, is utilized for meso- and local-scale analyses, while LOD 3 models derived from laser scanning provided in-depth insights at the building scale. The case studies included the Faculty of Civil Engineering, Architecture, and Geodesy building on the University of Split campus and the old town hall in the densely built city center. This framework highlights the advantages of integrating GIS and BIM technology with urban climate analyses, offering tools for data-driven decision-making and fostering sustainable, climate-resilient urban planning. Full article

Point cloud data, known for their accuracy and ease of acquisition, are commonly used for reconstructing level of detail 2 (LoD-2) building models. However, factors like object occlusion can cause incompleteness, negatively impacting the reconstruction process. To address this challenge, this paper proposes a method for reconstructing LoD-2 building models from incomplete point clouds. We design a generative adversarial network model that incorporates geometric constraints. The generator utilizes a multilayer perceptron with a curvature attention mechanism to extract multi-resolution features from the input data and then generates the missing portions of the point cloud through fully connected layers. The discriminator iteratively refines the generator’s predictions using a loss function that is combined with plane-aware Chamfer distance. For model reconstruction, the proposed method extracts a set of candidate polygons from the point cloud and computes weights for each candidate polygon based on a weighted energy term tailored to building characteristics. The most suitable planes are retained to construct the LoD-2 building model. The performance of this method is validated through extensive comparisons with existing state-of-the-art methods, showing a 10.9% reduction in the fitting error of the reconstructed models, and real-world data are tested to evaluate the effectiveness of the method. Full article

The level of detail (LOD) differentiates multi-scale representations of virtual 3D city models; however, the LOD tends to relay primarily the geometric details of buildings. When the LOD extends to other datasets, such as vegetation, transportation, terrain, water bodies, and city furniture, their LODs are not as clearly defined. Despite the general acceptance of this categorization, existing LOD formats also neglect non-geometric attributes. Integrating geometric and attribute data enables geometrically accurate and data-rich 3D models, ensuring that representations are as accurate as possible and that analyses contain as much information as possible. This paper proposes a family of LOD definitions considering both geometric and attribute data based on the geometric complexity and difficulty of obtaining, archiving, processing, and distributing the data. These definitions are intended to apply to all datasets by determining divisions in the LOD typically experienced across urban 3D model elements and their associated datasets, including buildings, vegetation, roads, relief, water bodies, and city furniture. Universally applicable definitions for datasets allow individuals to recreate studies or representations of 3D models to ensure the relevant data are present. These definitions also assist data providers in evaluating their data infrastructure and further strategizing and prioritizing updates or upgrades. Full article

Surveillance video has emerged as a crucial data source for web Geographic Information Systems (GIS), playing a vital role in traffic management, facility monitoring, and anti-terrorism inspections. However, previous methods encountered significant challenges in achieving effective large-scale multi-video overlapping visualization and efficiency, particularly when organizing and visualizing large-scale video-augmented geographic scenes. Therefore, we propose a parallel-optimized visualization method specifically for large-scale multi-video augmented geographic scenes on Cesium. Firstly, our method employs an improved octree-based model for the unified management of large-scale overlapping videos. Then, we introduce a novel scheduling algorithm based on Cesium, which leverages a Web Graphics Library (WebGL) parallel-optimized and dynamic Level-of-Detail (LOD) strategy. This algorithm is designed to enhance the visualization effects and efficiency of large-scale video-integrated geographic scenes. Finally, we perform comparative experiments to demonstrate that our proposed method significantly optimizes the visualization of video overlapping areas and achieves a rendering efficiency increase of up to 95%. Our method can provide a solid technical foundation for large-scale surveillance video scene management and multi-video joint monitoring. Full article

This article describes the development and implementation of a water resource management system utilizing open technologies such as the ESP32 microcontroller and MicroPython. This system stands out for its low cost, high efficiency and adaptability to various environments, thanks to the integration of free or low-cost communications such as LoRaWAN and NB-IoT, as well as the use of open-source programming, which offers flexibility. The article details the use of JSN-SR04T ultrasonic sensors, manufactured by JINZHAN, a company based in China, for water-level measurement and the use of 3D printing to manufacture customized components, demonstrating a scalable and replicable solution for efficient water management. Full article

Smart cities use technological solutions to reduce the drawbacks of urban living. The importance of BIM and GIS integration has increased with the popularity of smart city and 3D city concepts in recent years. In addition to 3D city models, Building Information Modeling (BIM) is an essential element of smart cities. The 3D city model web client in this study displays three-dimensional (3D) city models created using photogrammetric techniques, BIM, and campus infrastructure projects. The comparison and integration of the aforementioned systems were evaluated. A web-based 3D client framework and implementation for combined BIM and 3D city models are the goals of the submitted work. The Web is a very challenging platform for 3D data presentation. The Cesium engine based on HTML5 and WebGL is an open-source creation and the virtualcityMAP application using the Cesium infrastructure was used in this study. Full article

Level of detail (LoD) is an important factor in urban building energy modelling (UBEM), affecting functionality and accuracy. This work assesses the impacts of the LoD of the roof, window, and zoning on a comprehensive range of outcomes (annual heating load, peak heating demand, overheating, and time-series heating error) in a representative New Zealand house. Lower-LoD roof scenarios produce mean absolute error results ranging from 1.5% for peak heating power to 99% for overheating. Windows and shading both affect solar gains, so lower-LoD windows and/or shading elements can considerably reduce model accuracy. The LoD of internal zoning has the greatest effect on time-series accuracy, producing mean absolute heating error of up to 66 W. These results indicate that low-LoD “shoebox” models, common in UBEM, can produce significant errors which aggregate at scale. Accurate internal zoning models and accurate window size and placement have the greatest potential for error reduction, but their implementation is limited at scale due to data availability and automation barriers. Conversely, modest error reductions can be obtained via simple model improvements, such as the inclusion of eaves and window border shading. Overall, modellers should select LoD elements according to specific accuracy requirements. Full article

Oblique photography is a regional digital surface model generation technique that can be widely used for building 3D model construction. However, due to the lack of geometric and semantic information about the building, these models make it difficult to differentiate more detailed components in the building, such as roofs and balconies. This paper proposes a deep learning-based method (U-NET) for constructing 3D models of low-rise buildings that address the issues. The method ensures complete geometric and semantic information and conforms to the LOD2 level. First, digital orthophotos are used to perform building extraction based on U-NET, and then a contour optimization method based on the main direction of the building and the center of gravity of the contour is used to obtain the regular building contour. Second, the pure building point cloud model representing a single building is extracted from the whole point cloud scene based on the acquired building contour. Finally, the multi-decision RANSAC algorithm is used to segment the building detail point cloud and construct a triangular mesh of building components, followed by a triangular mesh fusion and splicing method to achieve monolithic building components. The paper presents experimental evidence that the building contour extraction algorithm can achieve a 90.3% success rate and that the resulting single building 3D model contains LOD2 building components, which contain detailed geometric and semantic information. Full article

The efficient extraction, storage, and visualization of geometric and semantic information is a key foundation for the operation of the building information modeling (BIM) platform. This study aims to develop a lightweight BIM system and optimize the system’s performance according to the specific characteristics of steel structures. This study proposes several novel techniques for extracting and decoupling the geometric and semantic information of components from industry foundation class (IFC) files. A redundancy removal approach combining the principal content analysis (PCA) algorithm and the Hausdorff-based comparison algorithm is proposed to identify standardized steel components, and a lightweight visualization method on Web3D for redundant instances is also presented. A loading mechanism of the level of detail (LOD) model based on a mesh simplification algorithm is presented to optimize the display efficiency. The developed system is evaluated by three steel structural models. Using the redundancy removal approach, the number of instances is decreased by 96.46% in less than 30 s and over 30 FPS (frame per second) is kept when rendering. Using the LOD loading mechanism, 95.38% of vertices and 98.46% of patches are eliminated under 50 mm precision. The experiment results indicate that users can quickly load large BIM models and fetch sufficient information from the website. Full article

The growing interest in building data management, especially the building information model (BIM), has significantly influenced urban management, materials supply chain analysis, documentation, and storage. However, the integration of BIM into 3D GIS tools is becoming more common, showing progress beyond the traditional problem. To address this, this study proposes data transformation methods involving mapping between three domains: industry foundation classes (IFC), city geometry markup language (CityGML), and web ontology framework (OWL)/resource description framework (RDF). Initially, IFC data are converted to CityGML format using the feature manipulation engine (FME) at CityGML standard’s levels of detail 4 (LOD4) to enhance BIM data interoperability. Subsequently, CityGML is converted to the OWL/RDF diagram format to validate the proposed BIM conversion process. To ensure integration between BIM and GIS, geometric data and information are visualized through Cesium Ion web services and Unreal Engine. Additionally, an RDF graph is applied to analyze the association between the semantic mapping of the CityGML standard, with Neo4j (a graph database management system) utilized for visualization. The study’s results demonstrate that the proposed data transformation methods significantly improve the interoperability and visualization of 3D city models, facilitating better urban management and planning. Full article

The investigation of collagen hydrolysates (CHs) is essential due to their widespread use in health, cosmetic, and therapeutic industries, attributing to the presence of bioactive dipeptides (DPs) and tripeptides (TPs). This study developed a novel targeted liquid chromatography–tandem mass spectrometry (LC-MS/MS) method with propyl chloroformate (PCF) derivatization to measure three bioactive peptides—Hydroxyprolyl-glycine (Hyp-Gly), Glycyl-prolyl-hydroxyproline (Gly-Pro-Hyp), and Prolyl-hydroxyproline (Pro-Hyp)—in CHs, with strong correlation coefficients (0.992, 1.000, and 0.995, respectively) and low limits of detection (LODs) of 1.40, 0.14, and 1.16 µM, respectively. Untargeted data-dependent acquisition (DDA) analyses measured peptide size distribution, while amino acid analysis assessed nutritional content. The analysis of ten commercial CHs revealed similar amino acid profiles but varied peptide lengths, indicating diverse hydrolysis conditions. Products with higher proportions of smaller peptides showed elevated levels of the targeted bioactive peptides, suggesting that a smaller peptide size may increase bioactivity. These findings can inform the optimization of CH supplements, providing consumers with detailed peptide content for more informed choices. Data are available via ProteomeXchange with the identifier PXD051699. Full article

For accurate urban planning, three-dimensional (3D) building models with a high level of detail (LOD) must be developed. However, most large-scale 3D building models are limited to a low LOD of 1–2, as the creation of higher LOD models requires the modeling of detailed building elements such as walls, windows, doors, and roof shapes. This process is currently not automated and is performed manually. In this study, an end-to-end framework for the creation of 3D building models was proposed by integrating multi-source data such as omnidirectional images, building footprints, and aerial photographs. These different data sources were matched with the building ID considering their spatial location. The building element information related to the exterior of the building was extracted, and detailed LOD3 3D building models were created. Experiments were conducted using data from Kobe, Japan, yielding a high accuracy for the intermediate processes, such as an 86.9% accuracy in building matching, an 88.3% pixel-based accuracy in the building element extraction, and an 89.7% accuracy in the roof type classification. Eighty-one LOD3 3D building models were created in 8 h, demonstrating that our method can create 3D building models that adequately represent the exterior information of actual buildings. Full article

The growing adoption of Building Information Modeling (BIM) within the architectural, engineering, and construction (AEC) sector raises questions about the quality of BIM data deliverables for project owners. Therefore, assessment and evaluation of such BIM data against relevant documents such as the BIM Execution Plan (BEP), the Level of Definition (LOD)/Level of Information (LOI) matrix, and quality control customized checklists become critical, especially in large construction projects. This study primarily aims to create an automated system for assessing the quality of 3D BIM model data, utilizing a proposed project quality control checklist. The automated system consists of four key elements: a BIM-based model, a Data Extraction and Analysis Module, a Data Storage Module, and a Data Visualization Module. The Data Extraction and Analysis Module extracts relevant information and parameters from BIM models to evaluate their quality against predefined checklists. Then, it transfers the information and stores the results in a database. The database is connected to an engineering project collaboration tool, ProjectWise, to automatically update and store the data in the cloud. The database is then connected to an interactive data visualization platform, Power BI, to enable automatic visualization of the generated quality assessment results of the BIM models’ data. This system was applied to a Canadian infrastructure construction project by its BIM department during the preliminary and detailed design phases. It demonstrated an average quality score (AQS) of 87.6% for the BIM models and significantly reduced failing items by around 30%. This study concludes that the system offers a robust, practical solution for enhancing the quality control process in BIM model data management, thereby aiding engineers in timely model adjustments to meet project requirements. Full article
