Search Results (42)

To address the challenges of prolonged current isolation times and high dependency on varistors in traditional flexible short-circuit fault isolation schemes for DC systems, this paper proposes a rapid fault isolation circuit design based on an adaptive solid-state circuit breaker (SSCB). By introducing an adaptive current-limiting branch topology, the proposed solution reduces the risk of system oscillations induced by current-limiting inductors during normal operation and minimizes steady-state losses in the breaker. Upon fault occurrence, the current-limiting inductor is automatically activated to effectively suppress the transient current rise rate. An energy dissipation circuit (EDC) featuring a resistor as the primary energy absorber and an auxiliary varistor (MOV) for voltage clamping, alongside a snubber circuit, provides an independent path for inductor energy release after faults. This design significantly alleviates the impact of MOV capacity constraints on the fault isolation process compared to traditional schemes where the MOV is the primary energy sink. The proposed topology employs a symmetrical bridge structure compatible with both pole-to-pole and pole-to-ground fault scenarios. Parameter optimization ensures the IGBT voltage withstand capability and energy dissipation efficiency. Simulation and experimental results demonstrate that this scheme achieves fault isolation within 0.1 ms, reduces the maximum fault current-to-rated current ratio to 5.8, and exhibits significantly shorter isolation times compared to conventional approaches. This provides an effective solution for segment switches and tie switches in millisecond-level self-healing systems for both low-voltage (LVDC, e.g., 750 V/1500 V DC) and medium-voltage (MVDC, e.g., 10–35 kV DC) smart DC distribution grids, particularly in applications demanding ultra-fast fault isolation such as data centers, electric vehicle (EV) fast-charging parks, and shipboard power systems. Full article

Modular multilevel converter (MMC)-based power electronic transformers (PETs) present a promising solution for connecting AC/DC microgrids to facilitate renewable energy access. However, the capacitor ripple voltage in MMC-based PET submodules hinders volume optimization and power density enhancement, significantly limiting their application in distribution networks. To address this issue, this study introduces an optimized method for suppressing the submodule capacitor ripple voltage in MMC-based PET systems under normal and grid fault conditions. First, an MMC–PET topology featuring upper and lower arm coupling is proposed. Subsequently, a double-frequency circulating current injection strategy is incorporated on the MMC side to eliminate the double-frequency ripple voltage of the submodule capacitor. Furthermore, a phase-shifting control strategy is applied in the isolation stage of the dual-active bridge (DAB) to transfer the submodule capacitor selective ripple voltages to the isolation stage coupling link, effectively eliminating the fundamental frequency ripple voltage. The optimized approach successfully suppresses capacitor ripples without increasing current stress on the isolated-stage DAB switches, even under grid fault conditions, which are not addressed by existing ripple suppression methods, thereby reducing device size and cost while ensuring reliable operation. Specifically, the peak-to-peak submodule capacitor ripple voltage is reduced from 232 V to 10 V, and the peak current of the isolation-stage secondary-side switch is limited to ±90 A. The second harmonic ripple voltage on the LVDC bus can be decreased from ±5 V to ±1 V with the proposed method under the asymmetric grid voltage condition. Subsequently, a system simulation model is developed in MATLAB/Simulink. The simulation results validated the accuracy of the theoretical analysis and demonstrated the effectiveness of the proposed method. Full article

In areas such as remote, rural, and mountainous regions, supplying low-voltage three-phase power has traditionally required distribution line extension and transformer installation. However, these areas often yield low electricity revenues, making cost recovery difficult for utilities. To address this challenge, this paper proposes a Single-to-Three-Phase Converter (STPC) capable of converting single-phase low-voltage input into three-phase output for use in low-voltage distribution systems. The STPC topology employs a single-phase half-bridge AC–DC stage and a three-phase full-bridge inverter stage using SiC-MOSFETs. To validate the system, simulations and experiments were conducted under various load conditions, including unbalanced, nonlinear, and motor loads. The results show that STPC maintains output stability while minimizing impact on the existing grid. The findings demonstrate STPC’s feasibility as an alternative to conventional line extension and transformer installation, with potential for application in grid-forming and low-voltage distribution current (LVDC) systems. Full article

This paper discusses the operation and control of a low-voltage DC (LVDC) isolated distribution network powered by distributed generation (DG) from a variable-speed wind turbine induction generator (WTIG) to supply unbalanced AC loads. The system incorporates a DC-DC storage converter to regulate network voltages and interconnect battery energy storage with the DC network. The wind turbines are equipped with a squirrel cage induction generator (IG) to connect a DC network via individual power inverters (WTIG inverters). Loads are unbalanced ACs and are interfaced using transformerless power inverters, referred to as load inverters. The DC-DC converter is equipped with a novel control strategy, utilizing a droop regulator for the DC voltage to stabilize network operation. The control system is modeled based on Clark and Park transformations and is developed for the load inverters to provide balanced AC voltage despite unbalanced load conditions. The system employs the perturbation and observation (P&O) method for maximum power point tracking (MPPT) to optimize wind energy utilization, while blade angle controllers maintain generator performance within rated power and speed limits under high wind conditions. System operation is analyzed under two scenarios: normal operation with varying wind speeds and the effects of load variations. Simulation results using PSCAD/EMTDC demonstrate that the proposed LVDC isolated distribution network (DC) achieves a stable DC bus voltage within ±5% of the nominal value, efficiently delivers balanced AC voltages with unbalanced levels below 2%, and operates with over 90% wind energy utilization during varying wind speeds, confirming LVDC network reliability and robustness. Full article

This study outlines the creation and lab verification of a low-voltage direct current (LVDC) back-to-back (B2B) converter intended as a versatile connection point for low-voltage users. The converter configuration features dual inverters that regulate the power distribution to AC loads and grid connections through a shared DC circuit. This arrangement enables the integration of various DC generation sources, such as photovoltaic systems, as well as DC consumers, like electric vehicle chargers, supported by DC/DC converters. Significant advancements include sensorless current estimation for grid-forming inverters, which removes the necessity for conventional current sensors by employing mathematical models and established system parameters. The experimental findings validate the system’s effectiveness in grid-connected and isolated microgrid modes, demonstrating its ability to sustain energy quality and system stability under different conditions. Our results highlight the considerable potential of integrating grid-forming functionalities in inverters to improve microgrid operations. Full article

Due to the development of power semiconductors and the increase in digital loads, DC microgrids are receiving attention, and their application scope is rapidly expanding. As the technological stability of high-voltage direct current (HVDC) continues to rise, the potential of low-voltage direct current (LVDC) distribution systems is becoming increasingly intriguing. Many researchers are actively conducting safety and efficiency research on DC distribution systems and power grids. In LVDC distribution systems, small-scale DC microgrids are formed by renewable energy sources supplying DC power. This paper analyzes the efficiency improvement that can be achieved by integrating a fire protection system into a DC microgrid. This research analyzed the changes when fire protection systems such as receivers, transmitters, fire alarms, emergency lighting, and evacuation guidance, which have traditionally used AC power, were converted to DC circuits. As a result, the power supply infrastructure within the DC microgrid can be simplified, energy loss can be reduced, and the stability of the power system can be improved. The research results of this paper suggest that DC circuit-based fire protection facilities can positively impact future smart grid and renewable energy goals. Full article

This paper deals with the operation method of an intelligent fault isolation device (IFID), which can detect and estimate faults in rapid and accurate ways considering the slope characteristics of fault currents with distribution line constants. Namely, the proposed operation method in IFID calculates the slope of the fault current with distribution line constants, and reduces its operation time by comparing the calculated slope value to the setting value to detect and evaluate the fault condition. Moreover, this paper implements the DC 400 V, 10 kW scaled IFID consisting of hardware (H/W) and software (S/W) sections based on the proposed operation method. The H/W section is composed of main and current limit switches, a current limit resistor, voltage and current sensors, and switching mode power supply (SMPS). Also, the S/W section consists of a control board and code composer studio (CCS) to calculate the slope characteristics of the fault current and control the semiconductor device. From the test results based on the proposed operation method, it was found that the IFID considering the slope characteristics of fault currents can detect and evaluate the fault condition and limit the fault current faster than the existing method to consider the fault current only. Full article

DC smart grids are a promising solution for the efficient integration of renewable energy sources and loads. Still, their widespread adoption is hindered by significant challenges related to fault response, identification, and clearance. The traditional DC fault analysis method is a useful tool for straightforwardly understanding the behaviour of fault current contributions from DC converters in LVDC networks during a fault. However, when a system with multiple converters and non-negligible fault impedance need to be considered, its accuracy is severely limited due to the assumptions included in the problem solution, thus leading to the following: (a) the dependency of the results’ reliability on fault impedance values and/or other converter fault current contributions; (b) the inaccuracy of the diode current estimation; and (c) the inaccuracy of the conductor joule integral. Thus, these results’ data may be unreliable for designing protection systems for one converter or for an entire network. In order to overcome these issues, this paper proposes an innovative, simple numerical approach to DC fault current evaluation, which can be adopted when the number of converters become significant, or the network is complex. This method arises from the primary interest in solving the circuit to extract the indicators (current peak value and time, joule integral, etc.) necessary for designing circuit protections. This approach proved to grant two main advantages over traditional methods: (a) it provides accurate results, with no need to introduce any specific assumption; (b) it can be structured to manage an arbitrary number of converters; and (c) it reduces the computational processing times and resources necessary to simulate an entire DC network in comparison to other circuit solution software. Full article

DC transformers have emerged as essential devices for medium voltage DC (MVDC)-low voltage DC (LVDC) distribution systems. However, conventional step-down single-level converters have limits on the voltage level of the MVDC-LVDC distribution system. This paper proposes a non-isolated step-down (NISD) DC transformer based on discontinuous conduction mode (DCM). The proposed structure can withstand high voltage levels by sharing voltages between energy storage modules dividing voltage levels. The proposed NISD DC transformer determines operational modes based on energy storage modules and performs the voltage conversion process. The effectiveness of the proposed NISD DC transformer is verified based on a case study using a power system computer-aided design and electromagnetic transient simulation engine including DC (PSCAD/EMTDC™). Full article

This paper presents an in-depth comparison of the benefits and limitations of using a low-voltage DC (LVDC) microgrid versus an AC microgrid with regard to the integration of low-carbon technologies. To this end, a novel approach for charging electric vehicles (EVs) on low-voltage distribution networks by utilizing an LVDC backbone is discussed. The global aim of the conducted study is to investigate the overall energy losses as well as voltage stability problems on DC and AC microgrids. Both architectures are assessed and compared to each other by performing a power flow analysis. Along this line, an actual low-voltage distribution network with various penetration levels of EVs, combined with photovoltaic (PV) systems and battery energy storage systems is considered. Obtained results indicate significant power quality improvements in voltage imbalances and conversion losses thanks to the proposed backbone. Moreover, the study concludes with a discussion of the impact level of EVs and PVs penetration degrees on energy efficiency, besides charging power levels’ impact on local self-consumption reduction of the studied system. The outcomes of the study can provide extensive insights for hybrid microgrid and EV charging infrastructure designers in a holistic manner in all aspects. Full article

With the rapid development of power electronics technology and its successful application, many demonstration projects of medium/low-voltage DC (M-LVDC) distribution systems have been constructed. The DC transformer (DCT) is the key equipment in the M-LVDC distribution system for interconnecting the MVDC and LVDC buses. In this paper, the characteristics of DCTs are summarized. The existing topologies of DCTs are analyzed, and the relevant control strategies are researched, including steady-state control, transient control, and cascaded control. The engineering application examples of DCTs are introduced by interpreting the medium and low-voltage DC distribution system demonstration project in Wujiang City, Suzhou. Finally, the challenges faced by the DCT are given, and the future development trend is predicted. This perspective provides a constructive basis for DCTs and an important reference for M-LVDC distribution systems. Full article

Low-voltage (LV) and high-voltage (HV) DC distribution systems are being investigated as alternatives due to the growth of DC distribution energy resources (DER), DC loads such as solar and wind power systems, and energy storage sources (ESSs). Furthermore, an HV/LV DC distribution system offers various advantages, including lower conversion losses, an easier connecting strategy for DC DERs, and less complex power management techniques. As renewable energy sources are increasingly incorporated into the electrical grid, it is important to create novel, effective approaches for connecting such sources and loads. It would hence be effective to merge DC distribution with AC distribution to fulfill the energy demands of both DC and AC consumers. To this end, this study proposes a multizone design with four buses: low-voltage direct current (LVDC), high-voltage direct current (HVDC), low-voltage alternating current (LVAC), and an electrical grid. A model of this system that covers crucial elements, including power systems, DER systems, and power electronic devices, to serve as a foundation for the analysis and design of this architecture is proposed. MATLAB/Simulink is used to conduct a simulation study to verify the performance of the proposed design. In this study, a hybrid electrical grid with an LVDC, HVDC, and LVAC distribution network test is used and implemented. Additionally, a transient and steady-state characteristic analysis of the test system is performed. Full article

This paper proposes a three-port power electronic transformer (PET) based on magnetic integration, where the modular multilevel converter (MMC) arm inductors and high-frequency transformer are integrated; thus, the low-voltage DC (LVDC) port can be directly obtained. Such a magnetic integration structure has advantages of reduction in magnetic volume and number of active switches, implying a compact structure and reduced cost. Compared with existing PETs, the proposed PET can save more than 60% of magnetic volume and more than 19% of device cost. The proposed PET is suitable for AC/DC hybrid distribution applications with medium-voltage DC (MVDC), medium-voltage AC (MVAC), and LVDC ports, especially for scenarios where moderate amounts of power (100 s of kW) are tapped from an LVDC port. The feasibility of the proposed three-port PET has been verified by simulation and experimental results. Full article

This article presents a deep theoretical analysis of the Active Disturbance Rejection Control (ADRC) regulator for the control of first-order systems, directly compared to a “traditional” Proportional Integral (PI) regulator. To complete the theoretical study, ADRC and PI are implemented into the model of a single-phase Dual Active Bridge (DAB) converter to regulate the voltage of a Direct Current (DC) network. Facing different types of disturbances and DC network parameters variations, strengths and weaknesses of the two controllers are highlighted. ADRC and PI controls are discretized and implemented in Control Hardware In the Loop (CHIL) simulations of a single-phase DAB converter to regulate the voltage of a node of multi-terminal and multi-level DC network. By changing the DAB connection points along the MVDC network, the controlled system is stressed with different disturbances, extending the result of single-terminal network software simulations. Full article

LVDC buildings use a low-voltage direct current (LVDC) distribution system for energy transmission and integrate photovoltaic (PV), battery energy storage (BES) and the utility grid as building energy resources. This technology can reduce energy loss in conversion to a certain extent and increase renewable energy compared with traditional AC distribution systems. Under the national goal of carbon peaking and carbon neutrality, LVDC buildings have been proven to be a new approach to energy conservation and emission reductions, and have been applied in engineering in China. However, the construction methods and integrated technologies of those projects are not clear, and technical barriers and policy constraints for the engineering application of LVDC buildings are not systematically discussed yet. This paper presents the latest study of LVDC building engineering applications the advantages and drawbacks of LVDC development in China. First, relevant policies and standards which support the development of LVDC building industries are summarized. More than 60 practical LVDC projects are investigated, and the application characteristics and the technology status of building types, and their capacity and design methods, etc., are analyzed. The attitudes of stakeholders toward LVDC buildings are surveyed to determine the policy direction according to the demands of this technology, with reference to building practitioners who intend to engage in LVDC projects. Full article
