Search Results (19)

The application of induction heating power supply in the continuous production line of tinplate has garnered significant research and scholarly attention. However, the impedance matching of LC or CLC resonant circuits in the system lacks flexibility and is susceptible to overvoltage during startup. As a solution to the problem, a novel four-order LCLC parallel resonant circuit was proposed in this study for high-frequency induction heating power supply. By incorporating auxiliary inductors in parallel with CLC compensating capacitor branches, the induction heating system can operate reliably and achieve optimal load impedance matching. The equivalent circuit and mathematical model of the new resonant load were established, and the frequency characteristics of the circuit system were analyzed. Then, the parallel resonance characteristics of the new resonant circuit were comprehensively elucidated, including the quality factor, impedance characteristics, behavior of resonant current, and properties of voltage regulation. Finally, a simulation model of a high-frequency induction heating power supply was developed based on the proposed LCLC resonant circuit and compared with LC and CLC resonant circuits. The results demonstrated that the induction heating power supply system utilizing the proposed LCLC parallel resonant load exhibits superior parallel resonant characteristics, enhanced load impedance-matching flexibility, and improved output voltage stability when compared to traditional LC or CLC parallel resonant loads. Full article

This study investigates the hydration behavior of cementitious materials incorporating fly ash, limestone and calcined clay (LC2), and seawater, aiming to understand the individual and synergistic effects of these components on hydration kinetics. The motivation behind this research lies in the growing interest in enhancing the performance and sustainability of cement-based materials by incorporating supplementary materials and utilizing seawater. To achieve this, the hydration process was meticulously examined using electrochemical impedance spectroscopy (EIS). An innovative equivalent circuit model was developed to analyze the results. The experimental data indicated that, with ongoing hydration, the diameter of the impedance arc in the high-frequency range gradually increases. A noteworthy observation is that increasing the proportion of fly ash and LC2 in the cement paste leads to a corresponding enlargement of the high-frequency arc, indicating a significant influence of these supplementary materials on the hydration process. Additionally, LC2 was found to be more effective in accelerating the hydration process compared to fly ash. Full article

This paper describes and validates an advanced synthesis design process of Frequency-Selective Surfaces (FSSs) with elliptic band-stop responses. A systematic procedure based on the Generalized Chebyshev Function and the extracted pole technique enables control of the position of the transmission zeros and the attenuation level to obtain an equiripple rejection response. A systematic process is followed to obtain the lumped LC values of the resonator circuits extracted as poles and the impedance inverters. Then, equivalent dipoles and transmission lines are obtained to carry out the electromagnetic design at normal incidence for a linearly polarized field. The impact of the higher-order modes of the periodic structure on the electrical response of the FSS, which can be relevant due to the stringent selected specifications, has been also analyzed. A fourth-order band-stop filter with a 3 GHz bandwidth centered at 30 GHz and its attenuation at 50 dB has been designed considering three different implementations: two filters using a vacuum as a transmission line with different connection lengths and a third one using a dielectric substrate to enable its manufacturing. In order to verify the design procedure using experimental results, the third filter with printed dipoles in the dielectric substrate has been manufactured and measured, thus validating the developed process. Full article

In this paper, a GaN high-electron-mobility transistor (HEMT) compact high-power wide-band power amplifier with an operation frequency from 0.8 GHz to 2 GHz is proposed. In order to realize a compact design, an internally matched method is employed. A wide-band matching strategy with an LC network and a multi-stage wide-band power combiner/divider is introduced in this design to achieve a wide bandwidth. A power combination structure is applied to have high output power. Wire-spiral inductance and film capacitors are employed to construct the compact matching network. The equivalent inductance of the bonding wire is also involved in the matching network. Experimental results show that the PAE (power-added efficiency) during the whole operation’s bandwidth (0.8 GHz to 2.0 GHz) is from 40% to 57%. The output power can reach from 48.3 dBm to 49.8 dBm with a circuit size of $30.8\times 27.4{\mathrm{mm}}^2$. Full article

Compared to inductive power transfer (IPT) technology, capacitive power transfer (CPT) technology offers unique advantages such as being cost-effective, lightweight, and free from eddy-current losses, making it more suitable for underwater power transfer. Unlike air, water can conduct electricity and the electric conductivity of different kinds of waters varies with different ion concentrations, which would greatly affect the equivalent model of the underwater couplers. To address this issue, multiple types of underwater coupler working in different kinds of water are compared and analyzed. The influence of the electrical conductivity of water on the capacitive coupler is comprehensively analyzed, and the novel capacitive coupler and its equivalent model are proposed to improve power transfer efficiency. To verify the theoretical analysis, the double-sided LC-compensated CPT circuit is built and tap water is used in the experiment. The experimental results are consistent with the theoretical analysis. In addition, the experimental results also validate the superiority of the proposed capacitive coupler compared to existing research. Full article

In this paper, a compact antenna design method is proposed for microstrip patch antennas using a double-layered defected ground structure (DGS) configuration. While a conventional single-layered defected ground structure yields a lower resonant frequency and Q-factor, a smaller circuit size can be achieved using an additional substrate with a higher dielectric constant. The size reduction obtained from the additional resonant LC elements is analytically explained using the equivalent circuit model. The characteristics of the additional substrates are investigated for various dielectric constants and thicknesses. From the experimental results, the proposed design method leads to a total size reduction of up to 51.7% and a miniaturized design for planar antennas with ground apertures. The proposed design method can be applied to various antenna designs with any DGS pattern. Furthermore, the size reduction method can maintain the structure of the resonant patch element and its radiation characteristics. Therefore, the proposed method is applicable to the design of microwave devices on microstrip-based configurations. Full article

An electrode pattern design generating a parabolic voltage distribution, in combination with usage of the linear response range of the liquid crystal (LC) material, has been recently proposed to obtain nearly ideal phase profiles for LC lenses. This technique features low driving voltages, simple structure, compact design, and the absence of high-resistivity (HR) layers. In this work, the universal design principle is discussed in detail, which is applicable not only to LC lens design, but also to other LC devices with any phase profile. Several electrode patterns are presented to form a parabolic voltage distribution. An equivalent electric circuit of the LC lens based on the design principle is developed, and the simulation results are given. In the experiments, an LC lens using the feasible parameters is prepared, and its high-quality performance is demonstrated. Full article

Functional materials, in the combination of lignocelluloses, known as natural fibers, with oxide materials, can result in cultivating functional properties such as flexibility, relativity good electrical conduction, good electrical charge storage capacity, and tunable electric permittivity. This study presents the morphological, dielectric, and impedance properties of lignocellulose–lead oxide (LC/PbO₂) composite sheets electrodeposited with silver metallic nanoparticles for various time spans. The uncoated samples show a rather simple behavior where the impedance data fit well to the two-system model with different relaxation times. On the other side, the impedance spectra of the electrodeposited sample have varying features, which mainly depend upon the deposition thickness of the Ag particles. The common feature is the drift of conductive species, as seen from the straight-line behavior in the Nyquist plots, which were fitted using a Warburg element in the equivalent circuit model. Full article

This paper presents a printed magnetic probe that can switch from broadband to tunable narrowband for near-field measurement. In the early design stage, we created a printed loop gap resonator as a magnetic reference sensor for the pre-compliance test in a band up to 6 GHz. Consequently, the results showed a good response in terms of the S11 and S21 parameters of the proposed probe compared with the commercial magnetic sensor XF-R 3-1. The source noise might spread among different frequency bands, making the broadband magnetic probe the closest choice for estimating the magnetic field in the near-field region. Unfortunately, broadband magnetic probes have lower sensitivity than narrowband ones. One of the solutions to get high sensitivity is to connect the LNA to the output of the passive magnetic sensor. This work proposes a novel method to solve this issue using a PIN diode to change the broadband status into a high sensitivity narrowband status and then tune this narrowband across the most critical applications such as 3.5 GHz, 3.75 GHz, 4.8 GHz, and 5.2 GHz with the help of a varactor diode. Compared to the broadband status, an improvement of more than 10 dB has been obtained across all these wireless bands. Furthermore, the proposed structure’s isolation between the electrical and magnetic fields is about 13 dB. Full article

Highly ordered nanostructure arrays have attracted wide attention due to their wide range of applicability, particularly in fabricating devices containing scalable and controllable junctions. In this work, highly ordered carbon nanotube (CNT) arrays grown directly on Si substrates were fabricated, and their electronic transport properties as a function of wall thickness were explored. The CNTs were synthesized by chemical vapor deposition inside porous alumina membranes, previously fabricated on n-type Si substrates. The morphology of the CNTs, controlled by the synthesis parameters, was characterized by electron microscopies and Raman spectroscopy, revealing that CNTs exhibit low crystallinity (LC). A study of conductance as a function of temperature indicated that the dominant electric transport mechanism is the 3D variable range hopping. The electrical transport explored by I–V curves was approached by an equivalent circuit based on a Schottky diode and resistances related to the morphology of the nanotubes. These junction arrays can be applied in several fields, particularly in this work we explored their performance in gas sensing mode and found a fast and reliable resistive response at room temperature in devices containing LC-CNTs with wall thickness between 0.4 nm and 1.1 nm. Full article

The objective of this paper is to study a 22 kW high-power wireless power transfer (WPT) system for battery charging in electric vehicles (EVs). The proposed WPT system consists of a three-phase half-bridge LC–LC (i.e., primary LC/secondary LC) resonant power converter and a three-phase sandwich wound coil set (transmitter, Tx; receiver, Rx). To transfer power effectively with a 250 mm air gap, the WPT system uses three-phase, sandwich-wound Tx/Rx coils to minimize the magnetic flux leakage effect and increase the power transfer efficiency (PTE). Furthermore, the relationship of the coupling coefficient between the Tx/Rx coils is complicated, as the coupling coefficient is not only dominated by the coupling strength of the primary and secondary sides but also relates to the primary or secondary three-phase magnetic coupling effects. In order to analyze the proposed three-phase WPT system, a detailed equivalent circuit model is derived for a better understanding. To give a design reference, a novel coil design method that can achieve high conversion efficiency for a high-power WPT system was developed based on a simulation-assisted design procedure. A pair of magnetically coupled Tx and Rx coils and the circuit parameters of the three-phase half-bridge LC–LC resonant converter for a 22 kW WPT system are adjusted through PSIM and CST STUDIO SUITE™ simulation to execute the derivation of the design formulas. Finally, the system achieved a PTE of 93.47% at an 85 kHz operating frequency with a 170 mm air gap between the coils. The results verify the feasibility of a simulation-assisted design in which the developed coils can comply with a high-power and high-efficiency WPT system in addition to a size reduction. Full article

In this paper, a compact textile ultrawideband (UWB) planar monopole antenna loaded with a metamaterial unit cell array (MTMUCA) structure with epsilon-negative (ENG) and near-zero refractive index (NZRI) properties is proposed. The proposed MTMUCA was constructed based on a combination of a rectangular- and a nonagonal-shaped unit cell. The size of the antenna was 0.825 λ₀ × 0.75 λ₀ × 0.075 λ₀, whereas each MTMUCA was sized at 0.312 λ₀ × 0.312 λ₀, with respect to a free space wavelength of 7.5 GHz. The antenna was fabricated using viscose-wool felt due to its strong metal–polymer adhesion. A naturally available polymer, wool, and a human-made polymer, viscose, that was derived from regenerated cellulose fiber were used in the manufacturing of the adopted viscose-wool felt. The MTMUCA exhibits the characteristics of ENG, with a bandwidth (BW) of 11.68 GHz and an NZRI BW of 8.5 GHz. The MTMUCA was incorporated on the planar monopole to behave as a shunt LC resonator, and its working principles were described using an equivalent circuit. The results indicate a 10 dB impedance fractional bandwidth of 142% (from 2.55 to 15 GHz) in simulations, and 138.84% (from 2.63 to 14.57 GHz) in measurements obtained by the textile UWB antenna. A peak realized gain of 4.84 dBi and 4.4 dBi was achieved in simulations and measurements, respectively. A satisfactory agreement between simulations and experiments was achieved, indicating the potential of the proposed negative index metamaterial-based antenna for microwave applications. Full article

Photovoltaic (PV) systems are subject to nearby lightning strikes that can contribute to extremely high induced overvoltage transients. Recently, the authors introduced a 3D semi-analytical method to study the electromagnetic transients caused by these strikes in a PV module. In the present paper we develop an improved model of the PV module that: (a) takes into account high-frequency effects by modelling capacitive and inductive couplings; (b) considers the electrical insulation characteristics of the module; (c) includes the connection to a DC/DC converter. The whole process involves three major steps, i.e., the magnetic-field computation, the evaluation of both common-mode- and differential-mode-induced voltages across the PV module, and the use of the calculated voltages as input to a lumped equivalent circuit of the PV module connected to the DC/DC converter. In such a framework, the influence of the PV operating condition on the resulting electrical stresses is assessed; moreover, the relevance or insignificance of some parameters, such as the module insulation or the frame material, is demonstrated. Finally, results show that the induced overvoltage are highly dependent both on the grounding of the conducting parts and on the external conditions such as lightning current waveforms and lightning channel (LC) geometry. Full article

The transmission electrode technique has been recently proposed as a versatile method to obtain various types of liquid-crystal (LC) lenses. In this work, an equivalent electric circuit and new analytical expressions based on this technique are developed. In addition, novel electrode shapes are proposed in order to generate different phase profiles. The analytical expressions depend on manufacturing parameters that have been optimized by using the least squares method. Thanks to the proposed design equations and the associated optimization, the feasibility of engineering any kind of aspheric LC lenses is demonstrated, which is key to obtain aberration-free lenses. The results are compared to numerical simulations validating the proposed equations. This novel technique, in combination with the proposed design equations, opens a new path for the design and fabrication of LC lenses and even other types of adaptive-focus lenses based on voltage control. Full article

The output LC filter of a photovoltaic (PV) string three-level grid-tied inverter that connects the filter capacitor neutral point to dc-link capacitor neutral point can reduce the common-mode (CM) current injected to the grid by letting the CM current circulate within the inverter. However, the internal CM current may resonate because of the existence of the resonant frequency of the internal CM LC circuit. Compared with the traditional continuous pulse-width modulation (CPWM), the resonance can be worse if discontinuous pulse-width modulation (DPWM) is applied, for the zero sequence quantity of DPWM contains more harmonics than that of CPWM. In this paper, a virtual negative resistor based common mode current resonance suppression method for a three-level grid-tied inverter is proposed to overcome the CM current resonance problem in DPWM application. Different positions of the virtual negative resistor in the equivalent CM circuit with different feedback variables are analyzed theoretically. The virtual negative resistor connected in series with the inductor in the equivalent CM circuit is selected to damp the CM current resonance for simplification and damping performance. Different from the implementation in CPWM where a pair of small voltage vectors exist and are used to adjust the CM voltage directly, the proposed method for DPWM application is implemented indirectly by adding the CM adjustment quantity to differential-mode (DM) control quantity with appropriate coefficients. Depending on the sector of DM control quantity in the $\mathsf{\alpha }\mathsf{\beta }$ reference frame, the coefficients are calculated using one of three specific voltage vectors. Experimental results are given to demonstrate the effectiveness of theoretical analyses and the proposed method. Full article
