Search Results (23)

The degradation of nonlinear filtering in INS/GNSS integrated navigation due to missing GNSS observations and system noise uncertainty is addressed in this paper. An improved cubature Kalman filter (ICKF) is proposed, leveraging a modified cubature point update framework (MUF) and the maximum likelihood (ML) principle. In the ICKF, the ML principle is employed to estimate the process noise covariance, which is then integrated into the MUF to construct the posterior cubature points directly, bypassing the need for resampling. As the process noise covariance is updated in real time, and the prediction cubature points’ error is directly transferred to the posterior cubature points, the proposed algorithm demonstrates reduced sensitivity to missing observations and system noise uncertainty. The effectiveness of the proposed algorithm has been validated through both simulation and practical experiments. Full article

Aimed at the problem of navigation performance degradation in inertial navigation system/global navigation satellite system (INS/GNSS)-integrated navigation systems due to measurement anomalies and non-Gaussian measurement noise in complex navigation environments, an adaptive unscented Kalman filter (AUKF) algorithm based on the maximum versoria criterion (MVC) is developed. The proposed method is designed to enhance INS/GNSS-integrated navigation system robustness and accuracy by addressing the limitations of conventional filtering approaches. An adaptive unscented Kalman filter is constructed to enable dynamic adjustment of filter parameters, allowing for real-time adaptation to measurement anomalies. This ensures accurate tracking of navigation parameter states, thereby improving the robustness of the INS/GNSS-integrated navigation system in the presence of abnormal measurements. On this basis, fully considering the high-order moments of estimation errors, the maximum versoria criterion is introduced as the optimization criterion to construct a novel cost function, further effectively suppressing deviations caused by non-Gaussian disturbances and improving system navigation accuracy. The effectiveness of the proposed method was verified through vehicle navigation experiments. The experimental results demonstrate that the proposed method outperforms traditional approaches, effectively handling measurement anomalies and non-Gaussian measurement noise while maintaining robust navigation performance. Specifically, compared to the EKF, UKF, and MCCUKF, the proposed method reduces the root mean square error of velocity and position by over 60%, 50%, and 30%, respectively, under complex navigation conditions. The algorithm exhibits good accuracy and stability in complex environments, showcasing its practical applicability in real-world navigation systems. Full article

This work presents an innovative approach for tuning the Kalman filter in INS/GNSS integration, combining states from the inertial navigation system (INS) and data from the Global Navigation Satellite System (GNSS) to enhance navigation accuracy. The INS uses measurements from accelerometers and gyroscopes, which are subject to uncertainties in scale factor, misalignment, non-orthogonality, and bias, as well as temporal, thermal, and vibration variations. The GNSS receiver faces challenges such as multipath, temporary signal loss, and susceptibility to high-frequency noise. The novel approach for Kalman filter tuning involves previously performing Monte Carlo simulations using ideal data from a predetermined trajectory, applying the inertial sensor error model. For the indirect filter, errors from inertial sensors are used, while, for the direct filter, navigation errors in position, velocity, and attitude are also considered to obtain the process noise covariance matrix Q. This methodology is tested and validated with real data from Castro Leite Consultoria’s commercial platforms, PINA-F and PINA-M. The results demonstrate the efficiency and consistency of the estimation technique, highlighting its applicability in real scenarios. Full article

In-flight alignment is a critical milestone for inertial navigation system/global navigation satellite system (INS/GNSS) applications in unmanned aerial vehicles (UAVs). The traditional position integration formula for in-flight coarse alignment requires the GNSS velocity data to be valid throughout the alignment period, which greatly limits the engineering applicability of the method. In this paper, a new robust position integration optimization-based alignment (OBA) method for in-flight coarse alignment is presented to solve the problem of in-flight alignment under a prolonged ineffective GNSS. In this methodology, to achieve a higher alignment accuracy in case the GNSS is not effective throughout the alignment period, the integration of GNSS velocity into the local-level navigation frame is replaced by the GNSS position in the Earth-centered, Earth-fixed frame, which avoids the need for complete GNSS velocity data. The simulation and flight test results show that the new robust position integration method proposed in this paper achieves higher stability and robustness than the conventional position integration OBA method and can achieve an alignment accuracy of 0.2° even when the GNSS is partially time-invalidated. Thus, this greatly extends the application of the OBA method for in-flight alignment. Full article

In the field of navigation and positioning, the inertial navigation system (INS)/global navigation satellite system (GNSS) integrated navigation system is known for providing stable and high-precision navigation services for vehicles. However, in extreme scenarios where GNSS navigation data are completely interrupted, the positioning accuracy of these integrated systems declines sharply. While there has been considerable research into using neural networks to replace the GNSS signal output during such interruptions, these approaches often lack targeted modeling of sensor information, resulting in poor navigation stability. In this study, we propose an integrated navigation system assisted by a novel neural network: an inverted-Transformer (iTransformer) and the application of a frequency-enhanced channel attention mechanism (FECAM) to enhance its performance, called an INS/FECAM-iTransformer integrated navigation system. The key advantage of this system lies in its ability to simultaneously extract features from both the time and frequency domains and capture the variable correlations among multi-channel measurements, thereby enhancing the modeling capabilities for sensor data. In the experimental part, a public dataset and a private dataset are used for testing. The best experimental results show that compared to a pure INS inertial navigation system, the position error of the INS/FECAM-iTransformer integrated navigation system reduces by up to 99.9%. Compared to the INS/LSTM (long short-term memory) and INS/GRU (gated recurrent unit) integrated navigation systems, the position error of the proposed method decreases by up to 82.4% and 78.2%, respectively. The proposed approach offers significantly higher navigation accuracy and stability. Full article

The objective of this paper is to tackle the issue of the degraded navigation accuracy of the inertial navigation system/global navigation satellite system (INS/GNSS) integrated navigation system in urban applications, especially under complex environments. This study utilizes historical state estimates and proposes a multi-step pseudo-measurement adaptive Kalman filter (MPKF) algorithm based on the filter performance evaluation. First, taking advantage of the independence between INS and GNSS, the enhanced second-order mutual difference (SOMD) algorithm is utilized for estimating the noise variance of the GNSS, which is decoupled from the estimate error of state and used as a module for filter performance evaluation. Then, the construction of the proposed method is presented, together with the analysis of the noise variance of multi-step pseudo-measurement. Ultimately, the efficacy of the MPKF is confirmed through a real-world vehicle experiment involving a tightly-coupled INS/GNSS integrated navigation application, demonstrating a noteworthy enhancement in navigation precision within densely wooded and built-up areas. Compared to the standard EKF and enhanced redundant measurement-based adaptive Kalman filter (ERMAKF), the proposed algorithm improves the positioning accuracy by 48% and 34%, velocity accuracy by 50% and 35%, and attitude accuracy by 38% and 48%, respectively, in the urban building segment. Full article

High-precision navigation solutions are a main requirement for autonomous vehicle (AV) applications. Global navigation satellite systems (GNSSs) are the prime source of navigation information for such applications. However, some places such as tunnels, underpasses, inside parking garages, and urban high-rise buildings suffer from GNSS signal degradation or unavailability. Therefore, another system is required to provide a continuous navigation solution, such as the inertial navigation system (INS). The vehicle’s onboard inertial measuring unit (IMU) is the main INS input measurement source. However, the INS solution drifts over time due to IMU-associated errors and the mechanization process itself. Therefore, INS/GNSS integration is the proper solution for both systems’ drawbacks. Traditionally, a linearized Kalman filter (LKF) such as the extended Kalman filter (EKF) is utilized as a navigation filter. The EKF deals only with the linearized errors and suppresses the higher orders using the Taylor expansion up to the first order. This paper introduces a loosely coupled INS/GNSS integration scheme using the invariant extended Kalman filter (IEKF). The IEKF state estimate is independent of the Jacobians that are derived in the EKF; instead, it uses the matrix Lie group. The proposed INS/GNSS integration using IEKF is applied to a real road trajectory for performance validation. The results show a significant enhancement when using the proposed system compared to the traditional INS/GNSS integrated system that uses EKF in both GNSS signal presence and blockage cases. The overall trajectory 2D-position RMS error reduced from $19.4$ m to $3.3$ m with $82.98\%$ improvement and the 2D-position max error reduced from $73.9$ m to $14.2$ m with $80.78\%$ improvement. Full article

The resolution accuracy of the inertial navigation system/global navigation satellite system (INS/GNSS) integrated system would be degraded in challenging areas. This paper proposed a novel algorithm, which combines the second-order mutual difference method with the maximum correntropy criteria extended Kalman filter to address the following problems (1) the GNSS measurement noise estimation cannot be isolated from the state estimation and suffers from the auto-correlated statistic sequences, and (2) the performance of EKF would be degraded under the non-Gaussian condition. In detail, the proposed algorithm determines the possible distribution of the measurement noise by a kernel density function detection, then depending on the detection result, either the difference sequences–based method or an autoregressive correction algorithm’s result is utilized for calculating the noise covariance. Then, the obtained measurement noise covariance is used in MCEKF instead of EKF to enhance filter adaptiveness. Meanwhile, to enhance the numerical stability of the MCEKF, we adopted the Cholesky decomposition to calculate the matrix inverse in the kernel function. The road experiment verified that our proposed method could achieve more accurate navigation resolutions than the compared ones. Full article

Aiming at the problem of fast divergence of pure inertial navigation system without correction under the condition of GNSS restricted environment, this paper proposes a multi-mode navigation method with an intelligent virtual sensor based on long short-term memory (LSTM). The training mode, predicting mode, and validation mode for the intelligent virtual sensor are designed. The modes are switching flexibly according to GNSS rejecting situation and the status of the LSTM network of the intelligent virtual sensor. Then the inertial navigation system (INS) is corrected, and the availability of the LSTM network is also maintained. Meanwhile, the fireworks algorithm is adopted to optimize the learning rate and the number of hidden layers of LSTM hyperparameters to improve the estimation performance. The simulation results show that the proposed method can maintain the prediction accuracy of the intelligent virtual sensor online and shorten the training time according to the performance requirements adaptively. Under small sample conditions, the training efficiency and availability ratio of the proposed intelligent virtual sensor are improved significantly more than the neural network (BP) as well as the conventional LSTM network, improving the navigation performance in GNSS restricted environment effectively and efficiently. Full article

Regardless of whether the global navigation satellite system (GNSS)/inertial navigation system (INS) is integrated or the INS operates independently during GNSS outages, the stochastic error of the inertial sensor has an important impact on the navigation performance. The structure of stochastic error in low-cost inertial sensors is quite complex; therefore, it is difficult to identify and separate errors in the spectral domain using classical stochastic error methods such as the Allan variance (AV) method and power spectral density (PSD) analysis. However, a recently proposed estimation, based on generalized wavelet moment estimation (GMWM), is applied to the stochastic error modeling of inertial sensors, giving significant advantages. Focusing on the online implementation of GMWM and its integration within a general navigation filter, this paper proposes an algorithm for online stochastic error calibration of inertial sensors in urban cities. We further develop the autonomous stochastic error model by constructing a complete stochastic error model and determining model ranking criterion. Then, a detecting module is designed to work together with the autonomous stochastic error model as feedback for the INS/GNSS integration. Finally, two experiments are conducted to compare the positioning performance of this algorithm with other classical methods. The results validate the capability of this algorithm to improve navigation accuracy and achieve the online realization of complex stochastic models. Full article

An autonomous navigation method based on the fusion of INS (inertial navigation system) measurements with the line-of-sight (LOS) observations of space targets is presented for unmanned aircrafts. INS/GNSS (global navigation satellite system) integration is the conventional approach to achieving the long-term and high-precision navigation of unmanned aircrafts. However, the performance of INS/GNSS integrated navigation may be degraded gradually in a GNSS-denied environment. INS/CNS (celestial navigation system) integrated navigation has been developed as a supplement to the GNSS. A limitation of traditional INS/CNS integrated navigation is that the CNS is not efficient in suppressing the position error of the INS. To solve the abovementioned problems, we studied a novel integrated navigation method, where the position, velocity and attitude errors of the INS were corrected using a star camera mounted on the aircraft in order to observe the space targets whose absolute positions were available. Additionally, a QLEKF (Q-learning extended Kalman filter) is designed for the performance enhancement of the integrated navigation system. The effectiveness of the presented autonomous navigation method based on the star camera and the IMU (inertial measurement unit) is demonstrated via CRLB (Cramer–Rao lower bounds) analysis and numerical simulations. Full article

In the fields of positioning and navigation, the integrated inertial navigation system (INS)/global navigation satellite systems (GNSS) are frequently employed. Currently, high-precision INS typically utilizes fiber optic gyroscopes (FOGs) and quartz flexural accelerometers (QFAs) rather than MEMS sensors. But when GNSS signals are not available, the errors of high-precision INS also disperse rapidly, similar to MEMS-INS when GNSS signals would be unavailable for a long time, leading to a serious degradation of the navigation accuracy. This paper presents a new AI-assisted method for the integrated high-precision INS/GNSS navigation system. The position increments during GNSS outage are predicted by the convolutional neural network-gated recurrent unit (CNN-GRU). In the process, the CNN is utilized to quickly extract the multi-dimensional sequence features, and GRU is used to model the time series. In addition, a new real-time training strategy is proposed for practical application scenarios, where the duration of the GNSS outage time and the motion state information of the vehicle are taken into account in the training strategy. The real road test results verify that the proposed algorithm has the advantages of high prediction accuracy and high training efficiency. Full article

Aircraft flying the trans-arctic routes usually apply inertial navigation mechanization in two different navigation frames, e.g., the local geographic frame and the grid frame. However, this change of navigation frame will cause filter overshoot and error discontinuity. To solve this problem, taking the inertial navigation system/global navigation satellite system (INS/GNSS) integrated navigation system as an example, an integrated navigation method based on covariance transformation is proposed. The relationship of the system error state between different navigation frames is deduced as a means to accurately convert the Kalman filter’s covariance matrix. The experiment and semi-physical simulation results show that the presented covariance transformation algorithm can effectively solve the filter overshoot and error discontinuity caused by the change of navigation frame. Compared with non-covariance transformation, the system state error is thereby reduced significantly. Full article

Automated driving has made considerable progress recently. The multisensor fusion system is a game changer in making self-driving cars possible. In the near future, multisensor fusion will be necessary to meet the high accuracy needs of automated driving systems. This paper proposes a multisensor fusion design, including an inertial navigation system (INS), a global navigation satellite system (GNSS), and light detection and ranging (LiDAR), to implement 3D simultaneous localization and mapping (INS/GNSS/3D LiDAR-SLAM). The proposed fusion structure enhances the conventional INS/GNSS/odometer by compensating for individual drawbacks such as INS-drift and error-contaminated GNSS. First, a highly integrated INS-aiding LiDAR-SLAM is presented to improve the performance and increase the robustness to adjust to varied environments using the reliable initial values from the INS. Second, the proposed fault detection exclusion (FDE) contributes SLAM to eliminate the failure solutions such as local solution or the divergence of algorithm. Third, the SLAM position velocity acceleration (PVA) model is used to deal with the high dynamic movement. Finally, an integrity assessment benefits the central fusion filter to avoid failure measurements into the update process based on the information from INS-aiding SLAM, which increases the reliability and accuracy. Consequently, our proposed multisensor design can deal with various situations such as long-term GNSS outage, deep urban areas, and highways. The results show that the proposed method can achieve an accuracy of under 1 meter in challenging scenarios, which has the potential to contribute the autonomous system. Full article

Aiming to improve the navigation accuracy during global navigation satellite system (GNSS) outages, an algorithm based on long short-term memory (LSTM) is proposed for aiding inertial navigation system (INS). The LSTM algorithm is investigated to generate the pseudo GNSS position increment substituting the GNSS signal. Almost all existing INS aiding algorithms, like the multilayer perceptron neural network (MLP), are based on modeling INS errors and INS outputs ignoring the dependence of the past vehicle dynamic information resulting in poor navigation accuracy. Whereas LSTM is a kind of dynamic neural network constructing a relationship among the present and past information. Therefore, the LSTM algorithm is adopted to attain a more stable and reliable navigation solution during a period of GNSS outages. A set of actual vehicle data was used to verify the navigation accuracy of the proposed algorithm. During 180 s GNSS outages, the test results represent that the LSTM algorithm can enhance the navigation accuracy 95% compared with pure INS algorithm, and 50% of the MLP algorithm. Full article
