Search Results (175)

This article presents a dynamic calibration procedure for triaxial accelerometers characterized by a very simple and low-cost setup, where the calibration bench consists of a vertically, freely rotating wheel. To keep the setup as simple as possible, the necessary prior knowledge about the geometry and the motion of the bench has been minimized: the only required constraint is the verticality of the rotation plane, which can be simply achieved in practice by means of a level tool. No prior knowledge is required about the bench rotation, as the calibration procedure estimates both the accelerometer parameters and the bench motion. The precision achieved by the proposed calibration has been tested on synthetic data to prove the absence of estimation biases and to evaluate the potential accuracy, and on real data (from a MEMS accelerometer) to evaluate the achievable precision. Full article

The weighted averaging algorithm is a widely adopted high-efficiency data fusion approach for micro-electro-mechanical system (MEMS) inertial measurement unit (IMU) array, where the configuration of weighting coefficients plays a critical role in improving measurement accuracy. In this study, an optimal weighted averaging algorithm based on the fruit fly optimization algorithm (FOA) is proposed by analyzing the data fusion mechanism of the MEMS IMU array. Firstly, a measurement model for the MEMS IMU array is constructed, and the principles of data fusion are systematically investigated. Secondly, the optimal weighting coefficients under ideal conditions are derived, and their limitations in practical applications are discussed. Building on this framework, the FOA is employed to search for optimal weights, enabling the realization of high-precision weighted averaging fusion. Simulation and experimental results demonstrate that the proposed method outperforms conventional approaches in terms of accuracy and robustness. Full article

This work devised an on-device learning approach to self-calibrate Micro-Electro-Mechanical Systems-based Inertial Measurement Units (MEMS-IMUs), integrating a digital signal processor (DSP), an accelerometer, and a gyroscope in the same package. The accelerometer and gyroscope stream their data in real time to the DSP, which runs artificial intelligence (AI) workloads. The real-time sensor data are subject to errors, such as time-varying bias and thermal stress. To compensate for these drifts, the traditional calibration method based on a linear model is applicable, and unfortunately, it does not work with nonlinear errors. The algorithm devised by this study to reduce such errors adopts Radial Basis Function Neural Networks (RBF-NNs). This method does not rely on the classical adoption of the backpropagation algorithm. Due to its low complexity, it is deployable using kibyte memory and in software runs on the DSP, thus performing interleaved in-sensor learning and inference by itself. This avoids using any off-package computing processor. The learning process is performed periodically to achieve consistent sensor recalibration over time. The devised solution was implemented in both 32-bit floating-point data representation and 16-bit quantized integer version. Both of these were deployed into the Intelligent Sensor Processing Unit (ISPU), integrated into the LSM6DSO16IS Inertial Measurement Unit (IMU), which is a programmable 5–10 MHz DSP on which the programmer can compile and execute AI models. It integrates 32 KiB of program RAM and 8 KiB of data RAM. No permanent memory is integrated into the package. The two (fp32 and int16) RBF-NN models occupied less than 21 KiB out of the 40 available, working in real-time and independently in the sensor package. The models, respectively, compensated between 46% and 95% of the accelerometer measurement error and between 32% and 88% of the gyroscope measurement error. Finally, it has also been used for attitude estimation of a micro aerial vehicle (MAV), achieving an error of only 2.84°. Full article

Lakes are complex ecosystems affected by various anthropogenic influences, including vessel-induced waves. Detecting these waves by a micro-electro-mechanical system (MEMS)-based inertial measurement unit (IMU) equipped on a buoy-based monitoring system can help assess their impacts and support developing sustainable water ecosystem management. This study evaluated and optimized the measurement accuracy of a wave-monitoring system designed to detect waves generated by recreational vessels on lakes. In laboratory tests, we analyzed and, separately, compared the hydraulic behavior of different buoy configurations and assessed the IMU integration in field test campaigns. Results showed that all tested buoys exhibited a mean average absolute deviation (AAD) of less than 20 mm, while the IMU integration achieved an overall AAD of $1.9$ mm. For small waves, characterized by wave heights < 50 mm, the IMU’s AAD corresponds to the buoy’s AAD. However, for larger waves, the buoy’s AAD often significantly exceeds that of the IMU, indicating that the hydraulic performance of the buoy limits measurement accuracy in case of greater waves. The best-performing buoy configuration in laboratory tests achieved a measurement accuracy (mean AAD) below 10 mm (or $10\%$ of wave height), confirming the suitability of the developed wave buoys for a vessel-induced wave-monitoring system on lakes. Full article

In-motion alignment is a critical step in obtaining the initial state of an integrated navigation system. This article considers the in-motion initial alignment problem using the multilocal linearization detection method. In contrast to the OBA-based method, which fully relies on satellite signals to estimate the initial state of the Kalman filter, the proposed method utilizes the designed quasi-uniform quaternion generation method to estimate several possible initial states. Then, the proposed method selects the most probable result based on the generalized Schweppe likelihood ratios among multiple hypotheses. The experiment result of the proposed method demonstrates the advantage of estimation performance within poor-quality measurement conditions for the long-duration coarse alignment using MEMS-IMU compared with the OBA-based method. The proposed method has potential applications in alignment tasks for low-cost, small-scale vehicle navigation systems. Full article

The aging population has created a significant challenge affecting the world; social and healthcare systems need to ensure elderly individuals receive the necessary care services to improve their quality of life and maintain their independence. In response to this need, developing integrated digital solutions, such as IoT based wearable devices combined with artificial intelligence applications, offers a technological platform for creating Ambient Intelligence (AI) and Assisted Living (AAL) environments. These advancements can help reduce hospital admissions and lower healthcare costs. In this context, this article presents an IoT application based on MEMS (micro electro-mechanical systems) sensors integrated into a state-of-the-art microcontroller (STM55WB) for recognizing the movements of older individuals during daily activities. human activity recognition (HAR) is a field within computational engineering that focuses on automatically classifying human actions through data captured by sensors. This study has multiple objectives: to recognize movements such as grasping, leg flexion, circular arm movements, and walking in order to assess the motor skills of older individuals. The implemented system allows these movements to be detected in real time, and transmitted to a monitoring system server, where healthcare staff can analyze the data. The analysis methods employed include machine learning algorithms to identify movement patterns, statistical analysis to assess the frequency and quality of movements, and data visualization to track changes over time. These approaches enable the accurate assessment of older people’s motor skills, and facilitate the prompt identification of abnormal situations or emergencies. Additionally, a user-friendly technological solution is designed to be acceptable to the elderly, minimizing discomfort and stress associated with using technology. Finally, the goal is to ensure that the system is energy-efficient and cost-effective, promoting sustainable adoption. The results obtained are promising; the model achieved a high level of accuracy in recognizing specific movements, thus contributing to a precise assessment of the motor skills of the elderly. Notably, movement recognition was accomplished using an artificial intelligence model called Random Forest. Full article

For Measurement While Drilling (MWD), the redundant Micro-Electro-Mechanical Systems Inertial Measurement Unit (MEMS-IMU) navigation system significantly enhances the reliability and accuracy of drill string attitude measurements. Such an enhancement enables precise control of the wellbore trajectory and enhances the overall quality of drilling operations. But installation errors of the redundant MEMS-IMUs still degrade the accuracy of drill string attitude measurements. It is essential to calibrate these errors to ensure measurement precision. Currently, the commonly used calibration method involves mounting the carrier on a horizontal plane and performing calibration through rotation. However, when the carrier rotates on the horizontal plane, the gravity acceleration component sensed by the horizontal axis of the IMU accelerometer in the carrier is very small, which leads to a low signal-to-noise ratio, so that the measured matrix obtained by the solution is dominated by noise. As a result, the accuracy of the installation is insufficient, and, finally, the effectiveness of the installation error compensation is reduced. In order to solve this problem, this study proposes a 45°-inclined six-position calibration method based on the selected hexagonal prism redundant structure for redundant MEMS-IMUs in MWD. Firstly, the compensation matrices and accelerometer measurement errors were analyzed, and the new calibration method was proposed; the carrier of the IMUs should be installed at an inclined position of 45°. Then, six measuring points were identified for the proposed calibration approach. Finally, simulation and laboratory experiments were conducted to verify the effectiveness of the proposed method. The simulation results showed that the proposed method reduced installation errors by 40.4% compared with conventional methods. The experiments’ results demonstrated reductions of 83% and 68% in absolute measurement errors for the x and y axes, respectively. As a result, sensor accuracy after compensation improved by over 25% compared with traditional methods. The calibration method proposed by this study effectively improves the accuracy of redundant systems, providing a new approach for the precise measurement of downhole trajectories. Full article

This study introduces an enhanced ORB-SLAM3 algorithm to address the limitations of traditional visual SLAM systems in feature extraction and localization accuracy within the challenging terrains of open-pit mining environments. It also tackles the issue of sparse point cloud maps for mobile robot navigation. By combining point-line features with a Micro-Electro-Mechanical System (MEMS) Inertial Measurement Unit (IMU), the algorithm improves the feature matching’s reliability, particularly in low-texture areas. The method integrates dense point cloud mapping and an octree structure, optimizing both navigation and path planning while reducing storage demands and improving query efficiency. The experimental results using the TUM dataset and conducting tests in a simulated open-pit mining environment show that the proposed algorithm reduces the absolute trajectory error by 44.33% and the relative trajectory error by 14.34% compared to the ORB-SLAM3. The algorithm generates high-precision dense point cloud maps and uses an octree structure for efficient 3D spatial representation. In simulated open-pit mining scenarios, the dense mapping outperforms at reconstructing complex terrains, especially in low-texture gravel and uneven surfaces. These results highlight the robustness and practical applicability of the algorithm in dynamic and challenging environments, such as open-pit mining. Full article

The mechatronic design approach to robotics deploys, inter alia, widely available mechanical design engineering tools that, together with standard production techniques, allow the accurate quantification of the system’s mass properties. While this enables the synthesis of model-based centralized controllers, friction still limits the achievable dynamic performances, as its prediction at the design stage is hampered by complex dependencies on loads, temperature, wear, and lubrication. Further uncertainties affecting mechatronic devices stem from the actuation systems, whose parameters are specified by the manufacturer with relatively loose accuracy. These challenges are addressed here through a method based on MEMS IMUs for the real-time estimation of both friction effects and uncertain actuator parameters. The resulting model, inclusive of the frictionless dynamics, is applied in a closed loop to improve the control performance. An experimental comparison with decentralized and non-adaptive regulators highlights severalfold reductions in tracking errors; the ability to track temperature-dependent friction variations is also shown. From this work, it may be concluded that the use of MEMS sensors, together with identification and adaptive control algorithms, sensibly increases the dynamic performance of robotic systems. The real-time properties of the method also enable future investigations into topics such as MEMS-based diagnostics and predictive maintenance. Full article

This paper presents a heading alignment procedure for drone navigation employing a single hover GNSS antenna combined with low-grade MEMs-IMU sensors. The design was motivated by the need for a drone-mounted differential interferometric SAR (DinSAR) application. Still, the methodology proposed here applies to any Unmanned Aerial Vehicle (UAV) application that requires high-precision navigation data for short-flight missions utilizing cost-effective MEMs sensors. The method proposed here involves a Bayesian parameter estimation based on a simultaneous cumulative Mahalanobis metric applied to the innovation process of Kalman-like filters, which are identical except for the initial heading guess. The procedure is then generalized to multidimensional parameters, thus called parametric alignment, referring to the fact that the strategy applies to alignment problems regarding some parameters, such as the heading initial value. The motivation for the multidimensional extension in the scenario is also presented. The method is highly applicable for cases where gyro-compassing is not available. It employs the most straightforward optimization techniques that can be implemented using a real-time parallelism scheme. Experimental results obtained from a real UAV mission demonstrate that the proposed method can provide initial heading alignment when the heading is not directly observable during takeoff, while numerical simulations are used to illustrate the extension to the multidimensional case. Full article

Inertial navigation systems (INSs) provide autonomous position estimation capabilities independent of global navigation satellite systems (GNSSs). However, the high cost of traditional sensors, such as fiber-optic gyroscopes (FOGs), limits their widespread adoption. In contrast, micro-electromechanical system (MEMS)-based inertial measurement units (IMUs) offer a low-cost alternative; however, their lower accuracy and sensor bias issues, particularly in maritime environments, remain considerable obstacles. This study proposes an improved method for bias estimation by comparing the estimated values from a trajectory generator (TG)-based acceleration and angular-velocity estimation system with actual measurements. Additionally, for X- and Y-axis accelerations, we introduce a method that leverages the correlation between altitude differences derived from an INS/GNSS/gyrocompass (IGG) and those obtained during the TG estimation process to estimate the bias. Simulation datasets from experimental voyages validate the proposed method by evaluating the mean, median, normalized cross-correlation, least squares, and fast Fourier transform (FFT). The Butterworth filter achieved the smallest angular-velocity bias estimation error. For X- and Y-axis acceleration bias, altitude-based estimation achieved differences of 1.2 × 10⁻² m/s² and 1.0 × 10⁻⁴ m/s², respectively, by comparing the input bias using 30 min data. These methods enhance the positioning and attitude estimation accuracy of low-cost IMUs, providing a cost-effective maritime navigation solution. Full article

Researchers are currently conducting several studies in the field of navigation systems and sensors. Even in the past, there was a lot of research regarding the field of velocity sensors for unmanned underwater vehicles (UUVs). UUVs have various services and significance in the military, scientific research, and many commercial applications due to their autonomy mechanism. So, it’s very crucial for the proper maintenance of the navigation system. Reliable navigation of unmanned underwater vehicles depends on the quality of their state determination. There are so many navigation systems available, like position determination, depth information, etc. Among them, velocity determination is now one of the most important navigational criteria for UUVs. The key source of navigational aids for different deep-sea research projects is water currents. These days, many different sensors are available to monitor the UUV’s velocity. In recent times, there have been five primary types of sensors utilized for UUV velocity forecasts. These include Doppler Velocity Logger sensors, paddlewheel sensors, optical sensors, electromagnetic sensors, and ultrasonic sensors. The most popular sensing sensor for estimating velocity at the moment is the Doppler Velocity Logger (DVL) sensor. DVL sensor is the most fully developed sensor for UUVs in recent years. In this work, we offer an overview of the field of navigation systems and sensors (especially velocity) developed for UUVs with respect to their use with tidal current sensing in the UUV setting, including their history, evolution, current research initiatives, and anticipated future. Full article

According to South Korea’s Ministry of Employment and Labor, approximately 25,000 construction workers suffered from various injuries between 2015 and 2019. Additionally, about 500 fatalities occur annually, and multiple studies are being conducted to prevent these accidents and quickly identify their occurrence to secure the golden time for the injured. Recently, AI-based video analysis systems for detecting safety accidents have been introduced. However, these systems are limited to areas where CCTV is installed, and in locations like construction sites, numerous blind spots exist due to the limitations of CCTV coverage. To address this issue, there is active research on the use of MEMS (micro-electromechanical systems) sensors to detect abnormal conditions in workers. In particular, methods such as using accelerometers and gyroscopes within MEMS sensors to acquire data based on workers’ angles, utilizing three-axis accelerometers and barometric pressure sensors to improve the accuracy of fall detection systems, and measuring the wearer’s gait using the x-, y-, and z-axis data from accelerometers and gyroscopes are being studied. However, most methods involve use of MEMS sensors embedded in smartphones, typically attaching the sensors to one or two specific body parts. Therefore, in this study, we developed a novel miniaturized IMU (inertial measurement unit) sensor that can be simultaneously attached to multiple body parts of construction workers (head, body, hands, and legs). The sensor integrates accelerometers, gyroscopes, and barometric pressure sensors to measure various worker movements in real time (e.g., walking, jumping, standing, and working at heights). Additionally, incorporating PPG (photoplethysmography), body temperature, and acoustic sensors, enables the comprehensive observation of both physiological signals and environmental changes. The collected sensor data are preprocessed using Kalman and extended Kalman filters, among others, and an algorithm was proposed to evaluate workers’ safety status and update health-related data in real time. Experimental results demonstrated that the proposed IMU sensor can classify work activities with over 90% accuracy even at a low sampling rate of 15 Hz. Furthermore, by integrating internal filtering, communication modules, and server connectivity within an application, we established a cyber–physical system (CPS), enabling real-time monitoring and immediate alert transmission to safety managers. Through this approach, we verified improved performance in terms of miniaturization, measurement accuracy, and server integration compared to existing commercial sensors. Full article

Drainage pipelines face significant threats to underground safety due to external defects. Ground Penetrating Radar (GPR) is a primary tool for detecting such defects from within the pipeline. However, existing methods are limited to single or multiple axial scan lines, which cannot provide the precise spatial coordinates of the defects. To address this limitation, this study introduces a novel GPR-based drainage pipeline inspection robot system integrated with multiple sensors. The system incorporates MEMS-IMU, encoder modules, and ultrasonic ranging modules to control the GPR antenna for axial and circumferential scanning. A novel Cross-Line Fusion of GPR (CLF-GPR) method is introduced to integrate axial and circumferential scan data for the precise localization of external pipeline defects. Laboratory simulations were performed to assess the effectiveness of the proposed technology and method, while its practical applicability was further validated through real-world drainage pipeline inspections. The results demonstrate that the proposed approach achieves axial positioning errors of less than 2.0 cm, spatial angular positioning errors below 2°, and depth coordinate errors within 2.3 cm. These findings indicate that the proposed approach is reliable and has the potential to support the transparency and digitalization of urban underground drainage networks. Full article

The accuracy of satellite positioning results depends on the number of available satellites in the sky. In complex environments such as urban canyons, the effectiveness of satellite positioning is often compromised. To enhance the positioning accuracy of low-cost sensors, this paper combines the visual odometer data output by Xtion with the GNSS/IMU integrated positioning data output by the satellite receiver and MEMS IMU both in the mobile phone through adaptive Kalman filtering to improve positioning accuracy. Studies conducted in different experimental scenarios have found that in unobstructed environments, the RMSE of GNSS/IMU/visual fusion positioning accuracy improves by 50.4% compared to satellite positioning and by 24.4% compared to GNSS/IMU integrated positioning. In obstructed environments, the RMSE of GNSS/IMU/visual fusion positioning accuracy improves by 57.8% compared to satellite positioning and by 36.8% compared to GNSS/IMU integrated positioning. Full article
