The shape memory capabilities of Heusler alloy microwires with two different contents of Fe element instead of Ga element following step-by-step ordering heat treatment were explored based on the stoichiometric ratio of Ni₂MnGa. The melt-drawing technique was used to create the polycrystalline microwires, and the two microwires had Fe atomic contents of 4.7 at.% and 5.5 at.%, respectively. The field emission scanning electron microscope was used to analyze the microwire’s surface condition as well as the microscopic tensile fracture morphology. Using an X-ray diffractometer, the microwires’ crystal structure was identified for phase analysis. Differential scanning calorimetry was used to examine the microwires’ behavior during martensitic transformation. Using a dynamic mechanical stretcher, the elongation and recovery rate of microwires’ one- and two-way shape memory behavior were examined. The findings demonstrated that the microwire phase structure, martensitic transformation behavior, and shape memory capabilities all displayed good properties after the heat treatment was ordered. Full article

In the present paper, we present an electron magnetic resonance (EMR) study of ${\mathrm{Ni}}_{50.2}{\mathrm{Mn}}_{28.3}{\mathrm{Ga}}_{21.5}$ powders obtained from melt-spun ribbons in the milling process. We registered EMR spectra in various temperatures at the X-band. In the EMR spectra recorded for the samples taken at the beginning of the milling process, the “training effect” was observed. After 2 h of milling, this phenomenon was no longer observed. To determine the basic EMR parameters, such as linewidth, resonance field, and asymmetry parameters, the experimental data were fitted using a single metallic Lorentz line. In high-temperature regions, we observed the influence of dispersion on the shape of the spectra, but as the temperature decreased, the asymmetry of line was reduced. The shift in the resonance field value at high temperatures and the temperature dependence of the linewidth below Curie temperature indicate that the investigated samples exhibited a characteristics of a spin-glass alloy. Full article

The structural, magnetocaloric, and magnetic characteristics in Heusler Ni₅₀Mn₃₅In₁₀X₅ (X = Ga, Fe, and Al) alloys were examined using X-ray diffraction and field-dependent magnetization measurements. All samples exhibited a mixture structure of cubic L2₁ and tetragonal L1₀ and underwent second-order magnetic transitions at T_C(Al5) = 220 K, T_C(Ga5) = 252 K, and T_C(Fe5) = 298 K. The Ga5 alloy exhibited structural change as indicated by a thermal hysteresis that may be seen in the saturation magnetic field in the M(T) dependences. The transition at the T_C point from a ferromagnetic to a paramagnetic state caused a drop in magnetization, supported by thermal hysteresis, at a low magnetic field (0.01 T). On the other hand, the Fe5 alloy presented a gradual decrease in magnetization with similar hysteresis behavior, also at a low magnetic field (0.01 T), whereas at 0.1 T of field, no features characteristic of this transition were detected. This could be due to a large difference in the metallic radius of Fe compared to that of In. Otherwise, magnetic investigations demonstrated that the replacement of In with Al may cause the structural transformation temperatures and T_C to be shifted to low temperatures. The present results imply that the structural transformation temperatures and the transition itself are highly dependent on chemical composition. Furthermore, under a magnetic field change of 5 T, the maximum magnetic entropy changes of 0.6 J/kg K, 1.4 J/kg K, and 2.71 J/kg K for the Ga5, Fe5, and Al5 alloys, respectively, were determined by their T_C. Refrigeration capacity values were found to be 25 J/kg, 74 J/kg, and 98 J/kg at µ₀∆H = 5 T. These ribbons are viable candidates for multifunctional applications due to their cheaper cost and their physical characteristics disclosed during the magnetostructural transition, which takes place close to the room temperature. Full article

The structure of a material is an important factor in determining its physical properties. Here, we adjust the structure of the Ni₅₀Mn₃₇Ga₁₃ spun ribbons by changing the wheel speed to regulate the exchange bias effect of the material. The characterization results of micromorphology and structure show that as the wheel speed increases, the martensite lath decreases from 200 nm to 50 nm, the structure changed from the NM to a NM and 10M mixed martensitic structure containing mainly NM, then changed to NM and 10M where 10M and NM are approaching. Meanwhile, H_E first increased and then decreased as the wheel speed increased. The optimum exchange bias effect (H_E = 7.2 kOe) occurs when the wheel speed is 25 m∙s⁻¹, mainly attributed to the enhanced ferromagnetism caused by part of 10M in NM martensite, which enhanced the exchange coupling of ferromagnetism and antiferromagnetism. This work reveals the structural dependence of exchange bias and provides a way to tune the magnitude of the exchange bias of Heusler alloys. Full article

Ni–Mn-based Heusler alloys are known to demonstrate magnetic shape memory and giant magnetocaloric effect (MCE). These effects depend on the phases, crystallographic and magnetic phase transitions, and the crystallographic texture characteristics. These structural characteristics, in turn, are a function of the processing parameters. In the current work, Ni_55.5Mn_18.8Ga₂₄Si_1.7 Heusler alloy was processed by melt-spinning under a helium atmosphere. This process results in a fine microstructure. The ribbon that was produced with a narrower nozzle width, faster wheel speed, and higher cast temperature, indicating a faster cooling rate, had double the magnetic entropy change close to room temperature. However, the other ribbon demonstrated a large entropy change over a broader temperature range, extending its usability. The effect of the melt-spinning process parameters on the developing microstructure, crystallographic structure and texture, transformation temperatures, and the magnetic entropy change were studied to explain the difference in magnetocaloric behavior. Full article

The magnetic domain structures and martensite microstructures of porous Ni₂MnGa Heusler alloys with various circle-shaped and ellipse-shaped pores were systematically studied by the phase field method. The magnetization curves and magnetic field-induced strains (MFIS) at the external field were determined. A mesoscopic mechanism was proposed for simulation to reveal the influence of the pores on the microstructures and the MFIS of porous magnetic shape memory alloy. The stress concentration effect and the recovery strain of the porous alloy are studied. The results indicate the MFIS value increases when ellipse-shaped pores elongate along the twin boundary. The effects of porosity and pore size on MFIS for porous Ni-Mn-Ga alloys with randomly distributed pores were also explored. The present study is of guiding significance for understanding the role played by pores on the MFIS and may provide a possible way to adjust the functional properties of ferromagnetic shape memory alloys. Full article

In this study, magnetostriction measurements were performed on the ferromagnetic Heusler alloy, Ni₂MnGa_0.88Cu_0.12, which is characterized by the occurrence of the martensitic phase and ferromagnetic transitions at the same temperature. In the austenite and martensite phases, the alloy crystallizes in the L2₁ and D0₂₂-like crystal structure, respectively. As the crystal structure changes at the martensitic transition temperature (T_M), a large magnetostriction due to the martensitic and ferromagnetic transitions induced by magnetic fields is expected to occur. First, magnetization (M-H) measurements are performed, and metamagnetic transitions are observed in the magnetic field of μ₀H = 4 T at 344 K. This result shows that the phase transition was induced by the magnetic field under a constant temperature. Forced magnetostriction measurements (ΔL/L) are then performed under a constant temperature and atmospheric pressure (P = 0.1 MPa). Magnetostriction up to 1300 ppm is observed around T_M. The magnetization results and magnetostriction measurements showed the occurrence of the magnetic-field-induced strain from the paramagnetic austenite phase to the ferromagnetic martensite phase. As a reference sample, we measure the magnetostriction of the Ni₂MnGa-type (Ni₅₀Mn₃₀Ga₂₀) alloy, which causes the martensite phase transition at T_M = 315 K. The measurement of magnetostriction at room temperature (298 K) showed a magnetostriction of 3300 ppm. The magnetostriction of Ni₂MnGa_0.88Cu_0.12 is observed to be one-third that of Ni₅₀Mn₃₀Ga₂₀ but larger than that of Terfenol-D (800 ppm), which is renowned as the giant magnetostriction alloy. Full article

We present the design, simulation, and characterization of a magnetic shape-memory alloy (MSMA) film actuator that transitions from bistable switching to resonant self-actuation when subjected to a stationary heat source. The actuator design comprises two Ni-Mn-Ga films of 10 µm thickness integrated at the front on either side of an elastic cantilever that moves freely between two heatable miniature permanent magnets and, thus, forms a bistable microswitch. Switching between the two states is induced by selectively heating the MSMA films above their Curie temperature Tc. When continuously heating the permanent magnets above Tc, the MSMA film actuator exhibits an oscillatory motion in between the magnets with large oscillation stroke in the frequency range of 50–60 Hz due to resonant self-actuation. A lumped-element model (LEM) is introduced to describe the coupled thermo-magnetic and magneto-mechanical performance of the actuator. We demonstrate that this performance can be used for the thermomagnetic energy generation of low-grade waste heat (T < 150 °C) with a high power output per footprint in the order of 2.3 µW/cm². Full article

Heusler alloys are subject of considerable interest because they exhibit a martensitic transformation (MT), a shape-memory effect and a giant magnetocaloric effect. As it is commonly believed, the pronounced magnetoelastic coupling plays a crucial role; however, the effect of alloy composition on MT is still under discussion. To describe the features of MT in Ni${}_{0.75-x}$Mn${}_x$Ga${}_{0.25}$ Heusler alloys, the phenomenological model that consistently considers the magnetic and lattice degrees of freedom and their mutual interplay has been developed. The magnetic entropy contribution was estimated within the framework of the microscopic approach. The proposed model allows us to describe the dependence of the martensitic transformation start temperature $M_s\left(x\right)$ on the Mn concentration x in reasonable agreement with the experiment. Full article

In this article, a microstructural model of the Heusler alloy with the shape memory effect caused by the application of an external magnetic field is constructed. The dynamics of the magnetization process are described using the Landau–Lifshitz–Gilbert equation. For the numerical implementation of the model using the finite element method, the variational equations corresponding to the differential formulation of the magnetic problem are used. Such an approach makes it possible to reduce (weaken) the requirements for the smoothness of the sought solution. The problem of magnetization of single crystals of the Ni₂MnGa alloy, which has a “herringbone”-type martensitic structure (a twinned variant of martensite), is considered. In each element of the twin, the magnetic domains with walls of a certain thickness are formed. The motion and interaction of these walls and the rotation of magnetization vector in the walls and domains under the action of the external differently directed magnetic fields are studied. These processes in the Heusler alloy are also accompanied by the detwinning process. A condition for the detwinning of a ferromagnetic shape memory alloy in a magnetic field is proposed, and the effect of the reorientation (detwinning) of martensitic variants forming a twin on the magnetization of the material and the occurrence of structural (detwinning) deformation in it are taken into account. First, the processes of magnetization and structural deformation in a single grain are considered at different angles between the anisotropy axes of twinned variants and the external magnetic field. For these cases, the magnetization curves are constructed, and the deformed states are identified. The model described such experimental facts as the detwinning process and the jump in magnetization on these curves as a result of this process. It was shown that the jump occurred at a certain magnitude of the strength of the applied external magnetic field and a certain direction of its action relative to the twinning system. Then, based on the obtained results, deformed states arising due to the detwinning process were determined for various (isotropic and texture-oriented) polycrystalline samples, and magnetization curves taking into account this process were constructed for these materials. Full article

In this article, based on the theory of micromagnetism, a microstructural model of the behavior of the Heusler alloy in a magnetic field is constructed. The dynamics of the magnetic process is described by the Landau–Lifshitz–Gilbert equation. Using the Galerkin procedure, variational equations corresponding to the differential relations of the magnetic problem are written out. For numerical simulation, we consider the problem of magnetization of a Ni${}_2$MnGa alloy polytwin crystals, each grain of which is a twinned variant of martensite and has pronounced anisotropic properties. First, we consider the process of magnetization of a single grain, when an external magnetic field is applied at different angles to the anisotropy axes of twinned variants, and then, based on the results obtained, we plot magnetization curves for various (isotropic and texture-oriented) polycrystalline samples. This paper does not consider the process of detwinning, which can occur in such a material during the magnetization at a sufficiently high external field strength. Full article

Fully compensated ferrimagnets do not create any magnetic stray field and allow for a completely polarized current of charges. As a result, these alloys show promising prospects for applications as spintronic devices. In this paper, we investigated the phase stability, the site preference, the tetragonal distortion and the influence of symmetry from the crystal structure and chemical environments of magnetic ions on the magnetic properties of Cr₂YZ and Mn₂YZ (Y = void, Ni, Cu, and Zn; Z = Ga, Ge, and As) full Heusler alloys by first-principles calculations. We found that the selected Cr₂-based alloys, except for Cr₂NiGa and Cr₂NiGe, prefer to crystallize in the centrosymmetric L2₁-type structure, while the selected Mn₂-based alloys, except for Mn₂CuAs, Mn₂ZnGe and Mn₂ZnAs, tend to crystallize in the non-centrosymmetric XA-type structure. Due to the symmetry, the antiferromagnetism of the selected L2₁-type alloys is very stable, and no spin-polarized density of states could be generated. In contrast, the magnetic moment of the selected XA-type alloys depends heavily on the number of valence electrons and tetragonal distortion, and spin-polarized density of states is generated. Therefore, the selected alloys with L2₁-type structures and their tetragonal-distorted structure are potential candidates for conventional antiferromagnets, while those with XA-type structure and their tetragonal-distorted structure are promising candidates for (fully) compensated ferrimagnets. Full article

Ni–Mn–Ga Heusler alloys are multifunctional materials that demonstrate macroscopic strain under an externally applied magnetic field through the motion of martensite twin boundaries within the microstructure. This study sought to comprehensively characterize the microstructural, mechanical, thermal, and magnetic properties near the solidus in binder-jet 3D printed 14M Ni₅₀Mn₃₀Ga₂₀. Neutron diffraction data were analyzed to identify the martensite modulation and observe the grain size evolution in samples sintered at temperatures of 1080 °C and 1090 °C. Large clusters of high neutron-count pixels in samples sintered at 1090 °C were identified, suggesting Bragg diffraction of large grains (near doubling in size) compared to 1080 °C sintered samples. The grain size was confirmed through quantitative stereology of polished surfaces for differently sintered and heat-treated samples. Nanoindentation testing revealed a greater resistance to plasticity and a larger elastic modulus in 1090 °C sintered samples (relative density ~95%) compared to the samples sintered at 1080 °C (relative density ~80%). Martensitic transformation temperatures were lower for samples sintered at 1090 °C than 1080 °C, though a further heat treatment step could be added to tailor the transformation temperature. Microstructurally, twin variants ≤10 μm in width were observed and the presence of magnetic anisotropy was confirmed through magnetic force microscopy. This study indicates that a 10 °C sintering temperature difference can largely affect the microstructure and mechanical properties (including elastic modulus and hardness) while still allowing for the presence of magnetic twin variants in the resulting modulated martensite. Full article

Structural and phase transformations in the microstructure and new metastable baro- and deformation-induced phases of the Ni₅₀Mn_28.5Ga_21.5 alloy, typical of the unique class of ferromagnetic shape memory Heusler alloys, have been systematically studied for the first time. Phase X-ray diffraction analysis, transmission and scanning electron microscopy, and temperature measurements of electrical resistivity and magnetic characteristics in strong magnetic fields were used. It was found that in the course of increasing the pressure from 3 to 12 GPa, the metastable long-period structure of martensite modulated according to the 10M-type experienced transformation into a final non-modulated 2M structure. It is proved that severe shear deformation by high pressure torsion (HPT) entails grainsize refinement to a nanocrystalline and partially amorphized state in the polycrystalline structure of the martensitic alloy. In this case, an HPT shear of five revolutions under pressure of 3 GPa provided total atomic disordering and a stepwise structural-phase transformation (SPT) according to the scheme 10M → 2M → B2 + A2, whereas under pressure of 5 GPa the SPT took place according to the scheme 10M → 2M → B2 → A1. It is shown that low-temperature annealing at a temperature of 573 K caused the amorphous phase to undergo devitrification, and annealing at 623–773 K entailed recrystallization with the restoration of the L2₁ superstructure in the final ultrafine-grained state. The size effect of suppression of the martensitic transformation in an austenitic alloy with a critical grain size of less than 100 nm at cooling to 120 K was determined. It was established that after annealing at 773 K, a narrow-hysteresis thermoelastic martensitic transformation was restored in a plastic ultrafine-grained alloy with the formation of 10M and 14M martensite at temperatures close to those characteristic of the cast prototype of the alloy. Full article

The investigation of caloric effects linked to first-order structural transitions in Heusler-type alloys has become a subject of considerable current interest due to their potential utilization as refrigerants in solid-state cooling devices. This study is mainly motivated by the possibility of developing refrigeration devices of improved energy efficiency with a reduced environmental impact. We produced partially textured and isotropic bulk samples of the Heusler-type magnetic shape memory alloy Ni₅₅Fe₁₁Mn₇Ga₂₇ by arc melting and spark plasma sintering (SPS), respectively. Their structural, microstructural, and phase transition characteristics and magnetocaloric and elastocaloric effects, associated with first-order martensitic transformation (MT), were studied. The elemental chemical compositions of both samples were close to nominal, and a martensitic-like structural transformation appeared around room temperature with similar starting and finishing structural transition temperatures. At room temperature, austenite exhibited a highly ordered L2₁-type crystal structure. The partial grain orientation and isotropic nature of the arc-melted and SPS samples, respectively, were revealed by X-ray diffraction and SEM observations of the microstructure. For the arc-melted sample, austenite grains preferentially grew in the (100) direction parallel to the thermal gradient during solidification. The favorable effect of the texture on the elastocaloric response was demonstrated. Finally, due to its partial grain orientation, the arc-melted bulk sample showed superior values of maximum magnetic entropy change (|ΔS_M|^max = 18.6 Jkg⁻¹K⁻¹ at 5 T) and elastocaloric adiabatic temperature change (|ΔT_ad^me|^max = 2.4 K at 120 MPa) to those measured for the SPS sample (|ΔS_M|^max = 8.5 Jkg⁻¹K⁻¹ and (|ΔT_ad^me|^max = 0.8 K). Full article
