Diamond coatings with three distinct surface textures, namely spherical, pyramidal, and prismatic morphologies, were fabricated using the hot-filament chemical-vapor deposition (HFCVD) method. Scanning electron microscopy (SEM) was employed to analyze the surface morphological characteristics and differences among the coatings. Raman spectroscopic analysis further confirmed that all three diamond films exhibited excellent deposition uniformity and high crystalline quality. A three-dimensional optical microscopy system was used to measure the surface roughness values, which were determined to be Ra 0.423 μm, Ra 0.515 μm, and Ra 0.809 μm, respectively. An HFCVD diamond-coated tool was innovatively employed for the lapping of sapphire wafers, enabling a systematic investigation of the tribological behavior during the lapping process. Based on the experimental results, three morphological material removal models were established. The study demonstrates that the spherical diamond coating achieves a superior surface finish (Ra 0.22 μm) due to its continuous multi-point contact geometry, governed by the agglomerated nanocrystalline structure. Sample 3 had the highest removal rate of 24.3 μm/min. This is related to its surface morphology characteristics and is also due to the two-body contact between the diamond-coated tool and sapphire, offering a high-efficiency alternative for precision machining. Full article

Aiming at the key problems of the material removal rate and surface integrity of existing tools in the lapping of sapphire hard and brittle crystals, an efficient lapping tool has been developed to explore a new process for HFVCD (hot filament chemical vapor deposition) diamond tools to efficiently lap sapphire wafers. With the premise of ensuring the surface roughness of the wafer is Ra ≤ 0.5 μm, the material removal rate is increased to more than 1 μm/h. To explore a high-efficiency lapping process for sapphire wafers using HFCVD diamond tools. The influence of key preparation parameters on the surface characteristics of CVD (chemical vapor deposition) diamond films was systematically investigated. Three types of CVD diamond coating tools with distinct surface morphologies were fabricated. These tools were subsequently employed to conduct lapping experiments on sapphire wafers in order to evaluate their processing performance. The experimental results demonstrate that the gas pressure, methane concentration, and substrate temperature collectively influenced the surface morphology of the diamond coatings. The fabricated coatings exhibited well-defined grain boundaries and displayed pyramidal, prismatic and spherical features, corresponding to high-quality microcrystalline and nanocrystalline diamond layers. In the lapping experiments, the prismatic CVD diamond coating tool exhibited the highest material removal rate, reaching approximately 1.7 μm/min once stabilized. The spherical diamond coating tool produced the lowest surface roughness on the lapped sapphire wafers, with a value of about 0.35 μm. Surface morphology-controllable diamond tools were used for the lapping processing of the sapphire wafers. This achieved a good surface quality and high removal rate and provided new ideas for the precision machining of brittle hard materials in the plane or even in the curved surface. Full article

This study proposes a laser texturing method to optimize adhesion and minimize residual stresses in CVD diamond films deposited on tungsten carbide (WC-Co). WC-5.8 wt% Co substrates were textured with quadrangular pyramidal patterns (35 µm) using a 1064 nm nanosecond-pulsed laser, followed by chemical treatment (Murakami’s solution + aqua regia) to remove surface cobalt. Diamond films were grown via HFCVD and characterized by Raman spectroscopy, EDS, and Rockwell indentation. The results demonstrate that pyramidal texturing increased the surface area by a factor of 58, promoting effective mechanical interlocking and reducing compressive stresses to −1.4 GPa. Indentation tests revealed suppression of interfacial cracks, with propagation paths deflected toward textured regions. The pyramidal geometry exhibited superior cutting post-deposition cooling time for stress relief from 3 to 1 h. These findings highlight the potential of laser texturing for high-performance machining tool applications. Full article

This study synthesized boron-doped diamond (BDD) thin films using hot-filament chemical vapor deposition at different carbon-to-hydrogen (C/H) ratios in the range of 0.3–0.9%. The C/H ratio influence, a key parameter controlling the balance between diamond growth and hydrogen-assisted etching, was systematically investigated while maintaining other deposition parameters constant. Microstructural and electrochemical analysis revealed that increasing the C/H ratio from 0.3% to 0.7% led to a reduction in sp2-bonded carbon and enhanced the crystallinity of the diamond films. The improved conductivity under these conditions can be attributed to effective substitutional boron doping. Notably, the film deposited at a C/H ratio of 0.7% exhibited the highest electrical conductivity and the widest electrochemical potential window (2.88 V), thereby indicating excellent electrochemical stability. By contrast, at a C/H ratio of 0.9%, the excessively supplied carbon degraded the film quality and electrical and electrochemical performance, which was owing to the increased formation of sp² carbon. In addition, this led to an elevated background current and a narrowed potential window. These results reveal that precise control of the C/H ratio is critical for optimizing the BDD electrode performance. Therefore, a C/H ratio of 0.7% provides the most favorable conditions for applications in advanced oxidation processes. Full article

The growth of diamond film with texture on stainless steel can significantly improve its wear properties, while conventional methods such as laser etching and ultrasonic vibration superimposed machining suffered from complex processes and extra equipment. Here, we propose a simple new method to prepare textured diamond film on stainless steel without any special apparatus. In this method, a W/W-N interlayer was first deposited on the stainless steel surface, and then the sample with the interlayer was put into a hot filament chemical vapor deposition (HFCVD) chamber to grow diamond films. The interlayer becomes cracked during the warm-up stage due to the large tensile stress formed by the thermal expansion coefficient difference between the interlayer and the steel. Then the deposited diamond films copy the morphology of the interlayer, forming the textured diamond film. The textured diamond film exhibits a small amount of stress, ~3.4 GPa, and greatly improved wear resistance. Our results provide a way to prepare textured diamond films with good wear resistance. Full article

Hot-filament chemical vapor deposition (HFCVD) has become the most widely used ways of preparing diamond film-coated tools due to the simple equipment used, its convenient operation, and its low cost. In the production process of an actual factory, a large number of coated tools need to be prepared in batches. Factors such as the hot-filament arrangement often affect the uniformity of coating on tools, making the performance of the tools prepared in the same batch unstable. This article uses ANSYS R15.0 software software in the context of computational fluid dynamics (CFD) to calculate the temperature field in the HFCVD system, and study the effect of filament spacing on the uniformity of the temperature field of the surface of the substrate. It was found that when the distance between filaments was 14 mm, 10 mm, 10 mm, 8 mm, 8 mm, the temperature field on the surface of the substrate was the most uniform. The experiments are consistent with the results of the simulation, indicating that simulation research has practical significance. Full article

In this work, optical–structural and morphological behavior when Nd is incorporated into ZnO is studied. ZnO and Nd-doped ZnO (ZnO-Nd) films were deposited at 900 °C on Silicon n-type substrates (100) by using the Hot Filament Chemical Vapor Deposition (HFCVD) technique. For this, pellets were made by from powders of ZnO(s) and a mixture of ZnO(s):Nd(OH)₃(s). The weight percent of the mixture ZnO:Nd(OH)₃ in the pellet is 1:3. The gaseous precursor generation was carried out by chemical decomposition of the pellets using atomic hydrogen which was produced by a tungsten filament at 2000 °C. For the ZnO film, diffraction planes (100), (002), (101), (102), (110), and (103) were found by XRD. For the ZnO-Nd film, its planes are displaced, indicating the incorporation of Nd into the ZnO. EDS was used to confirm the Nd in the ZnO-Nd film with an atomic concentration (at%) of Nd = 10.79. An improvement in photoluminescence is observed for the ZnO-Nd film; this improvement is attributed to an increase in oxygen vacancies due to the presence of Nd. The important thing about this study is that by the HFCVD method, ZnO-Nd films can be obtained easily and with very short times; in addition, some oxide compounds can be obtained individually as initial precursors, which reduces the cost compared to other techniques. Something interesting is that the incorporation of Nd into ZnO by this method has not yet been studied, and depending on the method used, the PL of ZnO with Nd can increase or decrease, and by the HFCVD method the PL of the ZnO film, when Nd is incorporated, increases more than 15 times compared to the ZnO film. Full article

In this study, well-defined tungsten oxide (WO₃) nanowall (NW) thin films were synthesized via a controlled hot filament chemical vapor deposition (HFCVD) technique and applied for electrochemical detection of methylamine toxic substances. Herein, for the thin-film growth by HFCVD, the temperature of tungsten (W) wire was held constant at ~1450 °C and gasification was performed by heating of W wire using varied substrate temperatures ranging from 350 °C to 450 °C. At an optimized growth temperature of 400 °C, well-defined and extremely dense WO₃ nanowall-like structures were developed on a Si substrate. Structural, crystallographic, and compositional characterizations confirmed that the deposited WO₃ thin films possessed monoclinic crystal structures of high crystal quality. For electrochemical sensing applications, WO₃ NW thin film was used as an electrode, and cyclic voltammetry (CV) and linear sweep voltammetry (LSV) were measured with a wide concentration range of 20 μM~1 mM of methylamine. The fabricated electrochemical sensor achieved a sensitivity of ~183.65 μA mM⁻¹ cm⁻², a limit of detection (LOD) of ~20 μM and a quick response time of 10 s. Thus, the fabricated electrochemical sensor exhibited promising detection of methylamine with considerable stability and reproducibility. Full article

Production of diamond coatings on titanium substrates has demonstrated as a promising strategy for applications ranging from biosensing to hard tissue engineering. The present study focuses on monitoring the nucleation and growth of bone-like carbonated-hydroxyapatite (C-HA) on polycrystalline diamond (PCD) synthetized on titanium substrate by means of a hot filament chemical vapor deposition (HF-CVD) method. The surface terminations of diamond coatings were selectively modified by oxidative treatments. The process of the C-HA deposition, accomplished by precipitation from simulated body fluid (SBF), was monitored from 3 to 20 days by Raman spectroscopy analysis. The coupling of morphological and structural investigations suggests that the modulation of the PCD surface chemistry enhances the bioactivity of the produced materials, allowing for the formation of continuous C-HA coatings with needle-like texture and chemical composition typical of those of the bone mineral. Specifically, after 20 days of immersion in SBF the calculated carbonate weight percent and the Ca/P ratio are 5.5% and 2.1, respectively. Based on these results, this study brings a novelty in tailoring the CVD-diamond properties for advanced biomedical and technological applications. Full article

Polycrystalline diamond (PCD) prepared by the high temperature and pressure method often uses Co as a binder, which had a detrimental effect on the cutting performance of PCD, thus Co needed to be removed. However, the removal of Co would cause residual holes and also make the cutting performance of PCD poorer. To address this issue, hot filament chemical vapor deposition (HFCVD) was used. During deposition, the residual holes cannot be filled fully, and Co would diffuse to the interface between CVD diamond coatings and the PCD substrate, which influenced the adhesive strength of the diamond coating with the PCD substrate. In order to investigate the influencing mechanism, both experiments and the density functional theory (DFT) calculations have been employed. The experimental results demonstrate that Co and the holes in the interface would reduce the interfacial binding strength. Further, we built interfacial structures consisting of diamond (100), (110), (111) surfaces and PCD to calculate the corresponding interfacial binding energy, charge density and charge density difference. After contrast, for Co and the holes located on the (110) surface, the corresponding interfacial binding energy was bigger than the others. This means that the corresponding C-C covalent bond was stronger, and the interfacial binding strength was higher. Based on this, conducting cobalt removal pretreatment, optimizing the PCD synthetic process and designing the site of Co can improve the performance of the PCD substrate CVD diamond coating tools. Full article

In this work, we present experimental data on carbon nanotubes integration during diamond synthesis. Carbon nanotubes layers were preliminarily deposited on silicon and diamond substrates, after which the substrates were loaded into the HFCVD reactor for further growth of the diamond phase. The CVD process was held in an argon-free H₂/CH₄ working gas mixture without the use of a catalyst for carbon nanotubes growth. It is shown that in a wide range of studied working gas composition (CH₄ concentration up to 28.6 vol.%) nanotubes etched from the substrate surface before the diamond growth process began. Full article

Zirconia ceramics (ZrO₂) have been used for a variety of applications due to their superior physical properties, including in machining tools and dentures. Nonetheless, due to its extreme hardness and brittleness in both sintered and half-sintered forms, zirconia is difficult to machine. In this study, half-sintered zirconia blocks are milled with tungsten carbide milling tools which arecoated with diamond film using hot filament chemical vapor deposition (HFCVD) at various substrate-to-filament distances. The objective was to determine the effect of substrate-to-filament distances on the coating thickness, diamond purity, coating grain size, and ZrO₂ machining performance during HFCVD. The experimental results show that, in HFCVD, the grain size and coating thickness of the diamond film on milling tools tend to decrease when the substrate-to-filament distances decrease. Tool failure happened at a cutting time of 200 min for all coated tools. However, the machining quality in terms of surface topology, surface roughness, and tool condition is superior for diamond-coated milling tools with smaller grain sizes and thinner thicknesses. It can be concluded that diamond milling tools with a smaller grain size and lesser thickness produced under shorter substrate-to-filament distances have a superior machining performance and a longer tool life. This study could potentially be used for parameter optimization in the production of coated tools. Full article

Dry friction between seal faces, caused by unstable or extreme operating conditions, significantly affects the running stability and service life of mechanical seals. Therefore, in this work, nanocrystalline diamond (NCD) coatings were prepared on the surface of silicon carbide (SiC) seal rings by hot filament chemical vapor deposition (HFCVD). The friction test results under dry environment reveals that the coefficient of friction (COF) of SiC–NCD seal pairs is about 0.07–0.09, which were reduced by 83–86% compared to SiC–SiC seal pairs. The wear rate of SiC–NCD seal pairs is relatively low, ranging from 1.13 × 10⁻⁷ mm³/N·m to 3.26 × 10⁻⁷ mm³/N·m under different test conditions, which is due to the fact that the NCD coatings prevent adhesive and abrasive wear between the SiC seal rings. The analysis and observation of the wear tracks illustrate that the excellent tribological performance of the SiC–NCD seal pairs is due to a self-lubricating amorphous layer formed on the worn surface. In conclusion, this work highlights a pathway to enable mechanical seals to satisfy the high application requirements under highly parametric working conditions. Full article

In this work, hybrid structures formed by nanostructured layers, which contain materials, such as porous silicon (PSi), carbon nanotubes (CNTs), graphene oxide (GO), and silicon-rich oxide (SRO), were studied. The PSi layers were obtained by electrochemical etching over which CNTs and GO were deposited by spin coating. In addition, SRO layers, in which silicon nanocrystals are embedded, were obtained by hot filament chemical vapor deposition (HFCVD) technique. Photoluminescence (PL) spectra were obtained from the hybrid structures with which a comparative analysis was completed among different PL ones. The SRO layers were used to confine the CNTs and GO. The main purpose of making these hybrid structures is to modulate their PL response and obtain different emission energy regions in the PL response. It was found that the PL spectra of the CNTs/SRO and GO/SRO structures exhibit a shift towards high energies compared to those obtained from the PSi layers; likewise, the PSi/CNTs/SRO and PSi/GO/SRO structures show a similar behavior. To identify the different emission mechanisms originated by PSi, GO, CNTs, and SRO, the PL spectra were deconvolved. It was found that the Psi/CNTs/SRO and Psi/GO/SRO structures exhibit a PL shift in respect to the PSi layers, for this reason, the modulation of the PL emission of the structures makes these hybrid structures promising candidates to be applied in the field of photonic and electroluminescent devices. Full article

As a significant parameter in tuning the structure and performance of the boron-doped diamond (BDD), the thickness was focused on the mediation of the boron doping level and electrochemical properties. BDD films with different thicknesses were deposited on silicon wafers by the hot filament chemical vapor deposition (HFCVD) method. The surface morphology and composition of the BDD films were characterized by SEM and Raman, respectively. It was found that an increase in the BDD film thickness resulted in larger grain size, a reduced grain boundary, and a higher boron doping level. The electrochemical performance of the electrode equipped with the BDD film was characterized by cyclic voltammetry (CV) and electrochemical impedance spectroscopy (EIS) in potassium ferricyanide. The results revealed that the thicker films exhibited a smaller peak potential difference, a lower charge transfer resistance, and a higher electron transfer rate. It was believed that the BDD film thickness-driven improvements of boron doping and electrochemical properties were mainly due to the columnar growth mode of CVD polycrystalline diamond film, which led to larger grain size and a lower grain boundary density with increasing film thickness. Full article
