Search Results (105)

The inspection of encapsulated MEMS devices typically relies on destructive methods which compromise the structural integrity of samples. In this work, we present the concept and preliminary experimental validation of a laser scanning setup to non-destructively inspect silicon-encapsulated microstructures by measuring small variations of transmitted light intensity in the near-infrared spectrum. This method does not require any particular sample preparation or damage, and it is based on the higher degree of transparency of silicon in the near-infrared and the transmission contrast resulting from the Fresnel reflections observed at the interfaces between the different materials of the MEMS device layers. We characterise the small feature resolving performance of the laser scanning setup using standard targets, and experimentally demonstrate the inspection of a MEMS latching device enclosed within silicon covers, comparing the contrast measurements with theoretical predictions. Full article

This study investigates the change in both the angular position and width of the reflectance minimum of an SPR sensor in the Kretschmann configuration when optical vortices instead of plane waves are used for illumination. An analytical expression of the reflectance is obtained for incident Laguerre–Gaussian beams, considering only the first-order approximation of the Fresnel reflection coefficient in a Taylor series. Numerical simulations reveal that the detection performance of SPR sensors is practically unaffected if optical vortices of this type are used as sources, even if the topological charges of the vortices are quite large. On the other hand, the use of optical vortices in SPR sensors could be very advantageous for positioning and manipulating analyte molecules on the surface of the sensor. Full article

Tracking the apparent movement of the sun with high precision is crucial in dual-axis tracking systems for solar concentration applications. It is important to develop control strategies to reduce losses by solar radiation displacement (drift) on the receiver and improve the solar concentration system. In concentrated photovoltaics, a high-precision tracking control is required to keep the concentration point. This paper compares open-loop and closed-loop solar tracking control strategies to solve drift problems and correct azimuth and elevation angles in a non-image reflective FRESNEL solar concentrator. The open-loop strategy consists of a programming code to calculate the apparent sun position, sending command signals to the actuator systems in azimuth and elevation tracker axes. In the open-loop strategy, the actual position of the sun is not verified. A closed-loop strategy with a visual monitoring device is proposed here to detect the sun’s position in real time. This can be simultaneously compared with a fixed reference to evaluate drift through time, calculate the generated error, and send feedback signals to correct azimuth and elevation angles. With this configuration, displacement containment of the solar point concentration projection was ±0.00215 m in the azimuth direction and ±0.0027 m in the elevation direction on the receiver. Full article

Remote sensing plays an important role in plant cultivation and ecological monitoring. This sensing is often based on measuring spectra of leaf reflectance, which are dependent on morphological, biochemical, and physiological characteristics of plants. However, interpretation of the reflectance spectra requires the development of new tools to analyze relations between plant characteristics and leaf reflectance. The current study was devoted to the development, parameterization, and verification of the analytical model to describe reflectance spectra of the dicot plant leaf with palisade and spongy mesophyll layers (on the example of pea leaves). Four variables (intensities of forward and backward collimated light and intensities of forward and backward scattered light) were considered. Light reflectance and transmittance on borders of lamina (Snell’s and Fresnel’s laws), light transmittance in the palisade mesophyll (Beer–Bouguer–Lambert law), and light transmittance and scattering in the spongy mesophyll (Kubelka–Munk theory) were described. The developed model was parameterized based on experimental results (reflectance spectra, contents of chlorophylls and carotenoid, and thicknesses of palisade and spongy mesophyll in pea leaves) and the literature data (final R² was 0.989 for experimental and model-based reflectance spectra). Further model-based and experimental investigations showed that decreasing palisade and spongy mesophyll thicknesses in pea leaves (from 35.5 to 25.2 µm and from 58.6 to 47.8 µm, respectively) increased reflectance of green light and decreased reflectance of near-infrared light. Similarity between model-based and experimental results verified the developed model. Thus, the model can be used to analyze leaf reflectance spectra and, thereby, to increase efficiency of the plant remote and proximal sensing. Full article

Polarized 3D imaging technology reconstructs the three-dimensional (3D) surface shape of an object by analyzing the polarization characteristics of light reflected from its surface. A key challenge in polarized 3D imaging is accurately estimating the zenith angle. Specular light poses a notable challenge in estimating the zenith angle because it conveys limited information regarding the target. To enhance the accuracy and robustness of zenith angle estimation for specular light, this study proposes a novel zenith angle estimation method that utilizes both specular and diffuse reflections. Based on the estimated zenith angle, the target surface shape was reconstructed. The feasibility of the proposed method was validated using polarimetric images of marine targets, offering a new solution for the accurate identification and 3D imaging of distant maritime targets. Full article

The need for reliable and uninterrupted communication systems in the marine environment has become critically important with increasing maritime activities, environmental monitoring, and the spread of autonomous systems. However, the complex structure of electromagnetic wave propagation in a sea environment limits the accuracy of the existing propagation models. Thus, the Modified Round Earth Loss (REL) model was first developed in this study to estimate the path loss more accurately in shore-to-ship communication. Subsequently, a piecewise modeling approach based on the principle of two-segment data modeling was proposed. In the Modified REL model, unlike the traditional REL model, the paths and gains of the direct and reflected waves were not considered equal in the calculations. Moreover, unlike in the classical approach, the receiver height was not taken as a fixed value; the estimated best receiver height value for each measurement was included in the calculations as a representation of the effect of roughness in the sea environment. Thus, the model is better adapted to various environmental conditions. In addition, the proposed piecewise model divides the propagation medium into two regions using a break point calculated by Fresnel zone theory. The Modified REL model was used for the first region and the log-distance model was used for the second region. This method allows for more accurate modeling of signal behaviors, especially at different distances. Experimental measurements and performance evaluations conducted using four different shore-to-ship communication scenarios show that the Modified REL model shows an average improvement of up to 3% in Root Mean Square Error (RMSE) values compared to the classical REL model. Additionally, the proposed piecewise model improves the fitting error of the Modified REL model, which models the data as a single whole, by an average of 22.25%. These findings emphasize the necessity of propagation models that are sensitive and adaptable to environmental changes for maritime communication. Full article

A Fresnel mirror is introduced at a hollow-core photonic bandgap fiber end by fusion splicing a short single-mode fiber segment, to reflect the light backward to an optical frequency domain reflectometry. The backward Fresnel reflection is used as a probe light to achieve light speed measurement with a high resolution and a high signal-to-noise ratio. Thus, its group velocity is obtained with the round-trip time delay as well as the beat frequency at the reflection peak. Multiple Fresnel peaks are observed from 2180.00 Hz to 13,988.75 Hz, corresponding to fusion-spliced hollow-core fiber segments with different lengths from 0.2595 m to 1.6678 m, respectively. The speed of light in the air guidance is calculated at 2.9753 × 10⁸ m/s, approaching that in vacuum, which is also in good agreement with 2.9672 × 10⁸ m/s given by the numerical analysis with an uncertainty of 10⁻³. Our demonstration promises a key to hollow-core waveguide characterization for future wide-bandwidth and low-latency optical communication. Full article

Increasing the transmittance of zinc sulfide (ZnS) infrared windows can effectively improve the imaging quality of infrared detection. In this study, an anti-reflective subwavelength structure (ASS) was manufactured on ZnS using a femtosecond burst Bessel laser with the goal of achieving high transmittance in the mid-infrared range. The period and depth parameters of the ASS were initially determined using the effective medium approximation (EMA) theory and subsequently optimized using the rigorous coupled-wave analysis (RCWA) method to eliminate surface Fresnel anti-reflections. The depth of the ASS increases with the number of bursts, while the structure profile transitions from Gaussian to conical. In addition, the ASS achieves 86% transmittance in the 7–10 µm range, and the average transmittance improves by 10% in the 5–12 µm range. Moreover, the wide-angle ASS with the hydrophobicity (contact angle 160°) is achieved on the ZnS window. Ultimately, the ASS on ZnS enhances the clarity of the infrared image. Full article

CrSBr is a recently discovered two-dimensional anti-ferromagnet. It has attracted much attention due to its superior properties for potential optoelectronic and spintronic applications. However, its complex refractive index with layer dependence has not been systematically studied yet. In this work, we studied the room-temperature complex refractive indices of thin CrSBr flakes of different thicknesses in the visible light range. Using micro-reflectance spectroscopy, we measured the optical contrast of thin CrSBr flakes with respect to different substrates. The complex refractive index was extracted by modeling the optical contrast with the Fresnel equations. We extracted the band gap values of CrSBr in the few-layer limit. We determined the band gaps for monolayer, bilayer, and trilayer CrSBr to be 1.88 eV, 1.81 eV, and 1.77 eV, respectively. As a comparison, the band gap for multilayer CrSBr is outside our measured range, that is, below 1.55 eV. Our results suggest that the band gap of CrSBr decreases as thickness increases. Full article

Black GaAs nanotip arrays (NTs) with 3300 nm lengths were fabricated via self-masked plasma etching. We show, both experimentally and numerically, that these NTs, with three gradient refractive index layers, effectively suppress Fresnel reflections at the air–GaAs interface over a broad range of wavelengths. These NTs exhibit exceptional UV-Vis light absorption (up to 99%) and maintain high NIR absorption (33–60%) compared to bare GaAs. Moreover, possessing a graded layer with a low refractive index (n = 1.01 to 1.12), they achieve angular and polarization-independent antireflection properties exceeding 80° at 632.8 nm, aligning with perfect antireflective coating theory predictions. This approach is anticipated to enhance the performance of optoelectronic devices across a wide range of applications. Full article

THz radiation has gained great importance due to its potential applications in a wide variety of fields. For this reason, continuous efforts have been made to develop technological tools for use in this versatile band of the electromagnetic spectrum. Here, we propose a reflecting device with long focusing performances in the sub-THz band, using a bimirror device in which the relative angle is mechanically adjusted with the displacement of one of the mirrors. Despite the simplicity of the setup, the performance of this device is satisfactory down to a frequency of 0.1 THz. Theory and experience confirm that the bimirror is capable of focusing 0.1 THz radiation with a 2× magnification of the maximum input intensity while maintaining a longitudinal full width at half maximum (FWHM) of about 6 mm, which is about 12 times the depth of focus of a cylindrical optical element of the same focal length. In the absence of suitable THz equipment, the invariance property of the Fresnel diffraction integral allowed the predicted behavior to be tested in the THz range using conventional equipment operating at visible frequencies. Full article

This study unveils an advanced methodology for characterizing various types of cow’s milk based on their optical properties, aiming to establish a straightforward yet comprehensive method. This study uses fundamental principles such as Snell’s Law and Fresnel coefficients to determine and demonstrate critical angles for total internal reflection and reflectance at p polarization. Notably, milk composition, particularly fat content, significantly and remarkably influences its refractive index, with higher fat content leading to elevated values. Additionally, the extinction coefficient, derived through the Beer–Lambert law, provides valuable and essential information regarding light absorption and scattering within the milk samples. The significance of this research relies upon its ability to comprehensively analyze various optical properties of milk, including critical angles, reflectance, and extinction coefficients. By doing so, it offers an exhaustive and detailed understanding of how milk responds to light across different wavelengths and angles of incidence. Moreover, the technique effectively distinguishes milk types based on their fat content and particle characteristics. This novel characterization technique holds promise for various applications within the dairy industry, such as milk quality control, classification, and adulteration detection, which is crucial for maintaining consumer trust and safety. Full article

The traditional single-mode fiber (SMF) optical time domain reflectometer (OTDR) may not be able to accurately detect and locate fault events in the dead zone of few-mode fiber (FMF) links. This paper introduces the concept of higher-order spatial mode detection dimensions unique to FMF, combined with the spatial mode coupling characteristics between modes. The Fresnel reflection from the end face of the fiber, the interior of the circulator, and the connector only occurs in the spatial mode of the injected optical pulse. The Rayleigh backscattering, which reflects the fault distribution characteristics of FMF links, can be detected by non-excited higher-order spatial modes. The proposed method can completely overcome the traditional OTDR dead zone. In this paper, the six-mode fiber is taken as an example for experimental verification. The detection optical pulse is injected into the fundamental mode LP₀₁, and the Rayleigh backscattering of LP_11a, LP_11b, LP_21a, LP_21b, and LP₀₂ higher-order spatial mode are collected and analyzed to accurately detect and locate the fusion splice fault event at 100 m and 500 m in the dead zone. Full article

Numerous analytical radar-scattering laws have been published through the past decades to interpret planetary radar observations, such as Hagfors’ law, which has been commonly used for the Moon, and the cosine law, which is commonly used in the shape modeling of asteroids. Many of the laws have not been numerically validated in terms of their interpretation and limitations. This paper evaluates radar-scattering laws for self-affine fractal surfaces using a numerical approach. Traditionally, the autocorrelation function and, more recently, the Hurst exponent, which describes the self-affinity, have been used to quantify the height correlation. Here, hundreds of three-dimensional synthetic surfaces parameterized using a root-mean-square (rms) height and a Hurst exponent were generated, and their backscattering coefficient functions were computed to evaluate their consistency with selected analytical models. The numerical results were also compared to empirical models for roughness and radar-scattering measurements of Hawaii lava flows and found consistent. The Gaussian law performed best at predicting the rms slope regardless of the Hurst exponent. Consistent with the literature, it was found to be the most reliable radar-scattering law for the inverse modeling of the rms slopes and the Fresnel reflection coefficient from the quasi-specular backscattering peak, when homogeneous statistical properties and a ray-optics approach can be assumed. The contribution of multiple scattering in the backscattered power increases as a function of rms slope up to about 20% of the backscattered power at normal incidence when the rms slope angle is 46°. Full article

The modulation of a terahertz (THz) wave on amplitude, phase and polarization is important for the application of THz technology, especially in the field of imaging, and is one of the current research hotspots. Silicon-based, optically excited THz modulator is a wavefront modulation technique with a simple, compact and reconfigurable optical path. It can realize the dynamic modulation of THz wavefronts by only changing the projected two-dimensional pattern, but it still suffers from the problems of lower modulation efficiency and slower modulation rates. In this article, the Drude model in combination with the multiple thin layers structure model and Fresnel matrix method is used to compare the modulation efficiencies of three modulation modes and more factors. The method is more accurate than the popular proposed method, especially when the thickness of the excited photoconductive layers reaches a few hundred microns. In comparing the three modes, namely transmission, ordinary reflection and total internal reflection, it is found the total internal reflection modulation mode has the best modulation efficiency. Further, under this mode, the effects of three factors, including the lifetime of photo-excited carriers, the wavelength of pump light and the frequency of THz wave, on the performance of THz modulator are analyzed. The simulation results show that the realization of total internal reflection using silicon prisms is a simple and effective method to improve the modulation efficiency of a silicon-based optically excited THz modulator, which provides references for the design of a photo-induced THz modulator. Full article
