Search Results (65)

A novel approach to fibre Bragg grating spectra processing is proposed. The method is based on the use of nonlinear filtration and raising the spectrum value to the second power. A combination of geometric and arithmetic mean filtering is used as nonlinear filtration. The properties of the denoising method are presented on simulation data with different signal-to-noise ratios and on experimental data. The most advantageous combination is raising the intensity of the spectrum to the square power preceded by its significant smoothing. The centroid, fast phase correlation, and cross-correlation methods are used to determine the wavelength shift in the spectrum. To obtain experimental data, measurements of the FBG in reflection mode placed in a temperature chamber with the possibility of temperature control are obtained. The simulations, measurements, and their numerical analysis confirm the usefulness of the proposed methods for demodulating the wavelength shift of FBG spectra. Full article

A respiration rate (RR) monitoring system was created by integrating a Fibre Bragg Grating (FBG) optical fibre sensor into a respirator mask. The system exploits the sensitivity of an FBG to temperature to identify an individual’s RR by measuring airflow temperature variation near the nostrils and mouth. To monitor the FBG response, a portable, battery-powered, wireless miniature interrogator system was developed to replace a relatively bulky benchtop interrogator used in previous studies. A healthy volunteer study was conducted to evaluate the performance of the developed system (10 healthy volunteers). Volunteers were asked to perform normal breathing whilst simultaneously wearing the system and a reference spirometer for 120 s. Individual breaths are then identified using a peak detection algorithm. The result showed that the number of breaths detected by both devices matched exactly (100%) across all volunteer trials. Full article

Sinkhole formation caused by leaking pipes in karst soluble rocks is a significant concern, leading to infrastructure damage and safety risks. In this paper, an experiment was conducted to investigate sinkhole formation in dense sand induced by a leaking pipe. Fibre Bragg grating (FBG) sensors were used to record the strain. A balloon was gradually deflated within a bed of wet silica sand to create an underground cavity. Eighteen FBG sensors, with a wavelength range between 1550 nm and 1560 nm, were embedded horizontally and vertically in the physical model at different levels to monitor deformation at various locations. A leaking pipe was installed to induce the collapse of the formed arch above the cavity. The strain measurements suggested the following four phases in the sinkhole formation process: (1) cavity formation, (2) progressive weathering and erosion, (3) catastrophic collapse, and (4) subsequent equilibrium conditions. The results showed differences in the strain signatures and distributions between the horizontal and vertical measurements. During the critical phase of the sinkhole collapse, the horizontal measurements primarily showed tension, while the vertical measurements indicated compression. This investigation demonstrates the effectiveness of FBGs as advanced monitoring tools for sinkhole precursor identification. The study also suggests using FBGs in geotechnical monitoring applications to improve the understanding and mitigation of sinkholes and related geohazards. Full article

Three-dimensional shape sensing in soft and continuum robotics is a crucial aspect for stable actuation and control in fields such as minimally invasive surgery, engine repairs and search and rescue operations, as the estimation of complex curvatures while using continuum robotic tools is required to manipulate through fragile paths. This challenge has been addressed using a range of different sensing techniques, for example, Fibre Bragg grating (FBG) technology, inertial measurement unit (IMU) sensor networks, or stretch sensors. Previously, an optics-based method using optoelectronic sensors was explored, offering a simple and cost-effective solution for shape sensing in a flexible tendon-actuated manipulator in two orientations. This was based on proximity-modulated angle estimation and has been the basis for the shape sensing method addressed in this paper. The improved and miniaturised technique demonstrated in this paper is based on the use of a convex shaped reflector with optoelectronic sensors integrated into a tendon-actuated robotic manipulator. Upgraded sensing capability is achieved using optimisation of the convex reflector shape in terms of sensor range and resolution, and improved calibration is achieved through the integration of spherical bearings for friction-free motion. Shape estimation is achieved in two orientations upon calibration of sensors, with a maximum Root-Mean-Square Error (RMS) of 3.37°. Full article

Deflection measurements are usually used as a key index in civil engineering for performing structural assessments of bridge safety. However, owing to technical or cost issues, it may be difficult to implement long-term monitoring of bridge deflection, especially for short- or medium-span bridges. Therefore, this study presents a novel method for measuring the deflection of simply supported girder bridges. In the proposed method, the strain measurement was implemented under traffic loading at only one position, such as middle span, and then the strain distribution along the girder was reconstructed to calculate the girder deflection with basic structural mechanical theory. To implement the method, the theory was constructed based on the displacement reciprocal theorem at first to assess the strain distribution along the girder from the strain measurement at some position during traffic loads passing across the bridge. Second, a strain measurement method, namely long-gauge fibre Bragg grating (FBG) sensing technology, was introduced to take strain measurements for a concrete bridge. Third, various finite element (FE) bridge models were developed to validate the proposed method’s accuracy, the results from which indicated that the method accurately implemented deflection measurement with an approximately 5% calculation error. In addition, the influence of some key parameters, such as vehicle type, vehicle speed, and structural damage, was investigated. The simulation results revealed that damage to the hinge joint in the middle location could significantly influence the proposed method’s accuracy such that the error may exceed 10%. Finally, on-site experiments were conducted on a simply supported girder bridge to further validate the proposed method’s accuracy, and an approximately 8% deflection assessment error was found. Considering the additional advantages of FBG sensing technology, the proposed method can also be effective for long-term deflection measurements of short- or medium-span bridges. Full article

Road-embedded inductive power transfer (IPT) systems have the potential to accelerate the electrification of the transportation sector. For these systems to be economically viable, however, they need to have a similar durability and lifespan to those of asphalt roads. One area that has lacked investigation is thermally induced stresses in a primary IPT pad, which are caused by the increase in the temperature of the pad when it is energized and the differing thermal expansion of the materials within. This paper presents an experimental and a finite element-based methodology for investigating the thermal–mechanical behaviour of a ¼-scale double-D pad, which was energized while suspended in air, as well as energized when embedded in pavement. A focus was placed on the measurement and prediction of strains in the magnetic ferrite cores because of their brittleness. Ferrite strains were measured using a combination of resistive strain gauges and non-metallic fibre Bragg grating (FBG) sensors. Coupled electromagnetic–thermal–structural simulations were conducted to predict temperature and strains in the system, with temperature-dependent properties obtained through physical testing. At an ambient temperature of 50 °C, the temperature in the middle of the copper litz wire coil was predicted to be 100 °C in both the suspended and embedded case. There was an excellent correlation with the experimental results, with a difference of less than 10% for most temperature measurements. When energized, the pad was predicted to experience an upward bow due to its temperature rise, resulting in bending strains in the ferrite cores. At an ambient temperature of 50 °C, the maximum tensile strain in the ferrites of the embedded pad was measured to be 62 microstrains (με), with a root-mean square error that was 18 με across three sensors. The experimental and validated numerical methodology can be applied to full-scale operational IPT pads to analyse and improve their thermal–mechanical performance. Full article

With the ever-increasing role that nuclear power is playing to meet the aim of net zero carbon emissions, there is an intensified demand for understanding the thermal hydraulic phenomena at the heart of current and future reactor concepts. In response to this demand, the development of high-resolution flow analysis instrumentation is of increased importance. One such under-utilised and under-researched instrumentation technology, in the context of fluid flow analysis, is fibre Bragg grating (FBG)-based sensors. This technology allows for the construction of simple, minimally invasive instruments that are resistant to high temperatures, high pressures and corrosion, while being adaptable to measure a wide range of fluid properties, including temperature, pressure, refractive index, chemical concentration, flow rate and void fraction—even in opaque media. Furthermore, concertinaing FBG arrays have been developed capable of reconstructing 3D images of large phase structures, such as bubbles in slug flow, that interact with the array. Currently a significantly under-explored application, FBG-based instrumentation thus shows great potential for utilisation in experimental thermal hydraulics; expanding the available flow characterisation and imaging technologies. Therefore, this paper will present an overview of current FBG-based flow characterisation technologies, alongside a systematic review of how these techniques have been utilised in nuclear thermal hydraulics experiments. Finally, a discussion will be presented regarding how these techniques can be further developed and used in nuclear research. Full article

The evolution of technological tools, namely affordable sensors for data collection, and the growing concerns about maintaining roads in adequate conditions have promoted the development of continuous pavement monitoring systems. This paper presents the installation and use of an innovative pavement monitoring system, which was developed to measure the effects of vehicle loads and temperature on the performance of a pavement structure. The sensors used are based on fibre Bragg grating optical technology, collecting data about the strains imposed in the pavement and the temperature at which those measurements are made. The site selection for the system’s installation and the essential installation details to ensure successful data collection are addressed. A calibration procedure was implemented by performing falling weight deflectometer tests and passing preweighed heavy vehicles over the sensors. In addition to validating the system installation, the results obtained in the calibration confirmed the importance of adequately choosing the distance between sensors. Differences of 50 mm in the position of the load may cause differences of about 20% to 25% in the resulting strains. These results confirmed the importance of increasing the sensor concentration in wheel paths. Furthermore, for loads between 25 kN and 65 kN, raising the temperature by 8 °C caused an increase of about 20% in the horizontal tensile strains measured in the pavement. In summary, it was possible to conclude that this innovative system is capable of capturing the effects of temperature and vehicle speed on the response of the pavement, which may be considered an advantage of this type of monitoring system when compared to those that are only used to determine the loads applied to the pavement or to characterise the type of vehicle. Full article

The high-voltage (HV) assets in the existing power transmission network will experience increased electrical, thermal, environmental and mechanical stresses and, therefore, robust condition monitoring is critical for power system reliability planning. Fibre Bragg grating (FBG) sensors offer a promising technology in HV applications due to their immunity to electromagnetic interference and multiplexing capability. This paper reviews the current technology readiness levels of FBG sensors for condition monitoring of transformers, transmission lines, towers, overhead insulators and power cables, with the aim of stimulating further development and deployment of fibre-based HV asset management systems. Currently, there are several reported cases of FBG sensors used for condition monitoring of HV assets in the field, proving their feasibility for long-term use in the power grid. The review shows that FBG technology is versatile and can facilitate multi-parameter measurements, which will standardise the demodulation equipment and reduce challenges with integrating different sensing technologies. Full article

The influence of the bonding procedure (the adhesive type, application procedure, etc.) on the static and dynamic strain transfers of bonded optical fibre sensors is studied theoretically and experimentally at room temperature. The achievable performances with four different types of adhesives (three urethane and one epoxy adhesive), and with different fibre types, are evaluated: acrylate-coated, polyimide-coated, and bare single-mode optical fibres. Static strain measurements, ranging from 20 to 200 µ strain, are performed using both fibre Bragg gratings (FBGs) and optical frequency domain reflectometry (OFDR), and are compared to reference strain-gauge measurements, and to the proposed analytical model, which is developed on the basis of stress equilibrium relations. This model is valid for bonding to all types of linear and elastic materials, as long as there is no sliding between the host material, the adhesive, and the optical fibre. The results agree between the analytical model and the experiments. Regarding the dynamic sinusoidal strain measurements, the studied dynamic range is from 10 to 100 Hz, and only the FBGs are tested. The results demonstrate that the sensitivities of strain sensors based on bonded uncoated fibres or bonded polyimide-coated fibres are comparable to those of strain gauges, and that it is possible to use bonded FBGs for precise dynamic strain measurements. Full article

Fibre optic sensors with integrated Bragg gratings are widely used in the diagnostics of machinery and equipment. They achieved their popularity thanks to their relatively simple operating principles. In addition, they allow the continuous monitoring of several variable physical parameters of objects, such as strain or temperature change, which directly translates into immediate feedback regarding potential damage. However, despite the easy-to-understand operating principle, selecting a specific type for a particular application can be problematic. This article aims to present the process of selecting the optimal set of fibre-optic sensors with integrated Bragg grating, which can be used in the process of monitoring the stress state of hanger rods of an engineering object such as an industrial boiler. The hanger rods of such boilers require constant technical supervision; however, the current measurement methods do not provide an effective and non-invasive diagnostic method. Therefore, the authors have undertaken the task of developing a universal diagnostic strategy for hanger rods. To this end, they will present the results of an analysis of the applicability of FBGs, examples of the use of different types of sensors, their installation methods, and the technical capabilities of the equipment necessary to handle the signals recorded with these sensors. Exemplary results of strain measurements of a selected hanger rod performed by the traditional method used now and with a selected FBG fibre optic sensor will be presented. In conclusion, concrete technical suggestions will be presented to be implemented in the existing industrial facility during the next part of the study. Full article

The work described herein details the deployment of an optical fibre strand with five fibre Bragg grating (FBG) sensors for individual cell-level temperature monitoring of a three-cell lithium-ion battery pack. A polymer guide tube with 3D printed plinths is employed, resulting in high precision temperature readings with an average error of 0.97 °C, 1.33 °C, and 1.27 °C for FBG sensors on each battery cell, surpassing traditional thermocouple and platinum resistance sensors in some circumstances. The temperature response of FBGs positioned between battery cells demonstrates that, in addition to sensing temperature at the cell level, temperature data can be effectively acquired between cells, suggesting that FBGs may be used to monitor the heat radiated from individual cells in a battery pack. Full article

Strain sensing technology using fibre Bragg grating (FBG) sensors is an attractive capability for aerospace structural health monitoring (SHM) and assessment because they offer resistance to harsh environments, low maintenance, and potential for high density and high strain sensing. The development of FBG inscription techniques through the fibre polymer coating using infrared (IR) lasers has overcome the mechanical weaknesses introduced by removal of the fibre coating, which is typically required for conventional UV laser inscription of FBGs. Type I and Type II femtosecond gratings are fabricated using through-coating inscription techniques, but the higher laser energy used for Type II gratings damages the glass fibre core, impacting mechanical performance. This paper investigates the fatigue performance of Type I and Type II through-coating FBG sensors with different fibre geometries and photosensitisation approaches to evaluate their overall reliability and durability, with a view to assess their performance for potential use in civil and defence SHM applications. The fatigue performance of FBG sensors was assessed under high-strain and high-frequency mechanical loading conditions by using a custom-designed electro-dynamically actuated loading assembly. In addition, pre- and post-fatigue microscopic analyses and high-resolution reflection spectrum characterisation were conducted to investigate the failure regions of the fibres and the effect of fatigue loading on reflection spectrum features. As expected, Type I gratings had a significantly higher fatigue life compared to Type II gratings. However, Type II gratings performed significantly better than conventional UV laser-inscribed FBGs and electrical foil strain gauges. Type II gratings withstand higher temperatures, and are therefore more suitable for application in harsh environments. Full article

The increasing energy demand has led to more explorations in the oil and gas industry. To achieve this, marine risers and pipelines are used to convey fluid and other resources to meet the increasing demand. In recent years, hybrid flexible composite risers have become more adaptable. Flexible risers have already proven to be a popular riser solution for various floating production systems in shallow to deepwater in many parts of the world due to their good dynamic behaviour and dependability. The hybrid flexible composite riser is made up of numerous layers of plastics, flexible pipes, composites, and steel. Some innovative monitoring methods, such as Fiber Optics Bragg Gratings (FBG), are based on a clamped composite structure with embedded optical fibre. This study presents characteristics of the monitoring techniques of composite flexible riser technology. The advantages of the monitoring techniques include aiding composite riser measurements, recording data from riser deformation, improving integrity assurance, and dependability of design from stable readings. It also proposes some design approaches as guidelines that are advised, with some policy implications. Full article

Additive manufacturing (AM) polymers are applied in many branches of the industry due to the possibility of fast and accurate production of elements with various and complex shapes. Fibre Bragg grating sensors (FBG) are widely applied in structural health monitoring (SHM) systems. The main objective of this research is to perform analyses of the influence of embedded FBG sensors on AM polymer elements’ durability. Two polymers (M3 X and M3 Crystal) with different mechanical properties were analysed. The tests were performed on samples with FBG sensors embedded in (different alignment) and attached to the surfaces of the elements. Firstly, the samples were exposed to elevated or sub-zero temperatures under stable relative humidity levels. The strain in the samples was measured using fibre Bragg grating (FBG) sensors. The achieved results allow us to determine the relationships between strain and temperature for both materials and the differences in their mechanical response to the thermal loading. Then, the samples were subjected to a tensile test. A comparison of the tensile strength values was performed for the samples without and with embedded FBG sensors. The samples after the tensile tests were compared, showing differences in the mechanisms of failures related to the polymers and the thermal treatment influence on the material internal structure. Additionally, strain values measured by the FBG sensors were compared to the strain values achieved from the testing machine showing a good agreement (especially for M3 X) and indicating the differences in the materials’ mechanical properties. The achieved results allow us to conclude there is a lack of influence of embedded FBG sensors on the mechanical durability of AM polymers. Full article
