To address the unclear coupling mechanism between thermal elastohydrodynamic lubrication (TEHL) and dynamic behaviors in planetary gear systems, a novel tribo-dynamic model for dual-star planetary gears considering TEHL effects is proposed. In this model, a TEHL surrogate model is first established to determine the oil film thickness and sliding friction force along the tooth meshing line. Subsequently, the dynamic model of the dual-star planetary gear transmission system is developed through coordinate transformations of the dual-star gear train. Finally, by integrating lubrication effects into both time-varying mesh stiffness and time-varying backlash, a tribo-dynamic model for the dual-star planetary gear transmission system is established. The study reveals that the lubricant film thickness is positively correlated with relative sliding velocity but negatively correlated with unit line load. Under high-speed conditions, a thickened oil film induces premature meshing contact, leading to meshing impacts. In contrast, under high-torque conditions, tooth deformation dominates meshing force fluctuations while lubrication influence diminishes. By establishing a test bench for the planetary gear transmission system, the obtained simulation conclusions are verified. This research provides theoretical and experimental support for the design of high-reliability planetary gear systems. Full article

Cylindrical roller bearings are widely used in industrial machinery, automotive systems, and aerospace applications, where their reliability directly affects the performance and safety of mechanical systems. The fatigue life of cylindrical roller bearings is significantly affected by their elastohydrodynamic lubrication condition, with variations potentially reaching multiple times. However, conventional quasi-static models often neglect lubrication effects. This study establishes a quasi-static analysis model for cylindrical roller bearings that incorporates the effects of elastohydrodynamic lubrication by integrating elastohydrodynamic lubrication theory with the Lundberg–Palmgren life model. The isothermal line contact elastohydrodynamic lubrication equations are solved using the multigrid method, and the contact load distribution is determined through nonlinear iterative techniques to calculate bearing fatigue life. Taking the N324 support bearing on the main shaft of an SFW250-8/850 horizontal hydro-generator as an example, the influences of radial load, inner race speed, and lubricant viscosity on fatigue life are comparatively analyzed. Experimental validation is conducted under both light-load and heavy-load operating conditions. The results demonstrate that elastohydrodynamic lubrication markedly increases contact loads, leading to a reduced predicted fatigue life compared with that of the De Mul model (which ignores lubrication). The proposed lubrication-integrated model achieves an average deviation of 5.3% from the experimental data, representing a 16.1% improvement in prediction accuracy over the De Mul model. Additionally, increased rotational speed and lubricant viscosity accelerate fatigue life degradation. Full article

Perfluorinated tetradecanoic acid was added as an additive to a base oil and tested under full film elastohydrodynamic (EHD) contact conditions between a steel ball and a steel disc. By varying key performance parameters, we aimed to assess the feasibility and limitations of perfluorinated carboxylic acids in reducing friction in lubricated contacts. The results demonstrate that the tested perfluorinated additive is effective in reducing friction when blended with a non-polar synthetic poly-alpha-olefin oil. However, no significant friction reduction was observed when the same additive was used in a slightly polar synthetic ester. The carboxylic acid functional group plays a crucial role in the observed friction-reducing effect. Adjusting the additive concentration further plays an important role in reducing friction. A concentration of at least 0.35 wt.% is required to achieve a notable friction reduction of approximately 10%. Increasing the concentration beyond this threshold continues to improve the friction-reducing effect. Conversely, increasing the contact pressure has a detrimental impact on friction reduction. The greatest reduction in friction—over 20% compared to the base oil—was achieved at the lowest contact pressure tested (0.69 GPa). Full article

In industrial applications, the operating state of bearings can directly affect the performance of mechanical equipment. Local defects, flexible raceways and lubrication have a great impact on the vibration characteristics of rolling bearings. However, previous works only considered the bearing as a rigid whole or unlubricated state. In order to solve this problem, a flexible–rigid combined bearing dynamics (FRBD) model considering grease lubrication is proposed in this paper. Both the flexible inner race and flexible outer race of a lubricated rolling bearing and a localized defect are formulated in the presented FRBD model. The influence of flexible–rigid combined and grease lubrication on the time- and frequency-domain responses of a rolling bearing with a local fault is analyzed. Based on the constructed model, the root mean square (RMS) value and maximum (MAX) value of time-domain statistical indicators are used to discuss the characteristic changes in acceleration vibration signals under different fault widths, inner-race speeds, and radial forces. In order to verify the accuracy of the FRBD model, the simulation results are compared with the experimental results. These results have a certain guiding role in fault diagnosis for the predictive maintenance of a rolling bearing. Full article

Uncontrolled wear in complex multiphysics systems can cause catastrophic failures, prompting the development of empirical methods and numerical prediction models for managing system lifetimes. This study introduces a novel approach for predicting wear on lubricated sliding surfaces by integrating rough contact mechanics into a nonlocal function with a non-uniform distribution. The model considers the sliding speed, contact area, fluid pressures, lubricant properties, and surface roughness. It employs a mixed elastohydrodynamic lubrication (mixed EHL) model to simulate lubrication and wear, using a multiscale roughness model to adjust the parameters based on the wear evolution. Validated against journal bearing data, the model accurately predicted wear rates and depths, revealing distinct roughness variations depending on the lubricant viscosity. Full article

In slurry shield tunneling projects, leakage from floating seals frequently leads to abnormal failures of disc cutters. To investigate the leakage characteristics at the floating seal end faces of the cutters, a numerical method is proposed for analyzing the dynamic leakage behavior of the floating seal end faces, considering the effects of wear. The elastohydrodynamic lubrication problem of the floating seal was addressed using the Reynolds equation and the slicing method, leading to the development of a computational model for the pressure and thickness distribution of the oil film on rough surfaces. Based on the Archard wear equation, a dynamic surface roughness model considering wear was established. Furthermore, a numerical model for dynamic leakage of the floating seal end faces in shield machine cutters, incorporating wear effects, was developed. Simulated friction and wear tests of the floating seal end faces, along with cutter seal leakage experiments, were conducted for validation. The results demonstrate that the dynamic surface roughness model considering wear can effectively predict the roughness evolution of worn surfaces. The trend of the theoretical leakage rate is generally consistent with that of the experimental results, verifying the effectiveness of the proposed model. Full article

Post-operative feedback from hip replacement surgeries indicates that implanted ceramic artificial hip joints may produce abnormal noises during movement. This occurrence of joint noise is highly correlated with insufficient lubrication of ceramic-on-ceramic (COC) prostheses. Studies have shown that surface texture design can improve lubrication performance. In this study, the elastohydrodynamic lubrication model was established with designing textures on the surface of the COC hip joint, using Matlab R2018b and GNU FORTRAN in Codeblocks 20.03 programming. Iterative calculations were performed to determine the average bearing capacity of the oil film and the friction coefficient. The study explored the impact of texture parameters, including the aspect ratio and density, on the lubrication and friction performance of the hip joints. The results indicate that the textured surface generally has a higher fluid film bearing capacity by 161.5~637.7% and a lower friction coefficient by 10.7~60% than the smooth surface. The average bearing capacity of the fluid film increases with an increasing texture aspect ratio, while the trend of the friction coefficient is identical to the average bearing capacity results. As the texture density increases, the average bearing capacity of the fluid film first decreases and then increases, and the trend of the friction coefficient also increases accordingly. Among the nine design groups ($Sp=0.05,0.15,0.35,\epsilon =0.075,0.1,0.15$), based on the fuzzy comprehensive evaluation, the local optimal solution is $Sp=0.15$, $\epsilon =0.075$ for lubrication and wear resistance. Full article

This paper presents a number of thrust-collar-specific effects to consider when simulating the elastohydrodynamic lubrication state. Plate bending can lead to edge loading and can be considered via an FEM model of the solids. When bending is of no concern, the effect of the close outside edge needs to be corrected in half-space deformation theory. Track heating requires a unique version of the Carslaw/Jaeger flash temperature solution for curved trajectories. Especially, the adapted treatment of stiffness effects leads to vastly different results in, e.g., lubrication gap height. Full article

In this paper, the calculation model and method of the lubrication performance of the thrust bearing, which considers the thermal bomb deformation, are constructed based on the working characteristics of the main pump thrust of the nuclear power plant. The key design parameters of the tile package Angle θ are analyzed by taking the design parameters of the thrust-bearing tile as the variable. The circumferential fulcrum coefficient of tile, the influence of tile thickness B, and tile elastic modulus E on the lubrication performance of thrust bearing are analyzed to obtain improved design parameters. The lubrication performance of the thrust bearing includes the minimum oil film thickness h_min, the maximum temperature of oil film T_max, total flow Q_x, total power consumption W, maximum thermal deformation of axial bush δT_max, and the maximum elastic deformation of the axial bush δF_max. The scale test of the designed thrust bearing is carried out. The take-off speed of the bearing is tested and compared with the results of the theoretical analysis. The study results show that the influence is becoming more obvious from θo to h_min. Moreover, the impact becomes more obvious from T_max to Q_x, B to hmin, and Q_x to δT_max and δF_max. Lastly, the impact is also obvious from E to Q_x and δF_max. Full article

The key to exploring the behavior of bearings through dynamic methods lies in establishing an accurate model for calculating the contact load between the roller and the raceway. Based on the half-space theory of Boussinesq, this study developed a full-order model for calculating the contact load of the finite line contact roller. The model adopted an iterative procedure to calculate the contact load of each roller slice according to deformations. According to the comparisons between the contact loads obtained by the proposed model and those obtained by FEA, the average error for a cylindrical roller was approximately 2%, while that for a tapered roller was approximately 17%. By neglecting the influences of inter-slice contact stresses on the deformation of local roller slice, a fast-calculating method for the full-order model was developed, thereby reducing the calculation time by approximately 77%. By integrating the fast method with the Dowson–Higginson’s formula, another model was developed to calculate the contact load under lubrication conditions. The proposed models were utilized to investigate the dynamic characteristics of a double-row tapered roller bearing, and the results were validated through experiments. The proposed method could be utilized to assess dynamic performances of bearings across different operating scenarios. Full article

Spherical bearings play a crucial role in maintaining the safety of bridge systems. The frequent operation and wear rate over their lifespan highlight the necessity for methods to improve their tribological performance. In this study, GQZ-60000 unidirectionally movable spherical bearings were the research object, and three different surface textures—spherical cap, ellipsoidal cap, and double spherical cap—were incorporated into a curved PTFE surface to enhance its tribological performance, with the major focus being on reducing the friction coefficient. The Jakobsson–Floberg–Olsson cavitation boundary condition was used to solve the Reynolds equation numerically to obtain the elastohydrodynamic lubrication pressure, and the parametric effect of the three textures on the friction coefficient were analyzed. Based on the simulation results, a rational texture with rational geometric values are recommended to obtain the minimum friction coefficient of the bearing. However, it was also found that the deformation of the lubricated surface significantly affects the lubricant film thickness, and cavitation of the lubricant film may also affect the selection of rational textures, especially when the relative sliding velocity between lubricated surfaces is high. Full article

Under mixed lubrication, the macro size is affected by the wear of the surface roughness peaks, which results in degradation of the bearing accuracy. To study the wear characteristics of rolling bearings under mixed lubrication, based on the elastohydrodynamic lubrication theory and Archard wear model, and considering the coupling of the oil film and roughness, a wear prediction model of angular contact ball bearings under mixed lubrication was established, and the influence of the working parameters and hardness on bearing wear was analyzed. The results show that the wear depth of the outer grove increases with an increase in the load, or a decrease in the rotational speed or the initial viscosity of lubricating oil. The load has the most significant effect on the wear depth of the outer grove. There is a critical value for the load, rotational speed, and initial viscosity of the lubricating oil, which varies with the parameters of other working conditions and the hardness of the materials. When the increase in load exceeds the critical value or the rotational speed and initial viscosity of lubricating oil are less than the critical value, the outer groove fails because the wear depth exceeds the critical value of wear depth. The ratio of the load on the rolling element to the hardness of the outer grove at different entrainment speeds and initial viscosities of lubricating oil can be used to predict the wear degree of the outer grove. When the ratio is greater than a certain threshold, the outer grove is faulted owing to wear, and the threshold decreases with an increase in the initial viscosity of lubricating oil or the decrease in rotational speed. Full article

The lubrication behavior and mechanical characteristics of the main bearing area of an aero-engine main shaft bearing determine the reliability and life of the main shaft bearing. In aero-engine main shaft bearings, the lubricant not only plays the role of lubrication but also affects the dynamic characteristics of the bearing; therefore, if the lubricant drag force is insufficient, it will lead to rolling body slipping. Slipping not only affects the reliability of the bearing operation but also will make the temperature of the contact area instantaneously increase, leading to the occurrence of gluing, scraping and other lubrication failure phenomena in the main bearing area. A lubricant under the shear conditions of traction characteristics is actually the external manifestation of rheological properties. Rheological properties are one of the elastic fluid power lubrication theories and are an important part of the study. Elasto-hydrodynamic lubrication theory of the oil film pressure, film thickness and temperature and solid domains interact to form a thermal–fluid–solid coupling relationship; this coupling relationship affects the main bearing area of the lubrication behavior and mechanical properties, thus affecting the lubrication state of the bearings and dynamic characteristics. With the continuous improvement of aero-engine performance requirements for main shaft bearings, it is of great significance to carry out a coupling study of the lubrication behavior and mechanical properties of the bearing contact zone under heavy load, high speed and high temperature conditions to improve the service performance, reliability and life of the bearings. Full article

This study explores the in situ measurement of contact temperature in thermo-elastohydrodynamic lubrication (TEHL) within cylindrical roller thrust bearings (CRTBs) utilizing vapour-deposited resistive thin-film sensors. The sensors, optimized for compactness and high spatial resolution, were strategically embedded on the stationary bearing raceways near the outer, inner, and mean radius. This configuration enabled a precise measurement of temperature variations in both pure rolling and rolling–sliding regions of the CRTBs. The experimental results revealed a consistent decrease in temperature from the inner and outer radius zones towards the mean radius as the slip-to-roll ratio (SRR) decreased in these regions. Temperature profiles showed an early rise in the inlet zone attributed to thermal inlet shear. At higher speeds, a secondary temperature peak indicative of full-film lubrication was observed in the outlet zone immediately following the Hertzian contact. The study further shows the influence of surface pressure, shear rates, sliding friction, and circumferential speed on contact temperature dynamics, offering insights into their complex interplay. Additionally, viscosity variations due to different oil temperatures were found to critically affect the rate of temperature rise and the propensity for mixed friction phenomena. A higher viscosity resulted in an earlier onset of the temperature rise in the contact, while a lower viscosity and higher speeds promote mixed lubrication, leading to reduced contact film temperatures. These findings provide valuable insights into the behaviour of CRTB-lubricated contacts under various operating conditions and serve as crucial validation data for advanced TEHL computational models. Full article

The surface texture technology has been applied to ball screws. However, the rough grinding surface of ball screws is not considered, and the elastohydrodynamic lubrication (EHL) characteristics and anti-friction and anti-wear mechanisms are not comprehensive and in-depth. Theoretical simulation and experimental measurement of the ground surface topography of the screw raceways are conducted to take into account the impact of the grinding surface on the EHL interaction between the ball and the raceway. The EHL model and friction torque model of ball screws have been established simultaneously, considering the ground surface topography of the raceway and the geometric features of the textures manufactured on the raceway surface. The friction reduction mechanism of the textured raceway of ball screws is elucidated in detail from the microscopic point of view, and the influence of the geometric features of the textures on the anti-friction characteristics of ball screws under different axial loads and rotation speeds is further analyzed and discussed. The proof-of-principle experiments of the friction-reducing performances of the textured raceways of the ball screws are conducted. The textured raceway of the ball screws provides an effective anti-friction effect that reduces the friction coefficient of the contact system of the ball screws by 15.2% at a normal contact force of 60.23 N, an entrainment speed of 167.5 m/s, a texture diameter of 40 μm, a texture depth of 10 μm and a texture areal density of 10%. Full article
