Annual outbreaks of floating Ulva prolifera blooms in the Yellow Sea have caused serious local environmental and economic problems. Rapid and effective monitoring of Ulva blooms from satellite observations with wide spatial-temporal coverage can greatly enhance disaster response efforts. Various satellite sensors and remote sensing methods have been employed for Ulva detection, yet automatic and rapid Ulva detection remains challenging mainly due to complex observation scenarios present in different satellite images, and even within a single satellite image. Here, a reliable and fully automatic method was proposed for the rapid extraction of Ulva features using the Tasseled-Cap Greenness (TCG) index from satellite top-of-atmosphere reflectance (R_TOA) data. Based on the TCG characteristics of Ulva and Ulva-free targets, a local adaptive threshold (LAT) approach was utilized to automatically select a TCG threshold for moving pixel windows. When tested on HY1C/D-Coastal Zone Imager (CZI) images, the proposed method, termed the TCG-LAT method, achieved over 95% Ulva detection accuracy though cross-comparison with the TCG and VBFAH indexes with a visually determined threshold. It exhibited robust performance even against complex water backgrounds and under non-optimal observing conditions with sun glint and cloud cover. The TCG-LAT method was further applied to multiple HY1C/D-CZI images for automatic Ulva bloom monitoring in the Yellow Sea in 2023. Moreover, promising results were obtained by applying the TCG-LAT method to multiple optical satellite sensors, including GF-Wide Field View Camera (GF-WFV), HJ-Charge Coupled Device (HJ-CCD), Sentinel2B-Multispectral Imager (S2B-MSI), and the Geostationary Ocean Color Imager (GOCI-II). The TCG-LAT method is poised for integration into operational systems for disaster monitoring to enable the rapid monitoring of Ulva blooms in nearshore waters, facilitated by the availability of near-real-time satellite images. Full article

Antarctic mapping with satellite images is an important basic task for polar environmental monitoring. Since the first Chinese marine satellite was launched in 2002, China has formed three series of more than 10 marine satellites in orbit. As global operational monitoring satellites of ocean color series, HY-1C and HY-1D have good coverage characteristics and imaging performance in polar regions, and they provide an effective tool for Antarctic monitoring and mapping. In this paper, Antarctic images acquired by the HY-1 satellite Coastal Zone Imager (CZI) sensor were used to study color matching in the mosaic process. According to the CZI characteristics for Antarctic imaging, experiments were carried out on the illuminance nonuniformity of a single image and color registration of multiple images. A gray-level segmentation color-matching method is proposed to solve the problem of image overstretching in the Antarctic image color-matching process. The results and statistical analysis show that the proposed method can effectively eliminate the color deviation between HY-1 Antarctic images, and the mosaic results have a good effect. Full article

Accurate Noctiluca scintillans bloom (NSB) recognition from space is of great significance for marine ecological monitoring and underwater target detection. However, most existing NSB recognition models require expert visual interpretation or manual adjustment of model thresholds, which limits model application in operational NSB monitoring. To address these problems, we developed a Noctiluca scintillans Bloom Recognition Network (NSBRNet) incorporating an Inception Conv Block (ICB) and a Swin Attention Block (SAB) based on the latest deep learning technology, where ICB uses convolution to extract channel and local detail features, and SAB uses self-attention to extract global spatial features. The model was applied to Coastal Zone Imager (CZI) data onboard Chinese ocean color satellites (HY1C/D). The results show that NSBRNet can automatically identify NSB using CZI data. Compared with other common semantic segmentation models, NSBRNet showed better performance with a precision of 92.22%, recall of 88.20%, F1-score of 90.10%, and IOU of 82.18%. Full article

HY-1C/D both carry a coastal zone imager (CZI) with a spatial resolution of 50 m and a swath width of 950 km, two observations can be achieved in three days when two satellites operating in a network. Accurate atmospheric correction is the basis for quantitative inversion of ocean color parameters using CZI However, atmospheric correction in estuarine and coastal waters with complex optical properties is a challenge due to the band setting of CZI. This paper proposed a novel atmospheric correction algorithm for CZI images applicable to turbid waters in estuarine and coastal zone. The Rayleigh scattering reflectance of CZI was calculated based on a vector radiative transfer model. Next, a semi-empirical radiative transfer model with suspended particle concentration as the parameter is used to model the water-atmosphere coupling. Finally, the parameters of the coupling model are solved by combining a global optimization method based on a genetic algorithm. The results indicate that the CZI-derived remote-sensing reflectance (R_rs) are in good agreement with the quasi-synchronous Landsat-8/9 operational land imager (OLI) derived R_rs in the green and red bands (R² > 0.96). Validation using in situ data revealed that the RMSE of the CZI-derived R_rs in the green and red bands was 0.0036 sr⁻¹ and 0.0035 sr⁻¹. More importantly, the values and spatial distributions of suspended particulate matter (SPM) estimated by CZI and those estimated by OLI in the Subei Shoal and the Yangtze River Estuary are basically consistent, and the validation using in situ data revealed that the inversion of SPM concentration by CZI was effective (R² = 0.86, RMSE = 0.0362 g/L), indicating that CZI has great potential and broad application prospects for monitoring the spatial and temporal dynamics of SPM in estuarine and coastal waters. The study results will lay the foundation for further estimating suspended sediment fluxes and carbon fluxes, thus providing data support and scientific basis for promoting resource development, utilization and conservation strategies in estuarine and coastal areas. Full article

Chlorophyll-a (Chl-a) change details derived from HY-1C/D images in the waters of the Zhoushan archipelago were analyzed. A new Chl-a inverse model was built based on the relationship between the in situ Chl-a and the combination of red, blue and green bands of the coastal zone imager (CZI). Chl-a as well as fishery resources were analyzed. The results showed the following. (1) The Chl-a concentration in the waters of the Zhoushan archipelago was mainly in the range of 0.5~6 μg/L. High Chl-a area distributed in the west side of the study area, with a value of 3.5~5.5 μg/L. The Chl-a concentration in the east side of the study area was relatively lower, with a value of 0.5~2 μg/L. Chl-a around the islands was higher than that in the area far away from the islands. In addition, Chl-a concentration increased obviously downstream of the island. (2) The spawning ground of many fish in the waters of the Zhoushan archipelago was abundant, and its spatial-temporal variation was consistent with the change of Chl-a. (3) The islands interacted with the current, inducing upwelling upstream and vortex streets downstream. The complex hydrodynamic environment promoted a vertical exchange of water bodies, thereby resulting in an increase in suspended sediment concentration, nutrients, Chl-a and attracting fish. Full article

When the in-orbit geometric calibration of optical satellite cameras is not performed in a precise or timely manner, optical remote sensing satellite images (ORSSIs) are produced with inaccurate camera parameters. The internal orientation (IO) biases of ORSSIs caused by inaccurate camera parameters show a discontinuous distorted characteristic and cannot be compensated by a simple orientation model. The internal geometric quality of ORSSIs will, therefore, be worse than expected. In this study, from the ORSSI users’ perspective, a feasible internal geometric quality improvement method is presented for ORSSIs with image reorientation. In the presented method, a sensor orientation model, an external orientation (EO) model, and an IO model are successively established. Then, the EO and IO model parameters are estimated with ground control points. Finally, the original image is reoriented with the estimated IO model parameters. Ten HaiYang-1C coastal zone imager (CZI) images, a ZiYuan-3 02 nadir image, a GaoFen-1B panchromatic image, and a GaoFen-1D panchromatic image, were tested. The experimental results showed that the IO biases of ORSSIs caused by inaccurate camera parameters could be effectively eliminated with the presented method. The IO accuracies of all the tested images were improved to better than 1.0 pixel. Full article

Existing red tide detection methods have mainly been developed for ocean color satellite data with low spatial resolution and high spectral resolution. Higher spatial resolution satellite images are required for red tides with fine scale and scattered distribution. However, red tide detection methods for ocean color satellite data cannot be directly applied to medium–high spatial resolution satellite data owing to the shortage of red tide responsive bands. Therefore, a new red tide detection method for medium–high spatial resolution satellite data is required. This study proposes the red tide detection U−Net (RDU−Net) model by considering the HY−1D Coastal Zone Imager (HY−1D CZI) as an example. RDU−Net employs the channel attention model to derive the inter−channel relationship of red tide information in order to reduce the influence of the marine environment on red tide detection. Moreover, the boundary and binary cross entropy (BBCE) loss function, which incorporates the boundary loss, is used to obtain clear and accurate red tide boundaries. In addition, a multi−feature dataset including the HY−1D CZI radiance and Normalized Difference Vegetation Index (NDVI) is employed to enhance the spectral difference between red tides and seawater and thus improve the accuracy of red tide detection. Experimental results show that RDU−Net can detect red tides accurately without a precedent threshold. Precision and Recall of 87.47% and 86.62%, respectively, are achieved, while the F1−score and Kappa are 0.87. Compared with the existing method, the F1−score is improved by 0.07–0.21. Furthermore, the proposed method can detect red tides accurately even under interference from clouds and fog, and it shows good performance in the case of red tide edges and scattered distribution areas. Moreover, it shows good applicability and can be successfully applied to other satellite data with high spatial resolution and large bandwidth, such as GF−1 Wide Field of View 2 (WFV2) images. Full article

We analyzed the impacts of islands on suspended sediment concentration (SSC) in Zhoushan Coastal waters based on data from HY-1C, which was launched in September 2018 in China, carrying Coastal Zone Imager (CZI) and Chinese Ocean Color and Temperature Scanner (COCTS) on it for offshore observation. A new SSC retrieved model was established based on the relationship between in situ SSC and the reflectance in red and near infrared bands of CZI image. Fifteen CZI images obtained from October to December 2019 were applied to retrieve SSC in Zhoushan coastal waters. The results show that SSC in study area is 100–1600 mg·L⁻¹. The SSC near islands changes obviously. Upstream of the islands, SSC is lower than downstream. During the flood and ebb, when the current passes through the islands, circumfluence will appear, under certain geophysical factors, generating Karman vortex streets downstream of the islands. The sediments were stirred by the fast speed current at the outer side of vortex street to the sea surface inducing higher SSC at the outer side of the vortex street, while the central sediments of the vortex street were lower. In the direction of ocean currents, the SSC of the vortex street downstream of islands is changing regularly, i.e., increasing, then decreasing and increasing again and then decreasing in a snaking vortex street whose length downstream is between 1000 and 8000 m long. Full article

The HY-1C satellite, as part of China’s optical satellite constellation for global ocean monitoring, monitors the ocean and coastal environment by the three broad visible bands of the Coastal Zone Imager (CZI) instrument. However, as a result of the sensor instrument noise, the atmospheric environment during imaging, and the shooting angle, the satellite images often show uneven illumination and inconsistent color between neighboring images. In this paper, according to the characteristics of the HY-1C CZI instrument, we propose a color consistency processing framework for coastal zone images of Antarctica. First of all, the high-frequency and low-frequency information of the image is separated by a statistical filter with simple clustering. The uneven lighting is then replaced by artificial lighting, which is globally uniform. Finally, the color difference between images is corrected by a color transfer method. In order to evaluate the color consistency results quantitatively, a new quantitative evaluation method is proposed. The experimental results for the coastal zone images of Antarctica show that the new processing framework can effectively eliminate the unevenness in the lighting and color. The mosaic results show a good performance in consistent lighting and tones, and the lack of visible mosaic lines proves the effectiveness of the proposed method. The quantitative evaluation analysis confirms the superiority of the proposed method over the Wallis method. Full article

The out-of-band (OOB) response is one of the key specifications for satellite optical sensors, which has important influences on quantitative remote sensing retrieval. In this paper, the effect of OOB response on the radiometric measurements made just above the sea surface is evaluated for the three broad visible bands (i.e., blue, green, and red) of the Coastal Zone Imager (CZI) onboard China’s ocean satellite HY-1C to be launched in September 2018. For the turbid coastal (Case 2) waters whose optical properties are mainly dominated by suspended sediment and colored dissolved organic material, the OOB effect can be neglected (<2%) for all three CZI visible bands. For the phytoplankton-dominated (Case 1) waters which are mainly distributed in the clear open ocean, a significant (>2%) OOB effect was found in the green band over oligotrophic waters (chlorophyll a concentration ≤~0.1 mg/m³), and accordingly a model based on the CZI blue-green band ratio is proposed to correct this effect. The OOB influence on the CZI ocean color retrieval is discussed. This research highlights the importance of the comprehensive pre-launch radiometric characterization and the OOB effect correction for the broad band space-borne sensor, in order to achieve a high-quality quantitative ocean product. Full article
