Effective stormwater management in urban areas requires enhancing the permeability of underlying surfaces. However, the impact of storm characteristics on infiltration processes in sponge cities remains insufficiently explored. This study uses the Horton method within the storm water management model to investigate how uniform and Chicago storm parameters affect infiltration rates. Our findings provide valuable insights: (1) Increasing porous pavement area proportionally reduces subarea sizes within subcatchments, and infiltration rates of porous pavements are supply-controlled. (2) Uniform storms result in consistent initial infiltration rates across pervious areas, subcatchments, and the entire catchment. The duration of this stable state decreases with higher return periods. Catchment infiltration volumes exhibit linear growth with greater storm intensities (R-squared = 0.999). (3) Peak infiltration rates and moments for pervious areas, subcatchments, and the overall catchment exhibit correlations with both the return period and the time-to-peak coefficient, with correlation coefficients ranging from −0.9914 to 0.9986 and p-values ranging from 0.0334 to 0.6923. This study quantifies the influence of design storm parameters on infiltration, providing valuable insights for stormwater infrastructure design and urban stormwater control. Full article

The temporal heterogeneity of rainfall is substantial in urban catchments, and it often has huge impacts on stormwater simulation and management. Using a design storm with a fixed pattern may cause uncertainties in hydrological modeling. Here, we propose an event-based stochastic parametric rainfall simulator (ESPRS) for stormwater simulation in a sponge city with green roofs, permeable pavements, and bioretention cells. In the ESPRS, we used five distributions to fit the measured rainfall events and evaluated their performance using Akaike’s Information Criterion, Anderson—Darling goodness-of-fit test, and p-values. The vast rainfall time series data generated using the ESPRS were used to run the storm water management model for outflow simulations in the catchment, thus revealing the influence of temporal rainfall characteristics on the hydrological responses. The results showed the following: (1) The ESPRS outperforms the Chicago method in predicting extreme precipitation events, and its control factors are the rainfall peak period, rainfall peak fraction, and cumulative rainfall fraction at the peak period. (2) The best-fit functions for the rainfall depth in each period have different distributions, mostly being in lognormal, gamma, and generalized extreme value distributions. (3) Rear-type precipitation events with high peak fractions are the most negative pattern for outflow control. The developed ESPRS can suitably reproduce rainfall time series for urban stormwater management. Full article

Urban flooding has become one of the most common natural hazards threatening people’s lives and assets globally due to climate change and rapid urbanization. Hydraulic structures, e.g., sluicegates and pumping stations, can directly influence flooding processes and should be represented in flood modeling and risk assessment. This study aims to present a robust numerical model by incorporating a hydraulic structure simulation module to accurately predict the highly transient flood hydrodynamics interrupted by the operation of hydraulic structures to support object-level risk assessment. Source-term and flux-term coupling approaches are applied and implemented to represent different types of hydraulic structures in the model. For hydraulic structures such as a sluicegate, the flux-term coupling approach may lead to more accurate results, as indicated by the calculated values of NSE and RMSE for different test cases. The model is further applied to predict different design flood scenarios with rainfall inputs created using Intensity-Duration-Frequency relationships, Chicago Design Storm, and surveyed data. The simulation results are combined with established vehicle instability formulas and depth-damage curves to assess the flood impact on individual objects in an urbanized case study area in Zhejiang Province, China. Full article

Design rainfall is the basis for deriving design floods in areas where rainfall data are lacking and has a significant impact on the construction of water engineering facilities and municipal engineering designs. The Chicago rainfall pattern method has great applicability for urban short-duration design rainfall. In order to analyze the influence of design storm rainfall patterns on urban flooding, numerical models of hydrological and hydrodynamic processes were applied to simulate design rainfall with different recurrence periods and different rain peaks and were also used to compare and analyze the total amount of water accumulation and inundation extent by taking the central city of Zhoukou as an example. The results show that when the design rainfall recurrence period is less than 20 years, the total volume and inundation extent of waterlogging in design rainfall with a smaller peak ratio is larger. When the return period is greater than 20 years, the pattern is reversed. However, as the return period grows, the difference in peak inundation volume due to different peak rainfall amounts decreases. This study has certain guiding significance for urban flood forecasting and early warning efforts. Full article

The rainstorm intensity formula and the design of rainstorm hyetographs are important aspects in drainage design standards. Against the backdrop of climate change, in most cities in Jiangsu Province of China, significant trends of increasing intensities of heavy rainfall are apparent. The parameters of the rainstorm intensity formula are no longer applicable in the current context of significantly stronger rainstorms. To adapt to this change, we first contrasted the fitting accuracy of the Gumbel distribution, the exponential distribution, and the Pearson III distribution for the rainstorm intensity formula in Jiangsu. It was found that the Gumbel distribution has the smallest relative mean square error in most cities, proving that it provides the best estimation of rainstorm intensity formula parameters. Therefore, the rainstorm intensity formula parameters for 13 cities was revised using the Gumbel distribution based on the rainfall data from 1991 to 2020. Then, the precipitation with a 100-year return period was calculated using the revised formula. Moreover, to compensate for the lack of storm hyetographs that have been designed for Jiangsu, we designed short-duration rainstorm hyetographs for 13 cities using the Chicago hyetograph method and the Pilgrim and Cordery (PC) method. The results show that most of the short-duration rainstorms lasted between 45 and 120 min and were dominated by single-peaked patterns, with the peak position typically occurring in the first half of the rainfall cycle. The peak coefficient distribution of short-duration rainstorms shows that short-duration rainstorms in the south reached their peak rainfall intensity earlier than those in the north. On this basis, using the Chicago method and PC method, short-duration storm hyetographs were designed, which could be used in the design of drainage systems to provide support in effectively reducing urban flood threats. By comparing the hyetographs with real short-duration rainstorm patterns, it was found that the precipitation process designed using the PC method was most similar to the actual precipitation process. However, the PC method was found to be highly dependent on local precipitation data, whereas only the rain peak coefficient is required to design the Chicago rainstorm hyetograph. Therefore, we primarily recommend hyetographs designed using the PC method for Jiangsu Province’s 13 major cities, while we recommend the Chicago hyetograph for the surrounding areas of the 13 cities that have no meteorological stations or lack data. Full article

Storm runoff is a growing concern against a background of increasing urban densification, land-use adaptation and climate change. In this study, a storm water management model was used to analyze the hydrological and water-quality effects of rain gardens (also known as bioretention cells) as nonpoint source control solutions in low-impact development (LID) practices for an urban catchment in the Nakagyo Ward area of Kyoto in Japan. The results of simulations with input involving Chicago hyetographs derived for different rainfall return periods (referred to as 3 a, 5 a, 10 a, 30 a, 50 a and 100 a) indicated the effectiveness of this arrangement, in particular for rainstorm 3 a, which exhibited the maximum contaminant reduction ratio (Total Suspended Solids (TSS) 15.50%, Chemical Oxygen Demand (COD) 16.17%, Total Nitrogen (TN) 17.34%, Total Phosphorus (TP) 19.07%) and a total runoff reduction volume of 46.56 × 106 L. With 5 a, the maximum number of flooding nodes was reduced to 87, demonstrating that rain gardens handle rainfall effectively over a five-year return period. There was a one-minute delay for 100 a, which again indicates that rain gardens support control of urban runoff and mitigate flooding. Such gardens were associated with reduced stormwater hazards and enhanced resistance to short-term rainstorms at the research site, and should be considered for urban planning in Kyoto and other cities all over the world. Full article

Grassed swales and permeable pavement that have greater permeable underlying surface relative to hard-pressing surface can cooperate with the city pipe network on participating in urban storm flood regulation. This paper took Nanshan village in Jiangsu Province as an example, the storm-water management model (SWMM) was used to conceptualize the study area reasonably, and the low-impact development (LID) model and the traditional development model were established in the region. Based on the storm-intensity equation, the simulation scene employed the Chicago hydrograph model to synthesize different rainfall scenes with different rainfall repetition periods, and then contrasted the storm-flood-management effect of the two models under the condition of using LID facilities. The results showed that when the rainfall repetition period ranged from 0.33a to 10a (a refers to the rainfall repetition period), the reduction rate of total runoff in the research area that adopted LID ranged from 100% to 27.5%, while the reduction rate of peak flow ranged from 100% to 15.9%, and when the values of unit area were the same, the combined system (permeable pavement + grassed swales) worked more efficiently than the sum of the individuals in the reduction of total runoff and peak flow throughout. This research can provide technical support and theoretical basis for urban LID design. Full article

The storm hyetograph is critical in drainage design since it determines the peak flooding volume in a catchment and the corresponding drainage capacity demand for a return period. This study firstly compares the common design storms such as the Chicago, Huff, and Triangular curves employed to represent the storm hyetographs in the metropolitan area of Guangzhou using minute-interval rainfall data during 2008–2012. These common design storms cannot satisfactorily represent the storm hyetographs in sub-tropic areas of Guangzhou. The normalized time of peak rainfall is at 33 ± 5% for all storms in the Tianhe and Panyu districts, and most storms (84%) are in the 1st and 2nd quartiles. The Huff curves are further improved by separately describing the rising and falling limbs instead of classifying all storms into four quartiles. The optimal time intervals are 1–5 min for deriving a practical urban design storm, especially for short-duration and intense storms in Guangzhou. Compared to the 71 observed storm hyetographs, the Improved Huff curves have smaller RMSE and higher NSE values (6.43, 0.66) than those of the original Huff (6.62, 0.63), Triangular (7.38, 0.55), and Chicago (7.57, 0.54) curves. The mean relative difference of peak flooding volume simulated with SWMM using the Improved Huff curve as the input is only 2%, −6%, and 8% of those simulated by observed rainfall at the three catchments, respectively. In contrast, those simulated by the original Huff (−12%, −43%, −16%), Triangular (−22%, −62%, −38%), and Chicago curves (−17%, −19%, −21%) are much smaller and greatly underestimate the peak flooding volume. The Improved Huff curve has great potential in storm water management such as flooding risk mapping and drainage facility design, after further validation. Full article
