Search Results (39)

This work presents a direct conversion transmitter (DCT) for 5G new radio (NR) that eliminates the RF driver by directly feeding a single stage cascode PA through a baseband buffer amplifier and passive up-conversion mixer. The baseband interface uses Class-AB buffers to hold the output capacitor voltage, enabling accurate sampling at the PA input. A mixer switch is selected for minimal on-resistance variation over the required baseband swing. The PA is designed with separate I and Q voltage inputs and a current summing structure. The PA operates at 2.5 V; other blocks use 1.2 V. Post-layout two-tone simulations at 5 GHz indicate 21 dBm output saturation power and −36.1 dBc of IMD3 at 9 dB PBO power while removing the driver to inter stage matching network of a two-stage design. The results validate a compact, driverless architecture for integrated transmitters. Full article

Unmanned aerial vehicles (UAVs) have become a tool for solving numerous practical tasks. UAV sensors provide images and videos for on-line or off-line data processing for object localization, classification, and tracking due to the use of trained convolutional neural networks (CNNs) and artificial intelligence. However, quality of images acquired by UAV-based sensors is not always perfect due to many factors. One of them could be noise arising because of several reasons. Its presence, especially if noise is intensive, can make significantly worse the performance characteristics of CNN-based techniques of object localization and classification. We analyze such degradation for a set of eleven modern CNNs for additive white Gaussian noise model and study when (for what noise intensity and for what CNN) the performance reduction becomes essential and, thus, special means to improve it become desired. Representatives of two most popular families, namely the block matching 3-dimensional (BM3D) filter and DRUNet denoiser, are employed to enhance images under condition of a priori known noise properties. It is shown that, due to preliminary denoising, the CNN performance characteristics can be significantly improved up to almost the same level as for the noise-free images without CNN retraining. Performance is analyzed using several criteria typical for image denoising, object localization and classification. Examples of object localization and classification are presented demonstrating possible object missing due to noise. Computational efficiency is also taken into account. Using a large set of test data, it is demonstrated that: (1) the best results are usually provided for SSD Mobilenet V2 and VGG16 networks; (2) the performance characteristics for cases of applying BM3D filter and DRUNet denoiser are similar but the use of DRUNet is preferable since it provides slightly better results. Full article

Phase-sensitive surface plasmon resonance (SPR) detection is widely employed in molecular dynamics studies and SPR imaging owing to its real-time capability, high sensitivity, and compatibility with imaging systems. A key research objective is to achieve higher measurement resolution of refractive index under optimal dynamic range conditions. We present an enhanced SPR phase imaging system combining a quad-polarization filter array for phase differential detection with a novel polarization pair, block matching, and 4D filtering (PPBM4D) algorithm to extend the dynamic range and enhance resolution. By extending the BM3D framework, PPBM4D leverages inter-polarization correlations to generate virtual measurements for each channel in the quad-polarization filter, enabling more effective noise suppression through collaborative filtering. The algorithm demonstrates 57% instrumental noise reduction and achieves 1.51 × 10⁻⁶ RIU resolution (1.333–1.393 RIU range). The system’s algorithm performance is validated through stepwise NaCl solution switching experiments (0.0025–0.08%) and protein interaction assays (0.15625–20 μg/mL). This advancement establishes a robust framework for high-resolution SPR applications across a broad dynamic range, particularly benefiting live-cell imaging and high-throughput screening. Full article

Random noise degrades the quality and reduces the interpretability of Ground Penetrating Radar (GPR) data. The Block Matching Three Dimension (BM3D) algorithm is effective at suppressing Gaussian noise, but ineffective at handling salt-and-pepper noise. On the other hand, the Improved Adaptive Median (IAM) filter is suitable for eliminating salt-and-pepper noise, but performs poorly against Gaussian noise. In this paper, we introduce and implement JBI, a joint denoising algorithm that integrates both BM3D and improved adaptive median filtering, exploiting the advantages of both algorithms to effectively remove both Gaussian and salt-and-pepper noise from GPR data. Applying the proposed joint filter to both synthetic and real field GPR data, infested with various proportions of different noise types, shows that the proposed joint denoising algorithm yields significantly better results than these two filters when used separately, and better than other commonly used denoising filters. Full article

During image collection, images are often polluted by noise because of imaging conditions and equipment limitations. Images are also disturbed by external noise during compression and transmission, which adversely affects consequent processing, like image segmentation, target recognition, and text detection. A two-dimensional amplitude image is one of the most common image categories, which is widely used in people’s daily life and work. Research on this kind of image-denoising algorithm is a hotspot in the field of image denoising. Conventional denoising methods mainly use the nonlocal self-similarity of images and sparser representatives in the converted domain for image denoising. In particular, the three-dimensional block matching filtering (BM3D) algorithm not only effectively removes the image noise but also better retains the detailed information in the image. As artificial intelligence develops, the deep learning-based image-denoising method has become an important research direction. This review provides a general overview and comparison of traditional image-denoising methods and deep neural network-based image-denoising methods. First, the essential framework of classic traditional denoising and deep neural network denoising approaches is presented, and the denoising approaches are classified and summarized. Then, existing denoising methods are compared with quantitative and qualitative analyses on a public denoising dataset. Finally, we point out some potential challenges and directions for future research in the field of image denoising. This review can help researchers clearly understand the differences between various image-denoising algorithms, which not only helps them to choose suitable algorithms or improve and innovate on this basis but also provides research ideas and directions for subsequent research in this field. Full article

In this paper, we present a novel color edge detection method that integrates collaborative filtering with multiscale gradient fusion. The Block-Matching and 3D (BM3D) filter is utilized to enhance sparse representations in the transform domain, effectively reducing noise. The multiscale gradient fusion technique compensates for the loss of detail in single-scale edge detection, thereby improving both edge resolution and overall quality. RGB images from the dataset are converted into the XYZ color space through mathematical transformations. The Colored Block-Matching and 3D (CBM3D) filter is applied to the sparse images to reduce noise. Next, the vector gradients of the color image and anisotropic Gaussian directional derivatives for two scale parameters are computed. These are then averaged pixel-by-pixel to generate a refined edge strength map. To enhance the edge features, the image undergoes normalization and non-maximum suppression. This is followed by edge contour extraction using double-thresholding and a novel morphological refinement technique. Experimental results on the edge detection dataset demonstrate that the proposed method offers robust noise resistance and superior edge quality, outperforming traditional methods such as Color Sobel, Color Canny, SE, and Color AGDD, as evidenced by performance metrics including the PR curve, AUC, PSNR, MSE, and FOM. Full article

Modern imaging systems produce a great volume of image data. In many practical situations, it is necessary to compress them for faster transferring or more efficient storage. Then, a compression has to be applied. If images are noisy, lossless compression is almost useless, and lossy compression is characterized by a specific noise filtering effect that depends on the image, noise, and coder properties. Here, we considered a modern HEIF coder applied to grayscale (component) images of different complexity corrupted by additive white Gaussian noise. It has recently been shown that an optimal operation point (OOP) might exist in this case. Note that the OOP is a value of quality factor where the compressed image quality (according to a used quality metric) is the closest to the corresponding noise-free image. The lossy compression of noisy images leads to both noise reduction and distortions introduced into the information component, thus, a compromise should be found between the compressed image quality and compression ratio attained. The OOP is one possible compromise, if it exists, for a given noisy image. However, it has also recently been demonstrated that the compressed image quality can be significantly improved if post-filtering is applied under the condition that the quality factor is slightly larger than the one corresponding to the OOP. Therefore, we considered the efficiency of post-filtering where a block-matching 3-dimensional (BM3D) filter was applied. It was shown that the positive effect of such post-filtering could reach a few dB in terms of the PSNR and PSNR-HVS-M metrics. The largest benefits took place for simple structure images and a high intensity of noise. It was also demonstrated that the filter parameters have to be adapted to the properties of residual noise that become more non-Gaussian if the compression ratio increases. Practical recommendations on the use of compression parameters and post-filtering are given. Full article

Synthetic aperture radar (SAR) has been extensively applied in remote sensing applications. Nevertheless, it is a challenge to process and interpret SAR images. The key to interpreting SAR images lies in transforming them into other forms of remote sensing images to extract valuable hidden remote sensing information. Currently, the conversion of SAR images to optical images produces low-quality results and incomplete spectral information. To address these problems, an end-to-end network model, S2MS-GAN, is proposed for converting SAR images into multispectral images. In this process, to tackle the issues of noise and image generation quality, a TV-BM3D module is introduced into the generator model. Through TV regularization, block-matching, and 3D filtering, these two modules can preserve the edges and reduce the speckle noise in SAR images. In addition, spectral attention is added to improve the spectral features of the generated MS images. Furthermore, we construct a very high-resolution SAR-to-MS image dataset, S2MS-HR, with a spatial resolution of 0.3 m, which is currently the most comprehensive dataset available for high-resolution SAR-to-MS image interpretation. Finally, a series of experiments are conducted on the relevant dataset. Both quantitative and qualitative evaluations demonstrate that our method outperforms several state-of-the-art models in translation performance. The solution effectively facilitates high-quality transitions of SAR images across different types. Full article

X-ray Fluorescence Computed Tomography (XFCT) is an emerging non-invasive imaging technique providing high-resolution molecular-level data. However, increased sensitivity with current benchtop X-ray sources comes at the cost of high radiation exposure. Artificial Intelligence (AI), particularly deep learning (DL), has revolutionized medical imaging by delivering high-quality images in the presence of noise. In XFCT, traditional methods rely on complex algorithms for background noise reduction, but AI holds promise in addressing high-dose concerns. We present an optimized Swin-Conv-UNet (SCUNet) model for background noise reduction in X-ray fluorescence (XRF) images at low tracer concentrations. Our method’s effectiveness is evaluated against higher-dose images, while various denoising techniques exist for X-ray and computed tomography (CT) techniques, only a few address XFCT. The DL model is trained and assessed using augmented data, focusing on background noise reduction. Image quality is measured using peak signal-to-noise ratio (PSNR) and structural similarity index (SSIM), comparing outcomes with 100% X-ray-dose images. Results demonstrate that the proposed algorithm yields high-quality images from low-dose inputs, with maximum PSNR of 39.05 and SSIM of 0.86. The model outperforms block-matching and 3D filtering (BM3D), block-matching and 4D filtering (BM4D), non-local means (NLM), denoising convolutional neural network (DnCNN), and SCUNet in both visual inspection and quantitative analysis, particularly in high-noise scenarios. This indicates the potential of AI, specifically the SCUNet model, in significantly improving XFCT imaging by mitigating the trade-off between sensitivity and radiation exposure. Full article

Chemical Exchange Saturation Transfer (CEST) magnetic resonance imaging (MRI) provides a novel method for analyzing biomolecule concentrations in tissues without exogenous contrast agents. Despite its potential, achieving a high signal-to-noise ratio (SNR) is imperative for detecting small CEST effects. Traditional metrics such as Magnetization Transfer Ratio Asymmetry (MTR_asym) and Lorentzian analyses are vulnerable to image noise, hampering their precision in quantitative concentration estimations. Recent noise-reduction algorithms like principal component analysis (PCA), nonlocal mean filtering (NLM), and block matching combined with 3D filtering (BM3D) have shown promise, as there is a burgeoning interest in the utilization of neural networks (NNs), particularly autoencoders, for imaging denoising. This study uses the Bloch–McConnell equations, which allow for the synthetic generation of CEST images and explores NNs efficacy in denoising these images. Using synthetically generated phantoms, autoencoders were created, and their performance was compared with traditional denoising methods using various datasets. The results underscored the superior performance of NNs, notably the ResUNet architectures, in noise identification and abatement compared to analytical approaches across a wide noise gamut. This superiority was particularly pronounced at elevated noise intensities in the in vitro data. Notably, the neural architectures significantly improved the PSNR values, achieving up to 35.0, while some traditional methods struggled, especially in low-noise reduction scenarios. However, the application to the in vivo data presented challenges due to varying noise profiles. This study accentuates the potential of NNs as robust denoising tools, but their translation to clinical settings warrants further investigation. Full article

Brillouin optical time domain reflectometry (BOTDR) detects fiber temperature and strain data and represents one of the most critical ways of identifying abnormal conditions such as ice coverage and lightning strikes on optical fiber composite overhead ground wire (OPGW) cable. Existing BOTDR extracts brillouin frequency shift (BFS) features with cumulative averaging and curve fitting. BFS feature extraction is slow for long-distance measurements, making realizing real-time measurements on fiber optic cables challenging. We propose a fast feature extraction method for block matching and 3D filtering (BM3D) + Sobel brillouin scattering spectroscopy (BGS). BM3D takes the advantage of non-local means (NLM) and wavelet denoising (WD) and utilizes the spatial-domain non-local principle to enhance the denoising in the transform domain. The global filtering capability of BM3D is utilized to filter out the low cumulative average BGS noise and the BFS feature extraction is completed using Sobel edge detection. Simulation verifies the feasibility of the algorithm, and the proposed method is embedded in BOTDR to measure 30 km of actual OPGW line. The experimental results show that under the same conditions, the processing time of this method is reduced by 37 times compared to that with the 50,000-time cumulative averaging + levenberg marquardt (LM) algorithm without severe distortion of the reference resolution. The method improves the sensor demodulation speed by using image processing technology without changing the existing hardware equipment, which is expected to be widely used in the new generation of BOTDR. Full article

Speckle noise is an inherent problem of synthetic aperture radar (SAR) images, which not only seriously affects the acquisition of SAR image information, but also greatly reduces the efficiency of image segmentation and feature classification. Therefore, research on how to effectively suppress speckle noise while preserving SAR image content information as much as possible has received increasing attention. Based on the non-local idea of SAR image block-matching three-dimensional (SAR-BM3D) algorithm and the concept of sparse representation, a novel SAR image despeckling algorithm is proposed. The new algorithm uses K-means singular value decomposition (K-SVD) to learn the dictionary to distinguish valid information and speckle noise and constructs a block filter based on K-SVD for despeckling, so as to avoid strong point diffusion problem in SAR-BM3D and achieve better speckle noise suppression with stronger adaptability. The experimental results on real SAR images show that the proposed algorithm achieves better comprehensive effect of speckle noise suppression in terms of evaluation indicators and information preservation of SAR images compared with several existing algorithms. Full article

We propose an improved BM3D algorithm for block-matching based on UNet denoising network feature maps and structural similarity (SSIM). In response to the traditional BM3D algorithm that directly performs block-matching on a noisy image, without considering the deep-level features of the image, we propose a method that performs block-matching on the feature maps of the noisy image. In this method, we perform block-matching on multiple depth feature maps of a noisy image, and then determine the positions of the corresponding similar blocks in the noisy image based on the block-matching results, to obtain the set of similar blocks that take into account the deep-level features of the noisy image. In addition, we improve the similarity measure criterion for block-matching based on the Structural Similarity Index, which takes into account the pixel-by-pixel value differences in the image blocks while fully considering the structure, brightness, and contrast information of the image blocks. To verify the effectiveness of the proposed method, we conduct extensive comparative experiments. The experimental results demonstrate that the proposed method not only effectively enhances the denoising performance of the image, but also preserves the detailed features of the image and improves the visual quality of the denoised image. Full article

In this study, we optimized the $\mathsf{\sigma }$-values of a block matching and 3D filtering (BM3D) algorithm to reduce noise in magnetic resonance images. Brain T2-weighted images (T2WIs) were obtained using the BrainWeb simulation program and Rician noise with intensities of 0.05, 0.10, and 0.15. The BM3D algorithm was applied to the optimized BM3D algorithm and compared with conventional noise reduction algorithms using Gaussian, median, and Wiener filters. The clinical feasibility was assessed using real brain T2WIs from the Alzheimer’s Disease Neuroimaging Initiative. Quantitative evaluation was performed using the contrast-to-noise ratio, coefficient of variation, structural similarity index measurement, and root mean square error. The simulation results showed optimal image characteristics and similarity at a σ-value of 0.12, demonstrating superior noise reduction performance. The optimized BM3D algorithm showed the greatest improvement in the clinical study. In conclusion, applying the optimized BM3D algorithm with a σ-value of 0.12 achieved efficient noise reduction. Full article

This work presents a compact batteryless node architecture suitable with the backscattering communication (BackCom) approach. The key functional blocks are demonstrated at 5.8 GHz, making use of commercially available components involving a DC/DC step-up converter, a 3.3 V data generator, and an ASK backscattering modulator based on a single GaAs HEMT in a cold-FET configuration. The node integrates a patch antenna exhibiting a non-50 $\mathsf{\Omega }$ optimal port impedance; the value is defined by means of a source pull-based optimization technique aimed at maximizing the DC/DC input current supplied by the RF to DC converter. This approach maximizes the node compactness, as well as the wireless power conversion efficiency. A prototype was optimized for the −5 dBm power level at the input of the RF to DC converter. Under this measurement condition, the experimental results showed a 63% increase in the harvesting current, rising from 145 to 237 $\mathsf{\mu }$A, compared to an identical configuration that used a microstrip matching network coupled with a typical 50-$\mathsf{\Omega }$ patch antenna. In terms of harvested power, the achieved improvement was from −13.2 dBm to −10.9 dBm. The conversion efficiency in an operative condition improved from 15% to more than 25%. In this condition, the node is capable of charging a 100 $\mathsf{\mu }$F to the operative voltage in about 27 s, and operating the backscattering for 360 ms with a backscattering modulation frequency of about 10 MHz. Full article
