In order to reduce the edge waves and defects of the strip in the forming process and obtain better properties of the strip, it is urgent to establish a better flexible cold forming process. In this paper, a finite element model of the production line was established to simulate the forming process, and the effective stress distribution at the corner of the strip was simulated. The effect of cold working hardening was basically consistent with that calculated by the analytical method and tensile test results. A mathematical model of the maximum normal strain along the tangent direction of the strip’s outer edge of each pass was established. With the constraint conditions that the maximum value of the normal strain value of each pass is less than the critical value and the upper and lower limit of the horizontal value of each test factor, and the maximum value of the normal strain of each pass as the goal, the number of cold forming passes, the bending angle of each pass and the working roll diameter of the roll have been determined. The optimized process parameters were used in the simulations. No edge wave at the strip edge and no “Bauschinger effect” in forming before high-frequency induction welding was found. The method proposed in this paper can optimize the key process parameters before the production line is put into operation, minimize the possible buckling of the strip edge during the forming process, and reduce the possible loss caused by design defects. Full article

High-strength steels such as Dual Phase (DP), Transformation-Induced Plasticity (TRIP), and Twinning-Induced Plasticity (TWIP) steels have gained importance in automotive applications due to the potential for weight reduction and increased performance in crash tests. However, as resistance increases, there is also an increase in springback due to residual stresses after the forming process. This is mainly because of the greater elastic region of these materials and other factors associated with strain hardening, such as the Bauschinger effect, that brings theory of kinematic hardening to mathematical modeling. This means that finite element software must consider these properties so that the simulation can accurately predict the behavior. Currently, this knowledge is still not widespread since it has never been used in conventional materials. Additionally, engineers and researchers use the Forming Limit Diagram (FLD) curve in their studies. However, it does not fully represent the actual failure limit of materials, especially in high-strength materials. Based on this, the Fracture Forming Limit Diagram (FFLD) curve has emerged, which proposes to resolve these limitations. Thus, this review aims to focus on how finite element methods consider all these factors in their modeling, especially when it comes to the responses of high-strength steels. Full article

Based on the transition state theory, a continuum plasticity theory is developed for metallic materials. Moreover, the nature of local stress fluctuation within a material point is considered by incorporating the probability distribution of the stresses. The model is applied to investigate the mechanical behaviors of 316 L stainless steel under various loading cases. The simulated results closely match the results obtained by the polycrystal plasticity model and experiments. The mechanical behaviors associated with strain rate sensitivity, temperature dependence, stress relaxation, and strain creep are correctly captured by the model. Furthermore, the proposed model successfully characterizes the Bauschinger effect, which is challenging to capture with a conventional continuum model without additional assumptions. The proposed model could be further employed in the design, manufacturing, and service of engineering components. Full article

The existing tensile–compression elastoplastic models are not suitable for varies of materials. An accurate constitutive model of the elastoplastic mechanical properties more suitable for 35CrNi3MoVR was produced by optimizing the existing fitting equations based on uniaxial tensile–compression tests, which are able to describe the elastoplastic stress–strain relation and Bauschinger effect varying with the maximum tensile plastic strain. A UMAT subroutine of the constitutive model in ABAQUS was proposed and conducted for FEM calculation. Hydraulic autofrettage tests were carried out under different pressures on thick-walled 35CrNi3MoVR tubes, and the results were compared with those of FEM calculations to further validate the accuracy of the fitting model. The results show that the constructed power function kinematic hardening model can effectively describe the elastoplastic mechanical properties of 35CrNi3MoVR and can be applied to the autofrettage calculation of this material. The comparison among the calculation results of different models proved that the model proposed in this research has better performance compared to other existing models. Taking the Mises stress at the inner surface of the thick-walled tubes as the evaluation criterion, the error of the power function kinematic hardening model reaches less than 3%, decreasing the error by at least 50%. Full article

Recent catastrophic earthquake events have reinforced the necessity of evaluating the seismic performance of buildings. Notably, the buildings can go into the plastic phase during a striking earthquake disaster. Under this condition, the current design codes assume seismic response reduction by virtue of the energy dissipation capacity of the structural members. In the strong-column–weak-beam design, which involves I-shaped beams and boxed columns, the mechanism is defined as a standard design scheme to prevent the building from collapsing. Therefore, energy dissipation relies highly on the I-shaped beam performance. However, the I-shaped beam performance can differ depending on the loading history experienced, whereas this effect is untouched in the prevailing evaluation equation. Hence, this study first performs cyclic loading tests of 11 specimens using different loading protocols. The experimental results clarify the fluctuation in the structural performance of I-shaped beams depending on the applied loading hysteresis, proving the necessity of considering the stress history for proper assessment. Furthermore, the database of experimental results is constructed based on the previous experimental studies. Ultimately, the novel evaluation equation is proposed to reflect the influences of the loading protocol. This equation is demonstrated to effectively assess the member performance retrieved from the experiment of 65 specimens, comprising 11 specimens from this investigation and 54 specimens from the database. The width–thickness ratio, shear span-to-depth ratio, and loading protocols are utilized as the evaluation parameters. Moreover, the prediction equation of the Bauschinger effect coefficient is newly established to convert the energy dissipation capacity under monotonically applied force into hysteretic energy dissipation under the cyclic forces. Full article

In the present work, the goal is to use two-scale simulations to be incorporated into the full-field open software DAMASK version 2.0.3 crystal plasticity framework, in relation to the Bauschinger effect caused by the composite effect of the presence of second-phase particles with surrounding deformation zones. The idea is to achieve this by including a back stress of the critical resolved shear stress in a single-phase simulation, as an alternative to explicitly resolving the second-phase particles in the system. The back stress model is calibrated to the volume-averaged behaviour of detailed crystal plasticity simulations with the presence of hard, non-shearable spherical particles or voids. A simplified particle-scale model with a periodic box containing only one of the spherical particles in the crystal is considered. Applying periodic boundary conditions corresponds to a uniform regular distribution of particles or voids in the crystal. This serves as an idealised approximation of a particle distribution with the given mean size and particle volume fraction. The Bauschinger effect is investigated by simulating tensile–compression tests with 5% and 10% volume fractions of particles and with 1%, 2%, and 5% pre-strain. It is observed that an increasing volume fraction increases the Bauschinger effect, both for the cases with particles and with voids. However, increasing the pre-strain only increases the Bauschinger effect for the case with particles and not for the case with voids. The model with back stress of the critical resolved shear stress, but without the detailed particle simulation, can be fitted to provide reasonably close results for the volume-averaged response of the detailed simulations. Full article

Interference fits are very common shaft–hub connections due to their low manufacturing costs and excellent technical properties. The Plastic Conditioning of this machine element is a new and not very well-known method. During the development of this method, it was discovered that Reverse Yielding occurs in certain applications and has a negative impact on the result. This paper examines the effects of Reverse Yielding on the technology of Plastic Conditioning of interference fits in Power Transmission Engineering. Based on the Shear Stress Hypothesis (SH), the Plane Stress State (PSS), and the ideal plastic behavior of materials, established stress–mechanical relationships are used to find the influencing parameters of Reverse Yielding on the technology of Plastic Conditioning and their limits. As a result, a new computational concept is developed that allows the user to maximize Plastic Conditioning while avoiding Reverse Yielding. Analytical calculation suggestions and diagrams for practical application are provided. Furthermore, the deviations in the obtained results, taking into account other material models such as the Von Mises Yield Criterion (VMYC) and material hardening, as well as the Bauschinger effect, are examined in comparison with our own numerical results from the development of Plastic Conditioning, and the resulting need for further research is defined. In addition, the method of Plastic Conditioning of interference fits is introduced and its basic principles are briefly explained. Full article

Although the Bauschinger effect has been investigated in some detail in various materials, the number of articles on the effect of grain size is extremely limited, and in current nanostructured materials it is practically absent. Since such materials are considered as promising for structural applications, it is important to understand their mechanical behavior under conditions of changing the direction of deformation, and, therefore, it is necessary to study the Bauschinger effect and its dependence on grain size. The Bauschinger effect was investigated by a single exemplary method for tensile compression of commercially pure hcp titanium and fcc copper, with different grain sizes in the range from hundreds of microns to hundreds of nanometers. The change in grain size was performed by structure refinement by the method of severe plastic deformation using equal-channel angular pressing and subsequent annealing. It has been established that, in both materials, the Bauschinger effect increases with a decrease in grain size, the degree of permanent strain and the duration of exposure between forward and reverse deformation. The signs of the Bauschinger parameter in copper and titanium are opposite. The relationship between the Bauschinger effect and the nature of strain hardening in titanium and softening in copper in the ultrafine-grained state is discussed. Full article

The simple shear test shows significant advantages when measuring the hardening and shear properties of thin sheet metal at large strains. However, previous shear tests had an end effect caused by local stress concentration and a boundary effect caused by deformation overflow, resulting in non-uniform strain distribution in the shear zone. Therefore, a unique V-shaped double-shear-zone specimen is proposed to measure the Bauschinger effect under cyclic shear loading conditions in this paper. Simple shear experiments and three different types of cycle shear experiments are conducted to analyze the uniformity of deformation in the shear zone and the effect of pre-strain and the number of cyclic loads on the Bauschinger effect of Q890 high-strength steel sheets. The results indicate that the proposed V-shaped double-shear-zone specimen can still maintain uniform shear deformation in forward/reverse cyclic loading experiments, even at large strains. Q890 high-strength steel exhibits a significant Bauschinger effect, which is more pronounced with the increase in shear pre-strain and loading cycles. The results of this paper provide a new approach for studying the hardening characteristics under large strain and the mechanical properties under cyclic shear loading for metal sheets. Full article

The deformation behaviour of aluminium reinforced by carbon nanotubes (Al/CNTs) nanocomposites during cold rolling was investigated in this work. Deformation processes after production by conventional powder metallurgy routes may be an efficient approach to improve the microstructure and mechanical properties by decreasing the porosity. Metal matrix nanocomposites have enormous potential to produce advanced components, mainly in the mobility industry, with powder metallurgy being one of the most reported production processes. For this reason, it is increasingly important to study the deformation behaviour of nanocomposites. In this context, nanocomposites were produced via powder metallurgy. Advanced characterization techniques carried out the microstructural characterization of the as-received powders and produced nanocomposites. The microstructural characterization of the as-received powders and produced nanocomposites was carried out through optical microscopy (OM), and scanning and transmission electron microscopy (SEM and TEM), complemented by electron backscattered diffraction (EBSD). The powder metallurgy route followed by cold rolling is reliable for Al/CNTs nanocomposites. The microstructural characterization shows that the nanocomposites exhibit a different crystallographic orientation than the Al matrix. CNTs in the matrix influence grain rotation during sintering and deformation. Mechanical characterization revealed that during deformation, there is an initial decrease in the hardness and tensile strength for the Al/CNTs and Al matrix. The initial decrease was attributed to the Bauschinger effect being more significant for the nanocomposites. The difference in the mechanical properties of the nanocomposites and Al matrix was attributed to distinct texture evolution during cold rolling. Full article

In this paper, the time- and temperature-dependent cyclic ratchetting plasticity of the nickel-based alloy IN100 is experimentally investigated in strain-controlled experiments in the temperature range from 300 °C to 1050 °C. To this end, uniaxial material tests are performed with complex loading histories designed to activate phenomena as strain rate dependency, stress relaxation as well as the Bauschinger effect, cyclic hardening and softening, ratchetting and recovery from hardening. Plasticity models with different levels of complexity are presented that consider these phenomena, and a strategy is derived to determine the multitude of temperature-dependent material properties of the models in a step-by-step procedure based on sub-sets of experimental data of isothermal experiments. The models and the material properties are validated based on the results of non-isothermal experiments. A good description of the time- and temperature-dependent cyclic ratchetting plasticity of IN100 is obtained for isothermal as well as non-isothermal loading with models including ratchetting terms in the kinematic hardening law and the material properties obtained with the proposed strategy. Full article

In sheet metal forming, the material is usually subjected to a complex nonlinear loading process, and the anisotropic hardening behavior of the material must be considered in order to accurately predict the deformation of the sheet. In recent years, the homogeneous anisotropic hardening (HAH) model has been applied in the simulation of sheet metal forming. However, the existing HAH model is established in the second-order stress deviator space, which makes the calculation complicated and costly, especially for a plane stress problem such as sheet metal forming. In an attempt to reduce the computational cost, an HAH model in plane stress state is proposed, and called the HAH-2d model in this paper. In the HAH-2d model, both the stress vector and microstructure vector contain only three in-plane components, so the calculation is significantly simplified. The characteristics of the model under typical nonlinear loading paths are analyzed. Additionally, the feasibility of the model is verified by the stress–strain responses of DP780 and EDDQ steel sheets under different two-step uniaxial tension tests. The results show that the HAH-2d model can reasonably reflect the Bauschinger effect and the permanent softening effect in reverse loading, and the latent hardening effect in cross loading, while the predictive accuracy for cross-loading softening remains to be improved. In the future, the HAH-2d model can be further modified to describe more anisotropic hardening behaviors and applied to numerical simulations. Full article

The increasing application of aluminum alloy, in combination with the growth in the complexity of components, provides new challenges for the numerical modeling of sheet materials. The material elastic–plasticity constitutive model is the most important factor affecting the accuracy of finite element simulation. The mixed hardening constitutive model can more accurately represent the real hardening characteristics of the material plastic deformation process, and the accuracy of the material property-related parameters in the constitutive model directly affects the accuracy of finite element simulation. Based on the Hill48 anisotropic yield criterion, combined with the Voce isotropic hardening model and the Armstrong–Frederic nonlinear kinematic hardening model, a mixed hardening constitutive model that considers material anisotropy and the Bauschinger effect was established. Analysis of the tension–compression experiment on the sheet using finite element method. Using the finite element model, the optimum geometry of the tension–compression experiment sample was determined. The cyclic deformation stress–strain curve of the 2A11 aluminum alloy sheet was obtained by a cyclic tensile–compression test, and the material characteristic parameters in the mixed hardening model were accurately determined. The reliability and accuracy of the established constitutive model of anisotropic mixed hardening materials were verified by the finite element simulation and by testing the cyclic tensile–compression problem, the springback problem, and the sheet in bending, unloading, and reverse bending problems. The tensile–compression experiment is an effective method to directly and accurately obtain the characteristic parameters of constitutive model materials. Full article

Additive manufacturing (AM) by electron beam melting (EBM) is a technique used to manufacture parts by melting powder metal layer-by-layer with an electron beam in a high vacuum, thereby generating a 3D topology. This paper studies the low-cycle fatigue of Ti–6Al–4V specimens obtained by EBM. Static tests were carried out according to ASTM E8 for a yield stress of 1023 MPa, a fracture stress of 1102 MPa, and a maximum tensile strength of 1130 MPa with a maximum true normal strain at fracture ε_max = 9.0% and an elastic modulus of 120 GPa. Then, fatigue tests were conducted at a load inversion rate of R = −1. It was observed that the material exhibited plastic strain softening, which was attributed to the Bauschinger effect. These results were plotted on a strain vs. life (ε−N) curve using the Ong version of the Coffin–Manson rule and the Baumel–Seager and Meggiolaro–Castro rules. The results were compared to forged Ti–6Al–4V alloys. The cyclic stress–strain behavior was described with the Ramberg–Osgood model. Finally, the fracture surface was analyzed using scanning electron microscopy (SEM) to observe the formation of primary cracks. The fracture morphology showed a mixed surface, also known as a “quasi-cleavage”, which is characterized by dimples, cleavage facets, extensive primary cracks with broken slipping planes, and a large number of inclusions. This phenomenon caused a possible brittle behavior in the material. Full article

Miniaturized mechanical testing based on small sample testing technology is a powerful technique to characterize the mechanical properties of different materials, and it is being used in different application fields. However, the small size of the specimens poses several challenges because the results are highly sensitive to measurement accuracy and the corresponding mechanical properties can change substantially due to the so-called specimen size effect. In this work, a novel testing device based on miniaturized specimens is presented. The equipment is designed to test materials in tensile and compressive loadings, but it is also capable of performing reverse-loading tests. Buckling of the specimen is an inherent phenomenon in compression loadings, especially for thin materials. Therefore, specimen geometry is properly studied and optimized to mitigate this effect. To evaluate the deformation of the specimen, the digital image correlation (DIC) technique is used to capture the full-field strain in the central gauge section of the sample. A sensitivity analysis of the DIC setting parameters was performed for this application. To evaluate the performance of the developed system, experimental results of monotonic tests and tests with reverse loadings (tension-compression) are presented, considering two high-strength steels (DP500 and DP780). Full article
