During the excavation of the underground cavern at the Baihetan hydropower station, significant time-dependent deformation of the surrounding rock was observed, posing a serious challenge to the long-term stability control of the caverns. In this study, numerical models of the layered excavation for typical monitoring sections in the main and auxiliary powerhouses on both banks of the Baihetan hydropower station were established using a viscoplastic damage model. The time-dependent deformation responses of the surrounding rock during the entire underground cavern excavation process were successfully simulated, and the deformation and failure mechanisms of the surrounding rock during layered excavation were analyzed in combination with field monitoring data. The results demonstrate that the maximum stress trajectories at the right-bank powerhouse under higher stress conditions exceeded those at the left-bank powerhouse by 6 MPa after the powerhouse excavation. A larger stress difference caused stress trajectories to move closer to the rock strength surface, therefore making creep failure more likely to occur in the right bank. Targeted reinforcement in high-disturbance zones of the right-bank powerhouse reduced the damage progression rate at borehole openings from 0.295 per month to 0.0015 per month, effectively suppressing abrupt deformations caused by cumulative damage. These findings provide a basis for optimizing the excavation design of deep underground caverns. Full article

The impact generated by landslide-induced surge waves in large reservoirs poses significant threats to the safety of coastal residents and their property. It is essential to further elucidate the characteristics of these surge waves and enhance the capabilities of surge wave prediction and emergency warning systems. This research takes the Wangjiashan landslide in the Baihetan Hydropower Station reservoir area as a prototype, constructing a three-dimensional landslide model at a 1:150 scale. Through experiments designed under varying water levels and slope friction coefficients, the spatiotemporal evolution patterns of the landslide-induced surge waves along the riverbank were analyzed. The research results indicate that through the use of the zero-crossing method, fundamental characteristics of landslide-induced surge waves such as the maximum wave height, maximum period, significant wave height, and significant wave period could be obtained. Based on the statistical analysis of significant wave heights, the surge waves were categorized into three levels—small waves, moderate waves, and large waves—accounting for 15.79%, 78.95%, and 5.26% of the total waves, respectively. The height of surge waves decreases with an increase in the slope friction coefficient and river channel water depth. Additionally, the interaction between the landslide’s entry velocity into the water and the water level determines the effectiveness of wave propagation. This research provides crucial data support and theoretical foundations for the prediction and emergency warning of landslide-induced surge waves, offering significant implications for the prevention and mitigation of reservoir and landslide disasters. Full article

Basalt is an important geotechnical material for engineering construction in Southwest China. However, it has complicated structural features due to its special origin, particularly the widespread occurrence of hidden cracks. Such discontinuities significantly affect the mechanical properties and engineering stability of basalt, and related research is lacking and unsystematic. In this work, taking the underground caverns in the Baihetan Hydropower Station as the engineering background, the size-dependent mechanical behaviors and excavation responses of basalt with hidden cracks were systematically explored based on a synthetic rock mass (SRM) model combining the finite-discrete element method (FDEM) and discrete fracture network (DFN) method. The results showed that: (1) The DFN–FDEM model generated based on the statistical characteristics of the geometric parameters of hidden cracks can consider the real structural characteristics of basalt, whereby the mechanical behaviors found in laboratory tests and at the engineering site could be exactly reproduced. (2) The representative elementary volume (REV) size of basalt blocks containing hidden cracks was 0.5 m, and the mechanical properties obtained at this size were considered equivalent continuum properties. With an increase in the sample dimensions, the mechanical properties reflected in the stress–strain curves changed from elastic–brittle to elastic–plastic or ductile, the strength failure criterion changed from linear to nonlinear, and the failure modes changed from fragmentation failure to local structure-controlled failure and then to splitting failure. (3) The surrounding rock mass near the excavation face of underground caverns typically showed a spalling failure mode, mainly affected by the complex structural characteristics and high in situ stresses, i.e., a tensile fracture mechanism characterized by stress–structure coupling. The research findings not only shed new light on the failure mechanisms and size-dependent mechanical behaviors of hard brittle rocks represented by basalt but also further enrich the basic theory and technical methods for multi-scale analyses in geotechnical engineering, which could provide a reference for the design optimization, construction scheme formulation, and disaster prevention of deep engineering projects. Full article

The Baihetan Hydropower Station reservoir area began impoundment in 2021, triggering the reactivation of ancient landslides and the formation of new ones. This not only caused direct landslide disasters but also significantly increased the likelihood of secondary surge wave disasters. This study takes the Wangjiashan (WJS) landslide in the Baihetan reservoir area as an example and conducts large-scale three-dimensional physical model experiments. Based on the results of the physical model experiments, numerical simulation is used as a comparative verification tool. The results show that the numerical simulation method effectively reproduces the formation and propagation process of the WJS landslide-induced surge waves observed in the physical experiments. At the impoundment water level of 825 m, the surge waves generated by the WJS landslide pose potential threats to the Xiangbiling (XBL) residential area. In this study, the numerical simulation based on computational fluid dynamics confirmed the actual propagation forms of the surge waves, aligning well with the results of the physical experiments at a microscopic scale. However, at a macroscopic scale, there is some discrepancy between the numerical simulation results and the physical experiment outcomes, with a maximum error of 25%, primarily stemming from the three-dimensional numerical source model. This study emphasizes the critical role of physical model experiments in understanding and mitigating surge wave disasters in China. Furthermore, physical experiments remain crucial for accurate disaster prediction and mitigation strategies. The theories and methods used in this study will provide important references for future research related to landslide disasters in reservoir areas. Full article

Slow-moving landslides often occur in areas of high relief, which are significantly affected by tropospheric delay. In general, tropospheric delay correction methods in the synthetic-aperture radar interferometry (InSAR) field can be broadly divided into those based on external auxiliary information and those based on traditional empirical models. External auxiliary information is hindered by the low spatial–temporal resolution. Traditional empirical models can be adaptable for the spatial heterogeneity of tropospheric delay, but are limited by preset window sizes and models. In this regard, this paper proposes an improved tropospheric delay correction method based on the multivariable move-window variation model (MMVM) to adaptively determine the window size and the empirical model. Considering topography and surface deformation, the MMVM uses multivariate variogram models with iterative weight to determine the window size and model, and uses the Levenberg–Marquardt (LM) algorithm to enhance convergence speed and robustness. The high-precision surface deformation is then derived. Combined with hotspot analysis (HSA), wide-area potential landslides can be automatically identified. The reservoir area of the Baihetan hydropower station in the lower reaches of the Jinsha River was selected as the study area, using 118 Sentinel-1A images to compare with four methods in three aspects: corrected interferograms, derived deformation rate, and stability of time-series deformation. In terms of mean standard deviation, the MMVM achieved the lowest value for the unwrapped phase in the non-deformed areas, representing a reduction of 56.4% compared to the original value. Finally, 32 landslides were identified, 16 of which posed a threat to nearby villages. The experimental results demonstrate the superiority of the proposed method and provide support to disaster investigation departments. Full article

With the operation of the world’s second-largest hydropower facility, Baihetan Hydropower Station, the risk of landslide deformation has increased. To address these potential threats, we employed Interferometric Synthetic Aperture Radar (InSAR) technology for a large-scale landslide investigation and comprehensively revealed the deformation mechanisms of landslides near the dam site. Our research indicates that the alternating geological features of soft and hard rock layers are the primary causes of landslides, especially the fracturing phenomena of vast amounts of mudstone upon contact with moisture. This leads to the reservoir’s left bank’s dip-slope being susceptible to slip and tensional failure, while the reservoir’s right bank’s reverse slope is more prone to plastic flow and tensional damage. Rapid water level changes and altered rainfall patterns are key factors that trigger landslide instability. Furthermore, we also explored the relationship between fault zones, seismic activity, and landslides, particularly noting the fully coupled state of the southern end of the Daliangshan fault zone, which might further exacerbate landslide deformation. Full article

The radial installation deviation of the turbine runner will change the gap flow between the upper crown and the lower ring seal, which will affect the radial force of the runner and the hydraulic excitation characteristics of the top cover. This research focuses on the 1GW Francis turbine on the right bank of the Baihetan hydropower station. The pressure distribution along the circumference of the top cover was analyzed, and the effects of deviations on the specific generation of hydraulic excitation forces were studied. This research shows that the increase in radial deviation will slightly reduce the output and efficiency, and the radial force on the runner increases parabolically. When the radial deviation is 1.5 mm, the radial force is 5.9 times higher compared to the case without any deviation, and the radius of the fitting circle of the radial force behavior trajectory increases with the increase in radial deviation. In addition, the radial deviation has little effect on the internal flow of the runner and the pressure distribution in the upper crown chamber. The dominant frequency components at the upstream monitoring points include fn, 15 fn, 24 fn, and 30 fn. The dominant frequency components at the downstream monitoring points include the blade passing frequencies of 15 fn and 30 fn. However, with the increase in radial deviation, the fluctuation amplitudes exhibit an asymmetric distribution, the uniformity of the pressure distribution in the circumferential direction of the labyrinth seal area becomes significantly worse, and the waveform of the downstream monitoring points changes significantly and presents a non-uniform distribution in one rotation cycle. Full article

Fluctuations in reservoir water levels exert a strong triggering effect on landslides along reservoir banks, constituting a long-term concern in the safe operation of hydroelectric projects and in the prevention and management of geological disasters. While existing research has investigated the impact of periodic water level changes on the deformation of reservoir bank landslides, observation and detection of such deformation are challenging, with noticeable gaps in understanding how these deformations respond to water level changes during the water impoundment period. To address this, our study targets the Baihetan Reservoir, leveraging 567 ascending and descending LiCSAR data and LiCSBAS (the small-baseline subset within LiCSAR) technology to construct a time series of ground deformations in the study area from 2019 to 2023. The TLCC (Time Lag Cross Correlation) model was employed to examine the time-lag response pattern of reservoir bank landslide deformations to reservoir water level changes during the impoundment period. Our findings indicate a clear time-lag response in reservoir bank landslide deformations to water level changes during the impoundment process. The rise in water levels emerged as a primary factor influencing the instability of reservoir bank landslides. During the half-year impoundment period of the Baihetan Reservoir, a time lag of 5–7 days was observed between landslide deformations and increases in water levels, with landslides on the eastern and western banks exhibiting differing time-lag response patterns. Our study illuminates the time-lag effect between water level changes during reservoir impoundment and reservoir bank landslide deformation monitoring. By proposing a quantitative analysis methodology utilizing LiCSBAS technology and the TLCC model, our findings can inform decision-making in the field of disaster prevention and reduction in reservoir engineering. Full article

The 1000 MW Francis turbine unit at the Baihetan hydropower station is the maximum capacity unit in the world at present, and it has adopted the runner type with long and short blades. For this ultra-high output Francis turbine, especially with the breakthrough runner structure, the hydraulic excitation phenomenon caused by internal dynamic and static interference is the key factor for the stability of the unit. In this study, the 1000 MW Francis turbine unit is taken as the research object, and the rated output conditions with different guide vane openings are selected for comparative analysis. The flow field structure and the pressure pulsation characteristics inside the guide vane and runner under different openings are obtained. The distribution characteristics and evolution law of the vortex in the runner under different guide vane openings are analyzed. The results show that the dynamic and static interference between the runner and the guide vane induces the local high-speed flow to appear in the vaneless area, and the larger the guide vane opening, the smaller the dynamic and static interference between the runner and the guide vane; the vortex in the runner mainly develops and evolves from the inlet to the outlet and is mainly distributed near the blade wall surface. The pressure pulsation inside the runner is mainly due to the action of dynamic and static interference. The pressure pulsation induced by the dynamic and static interferences shows a decreasing law from the runner inlet to the runner outlet. Full article

Columnar jointed rock mass (CJRM) formed by intact rock divided by special symmetrical columnar joints is a special type of rock with poor mechanical properties, strong anisotropy, and weak self-supporting ability, severely affecting the excavation safety and stability of underground tunnels. In this study, taking the Baihetan hydropower station as the engineering background, CJRM geological numerical models with different dip angles that combined well with the natural CJRM were generated based on the geological statistical parameters of the engineering site and were verified to have high rationality and accuracy. Tunnel excavation and overloading tests were carried out on these numerical models, and the results showed that the stress and displacement distributions after excavation exhibited strong anisotropic characteristics under different dip angles, and the positions where engineering safety problems are most likely to occur are the side walls, which are prone to stress-structure-controlled failure mode. The self-supporting ability at different dip angles after excavation from weak to strong are 45°, 60°, 75°, 90°, 30°, 0°, and 15°. The safety factors assessed by overloading for CJRM with dip angles of 0–90° degrees were 2.5, 2.6, 2.6, 1.8, 2.1, and 2.2, respectively, providing a valuable reference for the construction safety and support measures of CJRM excavation. Full article

The underground powerhouse of a hydropower station, in the form of a cavern group, is generally characterized by a large scale and complicated spatial structure. During the construction phase, extensive excavation in limited underground space may cause a multi-cavern effect between adjacent caverns and thus lead to deformation and failure of the surrounding rock mass, which undoubtedly compromises cavern stability and construction safety. This paper takes the drainage gallery LPL5-1 in the Baihetan underground powerhouse (adjacent to the main powerhouse) as a case study. During the excavation of the main powerhouse, the shotcrete at the upstream arch of LPL5-1 cracked, ballooned and peeled off. After field investigation and numerical simulations, the stress evolution induced by excavation is studied and the failure mechanism is analyzed. The results indicate that the multi-cavern effect led to the surrounding rock mass failures in LPL5-1, which is related to the continuous excavation of the main powerhouse and the resultant extensive stress adjustment. During the main powerhouse excavation, a stress concentration zone was generated at the upstream arch and was intensified with the excavation progressed. The expanded stress concentration zone affected LPL5-1 and made its surrounding rock mass split, thus causing the shotcrete cracking. Full article

To evaluate the variation in ecological risk induced by pollutants from the construction of Baihetan Dam, the largest hydropower station under construction in the world, this study proposes a fuzzy hazard quotient (HQ) model designed on the basis of triangular fuzzy number (TFN) theory. The fuzzy HQ model uses hazardous TFN to evaluate the ecological risk including uncertain observation data, and the transition TFN to analyze the variation in ecological risk before and after the dam construction. The results show the following: (i) The ecological risk of ammonia nitrogen (NH₃-N) showed a marked increasing trend after the construction of the dam because this activity weakened the degradation ability of the water body. The chronic hazard of NH₃-N was classified as “medium” grade and its acute hazard was “low” grade. (ii) The crucial acute hazard factor for the local aquatic ecosystem was copper (Cu) and the key chronic hazard factor was lead (Pb). (iii) After the construction of Baihetan Dam, both the long-term and short-term hazardous TFNs of Cu were classified as “medium” grade. The acute hazard of Pb belonged to “low” grade with high certainty, whereas its chronic hazard classification had uncertainties. Its long-term hazardous vectors upstream were {0.000, 0.928, 0.072}, whereas its long-term hazardous vectors downstream were {0.000, 0.108, 0.892}. (iv) Both of the ecological risks of Cu and Pb showed substantial decreasing trends after the construction of Baihetan Dam because the impounding effect of Baihetan Dam promoted the settlement of heavy metals with sediment. (v) The hazardous TFN method can be applied to perform an ecological risk evaluation that accounts for uncertainties in the observation data set, and the transition TFN method can analyze the variation in ecological risk with a small sample size. Therefore, the fuzzy HQ model is effective for the evaluation of ecological risk induced by dam construction. Full article

The Baihetan hydropower station is the second largest hydropower station worldwide. It began to store water in April 2021. We conducted a dense hybrid gravity and GNSS survey at 223 stations, obtained the free-air and Bouguer gravity anomalies, inversed the lithospheric density structure, and calculated the isostatic additional force (IAF) borne by lithosphere in the reservoir area. Moreover, we studied the gravity change and Coulomb stress change around the Baihetan reservoir due to impoundment. The main findings are the following. (1) Hybrid gravity and GNSS observations significantly improved the spatial resolution of the gravity field, and the maximum improvement reached up to 150 mGal. (2) A new method for risk assessment of reservoir-induced earthquakes is proposed from the perspective of lithospheric equilibrium. It was found that there is an IAF of −30 MPa at approximately 20 km upstream of the Baihetan dam, and the risk of a reservoir-induced earthquake in this area warrants attention. (3) It was found that the Coulomb stress variation on the Xiaojiang fault near Qiaojia at a depth of 10 km exceeded the threshold for inducing an earthquake (0.1 bar). Full article

The blast-induced damage of a high rock slope is directly related to construction safety and the operation performance of the slope. Approaches currently used to measure and predict the blast-induced damage are time-consuming and costly. A Bayesian approach was proposed to predict the blast-induced damage of high rock slopes using vibration and sonic data. The relationship between the blast-induced damage and the natural frequency of the rock mass was firstly developed. Based on the developed relationship, specific procedures of the Bayesian approach were then illustrated. Finally, the proposed approach was used to predict the blast-induced damage of the rock slope at the Baihetan Hydropower Station. The results showed that the damage depth representing the blast-induced damage is proportional to the change in the natural frequency. The first step of the approach is establishing a predictive model by undertaking Bayesian linear regression, and the second step is predicting the damage depth for the next bench blasting by inputting the change rate in the natural frequency into the predictive model. Probabilities of predicted results being below corresponding observations are all above 0.85. The approach can make the best of observations and includes uncertainty in predicted results. Full article

Because of its special structure, the anisotropic properties of columnar jointed rock mass (CJRM) are complicated, which brings difficulty to engineering construction. To comprehensively study the anisotropic characteristics of CJRM, uniaxial compression tests were conducted on artificial CJRM specimens. Quadrangular, pentagonal and hexagonal prism CJRM models were introduced, and the dip direction of the columnar joints was considered. Based on the test results and the structural features of the three CJRM models, the deformation and strength characteristics of CJRM specimens were analyzed and compared. The failure modes and mechanisms of artificial specimens with different dip directions were summarized in accordance with the failure processes and final appearances. Subsequently, the anisotropic degrees of the three CJRM models in the horizontal plane were classified, and their anisotropic characteristics were described. Finally, a simple empirical expression was adopted to estimate the strength and deformation of the CJRM, and the derived equations were used in the Baihetan Hydropower Station project. The calculated values are in good agreement with the existing research results, which reflects the engineering application value of the derived empirical equations. Full article
