Search Results (473)

Commutation failure is likely to occur when an AC fault occurs at the receiving end of an LCC-HVDC system. This threatens transient stability. Conventional commutation failure prevention (CFPREV) control mainly responds to commutation-voltage magnitude variation. However, commutation-voltage phase variation is not fully considered. Its fixed start-up threshold also makes it difficult to adapt to different fault severities. To address these problems, this paper establishes a transient nonlinear large-signal model of the inverter. The model incorporates power angle variation and describes the coupled effects of DC current rise, commutation-voltage drop, and power angle deviation on the extinction angle. Phase-portrait analysis is then used to illustrate the transient evolution and critical characteristics of first commutation failure (FCF). The critical commutation voltage is predicted under different fault severities and further converted into a dynamic CFPREV start-up threshold. Simulations based on the CIGRE LCC-HVDC benchmark model verify the prediction accuracy. They also show that the improved CFPREV strategy suppresses FCF mainly by starting up at an appropriate instant rather than increased compensation strength. Full article

Transformerless inverters are increasingly becoming essential in renewable energy generation, particularly for grid-connected photovoltaic (PV) and other sustainable and alternative energy resources. The transformerless designs offer higher efficiency, compact size, and reduced cost compared to traditional inverters with bulky transformers. These inverters minimize energy losses and enable direct connection to the grid by removing the low-frequency transformer. This paper investigates a highly reliable single-phase common-ground inverter for solar panels and other alternative energy generation. The proposed PV inverter has the benefits of existing non-isolated common-ground PV inverters, including direct connection of an input source’s negative terminal to the AC neutral terminal, eliminating leakage ground currents. The inverter is an enhancement of the dual-buck inverter, incorporating one additional diode and a flying capacitor. The dual-buck structure with the inductor inserted between the inverter phase leg prevents short-circuiting. This increases the reliability of the entire power electronics system. Moreover, using external diodes to freewheel the current, the configuration has no reverse recovery issues, allowing power MOSFETs to be employed with safe commutation at higher DC-link voltage and achieve higher efficiency. Summarily, this design prevents short-circuit issues, enhancing reliability and efficiency, and relaxing pulse-width-modulation dead times. The derivation of the PV inverter is carefully analyzed. A 700 W prototype of power converter hardware has been built. The comparative study validates the operational performance, and the grid-connected experiment confirms its theoretical analysis. Experimental results of the hardware prototype are discussed to prove the feasibility and effectiveness of the proposed PV inverter. Full article

The DC/AC ratio is a critical design variable in utility-scale photovoltaic (PV) systems because it governs inverter loading, clipping behavior, energy yield, and long-term economic performance. However, conventional sizing approaches often rely on heuristic rules or deterministic annual yield optimization without explicitly accounting for the thermodynamic, optical, and stochastic mechanisms that reshape the DC power envelope. This study develops a physics-informed and bankability-oriented PVsyst-based framework for optimal DC/AC sizing by integrating irradiance transposition, incidence-angle modifier losses, temperature-dependent semiconductor behavior, inverter clipping dynamics, degradation, and discounted lifetime levelized cost of electricity (LCOE). A 10 MWp fixed-tilt PV plant located in Western Türkiye under Mediterranean climatic conditions is analyzed. The base-case simulation yields 15.20 GWh/year with a specific yield of 1519 kWh/kWp/year and a performance ratio of 87.5%, while temperature losses are identified as the dominant loss mechanism, accounting for 6.21% of the annual energy reduction. A regression-based thermal sensitivity analysis shows that monthly PR decreases by approximately $4.9\times {10}^{-3}$ per °C increase in ambient temperature. The DC/AC sweep identifies an optimum range of 1.35–1.40, where improved inverter utilization balances nonlinear clipping growth. A temporal clipping analysis confirms that clipping is concentrated during summer midday periods and is sensitive to sub-hourly irradiance variability. Correlated Monte Carlo simulations and LCOE cost-sensitivity analyses demonstrate that the optimum remains structurally robust under uncertainty, degradation, and inverter cost assumptions. The results show that DC/AC sizing should be treated as a coupled thermodynamic–optical–electrical–economic optimization problem rather than a simple capacity-matching decision. Full article

Cascaded multilevel inverters constitute a promising system concept for battery electric powertrains due to their high efficiency, low harmonic distortion, and advanced battery management capabilities. This study presents a novel electro-thermal simulation framework for the symmetrical Parallel Enhanced Commutation Integrated Nested (PECIN) multilevel inverter. The proposed model employs a control-oriented approach that enables the development and evaluation of advanced inverter and battery control algorithms, which exploit the extensive series-parallel reconfiguration capabilities of the PECIN topology. The framework is based on electrical and thermal equivalent circuit models to capture physical behavior and cross-domain interactions. Electrical network analysis employs algorithms that iterate over each phase-arm network, replacing high-dimensional matrix inversions and thereby enhancing computational efficiency. The overall model is readily adaptable to various system configurations, including different AC and DC charging modes, and scalable with respect to the number of submodules and phases. Simulation results for a 31-level multilevel inverter in a three-phase AC charging configuration demonstrate the model’s operational capabilities. Execution time analysis shows that the current distribution calculation is the key contributor to computational effort as the number of submodules increases, resulting in a quadratic growth of the overall computational time. Full article

Previous studies showed that at the inverter end, the AC voltage will experience a slight increase, while further observations revealed an increase in DC current. Other findings indicated that the AC voltage at the rectifier side will experience a decrease, while both AC voltage and DC current will increase. This paper presents a hybrid multiterminal HVDC system, which was modelled and implemented using Matlab/Simulink software 2018b to investigate fault behaviors, focusing on DC line-to-ground faults and their impact on the overall system. Calculations were performed at the input of the Graetz bridge rectifier, the capacitor filter of the DC transmission line, and the three-phase LCL filter located at the inverter end. Results indicated that, at the rectifier end, the grid voltage will increase while the grid current will decrease with non-standard waveforms. It noted that at the inverter end, the AC voltage will decrease along with grid currents. In the DC transmission line, the DC current will decrease to near zero. Findings represent the contribution of the behaviors observed at both the rectifier and inverter ends of the grids during fault scenarios, providing a more profound understanding of how multiterminal HVDC systems behave under threat. Full article

Electric vehicle (EV) adoption in South Africa remains constrained by high upfront purchase costs, limited charging infrastructure, and policy uncertainty, creating a need for lower-cost and locally relevant pathways to transport decarbonisation. This study evaluates the feasibility of converting a legacy light commercial pickup platform from internal combustion engine (ICE) propulsion to battery-electric propulsion through integrated component sizing, longitudinal vehicle simulation, and techno-economic assessment. A retrofit architecture comprising a traction battery, inverter-controller, electric motor, and DC-DC converter was developed using first-principles vehicle dynamics and energy-demand analysis. The resulting configuration employed a 40 kW AC induction motor, an approximately 28 kWh battery pack, a 40–60 kW inverter with 60 kW peak capability, and a 0.75–1.2 kW auxiliary DC-DC converter. Simulation over a representative 1000 s drive cycle showed stable speed tracking, sustained vehicle motion over approximately 10 km, and peak battery currents exceeding 300 A during acceleration, while regenerative braking reduced net cumulative energy consumption relative to gross demand. The economic analysis indicated that the retrofit pathway yielded the lowest cumulative total cost of ownership over most of a 10-year horizon, with breakeven relative to the used ICE baseline occurring at approximately 3.4 years. Lifecycle analysis further showed that the retrofit configuration achieved the lowest combined production and operational carbon burden among the compared vehicle pathways. These findings indicate that ICE-to-EV retrofitting of legacy light commercial vehicles can provide a technically feasible, economically competitive, and environmentally advantageous electrification strategy for South Africa and comparable emerging markets. Full article

To suppress AC-side oscillation and improve steady-state current quality in current-source-inverter-fed permanent magnet synchronous motor (CSI-PMSM) systems, this paper proposes a predictive current control method based on steady-state characteristics. An equivalent model of the CSI-PMSM system is developed in the synchronous rotating dq reference frame, and the steady-state characteristics of the filter capacitor current are analyzed. The analysis shows that the capacitor current is generally nonzero under steady-state operation, whereas its deviation from the steady-state reference component should converge to zero. Based on this property, a discrete predictive model is constructed, and the stator current tracking error and the capacitor current deviation are incorporated into the cost function to achieve coordinated current tracking and LC oscillation suppression. In addition, a deadbeat preselection and a local finite-candidate optimization scheme are adopted to reduce the online computational burden. Experimental results obtained from a 3.7 kW CSI-PMSM platform demonstrate that, compared with conventional multi-loop PI control, the proposed method significantly reduces dq-axis current ripples and DC-link current fluctuations, while decreasing the stator current total harmonic distortion from 9.87% to 2.25%. These results verify the effectiveness and engineering feasibility of the proposed steady-state-consistent predictive current control method. Full article

This study evaluates how validation design affects the assessment of photovoltaic (PV) inverter fault prediction under sparse operational event conditions. Using an 89-day dataset from 18 co-located inverters at a single PV plant, minute-level SCADA measurements were transformed into 56-step input windows with 15 min future event labels. Three validation configurations were compared under the same XGBoost-based forecasting task: single-equipment temporal validation, pooled temporal validation, and leave-one-equipment-out (LOEO) validation. The results show that the three configurations provide different interpretations of predictive usefulness. Single-equipment validation achieved a mean PR-AUC of 0.699, pooled temporal validation achieved a PR-AUC of 0.637, and LOEO validation achieved a mean PR-AUC of 0.718 with a mean ROC-AUC of 0.930. Bootstrap confidence intervals confirmed that held-out equipment performance estimates were statistically more stable than in extremely sparse short-window settings; for example, held-out equipment 4 achieved a PR-AUC of 0.734 with a 95% confidence interval of 0.704–0.762. Variable-level permutation importance showed that predictive performance was mainly associated with DC-side voltage/current and selected AC-side electrical variables. These findings demonstrate that validation design is not a secondary implementation detail but a substantive methodological choice in PV predictive-maintenance evaluation. The study provides practical guidance for selecting validation strategies according to deployment scenarios, including asset-specific modeling, shared plant-level prediction, and predictive coverage for unseen or data-limited inverters. Full article

The growing use of electrochemical batteries in renewable energy systems has intensified the need for storage architectures that can sustain power delivery while limiting transient electrical stress and voltage instability challenges. This study addresses the research gap in experimentally establishing a physically interpretable framework that links battery-centered hybrid storage behavior at the DC bus to AC-side inverter performance under load and source disturbances. A laboratory-scale renewable microgrid integrating photovoltaic and wind generation, programmable load variation, inverter-based AC delivery, and hybrid battery–supercapacitor storage is experimentally implemented and evaluated against a battery-only baseline, supported by a unified analytical framework that quantifies how transient buffering improvements propagate through the power conversion chain. The results show that the hybrid configuration reduces DC-bus voltage droop from about 1.1 V to 0.6 V under heavy-load transitions, and from approximately 0.85 V to 0.44 V during source-side variability (e.g., photovoltaic and wind turbine variations). The hybrid system also improves AC-side behavior, yielding unified stabilization indices of 103.03% for the root-mean-square voltage and 79.51% for the peak-to-peak voltage. These findings demonstrate that the experimentally implemented lab-scale renewable microgrid with hybrid battery–supercapacitor storage provides an effective pathway for improving battery-supported microgrid stability, waveform quality, and transient resilience. Full article

The eddy current braking system (ECBS) is a crucial non-contact technology for high-speed railway. Conventional DC-excited systems face significant challenges such as excessive rail heating and high-capacity power supply requirements. This paper proposes a novel ECBS with AC excitation and auxiliary capacitor to achieve integrated energy recovery and power supply optimization. To evaluate its performance, a rigorous analytical framework is developed. First, a 2D subdomain model is established by incorporating the longitudinal end effect to solve the magnetic field distribution. Subsequently, an equivalent circuit is derived from the subdomain results to investigate steady-state braking characteristics and power flow. Analysis results demonstrate that the proposed system not only generates controllable braking force but also converts a portion of kinetic energy into storable electrical energy, effectively mitigating secondary rail heating. Most significantly, the implementation of an optimal auxiliary capacitor (134 μF) is found to reduce the required inverter capacity compared to inverter-only conditions. These findings provide a theoretical foundation and a practical design tool for developing high-performance, energy-efficient braking systems in high-speed transportation. Full article

The demand for reliable, compact, and highly dependable energy conversion systems has grown significantly due to their application in renewable energy systems and electric vehicles for transportation. One of the main converters used in this type of conversion system is the DC–AC converter, known as an inverter. The common study of inverter behavior has focused on addressing, in isolation, the topologies and modulation strategies that activate/deactivate the converter switches, whose main objectives are to improve power quality, increase power density under different operating conditions, and reduce losses. Some of the above objectives were addressed by oversized passive filters, which resulted in increased system volume, high cost, and reduced adaptability. This systematic review analyzes and organizes the state of the art regarding the relationship between the selection of inverter topology, modulation strategy (ranging from conventional modulation approaches to more advanced adaptive strategies), and optimization in conjunction with passive components to observe DC bus voltage management. The review was conducted following the PRISMA 2020 guidelines. A structured search was performed in IEEE Xplore, ScienceDirect, MDPI, and Scielo databases up to 2025, retrieving 9547 records. After duplicate removal and multi-stage screening of titles, abstracts, and full-text, 104 studies met the predefined technical inclusion criteria. Eligible studies were required to report quantitative performance metrics, validated modulation techniques, and explicit focus on inverter architectures or DC bus optimization. The selected studies were examined through comparative technical analysis of topology–modulation interaction, harmonic distortion performance, efficiency, and system-level integration. The study highlights the importance of taking a comprehensive approach at the complete system level by designing the elements addressed together, rather than being optimized in isolation for renewable energy and electric vehicle applications. Full article

This research paper presents Volvo SmartCell, an AC battery technology that integrates modular multilevel converters and battery cells to form a unified system for electric vehicle propulsion and power supply. The research work addresses the broader challenge of reducing driveline cost and complexity by replacing traditional components such as inverters, onboard chargers, centralized DC/DC converters, vehicle control units and many more. SmartCell uses distributed Cluster Boards comprised of H-bridges which are controlled via wireless communication to generate AC voltage, deliver redundant low voltage power, and support cell level protection mechanisms. The prototype testing demonstrates that the system can supply traction power by engaging clusters according to the required voltage depending on motor speed, achieve AC grid charging by synthesizing sinusoidal voltages without a dedicated charger, and provide autonomous DC/DC operation through cluster level voltage regulation. Simulations further indicate that multilevel voltage generation can reduce switching losses and improve electric machine efficiency compared to conventional systems. Additional benefits include active cell balancing, support for mixed cell chemistries, and high redundancy through multiple independent power branches. Challenges remain in wireless bandwidth limitations and cost optimization of Cluster Boards. Ongoing development aims to enhance communication robustness and validate safety for non-isolated grid charging. Full article

This paper develops a symmetry-oriented regime-level framework for resonant DC-AC inverters that extends classical source duality toward a multidimensional representation of inverter operation. The proposed formulation introduces a compact inverter signature vector and associated symmetry operators to organize source-domain, detuning side, commutation, switch-path, and modal correspondences within a unified hierarchy. On this basis, a symmetry-guided workflow is defined using compact screening metrics for stress/circulation balance, phase displacement, and commutation feasibility, enabling early-stage comparison of operating regimes before topology-specific detailed design closure. The framework is demonstrated through an extended-duality pairing of two resonant DC-AC inverter regimes: an open-input super-resonant ZVS-like corridor and a closed-input sub-resonant ZCS-like corridor. The case studies show how the proposed regime signatures and screening metrics support structured reasoning about soft-switching corridors, stress redistribution, and device-class-dependent implications, including wide-bandgap (WBG) design tendencies. The proposed metrics are intended as low-order screening indicators and regime-selection tools rather than substitutes for detailed circuit, thermal, EMI, and device-level validation. Within this scope, the paper contributes an operational symmetry formalism that links duality-based interpretation to practical early-stage design organization and robustness-oriented comparison. Full article

The growing electrification of ports and maritime transport requires flexible power systems capable of supplying multiple voltage levels with high efficiency and power quality. Battery-based power barges offer a promising solution, but their power conversion systems must handle wide voltage and power ranges while remaining stable under dynamic operating conditions. This paper presents a scalable multi-stage power conversion architecture for battery-based power barges that can supply both low-voltage and high-voltage AC loads from a common DC source. The system combines isolated Dual Active Bridge (DAB) DC–DC converters with a three-level Neutral-Point-Clamped (NPC) inverter. An input-parallel output-series DAB configuration is used for high-voltage operation, enabling modularity and scalability within semiconductor limits. A coordinated control strategy ensures stable DC-link regulation, balanced module operation, and high-quality AC voltage generation. Simulation results confirm stable operation, fast dynamic response, a voltage THD below 4%, and overall efficiency above 95%, demonstrating the suitability of the proposed architecture for future power barge and port electrification applications. Full article

The integration of renewable energy sources, including photovoltaic (PV) and fuel cell (FC) systems, into AC grids has attracted immense research interest in recent times. Furthermore, incorporating these renewable sources of energy into medium-voltage grids is garnering increased attention because of the obvious benefits of medium-voltage integration at elevated power levels. Photovoltaic applications entail the arrangement of solar panels capable of outputting voltages up to 1.5 kV; nonetheless, fuel cells display restricted output voltage, with a maximum market range of 400 to 700 V. Hence, the efficient integration of renewable energy sources into low-voltage or medium-voltage grids demands the utilization of a step-up direct current (DC–DC) inverter and a converter for connection to the alternating current (AC) grid, in which an efficient step-up converter is critical for the medium-voltage grid. Therefore, this study presents a three-phase buck-boost split-source inverter (BSSI) that resolves the constrained output voltage of the fuel cells. This study focuses on modifying the configuration of a conventional three-phase split-source inverter (SSI) circuit by adding a few components while maintaining the inverter’s modulation. This novel circuit design enables the reduction in voltage strains on the inverter switch components and improves DC-link use in relation to a traditional SSI configuration. For an 800 bus, maximal voltage stress on the primary inverter switches is lowered when compared with the standard SSI that delivers entire DC-bus voltage to switches. A rectifier-based model is employed to simulate the behavior of a renewable energy source. Combining these advantages with the conventional modulation of the inverter offers a more effective design. The buck-boost split-source inverter (BSSI) was analyzed using three distinct modulation techniques: the sinusoidal pulse-width modulation scheme (SPWM), the third-harmonic injected pulse-width modulation (THPWM) scheme, and space vector modulation (SVM). The proposed analysis was validated through MATLAB-SIMULINK and practical outcomes on a 5.0 kW model. The practical and SIMULINK data were found to be closely aligned with the analysis. The circuit developed in this study also ensures efficient DC-to-AC conversion, specifically with regard to low-voltage sources, like fuel cells or photovoltaic (PV) systems. Full article
