Search Results (12)

This work presents the design and experimental validation of a 2 × 2 MIMO communication system assisted by a directly modulated analog radio-over-fiber (A-RoF) fronthaul, targeting low-complexity connectivity solutions for underserved/remote regions. The study details the complete end-to-end architecture, including a wireless access segment to complement the 20-km optical fronthaul link. The system is implemented on an software defined radio (SDR) platform using GNU Radio 3.7.11, running on Ubuntu 18.04 with kernel 4.15.0-213-generic. It also employs adaptive modulation driven by real-time signal-to-noise ratio (SNR) estimation to keep bit error rate (BER) close to zero while maximizing throughput. Performance is characterized over 20 km of single-mode fiber (SMF) using coarse wavelength division multiplexing (WDM) and assessed through root mean square error vector magnitude (${\mathrm{EVM}}_{\mathrm{RMS}}$), throughput, and spectral integrity. The results identify an optimum radio-frequency drive region around $-16$ dBm enabling high-order modulation (e.g., 256-QAM), whereas RF input powers above approximately $-10$ dBm increase ${\mathrm{EVM}}_{\mathrm{RMS}}$ due to nonlinearity in the RF front-end/low-noise amplifier (LNA) and direct modulation stage, forcing the adaptive scheme to reduce modulation order and throughput. Over the optical-power sweep, when the incident optical power exceeds approximately $-8$ dBm, the system reaches ∼130 Mbps (24-MHz channel) with ${\mathrm{EVM}}_{\mathrm{RMS}}$ approaching ∼1%, highlighting the need for careful joint tuning of RF drive, optical launch power, and wavelength allocation across transceivers. Finally, the integrated access link employs diplexers for transmitter/receiver separation in a 2 × 2 configuration with 2.8 m antenna separation and low channel correlation, demonstrating a 10 m proof-of-concept range and enabling end-to-end spectrum/EVM/throughput observations across the full communication chain. Full article

This article presents the decision feedback equalizer (DFE), the maximum likelihood detection (MLD), and the radius-directed equalization (RDE) algorithms designed in MATLAB-R2018a to equalize the received signal in a dispersive optical link up to 120 km. DFE is essential for improving signal quality in several communication systems, including WiFi networks, cable modems, and long-term evolution (LTE) systems. Its capacity to mitigate inter-symbol interference (ISI) and rapidly adjust to channel variations renders it a flexible option for high-speed data transfer and wireless communications. Conversely, MLD is utilized in applications that require great precision and dependability, including multi-input–multi-output (MIMO) systems, satellite communications, and radar technology. The ability of MLD to optimize the probability of accurate symbol detection in complex, high-dimensional environments renders it crucial for systems where signal integrity and precision are critical. Lastly, RDE is implemented as an alternative algorithm to the CMA-based equalizer, utilizing the idea of adjusting the amplitude of the received distorted symbol so that its modulus is closer to the ideal value for that symbol. The algorithms are tested using a converged 5G mm-wave analog radio-over-fiber (A-RoF) system at 60 GHz. Their performance is measured regarding error vector magnitude (EVM) values before and after equalization for different optical fiber lengths and modulation formats (QPSK, 16-QAM, 64-QAM, and 128-QAM) and shows a clear performance improvement of the output signal. Moreover, the performance of the proposed algorithms is compared to three commonly used algorithms: the simple least mean square (LMS) algorithm, the constant modulus algorithm (CMA), and the adaptive median filtering (AMF), demonstrating superior results in both QPSK and 16-QAM and extending the transmission distance up to 120 km. DFE has a significant advantage over LMS and AMF in reducing the inter-symbol interference (ISI) in a dispersive channel by using previous decision feedback, resulting in quicker convergence and more precise equalization. MLD, on the other hand, is highly effective in improving detection accuracy by taking into account the probability of various symbol sequences achieving lower error rates and enhancing performance in advanced modulation schemes. RDE performs best for QPSK and 16-QAM constellations among all the other algorithms. Furthermore, DFE and MLD are particularly suitable for higher-order modulation formats like 64-QAM and 128-QAM, where accurate equalization and error detection are of utmost importance. The enhanced functionalities of DFE, RDE, and MLD in managing greater modulation orders and expanding transmission range highlight their efficacy in improving the performance and dependability of our system. Full article

This research presents a novel approach to 28 $\mathrm{GHz}$ impulse radio ultra-wideband (IR-UWB) transmission using pulse position modulation (PPM) over an analog radio-over-fiber (ARoF) link, investigating the impact of fiber-based fronthaul on the overall performance of the communication system. In this setup, an arbitrary waveform generator (AWG) is employed for PPM signal generation, while demodulation is performed with a commercial time-to-digital converter (TDC) based on an event timer. To enhance the reliability of transmitted reference PPM (TR-PPM) signals, the transmission system integrates Gray coding and Consultative Committee for Space Data Systems (CCSDS)-standard-compliant Reed-Solomon (RS) error correcting code (ECC). System performance was evaluated by transmitting pseudorandom binary sequences (PRBSs) and measuring the bit error ratio (BER) across a 5-m wireless link between two 20 $\mathrm{d}\mathrm{B}\mathrm{i}$ gain horn (Ka-band) antennas, with and without a 20 $\mathrm{k}\mathrm{m}$ single-mode optical fiber (SMF) link in transmitter side and ECC at the receiver side. The system achieved a BER of less than 8.17 × 10⁻⁷, using a time bin duration of 200 $\mathrm{p}\mathrm{s}$ and a pulse duration of 100 $\mathrm{p}\mathrm{s}$, demonstrating robust performance and significant potential for space-to-ground telecommunication applications. Full article

Biological control is a scientific management method used in modern agricultural production, and microbially derived biopesticides are one effective method with which to control weeds in agricultural fields. In order to determine the key genes for weed control by Trichoderma polysporum, transcriptome sequencing was carried out by high-throughput sequencing technology, and the strains of T. polysporum HZ-31 infesting Avena fatua L. at 24, 48, and 72 h were used as the experimental group, with 0 h as the control group. A total of 690,713,176 clean reads were obtained, and the sequencing results for each experimental group and the control group (0 h) were analyzed. In total, 3464 differentially expressed genes were found after 24 h of infection with the pathogen, including 1283 down-regulated genes and 2181 up-regulated genes. After 48 h of infection, the number of differentially expressed genes was 3885, of which 2242 were up-regulated and 1643 were down-regulated. The number of differentially expressed genes after 72 h of infection was the highest among all the groups, with 4594 differentially expressed genes, of which 2648 were up-regulated and 1946 were down-regulated. The up-regulated genes were analyzed by GO and KEGG, and the results showed that the up-regulated differentially expressed genes were mainly enriched in the biosynthesis of phenylalanine, tyrosine, and tryptophan; the degradation of aromatic compounds; methane metabolism; and other pathways. Among them, the PHA2, GDH, ADH2, and AROF genes were significantly enriched in the above-mentioned pathways, so they were hypothesized to play an important role in the synthesis of the herbicidally active substances of T. polysporum HZ-31. The results of this study can provide a theoretical basis for further studies on the pathogenicity of T. polysporum to A. fatua L., and accelerate the development and utilization of new and efficient bioherbicides. Full article

In order to meet the ever-increasing 5G and beyond Radio Access Network (RAN) densification demands, Fiber-Wireless transport networks are expected to play a key role in accelerating 5G deployment by providing the essential RAN flexibility, while at the same time avoiding costly fiber-trenching. Due to the inefficiency of the Radio-and-Fiber (R&F) networks for application in dense RAN topologies, Analog-Radio-over-Fiber (A-RoF) technology is regarded as a key enabling solution, since it greatly simplifies the remote antenna while offering very high spectral efficiency. For this type of dense A-RoF network, new and efficient Medium-Transparent-Medium Access Control (MT-MAC) protocols are required that can concurrently arbitrate optical and wireless resources, while at the same time offering the necessary Quality-of-Service (QoS) for correct operation of the combined Fronthaul/Midhaul/Backhaul segments present in 5G disaggregated RANs. In this paper, we propose a QoS-enabled MT-MAC (qMT-MAC) protocol that can combine Fronthaul/Midhaul/Backhaul flows under the same framework, while satisfying the strict delay and jitter requirements set by the relevant standards. Results show that qMT-MAC concurrently achieves the delay and jitter requirements for combined Fronthaul/Midhaul/Backhaul traffic even when loads approach the network’s capacity, while attested enhanced prioritization policies can offer up to a 64% delay reduction over State-of-the-Art MT-MAC protocols. Full article

This article describes a novel experimental study considering a multiband fibre–wireless system for constructing the transport network for fifth-generation (5G) networks. This study describes the development and testing of a 5G new radio (NR) multi-input multi-output (MIMO) hybrid fibre–wireless (FiWi) system for enhanced mobile broadband (eMBB) using digital pre-distortion (DPD). Analog radio over fibre (A-RoF) technology was used to create the optical fronthaul (OFH) that includes a 3 GHz supercell in a long-range scenario as well as a femtocell scenario using the 20 GHz band. As a proof of concept, a Mach Zehnder modulator with two independent radio frequency waveforms modifies a 1310 nm optical carrier using a distributed feedback laser across 10 km of conventional standard single-mode fibre. It may be inferred that a hybrid FiWi-based MIMO-enabled 5G NR system based on OFH could be a strong competitor for future mobile haul applications. Moreover, a convolutional neural network (CNN)-based DPD is used to improve the performance of the link. The error vector magnitude (EVM) performance for 5G NR bands is predicted to fulfil the Third Generation Partnership Project’s (3GPP) Release 17 standards. Full article

In this article, we simulate a converged 5G mm-wave analogue radio-over-fiber (A-RoF) system at 60 GHz, and perform offline signal processing to equalize the dispersive optical link with the three most frequently employed algorithms, i.e., the simple least mean square (LMS) algorithm, the constant modulus algorithm (CMA) and the adaptive median filtering (AMF), which are implemented in Matlab. The performances of the different algorithms are compared for various optical fiber lengths with respect to the EVM values obtained before and after equalization. In the case of QPSK in OFDM subcarriers, it is observed that the CMA algorithm performs better than the LMS and MF algorithms, with 2% and 1.4% EVM improvement respectively, while for 16QAM in OFDM subcarriers it is observed that the LMS algorithm has a very small improvement of 0.2% EVM compared to the MF algorithm, while CMA is not suitable for 16QAM modulation in the proposed converged 5G mm-wave A-RoF system at 60 GHz. Full article

DAHP synthase catalyzes the first step in the shikimate pathway, deriving the biosynthesis of aromatic amino acids (Trp, Phe and Tyr), phenazine-1-carboxamide, folic acid, and ubiquinone in Pseudomonas chlororaphis. In this study, we identified and characterized one DAHP synthase encoding gene phzC, which differs from the reported DAHP synthase encoding genes aroF, aroG and aroH in E. coli. PhzC accounts for approximately 90% of the total DAHP synthase activities in P. chlororaphis HT66 and plays the most critical role in four DAHP synthases in the shikimate pathway. Inactivation of phzC resulted in the reduction of PCN production by more than 90%, while the absence of genes aroF, aroG and aroH reduced PCN yield by less than 15%, and the production of PCN was restored after the complementation of gene phzC. Moreover, the results showed that phzC in P. chlororaphis HT66 is not sensitive to feedback inhibition. This study demonstrated that gene phzC is essential for PCN biosynthesis. The expression level of both phzC and phzE genes are not inhibited in feedback by PCN production due to the absence of a loop region required for allosteric control reaction. This study highlighted the importance of PhzC and applying P. chlororaphis for shikimate pathway-derived high-value biological production. Full article

The paper presents a method of selecting an optical channel for transporting the double-sideband radio-frequency-over-fiber (DSB-RFoF) radio signal over the optical fronthaul path, avoiding the dispersion-induced power penalty (DIPP) phenomenon. The presented method complements the possibilities of a short-range optical network working in the flexible dense wavelength division multiplexing (DWDM) format, where chromatic dispersion compensation is not applied. As part of the study, calculations were made that indicate the limitations of the proposed method and allow for the development of an algorithm for effective optical channel selection in the presence of the DIPP phenomenon experienced in the optical link working in the intensity modulation–direct detection (IM-DD) technique. Calculations were made for three types of single-mode optical fibers and for selected microwave radio carriers that are used in current systems or will be used in next-generation wireless communication systems. In order to verify the calculations and theoretical considerations, a computer simulation was performed for two types of optical fibers and for two selected radio carriers. In the modulated radio signal, the cyclic-prefix orthogonal frequency division multiplexing (CP-OFDM) format and the 5G numerology were used. Full article

5G mobile networks aim to support a large variety of services with different and demanding requirements. To achieve this, analog radio over fiber (ARoF) fronthaul along with millimeter-wave (mmWave) cells is a strong candidate to be part of the 5G architecture. Very high throughput can be achieved by using mmWave signals due to the large available bandwidths, which combines well with the advantages of employing ARoF technology. Nevertheless, combined mmWave and ARoF systems face a particular challenge as the impacts of both channels—such as high free-space path loss, phase noise, chromatic dispersion, and other degrading effects—affect the signal without the possibility for intermediate restoration. The selection of the signal waveforms plays an important role in reducing these defects. In addition, waveforms are one of the keys in the physical layer available towards satisfying the requirements for 5G and beyond. In this manuscript, several key requirements are presented to determine the merit of candidate waveform formats to fulfill the 5G requirements in the mmWave ARoF architecture. An overview of the different suitable waveforms for this architecture is provided, discussing their advantages and disadvantages. Moreover, a comprehensive comparison in terms of different requirements is also presented in this paper. Full article

This paper presents a solution for enabling the coexistence of digitized radio-over-fiber (D-RoF) and analog radio-over-fiber (A-RoF) interfaces operating in the optical fronthaul of 5G mobile systems. In the first section, we formulate the need to introduce new technologies to the cloud/centralized radio access network (C-RAN) (Next Generation RAN (NG-RAN) in 5G systems). A proposition of construction of the optical remote radio head (O-RRH)/gNodeB—distributed unit (gNB-DU), which will enable the operation of digital Splits/Options and new proposed analog Splits/Options, is presented. The methods performing calculations of bit rate and optical bandwidth demand in the fronthaul/midhaul, with reference to the parameters of the new-radio-release-15 (NR-Rel-15) wireless interface and subsequent releases, towards the next generations, are presented. The bandwidth demands were calculated for selected Splits/Options, and the results are shown in diagrams. A special section is devoted to description of the results achieved and presenting potential applications of the proposed construction of a radio-photonic device as well as new Splits/Options of the next generation fronthaul/midhaul. Full article

The 3rd Generation Partnership Project (3GPP) is in the process of developing 5th generation (5G) radio access technology, the so-called new radio (NR). The aim is to achieve the performance requirements forIMT-2020 radio interface technology. In this paper, we focus on the analysis of the transmission of 5G NR uplink physical channels, such as physical uplink shared channel (PUSCH) and physical uplink control channel (PUCCH), dedicated for data and control channels, respectively, as specified in the 3GPP standard, using digital signal processing (DSP)-assisted frequency division multiple access (FDMA) and time division multiple access (TDMA) channel aggregation techniques on an analogue radio-over-fiber (A-RoF) architecture. We verified that there is ~34% spectral efficiency gain and lower error vector magnitude (EVM) achieved using the TDMA technique. Full article
