The electromagnetic properties of 3D-printed carbon–carbonyl iron powder (CIP) composites are studied in the radio (20 Hz–1 MHz) and microwave (26–37 GHz) frequency ranges. Relatively high electrical conductivities (about several hundred S/m), typical for these structures in the radio frequency range, are observed. The temperature dependence of electrical conductivity is described by Arrhenius’ law, with distinct activation energies above and below a critical temperature, attributed to electron transport through various defects. The microwave properties of the investigated structures are particularly noteworthy. For instance, a 2 mm-plate with 20 wt.% magnetic inclusions achieves 52% absorption at 35 GHz. The microwave dielectric properties of the composite structures strongly depend on the concentration of carbonyl iron particles, with the highest values of the imaginary part of complex dielectric permittivity observed in carbon structures containing 20 wt.% CIP. Moreover, carbon composites with the highest CIP concentration exhibited interesting resonance states, demonstrating significant potential for Salisbury screen applications. Full article

Periodically modulated optical coatings, fabricated by depositing conformal films on modulated substrates, offer unique capabilities for spectral and spatial filtering of light. However, conventional deposition methods often do not achieve required replication and conformality on submicron-size structured surfaces. In this paper, we compare various thin film deposition techniques, including electron beam evaporation, atomic layer deposition, and ion beam sputtering, to evaluate their ability to control multilayer coating growth on periodically modulated substrates. Our study demonstrates that both single-layer and multilayer coatings produced by ion beam sputtering effectively replicate the initial geometry of structured surfaces, thereby enhancing optical performance. Full article

The experimental and theoretical study of photovoltage formation in perovskite solar cells under pulsed laser excitation at 0.53 μm wavelength is presented. Two types of solar cells were fabricated on the base of cesium-containing triple cation perovskite films: (1) Cs_x(FA_0.83MA_0.17)_(1−x)Pb(I_0.83Br_0.17)₃ and (2) Cs_x(FA_0.83MA_0.17)_(1−x)Pb_0.8Sn_0.2(I_0.83Br_0.17)₃. It is found that photovoltage across the solar cells consists of two components, U = U_ph + U_f. The first one, U_ph, is the traditional photovoltage arising due to laser radiation-induced electron-hole pair generation. The second one, U_f, is the fast component following the laser pulse and has a polarity opposite to that of U_ph. It is shown that the fast photovoltage component results from the laser radiation-caused heating of free carriers. The transient photovoltage measurements show that the values of the fast component U_f are nearly the same in both types of perovskite solar cells. The magnitude of the traditional photovoltage of mixed Pb-Sn perovskite solar cells is lower than that of Pb-based cells. Full article

This work presents the dielectric and ultrasonic properties of polydimethylsiloxane (PDMS) nanocomposites filled with titanium dioxide nanoparticles. The dielectric study was performed over a very broad range of frequencies (20 Hz–3 THz). The dielectric permittivity was almost frequency-independent in all the composites at room temperature over the whole range of measurement frequencies, and the dielectric losses were very low under these conditions (less than 2). The dielectric permittivity strongly increases with the nanoparticle concentration according to the Maxwell–Garnet model. Therefore, the investigated composites are suitable for various flexible electronic applications, particularly in the microwave and terahertz frequency ranges. Dielectric dispersion and increased attenuation of ultrasonic waves were observed at lower temperatures (below 280 K) due to the relaxation of polymer molecules at the PDMS/TiO₂ interface and in the polymer matrix. The relaxation time followed the Vogel–Vulcher law, while the freezing temperature increased with the titanium dioxide concentration due to interactions between the polymer molecules and nanoparticles. The significant hysteresis in the ultrasonic properties indicated that titanium dioxide acts as a crystallization center. This is confirmed by the correlation between the hysteresis in the ultrasonic properties and the structure of the composites. The small difference in the activation energy values obtained from the ultrasonic and dielectric investigations is related to the fact that the dielectric dispersion is slightly broader than the Debye-type dielectric dispersion. Full article

In the renewable energy field, the conversion of solar light into electrical or chemical energy is considered essential to moving towards a truly green energy economy. Solar energy can be harnessed not just through generating electricity with photovoltaic cells but also by driving photoelectrochemical (PEC) reactions such as water splitting or pollutant oxidation. In this study, TiO₂ films were synthesized electrochemically through a procedure called plasma electrolytic oxidation (PEO). Under specific conditions, as the Ti substrate dissolves and the oxide film grows, electron discharges occur across the film, and this ionizes both the oxide and some amount of electrolyte that had been in contact with it. The mixture then cools, leaving a macroporous TiO₂ structure. What is particularly interesting for PEC applications is that the films can be crystalline and doped after synthesis. XRD analysis revealed that a TiO₂ film that had been obtained at a voltage of 200 V had an anatase crystal structure. In addition, during ionization and cooling, ions from the solution can be incorporated into the film. By adding 0.1 M Cu₂SO₄ into the synthesis electrolyte, we were able to incorporate Cu into the films, as proven EDX and XPS. The TiO₂ and heterostructured films showed good PEC water-splitting activity and stability in alkaline media when illuminated with 365 nm LED light. It was found that the photocurrent obtained depends on the synthesis voltage and that the heterostructured films would generate ~2 times larger photocurrents. In addition, further surface functionalization (e.g., with Au) was investigated. Electron–hole recombination was evaluated using an advanced non-stationary photoelectrochemical technique—intensity-modulated photocurrent spectroscopy (IMPS). Generally, films have very little recombination and only at lower overpotentials up to ~1 V. Overall, the synthesis of oxide films through PEO may provide an efficient alternative to obtaining crystalline films via annealing, and various heterostructures can be created simply by modifying synthesis conditions. Full article

Magneto-plasmonic nanoparticles were fabricated using a 1064 nm picosecond-pulsed laser for ablation of Fe/Au and Fe/Au/Fe composite thin films in acetone. Nanoparticles were characterized by electron microscopy, ultraviolet-visible (UV-VIS) absorption, and Raman spectroscopy. Hybrid nanoparticles were arranged on an aluminum substrate by a magnetic field for application in surface-enhanced Raman spectroscopy (SERS). Transmission electron microscopy and energy dispersive spectroscopy analysis revealed the spherical core-shell (Au-Fe) structure of nanoparticles. Raman spectroscopy of bare magneto-plasmonic nanoparticles confirmed the presence of magnetite (Fe₃O₄) without any impurities from maghemite or hematite. In addition, resonantly enhanced carbon-based bands were detected in Raman spectra. Plasmonic properties of hybrid nanoparticles were probed by SERS using the adsorbed biomolecule adenine. Based on analysis of experimental spectra and density functional theory modeling, the difference in SERS spectra of adsorbed adenine on laser-ablated Au and magneto-plasmonic nanoparticles was explained by the binding of adenine to the Fe₃O₄ structure at hybrid nanoparticles. The hybrid nanoparticles are free from organic stabilizers, and because of the biocompatibility of the magnetic shell and SERS activity of the plasmonic gold core, they can be widely applied in the construction of biosensors and biomedicine applications. Full article

Unique electronic properties of graphene offer highly interesting ways to manipulate the functional properties of surfaces and develop novel structures which are sensitive to physical and chemical interactions. Nano-crystalline graphene is frequently preferable to crystalline monolayer in detecting devices. In this work, nano-crystalline graphene layers were synthesized directly on SiO₂/Si substrates by plasma-enhanced chemical vapour deposition (PECVD). The influence of the deposition time and temperature on the characteristics of the structures were studied. The optical properties and evaporation kinetics of pure water droplets were analysed, along with arrangement and composition of the grown layers. The nano-crystalline graphene layers grown at 500 °C were characterised by the refraction index 2.75 ± 0.35 and the normalised excess Gibbs free energy density 0.85/γ_water 10⁻⁴ m, both being similar to those of the monolayer graphene. The changes in the refraction index and the excess Gibbs free energy were related to the parameters of the Raman spectra and a correlation with the technological variables were disclosed. Full article

Porous 3D Cu layers with the following average parameters: thickness ~35 µm, pore density ~4.0 × 10⁶ cm⁻², and pore sizes ~25 µm were electrodeposited from an acidic sulphate electrolyte, and the suitability of different electrochemically active surface area determination methods for characterising these electrodes was assessed. Structural characterisation of the samples was conducted using SEM and an optical profiler, while electrochemical measurements were performed using cyclic voltammetry and electrochemical impedance spectroscopy. The evaluation of electrochemically active surface area involved the underpotential deposition of Tl and Pb monolayers as well as double-layer capacitance measurements. The results obtained indicate that both methods yield similar results for non-porous Cu electrodes. However, for Cu 3D nanostructures, the evaluation mode significantly influences the results. Double-layer capacitance measurements show significantly higher values for the electrochemically active surface area compared to the underpotential deposition (UPD) technique. The complex spatial structure of the Cu 3D layer hinders the formation of a continuous monolayer during the UPD process, which is the principal reason for the observed differences. Full article

Electrochemical deposition of silicon at room temperature is problematic due to the intrinsically low conductivity of the deposits. This study reports the photoelectrochemical (PEC) deposition of silicon (Si) and silicon–carbon (Si–C) layers from an ionic liquid at 40 °C using silicon tetrachloride (SiCl₄) as a silicon precursor. Amorphous layers are deposited on p-type silicon (p-Si), p-type gallium arsenide (p-GaAs), and aluminum–copper alloy AA2024. The semiconductor substrates are activated by white LED illumination, which generates photoelectrons, thereby making the substrate conductive with respect to the cathodic reaction. The photoresponsiveness of the deposits is proven by the light-induced photocurrents on an optically inactive substrate made of the alloy AA 2024. The proposed method paves the way for the electrochemical modification of semiconductors and metals with Si and Si–C structures, which are applicable in various fields, such as batteries, anti-corrosion coatings, photovoltaics, or PEC electrodes for hydrogen production. Full article

A laser-induced graphene (LIG) modified with chitosan (Chit) and conducting polymer polyfolate (PFA) was used as a base to develop a flat and flexible pH sensor. LIGs were formed using two different irradiation wavelengths of 355 nm and 532 nm. Depending on the wavelengths, the obtained electrodes were named LIG355 and LIG532. Microscopic imaging revealed that the bare LIG electrode surface had rough structures after laser treatment giving hydrophilic properties, and that PFA forms fibre-like structures on Chit coated LIG. Electrochemical investigation with the redox probe demonstrated that diffusion is a limiting process at the bare and modified LIG electrodes. A capacitive behaviour was observed from electrochemical impedance spectra at bare electrodes, showing a rather rough interface at LIG355 but a microporous one at LIG532. The developed flat and flexible electrode was sensitive to pH in the region from 6.0 to 9.0. In the studied pH range, the sensitivity was 27.86 ± 0.81 for PFA/Chit/LIG355 and 30.32 ± 0.50 mV/pH for PFA/Chit/LIG532 with moderate stability for a period of more than two months. Full article

Bulk polylactic acid (PLA)/multiwall carbon nanotube (MWCNT) composites were prepared and investigated in wide frequency ranges (20 Hz–1 MHz and 24–40 GHz). It was determined that the percolation threshold in bulk PLA/MWCNT composites is close to 0.2 vol.% MWCNT. However, the best microwave dielectric properties and absorption were observed in composites with 3.0–5.0 vol.% MWCNT. Therefore, for future investigations, we selected layered (laminate) polymeric structures with gradual changes in MWCNT concentration from 0.2 to 8.0 vol.% MWCNT. Two approaches to laminate structure designs were examined and compared: a five-layer composite and a nine-layer composite that included four pure PLA middle layers. The addition of MWCNT enhanced the elastic modulus by up to 1.4-fold and tensile strength by up to 1.2-fold, with the best performance achieved at 5.0 vol.% loading. High microwave shielding was observed for these layered PLA/MWCNT structures with a gradient change in MWCNT concentration (up to 26 dB in both transmission and absorption coefficients) in the broad frequency range (from 24 to 40 GHz). Obtained structures are highly anisotropic, and the absorption coefficient is 2–5 dB higher in the direction of MWCNT concentration increase; however, the transmission coefficient is the same in both directions. The properties of microwave absorption are mainly unaffected by the additional polymeric layers. The absorption of the layered structure is greater than the absorption of single-layer composites with an optimal MWCNT concentration of the same thickness. The proposed laminate structure design is promising in the field of efficient electromagnetic shielding. Full article

To fabricate graphene-based high-frequency electronic and optoelectronic devices, there is a high demand for scalable low-contaminated graphene with high mobility. Graphene synthesized via chemical vapor deposition (CVD) on copper foil appears promising for this purpose, but residues from the polymethyl methacrylate (PMMA) layer, used for the wet transfer of CVD graphene, drastically affect the electrical properties of graphene. Here, we demonstrate a scalable and green PMMA removal technique that yields high-mobility graphene on the most common technologically relevant silicon (Si) substrate. As the first step, the polarity of the PMMA was modified under deep-UV irradiation at λ = 254 nm, due to the formation of ketones and aldehydes of higher polarity, which simplifies hydrogen bonding in the step of its dissolution. Modification of PMMA polarity was confirmed by UV and FTIR spectrometry and contact angle measurements. Consecutive dissolution of DUV-exposed PMMA in an environmentally friendly, binary, high-polarity mixture of isopropyl alcohol/water (more commonly alcohol/water) resulted in the rapid and complete removal of DUV-exposed polymers without the degradation of graphene properties, as low-energy exposure does not form free radicals, and thus the released graphene remained intact. The high quality of graphene after PMMA removal was confirmed by SEM, AFM, Raman spectrometry, and by contact and non-contact electrical conductivity measurements. The removal of PMMA from graphene was also performed via other common methods for comparison. The charge carrier mobility in graphene films was found to be up to 6900 cm²/(V·s), demonstrating a high potential of the proposed PMMA removal method in the scalable fabrication of high-performance electronic devices based on CVD graphene. Full article

Ceramic composites with nanoparticles are intensively investigated due to their unique thermal, mechanic and electromagnetic properties. In this work, dielectric properties of phosphate ceramics with round silver nanoparticles of various sizes were studied in the wide frequency range of 20 Hz–40 GHz for microwave shielding applications. The percolation threshold in ceramics is close to 30 wt.% of Ag nanoparticles content and it is higher for bigger-sized nanoparticles. The microwave complex dielectric permittivity of ceramics above the percolation threshold is rather high (ε′ = 10 and ε″ = 10 at 30 GHz for ceramics with 50 wt.% inclusions of 30–50 nm size, it corresponds to almost 61% absorption of 2 mm-thickness plate) therefore these ceramics are suitable for microwave shielding applications. Moreover, the microwave absorption is bigger for ceramics with a larger concentration of fillers. In addition, it was demonstrated that the electrical transport in ceramics is thermally activated above room temperature and the potential barrier is almost independent of the concentration of nanoparticles. At very low temperature, the electrical transport in ceramics can be related to electron tunneling. Full article

The high efficiency of perovskite solar cells strongly depends on the quality of perovskite films and carrier extraction layers. Here, we present the results of an investigation of the photoelectric properties of solar cells based on perovskite films grown on compact and mesoporous titanium dioxide layers. Kinetics of charge carrier transport and their extraction in triple-cation perovskite solar cells were studied by using transient photovoltage and time-resolved photoluminescence decay measurements. X-ray diffraction analysis revealed that the crystallinity of the perovskite films grown on mesoporous titanium dioxide is better compared to the films grown on compact TiO₂. Mesoporous structured perovskite solar cells are found to have higher power conversion efficiency mainly due to enlarged perovskite/mesoporous -TiO₂ interfacial area and better crystallinity of their perovskite films. Full article

Here we report the optimization of the fabrication conditions for AuNi bimetallic catalysts supported on self-ordered titania nanotube arrays (AuNi-TiO₂ntb). A series of efficient AuNi-TiO₂ntb catalysts with small amounts of Au in the range of 1.74 to 15.7 μg_Au·cm⁻² have been fabricated by anodization, electroless Ni plating, and galvanic displacement techniques. The electrocatalytic activity of the catalysts has been evaluated for BH₄⁻ ion oxidation in an alkaline medium using cyclic voltammetry and chronoamperometry. The performance of a NaBH₄-H₂O₂ fuel cell with Ni-TiO₂ntb and AuNi-TiO₂ntb anode catalysts has been investigated at different temperatures. It was found that the electrocatalytic activity of AuNi-TiO₂ntbs catalysts was improved remarkably when the Ni layer of 100 and 400 nm was used for the deposition of Au crystallites. The Ni-TiO₂ntb catalyst generates the maximum power density values of ca. 85–121 mW·cm⁻² at a temperature of 25–55 °C, whereas the AuNi-TiO₂ntb catalysts that have the Au loading of 3.07 and 15.7 μg_Au·cm⁻² achieve the power density values of ca. 104–147 and 119–170 mW·cm⁻², respectively, at a temperature of 25–55 °C. Full article
