Research on Testing Method for Shielding Effectiveness of Irregular Cavity Based on Field Distribution Characteristics

by
Jinjing Ren
1,
Yuhao Pan
1,
Zhongyuan Zhou
1,* and
Tao Zhang
2,3
1
Research Center for Electromagnetic Environmental Effects, Southeast University, Nanjing 211189, China
2
Aviation Key Laboratory of Science and Technology on Electromagnetic Environmental Effects, Shenyang 110135, China
3
School of Information Science and Engineering, Southeast University, Nanjing 211189, China
*
Author to whom correspondence should be addressed.
Electronics 2023, 12(4), 1035; https://doi.org/10.3390/electronics12041035
Submission received: 26 November 2022 / Revised: 6 February 2023 / Accepted: 16 February 2023 / Published: 19 February 2023
(This article belongs to the Special Issue Application of Computational Electromagnetics Techniques and Artificial Intelligence in the Engineering)
Browse Figures
Versions Notes

Abstract

A method of measuring the shielding effectiveness of the irregular cavity is proposed in this paper. An electromagnetic topology model of the irregular cavity is established according to the characteristics of the irregular cavity, and the electromagnetic field distribution characteristics inside the irregular cavity are obtained based on the simulation of the field distribution of the irregular cavity. Combined with the test method of regular cavity shielding effectiveness, the characterization and testing methods of the shielding effectiveness of the irregular cavity are given comprehensively, which compared with the conventional testing method, verifies how effectively the shielding effectiveness of the irregular cavity is tested.
Keywords: irregular cavity; electromagnetic topology; field distribution; shielding effectiveness; test method irregular cavity; electromagnetic topology; field distribution; shielding effectiveness; test method
