Effects of Machining Parameters on the Quality in Machining of Aluminium Alloys Thin Plates
Abstract
:1. Introduction
2. Materials and Methods
2.1. Machining Tests
2.2. Force Mechanistic Model
2.3. Quality Evaluation
3. Results and Discussion
3.1. Final Thickness Error
3.2. Roughness
3.3. Forces and Power Models
4. Conclusions
Author Contributions
Funding
Acknowledgments
Conflicts of Interest
References
