Design and Evaluation of a Capacitive Micromachined Ultrasonic Transducer(CMUT) Linear Array System for Thickness Measurement of Marine Structures Under Varying Environmental Conditions
Abstract
1. Introduction
2. CMUT Linear Array Design and Fabrication
2.1. Design
2.2. Fabrication
3. Development and Operational Principle of Thickness Detection System
4. Experimental Results and Discussion
5. Conclusions
