# Properties of Arctic Aerosol Based on Sun Photometer Long-Term Measurements in Ny-Ålesund, Svalbard

^{1}

^{2}

^{*}

## Abstract

**:**

## 1. Introduction

## 2. Instruments, Methods, and Data

## 3. A New Model for the Ångström Exponent

#### 3.1. Mie Calculus

#### 3.2. Case Study: Sun Photometer-Lidar

## 4. Results

#### 4.1. Trends in the AOD

#### 4.2. Histograms of Aerosol Load and Properties

## 5. Discussion Concerning the Aerosol Origin

#### 5.1. FLEXTRA Five-Day Back-Trajectories

#### 5.1.1. Aerosol Origin Due to Arriving Air Pollution

#### 5.1.2. Aerosol Sources and Sinks

#### 5.1.3. Remarks on the Advection Altitude

## 6. Conclusions

## Author Contributions

## Funding

## Acknowledgments

## Conflicts of Interest

## Appendix A. Definition of the Aerosol Distribution

## Appendix B. Additional Mie Calculus

**Figure A1.**Mie calculus for a homogeneous aerosol layer with a refractive index on $n=1.44+{10}^{-5}i$ and a standard deviation of $\sigma =1.05$.

## Appendix C. Trend of Both Modified Ångström Exponents

**Figure A2.**Trend of the traditional and modified Ångström exponents $AE$ (upper row), $\alpha $, and $\beta $ (lower row) for the years 2009–2017.

## References

- Maturilli, M.; Ebell, K. Twenty-five years of cloud base height measurements by ceilometer in Ny-Ålesund, Svalbard. Earth Syst. Sci. Data
**2018**, 10, 1451–1456. [Google Scholar] [CrossRef] - Shaw, G.E. The Arctic haze phenomenon. Bull. Am. Meteorol. Soc.
**1995**, 76, 2403–2414. [Google Scholar] [CrossRef] - Quinn, P.; Shaw, G.; Andrews, E.; Dutton, E.; Ruoho-Airola, T.; Gong, S. Arctic haze: current trends and knowledge gaps. Tellus B Chem. Phys. Meteorol.
**2007**, 59, 99–114. [Google Scholar] [CrossRef][Green Version] - Hara, K.; Yamagata, S.; Yamanouchi, T.; Sato, K.; Herber, A.; Iwasaka, Y.; Nagatani, M.; Nakata, H. Mixing states of individual aerosol particles in spring Arctic troposphere during ASTAR 2000 campaign. J. Geophys. Res. Atmos.
**2003**, 108, 4209. [Google Scholar] [CrossRef] - Udisti, R.; Bazzano, A.; Becagli, S.; Bolzacchini, E.; Caiazzo, L.; Cappelletti, D.; Ferrero, L.; Frosini, D.; Giardi, F.; Grotti, M.; et al. Sulfate source apportionment in the Ny-Ålesund (Svalbard Islands) Arctic aerosol. Rend. Lincei
**2016**, 27, 85–94. [Google Scholar] [CrossRef] - Warneke, C.; Bahreini, R.; Brioude, J.; Brock, C.; De Gouw, J.; Fahey, D.; Froyd, K.; Holloway, J.; Middlebrook, A.; Miller, L.; et al. Biomass burning in Siberia and Kazakhstan as an important source for haze over the Alaskan Arctic in April 2008. Geophys. Res. Lett.
**2009**, 36, L02813. [Google Scholar] [CrossRef] - Markowicz, K.M.; Pakszys, P.; Ritter, C.; Zielinski, T.; Udisti, R.; Cappelletti, D.; Mazzola, M.; Shiobara, M.; Xian, P.; Zawadzka, O.; et al. Impact of North American intense fires on aerosol optical properties measured over the European Arctic in July 2015. J. Geophys. Res. Atmos.
**2016**, 121, 14,487–14,512. [Google Scholar] [CrossRef][Green Version] - Park, K.T.; Jang, S.; Lee, K.; Yoon, Y.J.; Kim, M.S.; Park, K.; Cho, H.J.; Kang, J.H.; Udisti, R.; Lee, B.Y.; et al. Observational evidence for the formation of DMS-derived aerosols during Arctic phytoplankton blooms. Atmos. Chem. Phys.
**2017**, 17, 9665–9675. [Google Scholar] [CrossRef][Green Version] - Tunved, P.; Ström, J.; Krejci, R. Arctic aerosol life cycle: Linking aerosol size distributions observed between 2000 and 2010 with air mass transport and precipitation at Zeppelin station, Ny-Ålesund, Svalbard. Atmos. Chem. Phys.
**2013**, 13, 3643–3660. [Google Scholar] [CrossRef] - Dubovik, O.; Holben, B.; Eck, T.F.; Smirnov, A.; Kaufman, Y.J.; King, M.D.; Tanré, D.; Slutsker, I. Variability of absorption and optical properties of key aerosol types observed in worldwide locations. J. Atmos. Sci.
**2002**, 59, 590–608. [Google Scholar] [CrossRef] - Li, S.; Kahn, R.; Chin, M.; Garay, M.; Liu, Y. Improving satellite-retrieved aerosol microphysical properties using GOCART data. Atmos. Meas. Tech.
**2015**, 8, 1157–1171. [Google Scholar] [CrossRef][Green Version] - Mei, L.; Xue, Y.; de Leeuw, G.; von Hoyningen-Huene, W.; Kokhanovsky, A.A.; Istomina, L.; Guang, J.; Burrows, J.P. Aerosol optical depth retrieval in the Arctic region using MODIS data over snow. Remote Sens. Environ.
**2013**, 128, 234–245. [Google Scholar] [CrossRef] - Herber, A.; Thomason, L.W.; Gernandt, H.; Leiterer, U.; Nagel, D.; Schulz, K.H.; Kaptur, J.; Albrecht, T.; Notholt, J. Continuous day and night aerosol optical depth observations in the Arctic between 1991 and 1999. J. Geophys. Res. Atmos.
**2002**, 107, AAC 6-1–AAC 6-13. [Google Scholar] [CrossRef] - Rozwadowska, A.; Zieliński, T.; Petelski, T.; Sobolewski, P. Cluster analysis of the impact of air back-trajectories on aerosol optical properties at Hornsund, Spitsbergen. Atmos. Chem. Phys.
**2010**, 10, 877–893. [Google Scholar] [CrossRef][Green Version] - Toledano, C.; Cachorro, V.; Gausa, M.; Stebel, K.; Aaltonen, V.; Berjón, A.; de Galisteo, J.O.; De Frutos, A.; Bennouna, Y.; Blindheim, S.; et al. Overview of sun photometer measurements of aerosol properties in Scandinavia and Svalbard. Atmos. Environ.
**2012**, 52, 18–28. [Google Scholar] [CrossRef] - Stock, M.; Ritter, C.; Aaltonen, V.; Aas, W.; Handorf, D.; Herber, A.; Treffeisen, R.; Dethloff, K. Where does the optically detectable aerosol in the European Arctic come from? Tellus B Chem. Phys. Meteorol.
**2014**, 66, 21450. [Google Scholar] [CrossRef] - Tomasi, C.; Kokhanovsky, A.A.; Lupi, A.; Ritter, C.; Smirnov, A.; O’Neill, N.T.; Stone, R.S.; Holben, B.N.; Nyeki, S.; Wehrli, C.; et al. Aerosol remote sensing in polar regions. Earth-Sci. Rev.
**2015**, 140, 108–157. [Google Scholar] [CrossRef][Green Version] - Maturilli, M.; Herber, A.; König-Langlo, G. Surface radiation climatology for Ny-Ålesund, Svalbard (78.9 N), basic observations for trend detection. Theor. Appl. Climatol.
**2015**, 120, 331–339. [Google Scholar] [CrossRef] - Pakszys, P.; Zielinski, T.; Markowicz, K.; Petelski, T.; Makuch, P.; Lisok, J.; Chilinski, M.; Rozwadowska, A.; Ritter, C.; Neuber, R.; et al. Annual changes of aerosol optical depth and Ångström exponent over Spitsbergen. In Impact of Climate Changes on Marine Environments; Springer: Berlin, Germany, 2015; pp. 23–36. [Google Scholar]
- Stock, M. Charakterisierung der troposphärischen Aerosolvariabilität in der europäischen Arktis [Characterization of Tropospheric Aerosol Variability in the European Arctic]. Ph.D. Thesis, University of Potsdam and Alfred Wegener Institute, Helmholtz Centre for Polar and Marine Research, Potsdam, Germany, 2010. [Google Scholar]
- Graßl, S. Properties of Arctic Aerosols based on Photometer Long-Term Measurements in Ny-Ålesund. Master’s Thesis, Ludwig-Maximilians University, Munich and Alfred Wegener Institute, Helmholtz Centre for Polar and Marine Research, Potsdam, Germany, 2019. [Google Scholar]
- Stohl, A.; Berg, T.; Burkhart, J.; Fjæraa, A.; Forster, C.; Herber, A.; Hov, Ø.; Lunder, C.; McMillan, W.; Oltmans, S.; et al. Arctic smoke–record high air pollution levels in the European Arctic due to agricultural fires in Eastern Europe in spring 2006. Atmos. Chem. Phys.
**2007**, 7, 511–534. [Google Scholar] [CrossRef] - Stohl, A.; Haimberger, L.; Scheele, M.; Wernli, H. An intercomparison of results from three trajectory models. Meteorol. Appl.
**2001**, 8, 127–135. [Google Scholar] [CrossRef][Green Version] - Lüpkes, C.; Vihma, T.; Birnbaum, G.; Wacker, U. Influence of leads in sea ice on the temperature of the atmospheric boundary layer during polar night. Geophys. Res. Lett.
**2008**, 35, L03805. [Google Scholar] [CrossRef] - Tomasi, C.; Lupi, A.; Mazzola, M.; Stone, R.S.; Dutton, E.G.; Herber, A.; Radionov, V.F.; Holben, B.N.; Sorokin, M.G.; Sakerin, S.M.; et al. An update on polar aerosol optical properties using POLAR-AOD and other measurements performed during the International Polar Year. Atmos. Environ.
**2012**, 52, 29–47. [Google Scholar] [CrossRef][Green Version] - Cachorro, V.E.; Durán, P.; Vergaz, R.; de Frutos, A.M. Columnar physical and radiative properties of atmospheric aerosols in north central Spain. J. Geophys. Res. Atmos.
**2000**, 105, 7161–7175. [Google Scholar] [CrossRef] - O’Neill, N.T.; Dubovik, O.; Eck, T.F. Modified Ångström exponent for the characterization of submicrometer aerosols. Appl. Opt.
**2001**, 40, 2368–2375. [Google Scholar] [CrossRef] - O’Neill, N.; Eck, T.; Holben, B.; Smirnov, A.; Dubovik, O.; Royer, A. Bimodal size distribution influences on the variation of Angstrom derivatives in spectral and optical depth space. J. Geophys. Res. Atmos.
**2001**, 106, 9787–9806. [Google Scholar] [CrossRef] - O’Neill, N.; Eck, T.; Smirnov, A.; Holben, B.; Thulasiraman, S. Spectral discrimination of coarse and fine mode optical depth. J. Geophys. Res. Atmos.
**2003**, 108, AAC 8–1–AAC 8–15. [Google Scholar] [CrossRef] - Shifrin, K.S. Simple relationships for the Ångström parameter of disperse systems. Appl. Opt.
**1995**, 34, 4480–4485. [Google Scholar] [CrossRef] [PubMed] - Kreuter, A.; Wuttke, S.; Blumthaler, M. Improving Langley calibrations by reducing diurnal variations of aerosol Ångström parameters. Atmos. Meas. Tech.
**2013**, 6, 99–103. [Google Scholar] [CrossRef] - Schuster, G.L.; Dubovik, O.; Holben, B.N. Angstrom exponent and bimodal aerosol size distributions. J. Geophys. Res. Atmos.
**2006**, 111, D07207. [Google Scholar] [CrossRef] - Hulst, H.C.; van de Hulst, H.C. Light Scattering by Small Particles; Courier Dover Publications: Toledo, OH, USA, 1957. [Google Scholar]
- Böckmann, C. Hybrid regularization method for the ill-posed inversion of multiwavelength Lidar data in the retrieval of aerosol size distributions. Appl. Opt.
**2001**, 40, 1329–1342. [Google Scholar] [CrossRef] - Veselovskii, I.; Kolgotin, A.; Griaznov, V.; Müller, D.; Wandinger, U.; Whiteman, D.N. Inversion with regularization for the retrieval of tropospheric aerosol parameters from multiwavelength Lidar sounding. Appl. Opt.
**2002**, 41, 3685–3699. [Google Scholar] [CrossRef] [PubMed] - Kulla, B.S.; Ritter, C. Water Vapor Calibration: Using a Raman Lidar and Radiosoundings to Obtain Highly Resolved Water Vapor Profiles. Remote Sens.
**2019**, 11, 616. [Google Scholar] [CrossRef] - Ritter, C.; Neuber, R.; Schulz, A.; Markowicz, K.; Stachlewska, I.; Lisok, J.; Makuch, P.; Pakszys, P.; Markuszewski, P.; Rozwadowska, A.; et al. 2014 iAREA campaign on aerosol in Spitsbergen—Part 2: Optical properties from Raman-Lidar and in-situ observations at Ny-Ålesund. Atmos. Environ.
**2016**, 141, 1–19. [Google Scholar] [CrossRef] - Hoffmann, A. Comparative Aerosol Studies Based on Multi-Wavelength Raman Lidar at Ny-Ålesund, Spitsbergen. Ph.D. Thesis, Universität Potsdam, Potsdam, Germany, 2011. [Google Scholar]
- Hoffmann, A.; Ritter, C.; Stock, M.; Maturilli, M.; Eckhardt, S.; Herber, A.; Neuber, R. Lidar measurements of the Kasatochi aerosol plume in August and September 2008 in Ny-Ålesund, Spitsbergen. J. Geophys. Res. Atmos.
**2010**, 115, D00L12. [Google Scholar] [CrossRef] - Shibata, T.; Shiraishi, K.; Shiobara, M.; Iwasaki, S.; Takano, T. Seasonal Variations in High Arctic Free Tropospheric Aerosols Over Ny-Ålesund, Svalbard, Observed by Ground-Based Lidar. J. Geophys. Res. Atmos.
**2018**, 123, 12353–12367. [Google Scholar] [CrossRef] - Ritter, C.; Angeles Burgos, M.; Böckmann, C.; Mateos, D.; Lisok, J.; Markowicz, K.; Moroni, B.; Cappelletti, D.; Udisti, R.; Maturilli, M.; et al. Microphysical properties and radiative impact of an intense biomass burning aerosol event measured over Ny-Ålesund, Spitsbergen in July 2015. Tellus B Chem. Phys. Meteorol.
**2018**, 70, 1–23. [Google Scholar] [CrossRef] - Eckhardt, S.; Stohl, A.; Beirle, S.; Spichtinger, N.; James, P.; Forster, C.; Junker, C.; Wagner, T.; Platt, U.; Jennings, S. The North Atlantic Oscillation controls air pollution transport to the Arctic. Atmos. Chem. Phys.
**2003**, 3, 1769–1778. [Google Scholar] [CrossRef][Green Version] - Christensen, J.; Goodsite, M.; Heidam, N.; Skov, H.; Wåhlin, P. Chapter 1. Atmospheric Environment. In AMAP Greenland and the Faroe Islands 1997–2001; Riget, F., Christensen, J., Johansen, P., Eds.; Danish Cooperation for Environment in the Arctic Ministry of Environment: Copenhagen, Denmark, 2003; Volume 2, pp. 11–46. [Google Scholar]
- Baskaran, M.; Shaw, G.E. Residence time of arctic haze aerosols using the concentrations and activity ratios of 210Po, 210Pb and 7Be. J. Aerosol Sci.
**2001**, 32, 443–452. [Google Scholar] [CrossRef]

**Figure 1.**Green circles are individual measurements, the colored lines the fitted exponential law. Left: The data were fitted with the traditional Ångström law of Equation (1). Right: Equation (2) with two wavelength ranges of the UV and visible (<700 nm) and the near-infrared (>700 nm) were used for the same dataset.

**Figure 3.**30th and 70th percentile for traditional and modified Ångström parameters $AE$, $\alpha $, and $\beta $ depending on the noise level $\Delta AOD$.

**Figure 4.**Radius dependency of the traditional and modified Ångström exponent $AE$, $\alpha $, and $\beta $ for different refractive indexes and standard derivations $\sigma $.

**Figure 5.**Example of a clear day with a small cloud appearing at 14:30 with changes in the computed Ångström parameters afterwards.

**Figure 6.**Monthly means in AOD for the years 1994–2000 (first row), 2001–2009 (bottom, left), and 2009–2017 (bottom, right). The dashed magenta lines are the monthly means of the corresponding time interval. Note that the year 2009 is plotted as well in both plots (bottom) as a reference.

**Figure 7.**Left: Monthly mean $AO{D}_{500}$ for the years 1994–2000 (already published in Herber et al. [13]).

**Figure 8.**Histogram of one-minute photometer data of $AO{D}_{500}$ for April 2013 (left) and April 2017 (right).

**Figure 9.**Histograms of the spectral slope $\beta $ for April 2013 (left) and April 2017 (right). The blue bars are the total amount of measurements, whereas the yellow and red bars only represent the fraction of $\alpha >1.5$ and $\alpha <1.5$, respectively.

**Figure 10.**Correlation between the modified Ångström exponent $\alpha $ and its spectral slope $\beta $ for the haze season (April) and for summer conditions (August) of the years 2009–2017. The grey area indicates the possible combinations for $\alpha $ and $\beta $ using the Mie calculus of Figure 4.

**Figure 11.**Five-day back-trajectories arriving at a 1500 m altitude over Zeppelin Station for days with “low AOD” (left) and “high AOD” (right) for April 2013. Thick grey dots mark areas with a relative humidity >90% as an indication of hygroscopic growth of the aerosol.

**Figure 12.**Fraction of how long the air parcel was over land, ocean, or ice for the months of April, May, and August and arrived at a height of 1500 m over Ny-Ålesund for the years 2013–2017. The numbers below the bars indicate the total number of points for each category.

**Figure 13.**Fraction of how long the air parcel was over land, ocean, or ice. Left: All data points are plotted, independent of the height of the air parcel. Right: Only the cases are plotted where the air parcel was within the boundary layer (defined as $p>900$ hPa). This plot only shows the data for the arriving heights of 500 m and 1500 m above Zeppelin Station for all Aprils, 2013–2016. The numbers below the bars indicate the total number of points for each category.

**Figure 14.**Fraction of how long the air parcel was over land, ocean, or ice. Left: All data points are plotted, independent of the height of the air parcel. Right: Only the cases are plotted where the air parcel was within the boundary layer (defined as $p>900$ hPa). This plot only shows the data for the arriving heights of 500 m and 1500 m above Zeppelin Station for all Augusts, 2013–2017. The numbers below the bars indicate the total number of points for each category.

**Table 1.**Different possibilities for an effective radius, ${r}_{eff}$, depending on the standard deviation $\sigma $ of the distribution and refractive indexes ${n}_{1}$ and ${n}_{2}$ for given parameters $\alpha =1$, $\beta =-1.5$, and $AE=1$. The best matching combination of $\alpha $ and $\beta $ is highlighted in red.

Refractive Index${\mathit{n}}_{1}=1.60+0.01\mathit{i}$ | |||
---|---|---|---|

$\mathit{\sigma}$ | $\mathit{AE}$ | $\mathit{\alpha}$ | $\mathit{\beta}$ |

1.3 | ${r}_{eff,1}=0.01\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m | ${r}_{eff}=0.13\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m | ${r}_{eff,1}=0.11\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m |

${r}_{eff,2}=0.18\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m | ${r}_{eff,2}=0.34\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m | ||

1.5 | ${r}_{eff}=0.14\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m | ${r}_{eff}=0.09\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m | ${r}_{eff,1}=0.09\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m |

${r}_{eff,2}=0.20\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m | |||

1.7 | ${r}_{eff}=0.10\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m | ${r}_{eff}=0.07\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m | ${r}_{eff,1}=0.11\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m |

${r}_{eff,2}=0.34\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m | |||

Refractive Index${\mathit{n}}_{\mathbf{2}}=\mathbf{1}.\mathbf{44}+{\mathbf{10}}^{-\mathbf{5}}\mathit{i}$ | |||

$\mathit{\sigma}$ | $\mathit{AE}$ | $\mathit{\alpha}$ | $\mathit{\beta}$ |

1.3 | ${r}_{eff}=0.16\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m | ${r}_{eff}=0.10\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m | ${r}_{eff,1}=0.09\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m |

${r}_{eff,2}=0.16\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m | |||

1.5 | ${r}_{eff}=0.21\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m | ${r}_{eff}=0.14\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m | ${r}_{eff,1}=0.06\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m |

${r}_{eff,2}=0.35\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m | |||

1.7 | ${r}_{eff}=0.28\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m | ${r}_{eff}=0.19\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m | ${r}_{eff,1}=0.05\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m |

${r}_{eff,2}=0.16\phantom{\rule{3.33333pt}{0ex}}\mathsf{\mu}$m |

**Table 2.**$AO{D}_{500}$ thresholds to distinguish back-trajectories arriving at Zeppelin Station with high and low AOD. They are the minima in the bimodal $AO{D}_{500}$ distributions.

Year | April | May | August |
---|---|---|---|

2013 | 0.07 | 0.04 | 0.035 |

2014 | 0.07 | 0.056 | 0.08 |

2015 | 0.085 | 0.09 | 0.07 |

2016 | 0.08 | 0.05 | 0.1 |

2017 | - | 0.08 | 0.035 |
