Optimal Speed Regulation Control of the Hybrid Dual Clutch Transmission Shift Process †
Abstract
:1. Introduction
2. Problem Formulation
2.1. Gear Shift Process in Pure Electric Drive Mode
2.2. Powertrain Model and Parameters Identification
3. Controller Design
3.1. MPC Controller Design
3.2. Controller Parameters Tuning
3.3. Disturbance Observer Design
4. Results
4.1. Simulation Results
4.2. Experimental Results
5. Conclusions
