An Enhanced Three-Dimensional Auxetic Lattice Structure with Improved Property
Abstract
1. Introduction
2. Experimental
2.1. Structure Design
2.2. Fabrication of Lattice Samples
2.3. Mechanical Measurement
3. Results and Discussion
3.1. Parameter Studies of the Structures
3.1.1. Effect of Strut Diameter d
3.1.2. Effect of θ Angle
3.2. Effect of Compression Direction
3.3. Effect of Material
3.4. Analysis of Enhanced Mechanical Properties
4. Conclusions
Author Contributions
Funding
Conflicts of Interest
References
