Modelling a Switching Process of IGBTs with Influence of Temperature Taken into Account

Department of Marine Electronics, Gdynia Maritime University, 81-225 Gdynia, Poland
*
Author to whom correspondence should be addressed.
This paper is an extended version of our paper published in 24th International Workshop on Thermal Investigations of ICs and Systems Therminic 2018, Kista, 164 40 Stockholm, Sweden, 26–28 September 2018, doi:10.1109/THERMINIC.2018.8592873.
Energies 2019, 12(10), 1894; https://doi.org/10.3390/en12101894 (registering DOI)
Received: 1 April 2019 / Revised: 27 April 2019 / Accepted: 14 May 2019 / Published: 18 May 2019
(This article belongs to the Special Issue Thermal and Electro-thermal System Simulation)
  |
PDF [3435 KB, uploaded 18 May 2019]
  |

Abstract

In this article the problem of modelling a switching process of Insulated Gate Bipolar Transistors (IGBTs) in the SPICE software is considered. The new form of the considered transistor model is presented. The model includes controlled voltage and current sources, resistors and voltage sources. In the model, influence of temperature on dc and dynamic characteristics of the IGBT is taken into account. A detailed description of the dynamic part of this model is included in the article and some results of experimental verification are shown. Verification is performed for a transistor IRG4PC40UD by International Rectifier. The presented results of computations and measurements show clearly influence of temperature on on-time and off-time, and additionally switching energy losses are observed. Moreover, the results of investigations performed with the use of the new model are compared to the results of computations performed with classical models of the considered device given in the literature. It is proved that the new model makes it possible to obtain a better match to the results of measurements than the considered models described in the literature. View Full-Text
Keywords: power semiconductor devices; IGBT; modelling; transient analysis; SPICE; switching; thermal phenomena power semiconductor devices; IGBT; modelling; transient analysis; SPICE; switching; thermal phenomena
