Search Results (38)

Accurate and reliable pedestrian positioning service is essential for providing Indoor Location-Based Services (ILBSs). Zero-Velocity Update (ZUPT)-aided Strapdown Inertial Navigation System (SINS) based on foot-mounted wearable Inertial Measurement Units (IMUs) has shown great performance in pedestrian navigation systems. Though the velocity errors will be corrected once zero-velocity measurement is available, the navigation system errors accumulated during measurement outages are yet to be further optimized by utilizing historical data during both stance and swing phases of pedestrian gait. Thus, in this paper, a novel Forward–Backward navigation and Rauch–Tung–Striebel smoothing (FB-RTS) navigation scheme is proposed. First, to efficiently re-estimate past system state and reduce accumulated navigation error once zero-velocity measurement is available, both the forward and backward integration method and the corresponding error equations are constructed. Second, to further improve navigation accuracy and reliability by exploiting historical observation information, both backward and forward RTS algorithms are established, where the system model and observation model are built under the output correction mode. Finally, both navigation results are combined to achieve the final estimation of attitude and velocity, where the position is recalculated by the optimized data. Through simulation experiments and two sets of field tests, the FB-RTS algorithm demonstrated superior performance in reducing navigation errors and smoothing pedestrian trajectories compared to traditional ZUPT method and both the FB and the RTS method, whose advantage becomes more pronounced over longer navigation periods than the traditional methods, offering a robust solution for positioning applications in smart buildings, indoor wayfinding, and emergency response operations. Full article

When natural disasters such as earthquakes occur, accurate navigation and positioning information may not be available, making a purely inertial pedestrian navigation system particularly important for rescuers. In this paper, researchers propose a zero-velocity update architecture for pedestrian navigation based on the Informer model, which is integrated into wearable devices. This architecture modifies the fully connected layer of the Informer model to be used for the binary classification task of the zero-velocity update method (ZUPT), allowing for accurate identification of gait information at each moment using only inertial measurement data. By wearing the device on the foot during natural disasters like earthquakes, the location of the pedestrian can be more accurately determined, facilitating rescue efforts. During the experimental process, a Kalman filter model was constructed to achieve zero-velocity updating of the pedestrian’s motion trajectory. A 2000 m walking experiment and a 210 m mixed-gait experiment were conducted to accurately identify gait information at each moment, thereby reducing the cumulative error of the inertial system. Subsequently, a convolutional neural network (CNN) model and a model combining CNN with a long short-term memory network (CNN + LSTM) were introduced as comparative experiments to verify the performance of the proposed architecture. The experimental results demonstrate that the proposed architecture enhances the adaptability of the zero-velocity update algorithm in underground or sheltered spaces, with all results outperforming the other two models. Full article

The MEMS inertial sensors based on the pedestrian localization system assisted by the zero-velocity update (ZUPT) algorithm has gained widespread attention, due to its effective independent localization in indoor environments. However, in the realistic pedestrian localization test, the system often appears to drift because of the long-term error accumulation of inertial sensors and the limitation of the error suppression of traditional pedestrian localization algorithms. In this article, based on full analysis of existing constraint-based methods, a multi-condition constrained pedestrian localization algorithm is proposed, which integrates zero velocity detection based on phase threshold constraint, single and dual feet fusion constraint algorithms, to suppress drift and improve localization accuracy. The experimental results demonstrate that the multi-condition constraint algorithm can reduce localization errors by 59% compared to the unconstrained approach, and by 42% and 26% compared to algorithms using only single-foot or dual-feet constraints, respectively. The trajectory generated from the experiments further shows that the proposed algorithm produces a trajectory that more closely aligns with the actual walking path. Full article

To suppress pedestrian positioning drift, a velocity constraint commonly known as zero-velocity update (ZUPT) is widely used. However, it cannot correct the error in the non-zero velocity interval (non-ZVI) or observe heading errors. In addition, the positioning accuracy will be further affected when a velocity error occurs in the ZVI (e.g., foot tremble). In this study, the foot, ankle, and shank were regarded as a triangular structure. Consequently, an angle constraint was established by utilizing the sum of the internal angles. Moreover, in contrast to the traditional ZUPT algorithm, a velocity constraint method combined with Coriolis theorem was constructed. Magnetometer measurements were used to correct heading. Three groups of experiments with different trajectories were carried out. The ZUPT method of the single inertial measurement unit (IMU) and the distance constraint method of dual IMUs were employed for comparisons. The experimental results showed that the proposed method had high accuracy in positioning. Furthermore, the constraints built by the lower limb structure were applied to the whole gait cycle (ZVI and non-ZVI). Full article

The pipe jacking guidance system based on a fiber optic gyroscope (FOG) has gained extensive attention due to its high degree of safety and autonomy. However, all inertial guidance systems have accumulative errors over time. The zero-velocity update (ZUPT) algorithm is an effective error compensation method, but accurately distinguishing between moving and stationary states in slow pipe jacking operations is a major challenge. To address this challenge, a “MV + ARE + SHOE” three-conditional zero-velocity detection (TCZVD) algorithm for the fiber optic gyroscope inertial navigation system (FOG-INS) is designed. Firstly, a Kalman filter model based on ZUPT is established. Secondly, the TCZVD algorithm, which combines the moving variance of acceleration (MV), angular rate energy (ARE), and stance hypothesis optimal estimation (SHOE), is proposed. Finally, experiments are conducted, and the results indicate that the proposed algorithm achieves a zero-velocity detection accuracy of 99.18% and can reduce positioning error to less than 2% of the total distance. Furthermore, the applicability of the proposed algorithm in the practical working environment is confirmed through on-site experiments. The results demonstrate that this method can effectively suppress the accumulated error of the inertial guidance system and improve the positioning accuracy of pipe jacking. It provides a robust and reliable solution for practical engineering challenges. Therefore, this study will contribute to the development of pipe jacking automatic guidance technology. Full article

To regulate the energy flow in orchard ecosystems and maintain the environment, weeding has become a necessary measure for fruit farmers, and the use of automated mowers can help reduce labor costs and improve the economic efficiency of orchards. However, due to the complexity of the geographic and spatial environment of the orchard, in particular, the loose and undulating road surface, the interference of satellite signals by large trees, etc., which decreases the positioning accuracy and stability of the positioning system of the mower, and the high cost of the sensor also affect the popularization of intelligent mowers for these applications. To address the above problems, this paper constructs a positioning system through a low-cost global navigation satellite system (GNSS), inertial measurement unit (IMU), and odometry, and utilizes the Kalman filter algorithm based on the error state for a combined GNSS/IMU positioning so that the inertial navigation system can maintain a more accurate positioning when the GNSS signals are poor. Considering the side-slip and error accumulation problems of the odometry of the traction mower, the combined GNSS/IMU positioning information is used to optimize the odometry model and improve the navigation and positioning accuracy. To reduce the measurement error of the IMU and the problem of error accumulation, this paper utilizes the nonholonomic constraint (NHC) of a lawn mower to suppress the dispersion of IMU measurement errors and constructs periodic and nonperiodic zero-velocity updating (ZUPT) strategies in combination with the travel paths of lawn mower navigation operations in the region to update the IMU data to improve the positioning accuracy and stability of the positioning system. The experiments show that the average error of the constructed positioning system is controlled within 0.15 m, the maximum error is maintained at approximately 0.3 m, and the positioning system constructed by using low-cost sensors can achieve a positioning accuracy similar to that of the differential global navigation satellite system (DGNSS), which is beneficial for the promotion and application of intelligent mowers in orchards. Full article

Pedestrian navigation methods based on inertial sensors are commonly used to solve navigation and positioning problems when satellite signals are unavailable. To address the issue of heading angle errors accumulating over time in pedestrian navigation systems that rely solely on the Zero Velocity Update (ZUPT) algorithm, it is feasible to use the pedestrian’s motion constraints to constrain the errors. Firstly, a human step length model is built using human kinematic data collected by the motion capture system. Secondly, we propose the bipedal constraint algorithm based on the established human step length model. Real field experiments demonstrate that, by introducing the bipedal constraint algorithm, the mean biped radial errors of the experiments are reduced by 68.16% and 50.61%, respectively. The experimental results show that the proposed algorithm effectively reduces the radial error of the navigation results and improves the accuracy of the navigation. Full article

The zero-velocity update (ZUPT) algorithm is a pivotal advancement in pedestrian navigation accuracy, utilizing foot-mounted inertial sensors. Its key issue hinges on accurately identifying periods of zero-velocity during human movement. This paper introduces an innovative adaptive sliding window technique, leveraging the Fourier Transform to precisely isolate the pedestrian’s gait frequency from spectral data. Building on this, the algorithm adaptively adjusts the zero-velocity detection threshold in accordance with the identified gait frequency. This adaptation significantly refines the accuracy in detecting zero-velocity intervals. Experimental evaluations reveal that this method outperforms traditional fixed-threshold approaches by enhancing precision and minimizing false positives. Experiments on single-step estimation show the adaptability of the algorithm to motion states such as slow, fast, and running. Additionally, the paper demonstrates pedestrian trajectory localization experiments under a variety of walking conditions. These tests confirm that the proposed method substantially improves the performance of the ZUPT algorithm, highlighting its potential for pedestrian navigation systems. Full article

Cableways have been widely used in industrial areas, cities, and scenic spots due to their advantages, such as being a convenient mode of transportation, time-saving, labor-saving, and low cost, as well as offering environmental protection. To ensure the safe operation of a cableway, based on the characteristic that the velocity of the cableway bracket is approximately zero in a static deformation monitoring environment, a deformation monitoring method called zero velocity update (ZUPT)-based GNSS/IMU tightly coupled algorithm with the constraint of the Earth’s rotation angular velocity was proposed. The proposed method can effectively solve the problem of a single GNSS being unable to output attitude, which is directly related to the status of wire ropes and cable cars. Meanwhile, ZUPT is used to restrain the Kalman filter’s divergence when IMU is stationary. However, the improvements of ZUPT on attitude are not obvious, so the constraint of the Earth’s rotation angular velocity was applied. The performance of the proposed method was evaluated through monitoring the cableway bracket of the Yimeng Mountain Tourism area in Shandong. Compared with the ZUPT-based GNSS/IMU tightly coupled algorithm (ZUPT-TC), the proposed method can further constrain the error accumulation of IMU while stationary and, therefore, it can provide reliable position and attitude information on cableway brackets. Full article

This paper presents a framework for accurately and efficiently estimating a walking human’s trajectory using a computationally inexpensive non-Gaussian recursive Bayesian estimator. The proposed framework fuses global and inertial measurements with predictions from a kinematically driven step model to provide robustness in localization. A maximum a posteriori-type filter is trained on typical human kinematic parameters and updated based on live measurements. Local step size estimates are generated from inertial measurement units using the zero-velocity update (ZUPT) algorithm, while global measurements come from a wearable GPS. After each fusion event, a gradient ascent optimizer efficiently locates the highest likelihood of the individual’s location which then triggers the next estimator iteration.The proposed estimator was compared to a state-of-the-art particle filter in several Monte Carlo simulation scenarios, and the original framework was found to be comparable in accuracy and more efficient at higher resolutions. It is anticipated that the methods proposed in this work could be more useful in general real-time estimation (beyond just personal navigation) than the traditional particle filter, especially if the state is many-dimensional. Applications of this research include but are not limited to: in natura biomechanics measurement, human safety in manual fieldwork environments, and human/robot teaming. Full article

This paper proposes a novel Blockchain-based indoor navigation system that combines a foot-mounted dual-inertial measurement unit (IMU) setup and a zero-velocity update (ZUPT) algorithm for secure and accurate indoor navigation in GNSS-denied environments. The system estimates the user’s position and orientation by fusing the data from two IMUs using an extended Kalman filter (EKF). The ZUPT algorithm is employed to detect and correct the error introduced by sensor drift during zero-velocity intervals, thus enhancing the accuracy of the position estimate. The proposed Low SWaP-C blockchain-based decentralized architecture ensures the security and trustworthiness of the system by providing an immutable and distributed ledger to store and verify the sensor data and navigation solutions. The proposed system is suitable for various indoor navigation applications, including autonomous vehicles, robots, and human tracking. The experimental results provide clear and compelling evidence of the effectiveness of the proposed system in ensuring the integrity, privacy, and security of navigation data through the utilization of blockchain technology. The system exhibits an impressive ability to process more than 680 transactions per second within the Hyperledger-Fabric framework. Furthermore, it demonstrates exceptional accuracy and robustness, with a mean RMSE error of 1.2 m and a peak RMSE of 3.2 during a 20 min test. By eliminating the reliance on external signals or infrastructure, the system offers an innovative, practical, and secure solution for indoor navigation in environments where GNSS signals are unavailable. Full article

In scenarios with insufficient structural features, LiDAR-based SLAM may suffer from degeneracy, resulting in impaired robot localization and mapping and potentially leading to subsequent deviant navigation tasks. Therefore, it is crucial to develop advanced algorithms and techniques to mitigate the degeneracy issue and ensure the robustness and accuracy of LiDAR-based SLAM. This paper presents a LiDAR–inertial simultaneous localization and mapping (SLAM) method based on a virtual inertial navigation system (VINS) to address the issue of degeneracy. We classified different gaits and match each gait to its corresponding torso inertial measurement unit (IMU) sensor to construct virtual foot inertial navigation components. By combining an inertial navigation system (INS) with zero-velocity updates (ZUPTs), we formed the VINS to achieve real-time estimation and correction. Finally, the corrected pose estimation was input to the IMU odometry calculation procedure to further refine the localization and mapping results. To evaluate the effectiveness of our proposed VINS method in degenerate environments, we conducted experiments in three typical scenarios. The results demonstrate the high suitability and accuracy of the proposed method in degenerate scenes and show an improvement in the point clouds mapping effect. The algorithm’s versatility is emphasized by its wide applicability on GPU platforms, including quadruped robots and human wearable devices. This broader potential range of applications extends to other related fields such as autonomous driving. Full article

There are many demands for the cooperative localization (CL) of multiple people, such as firefighter rescue. The classical foot-mounted inertial navigation based on zero velocity update (ZUPT) suffers from accumulating error due to the low-cost inertial sensor, and the pre-placed anchors in the ultra-wideband (UWB) system limit the application in an unknown environment. In this study, a group of sensors including the inertial measurement unit (IMU), magnetometer, barometer, and UWB sensor is used. Through the different characteristics of sensors and the position relationship between people, a cooperative localization system using an extended Kalman filter for three-dimensional firefighter tracking is proposed. Ranging information between firefighters from UWB is utilized, and couplings introduced by relative measurement are estimated. Two experiments are designed to verify the proposed algorithm in building and forest environments. Compared with the results of single-person inertial navigation, the average positioning precision of the algorithm in the building and forest is, respectively, improved by 38.93% and 79.01%. This approach successfully suppresses the divergence of positioning errors, and fixed UWB anchors are not needed. Full article

With the development of indoor location-based services (ILBS), the dual foot-mounted inertial navigation system (DF-INS) has been extensively used in many fields involving monitoring and direction-finding. It is a widespread ILBS implementation with considerable application potential in various areas such as firefighting and home care. However, the existing DF-INS is limited by a high inaccuracy rate due to the highly dynamic and non-stable stride length thresholds. The system also provides less clear and significant information visualization of a person’s position and the surrounding map. This study proposes a novel wearable-foot IOAM-inertial odometry and mapping to address the aforementioned issues. First, the person’s gait analysis is computed using the zero-velocity update (ZUPT) method with data fusion from ultrasound sensors placed on the inner side of the shoes. This study introduces a dynamic minimum centroid distance (MCD) algorithm to improve the existing extended Kalman filter (EKF) by limiting the stride length to a minimum range, significantly reducing the bias in data fusion. Then, a dual trajectory fusion (DTF) method is proposed to combine the left- and right-foot trajectories into a single center body of mass (CBoM) trajectory using ZUPT clustering and fusion weight computation. Next, ultrasound-type mapping is introduced to reconstruct the surrounding occupancy grid map (S-OGM) using the sphere projection method. The CBoM trajectory and S-OGM results were simultaneously visualized to provide comprehensive localization and mapping information. The results indicate a significant improvement with a lower root mean square error (RMSE = 1.2 m) than the existing methods. Full article

Pedestrian navigation systems could serve as a good supplement for other navigation methods or for extending navigation into areas where other navigation systems are invalid. Due to the accumulation of inertial sensing errors, foot-mounted inertial-sensor-based pedestrian navigation systems (PNSs) suffer from drift, especially heading drift. To mitigate heading drift, considering the complexity of human motion and the environment, we introduce a novel hybrid framework that integrates a foot-state classifier that triggers the zero-velocity update (ZUPT) algorithm, zero-angular-rate update (ZARU) algorithm, and a state lock, a magnetic disturbance detector, a human-motion-classifier-aided adaptive fusion module (AFM) that outputs an adaptive heading error measurement by fusing heuristic and magnetic algorithms rather than simply switching them, and an error-state Kalman filter (ESKF) that estimates the optimal systematic error. The validation datasets include a Vicon loop dataset that spans 324.3 m in a single room for approximately 300 s and challenging walking datasets that cover large indoor and outdoor environments with a total distance of 12.98 km. A total of five different frameworks with different heading drift correction methods, including the proposed framework, were validated on these datasets, which demonstrated that our proposed ZUPT–ZARU–AFM–ESKF-aided PNS outperforms other frameworks and clearly mitigates heading drift. Full article
