Search Results (28)

Canadian sawmills commonly use chipper-canters to process softwood logs into squared lumber and wood chips for pulp mills. However, the declining demand for newsprint and print paper has led to an oversupply of wood chips, resulting in economic losses and environmental concerns. To address this issue, a strander-canter capable of producing both softwood cants and strands for oriented strand board (OSB) presents a promising alternative. This study evaluates the feasibility of using jack pine strands generated by a novel strander-canter equipped with a cutterhead for OSB strand production. Strands were generated from frozen and unfrozen logs under varying cutting parameters and incorporated in the core layer of the panels. Industrial aspen strands were used for the surface layers. OSB panels were assessed for mechanical and physical properties following the CSA O325:21 standard. Strand size distribution and vertical density profiles were also analyzed. The results indicated that panels made from jack pine strands demonstrated bending and internal bond properties that were either comparable to or superior to those of the control panels. However, including jack pine strands in the core layer increased the thickness swelling of the panels. Full article

Comminution is performed by using two main types of machines: grinders and chippers. Grinders are commonly used to treat contaminated wood biomass. In South Korea, cut-to-length harvesting is the main salvage logging method, and felled trees and residues often become dirtied during extraction, where logs are moved from the stump to the roadside using a small shovel. Therefore, grinders are preferred for the comminution of wood biomass for conversion into hog fuel. This study aimed to evaluate productivity and hog fuel quality as outcomes of wood biomass sorting. The productivities for unsorted residues and logs were 11.2 ± 1.48 ton/PMH₀ and 12.4 ± 1.73 ton/PMH₀ at a moisture content of 24%, respectively. Between 33.5% and 46.0% of the total hog fuel mass passed through the screen and reached an acceptable size (3.15 mm to 63 mm). The bulk densities of the two materials ranged from 132.4 kg/m³ to 148.8 kg/m³ on a dry basis. The results of this study suggest that sorting the feedstock has the potential to reduce the number of oversized particles in the hog fuel without screening. Full article

The production of wood chips can be achieved using different types of wood chippers whose productivity can be influenced by many factors including proper knife management. Research was conducted to determine the productivity of the new Diamant chipper in chipping air-dried tops stacked at a roadside landing and to compare the efficiency of dry sharpening and wet sharpening in restoring chipper productivity, the time required by dry sharpening with that of knife replacement, and the cost of dry sharpening to knife change in real-life conditions. To clearly define the influence of knife management, a model of the effect of knife wear on chipper productivity was produced. Analysis of variance was used to check the significance of any differences in chipping and total time consumption per cycle. Multiple regression was used to express the relationship between chipping time consumption per cycle and the cumulated mass processed by a set of knives—the latter taken as an indicator of knife wear. The study lasted 10 full workdays, included a total of 136 truckloads or 3560 t of fresh wood chips (or green tons = gt), and resulted in the average productivity of 59.0 gt per productive chipping hour (excluding all delays) or 39.4 gt per machine scheduled hour (including all delays). Delays represented 37% of total worksite time. Knife management (dry sharpening or change) accounted for 30% of the total delay time due to raw material contamination. Dry sharpening took 30% less time than a full knife change. As wear accumulated and knives lost their edge, the chipping time per cycle increased from 25 in the first cycle (full truck load) to 38 min in the third cycle. The presented study offers robust productivity figures, together with a reliable estimate of the productivity losses caused by knife wear, and could help improve knife management in order to increase chipper productivity as well as reduce unnecessary delays. Full article

Wood fuel from the agroforestry sector is one of the main strategies cited by the EU for reducing energetic dependance on foreign markets. Its sustainability, both economic and environmental, can be improved through the optimization of harvesting and chipping operations. This study was focused on the dynamic and energetic balance of the chipping phase carried out by a chipper operated by the power-take-off (PTO) of a medium-power tractor. Both machines were equipped with sensors for real-time monitoring of fuel consumption, PTO torque and speed, trunk diameter and working time during the comminution of 61 poplar trees grown in a medium rotation coppice system. The data analysis was carried out on the entire dataset (about 29,000 records) without considering their belonging to different trees. By means of proper data ordinations, it has been possible to define all the intervals in which the chipping stopped (e.g., between two trees) and to exclude them from the intervals of actual chipping. This has allowed forcomputation of operative and actual working time, as well as of the basic power required to operate the chipper and the power for actual chipping. Subsequently, the parameter values observed during actual chipping were related to the cutting diameters measured at the same instant. Subsequently, the dataset was divided according to seven diameter classes, and, for each class, the descriptive statistical indices of working time, work productivity, CO₂ emissions, energy requirement and fuel consumption were calculated. Eventually, the correlation between the variations in trunk diameter and other parameters was verified both on the whole dataset and based on the class average values. The analysis made it possible to identify the conditions of greatest efficiency for the chipper. More generally, the method could help to increase the accuracy of measurements aimed at characterizing the performance of chippers from the point of view of dynamic energy requirements as well as in relation to different wood species. Full article

A variety of events such as high-altitude electromagnetic pulses, extreme solar storms, and coordinated cyber attacks could result in a catastrophic loss of infrastructure on a continental or global scale. The lengthy repair of critical infrastructure creates a need for alternative fuels such as wood gas. Wood gas is produced by heating wood in a low-oxygen environment and can be used to power combustion engines. This work investigates a novel wood chipper, designed as an energy-efficient tool for producing wood gas stock, wood chips, aiming to speed up the transition to alternative fuel. A prototype is built and tested to determine the energy efficiency and production rate of the device. The results suggest that the wood chipper could produce one cord of wood chips, 3.6 m³, in less than a day and is a viable alternative to other manual wood-processing methods. In addition, the global scaling up of production of the wood chipper is considered, indicating that the mass production of the wood chipper could accelerate the transition of wood gas production methods from manual to machine-driven immediately after a catastrophic event. Full article

Wood chipboard, common in interior spaces for applications ranging from furniture to decorative panelling, often falls short due to the presence of toxic adhesives, posing risks to both human health and the environment. This research delves into the potential transformation of wood chipboard into a 100% bio-based product. Previous research has shown the possibility of the partial replacement of petrochemical-based adhesives with bio-based adhesives. Hence, previous results do not reach the policy ambitions of the Green Deal of making the Green Transition to a bio-based economy. For chipboard production, logging residues from Latvian State Forests were systematically gathered within two months post-logging, comprising primarily Picea abies and Pinus sylvestris biomass, including branches, needles, bark, and various particles. A custom chipper and Vibrotehnik PM-120 hammer mill were employed for particle size separation into three fractions via sieving: <2.8 mm, 2.8–8 mm, and 8.0–10.0 mm, and combined with binders and hot-pressed into board samples. As a result, particle boards containing 100% bio-based carbon were achieved, demonstrating the possibility of excluding petroleum adhesives from chipboard production, paving the way for new research exploring bio-based binders and conifer bark. Full article

Exploiting renewable energy sources is one of the main strategies defined by the EU to overcome dependence on foreign markets for energy supply. Wood fuel sourced from the agroforestry sector can contribute significantly to achieving the goal, though its economic and environmental sustainability is intimately dependent on proper harvesting and chipping operations. In the present article, both economic and environmental aspects of Medium Rotation Coppice (MRC) were investigated regarding chipping. A small-scale chipper and tractor were equipped with real-time sensors to monitor time, t (s); fuel consumption, F (cm³); PTO torque, M (daNm); PTO speed, s (min⁻¹); and stem diameter, D (mm) during the comminution of 61 poplar plants (gathered in 5 classes according to trunk diameter) grown in MRC system. More than 29,000 records were taken and analyzed. Predictive models for working time, working productivity, CO₂ emission, energy consumption, fuel consumption and costs were also produced. Higher diametric classes exhibited lower fuel consumption, less CO₂ emission and less energy demand during chipping. Time and operating costs were statistically different among classes, with minimum values of 0.22 (SD ± 0.02) h·Mg⁻¹ and 12.07 (SD ± 0.93) €·Mg⁻¹ in class 5 and maximum values of 0.64 (SD ± 0.09) h·Mg⁻¹ and 35.34 (SD ± 4.88) €·Mg⁻¹ in class 1, respectively. Fuel consumption ranges from 3.04 (SD ± 0.88) L·Mg⁻¹ in class 5 to 7.32 (SD ± 1.46) L·Mg⁻¹ in class 1. The lowest CO₂ emission of 8.03 (SD ± 2.32) kg·Mg⁻¹ was found class 5. However, the total cost of coppice production did not exceed large-scale MRC production due to the lower purchase price of the machinery involved. Eventually, predictive models showed high reliability as estimating tools for important variables, such as working time, working productivity, CO₂ emissions, energy consumption, fuel consumption and costs. Full article

Solid biofuels, including wood chips, are still the most important feedstock in the structure of primary energy production from renewable energy sources. Wood chips are derived mainly from forests and the wood industry, including sawmills. However, the considerable diversity of chipper types results in great differences in their final production efficiency. The objective of this study was to analyze and evaluate the efficiency of three mobile chippers used in wood chip production by determining their throughput rate, diesel fuel and energy consumption, cost of chipping and greenhouse gas emission, as well as the quality of the chips. By far shortest time (0.82 min. Mg⁻¹) of producing 1 Mg of wood chips was found for the Albach 565 kW chipper. Moreover, the mean time needed for the production of 1 Mg of chips with a chipper of the same make but with a smaller engine (Albach 515 kW) was 8.8% longer. This time was 284.9% longer than when the Bruks chipper was used. However, the highest mean effectiveness of diesel fuel use (expressed as the lowest diesel fuel consumption of 1.41 dm³ Mg⁻¹), the lowest energy consumption (52.02 MJ Mg⁻¹), the lowest cost of diesel fuel use (2.28 € Mg⁻¹) and the lowest GHG emission (4.27 kg Mg⁻¹ CO_2eq) in wood chip production were determined for the Albach 515 kW chipper. In contrast, the poorest parameters were determined for the Bruks chipper. Full article

Aimed at the problems of difficult treatment, unreasonable utilization and serious waste of fruit tree residue, combined with the terrain and planting characteristics of hilly orchards, a self-propelled monorail branch chipper was developed. It can realize long distances and large ranges of crushing operations and debris tiling in the garden. Because the monorail branch chipper adopts the half-empty suspension support method, the moving operations and discontinuous cutting of branches can lead to vibration failures or hazards. In response to this problem, modal analysis of a track system with different numbers of nodes by ANSYS software showed that an increase in the number of track sections decreases the natural frequency of each order under the condition of rigid fixation of the support rods, and weakness of vibration is especially seen in sections 1–4, but after a certain amount, the vibrational change tends to level off. The number of lateral rods should be increased for distal short rail branches of less than four sections to reduce operational and operational vibration. The vibration level test results of field multi-condition and multi-point grinding operations showed that the static vibration amplitude of the crusher is basically the same as that of the mobile state. The vibration amplitude of the chipper is significantly increased when in the states from no-load to grinding operation, and the maximum vibration occurs in the left and right direction of the transverse rail, which provides a theoretical basis and optimization direction for further optimization of the single-track branch chipper operational stability problem. Full article

The projected increase in the availability of gaseous fuels by growing popularity of household natural gas (NG) filling stations and the increase in the production of gaseous biogas-derived fuels is conducive to an increase in the use of NG fuel. Currently, natural gas in various forms (compressed natural gas (CNG), liquefied natural gas (LNG)) is popular in maritime, rail and road transport. A new direction of natural gas application may be non-road mobile machines powered by a small spark-ignition engine (SI). The use of these engines in the wood chippers can cause the reduction of machine costs and emissions of harmful exhaust gases. In addition, plant material chippers intended for composting in bio-gas plants can be driven by the gas they are used to produce. The biogas can be purified to bio-methane to meet natural gas quality standards. The article presents the design of the natural gas supply system, which is an upgrade of the Lifan GX 390 combustion engine spark ignition engine (Four-stroke, OHV (over head valve) with a maximum power of 9.56 kW), which is a common representative of small gasoline engines. The engine is mounted in a cylindrical chipper designed for shredding branches with a maximum diameter of up to 100 mm, which is a typical machine used for cleaning work in urban areas. The engine powered by CNG and traditionally gasoline has been tested in real working conditions, when shredding cherry plum (Prunus cerasifera Ehrh. Beitr. Naturk. 4:17. 1789 (Gartenkalender4:189–204. 1784)). Their diameter was ca. 80 mm, 3-metere-long, and humidity content ca. 25%. The systems were tested under the same actual operating conditions, the average power generated by the drives during shredding is about 0.69 kW. Based on the recorded results, it was found that the CNG-fuelled engine was characterized by nitrogen oxides (NO_x) emissions higher by 45%. The other effects of CNG were a reduction in carbon dioxide (CO₂), carbon monoxide (CO) and hydrocarbon (HC) emissions of about 81%, 26% and 57%, respectively. Additionally, the use of CNG reduced fuel consumption by 31% and hourly estimated machine operating costs resulting from fuel costs by 53% (for average fuel price in Poland: gasoline: 0.99 EUR/L and CNG: 0.71 EUR/m³ on 08 November 2020). The modernization performed by the authors ensured the work of the drive unit during shredding, closer to the value of stoichiometric mixtures. The average (AVG) value of the air fuel ratio (AFR) for CNG was enriched by 1.2% (AVG AFR was 17), while for the gasoline engine the mixture was more enriched by 4.8% (AVG AFR was 14). The operation of spark-ignition (SI) combustion engines is most advantageous when burning stoichiometric mixtures due to the cooperation with exhaust aftertreatment systems (e.g., three-function catalytic converter). A system powered by CNG may be beneficial in systems adapting to operating conditions, used in low-power shredding machines, whose problem is increased HC emissions, and CNG combustion may reduce them. The developed system does not exceed the emission standards applicable in the European Union. For CO emissions expressed in g/kWh, it was about 95% lower than the permissible value, and HC + NO_x emissions were 85% lower. This suggests that the use of the fuel in question may contribute to tightening up the permissible emission regulations for non-road machinery. Full article

The effectiveness and precision of transporting wood chips on the transport trailer or hopper depends on an inclination angle, a conveyor belt speed, and length. In order to devise a methodology aiding designing and the selection of technical and performance parameters (aiding the settings of conveyor belt sub-assemblies), the authors carried out the simulation tests concerning wood chips transport on the belt conveyor and their outlet. For the purposes of these tests, a simulation model was performed in the Rocky DEM (discrete element method) software in the numerical analysis environment and compared to analytical tests. The tested wood chips were taken from cherry plum branches chipping processes (Prunus cerasifera Ehrh. Beitr. Naturk. 4:17. 1789 (Gartenkalender 4:189-204. 1784)), out of which seven basic fractions were separated, which differed mainly in terms of their diameter from 5 mm to 50 mm and the length of 150 mm. The article presents the results of wood chips ejection distance in the form of the 3D functions of wood chips ejection distance depending on the conveyor belt inclination angle and belt speed. The results are presented for five conveyor belt lengths (1 m, 2 m, 3 m, 4 m, 5 m). The tests also involved the conveyor belt inclination angle in the range from 10° to 50° and the belt velocity in the range from 1 m/s² to 5 m/s². The numerical test results demonstrate higher average values of wood chips ejection distance than designated in the analytical model. The average arithmetical difference in the results between the numerical and analytical model is at the level of 13%. Full article

The aim of the research was to verify the impact of selected parameters on the efficiency and organization of chipper operations. The paper analyzes chipping operations in Polish forests with a focus on work site location, overnight chipper location, chipper workload per site, fuel consumption, and work shift duration, as all of these factors may affect operating efficiency. The mean chipper travel distance between sites during a shift ranged from 4.74 km to 9.5 km (chippers moved on average every other day). The mean work shift duration was 12.4 h. At the end of a shift, the chippers traveled on average from 4.2 km to 6.3 km to an overnight location. At the beginning of a workday, the chippers were dispatched to sites at a distance of 2.5 km to 4.0 km. The average fuel consumption of the forwarder-mounted chippers was 16 L/h and that of the truck-mounted chipper was 7.7 L/h. It was found that the following actions have a decisive influence on the effectiveness of the operation of the chippers: determination of the size of individual tasks and the deployment of successive forest areas, indication of the proper location of the machine base, and the method of accessing the forest area. Full article

A high volume of wood forest biomass is be available at the roadside when whole three (WT) harvesting systems are applied. Besides, salvage logging operations are favourable conditions to accumulate a large amount of low-quality biomass due to the recovery of damaged trees. In mountain regions, such as the Alps, the forest’s accessibility can be a significant constraint for the eco-efficiency of chipping operations. The present study aims at evaluating the efficiency of wood-chipping operations in mountain areas based on long-term monitoring. One chipper-truck was monitored over 1200 working hours using telemetry. Different efficiency parameters were collected: machine position, collected using Global Navigation Satellite System (GNSS) receiver, and engine parameters, collected using the CAN Bus system based on J 1939. Efficiency parameters were used to compare different in-wood or landing configurations. The results show the influence of the different location of the chipping sites according to the road network. Chipping operations in space-constrained sites cause an increase in delay time and CO₂ emissions. Full article

In this study, two operational methodologies to extract thinned woods were investigated in the Nasunogahara area, Tochigi Prefecture, Japan. Methodology one included manual extraction and light truck transportation. Methodology two included mini-forwarder forwarding and four-ton truck transportation. Furthermore, a newly introduced chipper was investigated. As a result, costs of manual extractions within 10 m and 20 m were JPY942/m³ and JPY1040/m³, respectively. On the other hand, the forwarding cost of the mini-forwarder was JPY499/m³, which was significantly lower than the cost of manual extractions. Transportation costs with light trucks and four-ton trucks were JPY7224/m³ and JPY1298/m³, respectively, with 28 km transportation distances. Chipping operation costs were JPY1036/m³ and JPY1160/m³ with three and two persons, respectively. Finally, the total costs of methodologies one and two from extraction within 20 m to chipping were estimated as JPY9300/m³ and JPY2833/m³, respectively, with 28 km transportation distances and three-person chipping operations (EUR1 = JPY126, as of 12 August 2020). Full article

Alternative fuel within the meaning of Directive 2014/94/EU is, among others, LPG (liquefied petroleum gas), characterized by a lower purchase cost and lower emissions of toxic exhaust compounds in comparison to the combustion of classic gasoline. In wood chippers, intended for chopping branches, with low-power internal combustion engines that meet the emission standards in force in 2019 in the European Union, in accordance with Regulation 2016/1628/EU, carburetor fuel supply systems are commonly used. Innovative trends in the development of these drives are: electronic fuel injection, systems supporting the adaptation of the working elements to the conditions of use and the use of alternative fuels. The first two solutions significantly affect the cost of purchasing a power unit or modernizing it. The authors of this article indicate, as a beneficial alternative, a cheap (EUR 105) possibility of modernizing the carburetor fuel supply system. It is based on a modification that will allow for the use of LPG instead of gasoline to drive the working system of the wood chipper. This article presents the results of tests on the fuel consumption of a wood chipper powered with gasoline (3.04 L h⁻¹) and LPG (3.65 L h⁻¹) during continuous chipping. The cost of an hour of chipping related to fuel consumption was determined, which was equal to 3.89 € h⁻¹ while using gasoline, and 2.19 € h⁻¹ when using LPG. The mass flow rate (0.66 t h⁻¹) and volumetric flow rate (3.5 m³ h⁻¹) of a wood chipper powered by a low-power (9.5 kW) internal combustion engine with spark ignition were determined. In addition, we determined the cost of producing 1 m³ of biomass from chipping freshly cut oak branches (Quercus robur L. Sp. Pl. 996 1753) with a maximum diameter of 80 mm and a humidity of 25%. The branches were selected earlier in such a way that their dimensions as as similar as possible. This amounted to EUR 1.11 for a gasoline-powered drive and EUR 0.63 for a LPG powered one. The benefits of using an alternative fuel supply system, the installation of which increases the cost of the machine by 8.4%, have been confirmed. Full article
