Large-span precast prestressed concrete box girders have been widely used in bridge construction near or across the sea. However, this would easily lead to a hydration heat problem, including large initial tensile stress and concrete cracks during the stage of concrete pouring. A 5 m long segment of the prestressed concrete box girder for the Hangzhou Bay Cross-Sea Railway Bridge was continuously monitored to investigate the hydration heat effect on the long-span concrete box girder during the pouring stage of construction. The initial temperature variation and stress distribution of the concrete in the segment were analyzed through finite element analysis based on the experimental data and temperature monitoring results. A suitable concrete pouring and maintenance plan for the box girder was proposed after the comparison of several construction schemes. The results indicate that the primary cause of initial tensile stress is the temperature difference between the inner and outer surfaces of the long-span precast concrete box girder. By adding some ventilation inside the box girder with suitable maintenance measures, the initial tensile stress in the concrete can be effectively reduced, thus mitigating the risk of early cracking. Full article

Friction pendulum bearings are widely used seismic isolation devices for bridges, with their behavior governed by friction during excitation. Sliding velocity and contact pressure are among the factors that substantially affect the friction coefficient. Common friction models include the Coulomb model, which assumes constant friction and neglects both sliding velocity and contact pressure, and the velocity-dependent model, which ignores contact pressure. This study investigates the impact of neglecting contact pressure on bridge response by additionally employing a velocity-pressure-dependent friction model and comparing the effects of these three models on the bridge response. Five 3-span box-girder RC bridges were modeled in OpenSees (v3.5.0) using Coulomb, velocity-dependent, and velocity-pressure-dependent friction models. Deck height variations were introduced to account for axial load changes on bearings. Nonlinear time history analyses were performed to evaluate seismic responses. The study also explored the effects of substructure-to-superstructure mass ratio and variations in the experimentally obtained rate parameter of velocity-dependent and velocity-pressure-dependent models. Results indicate that the velocity-pressure-dependent model provides more consistent predictions, while the rate parameter has negligible effects. The velocity-pressure-dependent model increases isolator displacement by nearly 2.5 times compared to the Coulomb and velocity-dependent models. Differences in responses are influenced more by the mass ratio than by the deck aspect ratio. Full article

Bridges are widely used for train transportation. Some bridges must be constructed close to geologic faults or across them due to the constraints of travel route alignment and the geographical environment. Taiwan is located at the junction of the Eurasian Plate and the Philippine Plate, where geological joints are present and earthquakes are frequent. In Taiwan, the monitoring and early warning of structural displacements is increasingly important, especially in the mutual control and monitoring of bridges and railways. This study utilizes fiber as a continuous sensor to monitor the safety of railway bridges in a near-fault region. This research builds upon the theory of Brillouin frequency shift (BFS) and applies it to a practical scenario of a fault-crossing railway bridge. BFS is related to the strain and temperature change in a single-mode fiber. Distributed fiber optic sensing (DFOS) systems enable us to detect shifts in frequency on the sensing fiber. A systemic approach to installing DFOS systems will be discussed. Data from a DFOS system are collected, and through data processing, they are converted into strain with regard to the deformations (bending, tension, compression) of a box girder bridge. Changes in the geometric structure of the box girder bridge throughout the year are measured and processed into graphical data. This system can be effectively applied to the structural safety monitoring of railway bridges. Through this research, several functions have been achieved, including continuous displacement, automatic monitoring, and real-time automatic alarm functions, without the need for human intervention. Full article

The narrow-width steel box girder is an important type of steel–concrete composite bridge structure, which is usually composed of reinforced concrete wing plates, narrow steel boxes partially injected with concrete, and shear connectors that promote shear force transfer. The utilization of narrow-width steel box girders, augmented by partially filled concrete, embodies the synthesis of steel and concrete elements, fostering structural efficiency. Moreover, its attributes, including reduced structural weight, diminished vertical profile, enhanced load-bearing capacity, and augmented stiffness, have prompted its gradual integration into bridge engineering applications. In this study, the calculated values of shear strength under three current design codes were reviewed, and the shear failure phenomena and its determinants of narrow-width steel box–ultra-high-performance concrete (UHPC) composite beams under negative bending moment conditions were investigated, which were mainly determined by shear span ratio, concrete wing plate, UHPC steel fiber content, UHPC plate thickness, and transverse partition inside the box. Concurrently, this paper evaluates two innovative structural designs, including a double-narrow steel box girder and a three-narrow steel box girder. In addition, strategies to reduce crack formation under the negative bending moment of long-span continuous narrow and wide box girder abutments are discussed, and we show that this measure can effectively control the formation of cracks to support the negative bending moment zone. At the same time, the scope of the application of a narrow-width steel box girder composite bridge is reviewed, and the conclusion is that a narrow-width steel box girder is mainly used in small-radius flat-curved bridges or widened-ramp bridges with a span of 30 m or more in interworking areas and in the main line with a 60–100 m span in mountainous or urban areas. Finally, the research direction of the shear resistance of the UHPC–narrow steel box girder under negative bending moments is proposed. Full article

The objective of this study was to determine the reasonable flexural functions of ultra-wide box girders, reveal the mechanism of the shear lag effect, and improve the analysis theory of ultra-wide box girders. Considering a single-box three-chamber thin-walled box girder as an example, starting from an uneven transfer of shear flow, the flexural displacement function of the curved box girder under the influence of shear deformation of each plate was derived according to the flexural theory of a thin-walled box girder, balance equation of a thin-walled microelement plate, and theory of plane stress. The energy variational method was used to analyze the flexural displacement function, providing a theoretical solution for the shear lag effect of the curved box girder. A displacement correction of the cantilever plate displacement function was performed by comparing the calculation results for the shear lag coefficients. The results indicated that under the shear deformation of each plate, the flexural displacement functions of the wing and web plates of the box girder no longer satisfy the assumption of plane section. The flexural displacement function is a quadratic function of the transverse wing plate, and the web height is the sum of the first- and third-order functions. The theoretical calculation results agree sufficiently well with the experimental results, proving that the flexural displacement function of the box girder under the influence of the shear deformation of each plate is reliable. Full article

Based on the engineering background of the wide-width single cable-stayed bridge, the shear lag effects of the cross-section of these bridge box girders under the action of the eccentric load were experimentally studied. The behavior of shear lag effects in the horizontal and longitudinal bridge directions under eccentric load in the operational stage of a single cable-stayed bridge was analyzed by a model testing method and a finite element (FE) analytical method. The results showed that the plane stress calculation under unidirectional live load was similar to the results from spatial FE analysis and structural calculations performed according to the effective flange width described in the design specification. At the position of the main beam near the cable force point of action, the positive stress at its upper wing edge was greatest. At a distance from the cable tension point, the maximum positive stress position trend showed that from the center of the top flange to the junction of the top flange and the middle web to the junction of the top flange and the middle web and the side web. Under eccentric load, the positive and negative shear lag effects on the end fulcrum existed at the same time, and the shear lag coefficient on the web plate was larger than the shear lag coefficient on the unforced side. Due to the influence of constraint at the middle fulcrum near the middle pivot point, positive and negative shear lag effects were significant, and the coefficient variation range was large, resulting in large tensile stress on the roof plate in this area. According to FE analytical results, stress and shear forces of a single box three-chamber box girder under eccentric load were theoretically analyzed, the bending load decomposed into the accumulation of bending moment and axial force, using the bar simulation method, and the overall shear lag effect coefficient λ was obtained and verified. Full article

The paving layer on the steel box girder bridge deck is widely used when constructing pavements for steel bridges. Owing to the orthotropic feature of steel decks, a transverse clapboard and rib can lead to a concentration of stress. Consequently, fatigue cracks are often identified in asphalt concrete pavement layers due to re-compaction caused by heavy vehicles. This study aims to derive an evaluation method of fatigue life for asphalt pavement based on the inhomogeneous Poisson stochastic process in view of the highly random and uncertain working conditions of layered composite structures. According to the inhomogeneous Poisson stochastic process, along with Miner’s fatigue damage accumulation theory and the linear elastic fracture mechanics theory, the fatigue life formula could be deduced. Meanwhile, fatigue experiments for asphalt concrete are designed to investigate the correlation between the theoretical formula and the actual fatigue damage life of the material. Compared with the test, the accuracy error is within 10%, which is better than other traditional methods. Therefore, the fatigue life prediction model could better reflect the loading order effect and the interaction between loads, providing a new path for the fatigue reliability design of steel bridge deck asphalt pavement. Full article

Although a crane is exposed to a wide range of loads, there is a growing need for a lighter, more slender design. As a result, double girder cranes are becoming single girder cranes, aiming to make the steel structure as light as possible. The optimization potential of the classic design as a hollow-box girder is approaching its end. In order to meet today’s requirements, a new design was developed, which combines beams with curved panels into a new cross-section to be used as the crane’s main girder. Compound cross-sections pose a challenge for the mechanical engineer as there are usually no comparative data available and designing using numerical methods is complex. For this reason, a scaled model was abstracted for which a load determination will be carried out in 2024. This article deals with the finite element calculations for the design of the test specimen. A global numerical analysis was used to determine the buckling load, and several imperfection patterns were investigated. The results revealed that the buckling loads are similar to each other. This finding may lead to the conclusion that the most damaging imperfection pattern has yet to be found, which supports the need for an accompanying series of tests. Full article

Orthotropic anisotropic steel bridge panels are widely used in civil engineering due to their advantages of light deadweight, high ultimate bearing capacity, and wide range of applications. However, their fatigue problem is serious, and the fatigue-resistant design of the steel box girder diaphragm curved cutout is still difficult. In order to effectively predict the fatigue life of this typical fatigue-susceptible detail, a fatigue test of the specimen with curved notched segments of the diaphragm was carried out. ABAQUS 2016 version finite element analysis software was used to establish three kinds of finite element simplified models of the fatigue specimens with curved notches, and the laws of the influence of different notch radii on the fatigue life of the specimens were studied. Through the finite element solution of the three arc notch specimen models with different radii under the tensile load of 50 kN their respective principal stress distributions were obtained. The critical distance theory was introduced to analyze the characteristic stresses in the stress concentration area of the arc notch, and the point method and line method were used to calculate the characteristic stresses. The fatigue life prediction models of three kinds of notched components were established by combining the material fatigue limit and FE-safe life results. The results show that the point method is more conservative than the line method; no matter if the point method or the line method is used, the characteristic stress and the notch radius are inversely proportional to each other, and it is beneficial for the fatigue life of the structure to appropriately increase the notch radius. The fatigue prediction model of steel box girder diaphragms with curved notches based on the critical distance theory is of high accuracy, which is basically consistent with the test results, verifying the feasibility of the critical distance theory in the fatigue life prediction of notched specimens, and providing a reference for the fatigue life assessment of similar steel structures. Full article

The large-segment hoisting construction technology for bridges is increasingly widely used due to its flexibility and efficiency, although it also poses challenges to construction monitoring. Traditional monitoring technology is unitary with low data processing efficiency, making it difficult to meet the accuracy requirements of large-segment hoisting. The application of digital technology has brought about an opportunity for innovation in bridge construction monitoring technology. To address existing challenges and explore digital applications, this paper takes the integral hoisting construction control of the large-segment steel box girder in a large cross-sea bridge as an example, developing an alignment, stress, and temperature monitoring scheme by taking the key points of hoisting construction control into consideration. A monitoring platform was developed, and the workflow of large-segment hoisting construction monitoring is systematically summarized from the viewpoint of practical engineering, which provides a valuable reference for achieving precise and efficient construction monitoring and control in similar projects. Full article

In the context of noise reduction schemes for box-girder bridges (BGBs) used in high-speed railway, the thickened top plate design can effectively reduce the structural noise of the BGB, which has been widely recognized. However, it is difficult to obtain the optimum thickness of the top plate of the BGB without mastering the key mechanism of the noise reduction scheme. Therefore, this study took a 32 m simple-supported concrete BGB in the context of a high-speed railway as the research object and analyzed and compared the sound vibration characteristics of the entire thickened top plate versus the locally thickened top plate on BGB tracks, and the optimal noise reduction mechanism of the thickened top plate design scheme was studied in detail. The key issues of the thickened top plate noise reduction scheme are discussed. The results show that thickening the top plate can obviously reduce the bridge’s structural noise when subjected to severe vibration and high frequency bands because the vibration of the BGB is reduced. However, in the low frequency band, acoustic radiation can occur as a result of the small amplitude vibration, and this phenomenon is closely related to the vibrational distribution of the BGB. Therefore, it is necessary to focus on the vibrational distribution of the BGB as a priority when carrying out noise reduction using a thickened top plate. This paper points out the most significant factors affecting the acoustic radiation ability of the BGB in different frequency bands, especially the key problem of the strong acoustic radiation ability caused by small vibrations in low frequency band. The research results can provide an important theoretical basis for the optimal thickness design of the BGB. Full article

This article develops three transverse rib setting schemes for a 20 m wide cantilever segmental box girder of a particular engineering bridge deck, analyzes the stress rules under loads such as dead load, live load, and temperature, and studies the lateral deformation characteristics of the three schemes under symmetrical and eccentric live load arrangements on the bridge deck. Research has shown that setting transverse ribs can significantly improve the transverse stress, crack resistance, and reduce vertical deformation of the cross-section. However, its effect gradually weakens with the increase in the number of transverse ribs. Considering the convenience and simplicity of construction, installing a transverse rib structure for the large cantilever section box girder in this project is recommended. Full article

Simply supported prestressed concrete (PC) box girders have been widely adopted in high-speed railway bridges. In complex climatic environments, the corrosion of the prestressing strands always occurs and deteriorates the flexural behavior of PC box girders. In the present study, six T-shaped scaled beams were designed and fabricated according to the specifications for a high-speed railway PC box girder. The corrosion process of the prestressing strand in scaled beams was experimentally simulated by using the constant current accelerated corrosion method. The flexural behavior of corroded high-speed railway simply supported PC box girders was then investigated through four-point bending tests and theoretical investigation. The experimental results showed that strand corrosion significantly decreased the flexural behavior of the test beams. When the mass loss was 12.30%, the cracking load, ultimate load, and ductility decreased by 27.8%, 29.9%, and 11.5%, respectively. The effect of strand corrosion on flexural stiffness displayed a difference before and after concrete cracking. The failure mode changed when strand mass loss was above a critical value (7%). The flexural bearing capacity degradation law of corroded PC beams could be divided into two distinct stages. A strand mass loss of less than 7% could lead to a linear degradation law with a relatively slight reduction. As mass loss increased, it exhibited an exponential and sharp declining trend. An analytical model including the effects of strand cross-section reduction, strand property deterioration, and concrete cracking was also proposed to predict the flexural behavior of corroded PC beams. By comparison with the experimental data, it was found that the model could predict the cracking moment, flexural bearing capacity, and failure mode well. Full article

For a wide-flanged composite box girder bridge, the risk of fatigue cracking in the external inclined strut welded joint under the fatigue vehicle load is a problem. The main purposes of this research are to verify the safety of the main bridge of the Linyi Yellow River Bridge, a continuous composite box girder bridge, and to propose suggestions for optimization. In this research, a finite element model of one segment of the bridge was established to investigate the influence surface of the external inclined strut, and, using the nominal stress method, it was confirmed that the fatigue cracking of the welded details of the external inclined strut was risky. Subsequently, a full-scale fatigue test of the external inclined strut welded joint was carried out, and the crack propagation law and S-N curve of the welded details were obtained. Finally, a parametric analysis was conducted with the three-dimensional refined finite element models. The results showed that the welded joint in the real bridge has a fatigue life larger than that of the design life, and methods such as increasing the flange thickness of the external inclined strut and the diameter of the welding hole are beneficial to improve its fatigue performance. Full article

Steel–concrete composite box beams are widely used in bridge engineering, which might bear transverse and longitudinal bending moments simultaneously under vehicle loads. To investigate the fatigue performance of joints between the steel girders and the top reinforced concrete (RC) slabs under transverse bending moments, a reduced scale joint between the weathering steel girder with the corrugated steel web (CSW) and the top RC slab was designed and tested under constant amplitude fatigue loads. Test results show that the joint initially cracked in the weld metal connecting the CSW with the bottom girder flange during the fatigue loading process. The initial crack propagated from the longitudinal fold to the adjacent inclined folds after the specimen was subjected to 7.63 × 10⁵ loading cycles and caused the final fatigue failure. Compared with the calculated fatigue lives in the methods recommended by EC3 and AASHTO, the fatigue performance of the details involved in the joint satisfied the demands of fatigue design. Meanwhile, finite element (FE) models of joints with different parameters were established to determine their effect on the stress ranges at the hot spot regions of the joints. Numerical results show that improving the bending radius or the thickness of the CSW helps to reduce the stress ranges in the hot spot regions, which is beneficial to enhance the fatigue resistance of the investigated fatigue details accordingly. Full article
