When processing widely used materials in welded structures such as steels, a surface operation such as plasma cutting applied in the automated Computer Numerical Control (CNC) version can provide technical and economic benefits to the cut components, but the impact on health and environment must be addressed accordingly. In this paper, a plate with a base material made of S355J2 + AR structural steel is cut in 10 pieces with plasma in a water-bed designed and manufactured by the authors in order to mitigate such risks. The surfaces cut in the water-bed are compared to surfaces cut in open air by macroscopic analyses of the edge cut, by microscopic analyses of the cut parts—base material, heat-affected zone, and cut area—and by hardness determinations. The results reveal improvements as a result of plasma cutting in the water-bed: slag reduction, preservation of granulation, transformations in the austenitic temperature zone, and hardness in the heat-affected zone. Compared to a classical cutting procedure such as oxygen flame cutting, the proposed procedure offers a clean alternative and also requires low maintenance. Full article

Welding defects threaten structural integrity, demanding efficient and accurate detection methods. Traditional radiographic testing defects interpretation is subjective, necessitating automated solutions to improve accuracy and efficiency. This study integrates wavelet transform convolutions (WTConv) into YOLOv11n, creating WT-YOLO, to enhance defect detection in X-ray films. Wavelet transforms enable multi-resolution analysis, extracting both high-frequency and low-frequency features critical for detecting various welding defects. WT-YOLO replaces standard convolutional layers with WTConv, improving multi-scale feature extraction and noise suppression. Trained on 7000 radiographic images, WT-YOLO achieved a 0.0212 increase in mAP75 and a 0.0479 improvement in precision compared to YOLOv11n. On a test set of 200 images per defect category across seven defect types, WT-YOLO showed precision improvements of 0.0515 for cracks, 0.0784 for lack of fusion, 0.0067 for incomplete penetration, 0.1180 for concavity, 0.0516 for undercut, and 0.0204 for porosity, while experiencing a slight 0.0028 decline for slag inclusion. Compared to manual inspection, WT-YOLO achieved higher precision for cracks (0.0037), undercut (0.1747), slag inclusion (0.1129), and porosity (0.1074), with an inference speed 300 times faster than manual inspection. WT-YOLO enhances weld defect detection capabilities, providing the possibility for a robust solution for industrial applications. Full article

The recall rate of the original YOLOv4 model for detecting internal defects in aluminum alloy welds is relatively low. To address this issue, this paper introduces an enhanced model, YOLOv4-cs1. The improvements include optimizing the stacking method of residual blocks, modifying the activation functions for different convolutional layers, and eliminating the downsampling layer in the PANet (Pyramid Attention Network) to preserve edge information. Building on these enhancements, the YOLOv4-cs2 model further incorporates an improved Spatial Pyramid Pooling (SPP) module after the third and fourth residual blocks. The experimental results demonstrate that the recall rates for pore and slag inclusion detection using the YOLOv4-cs1 and YOLOv4-cs2 models increased by 28.9% and 16.6%, and 45% and 25.2%, respectively, compared to the original YOLOv4 model. Additionally, the mAP values for the two models are 85.79% and 87.5%, representing increases of 0.98% and 2.69%, respectively, over the original YOLOv4 model. Full article

Objectives: Slag injuries in industrial settings pose risks of hearing loss and complications. The aim of this study is to provide specialists with a better understanding of the sequelae, treatment, and long-term outcomes that a patient may have following a slag injury to the tympanic membrane. Data Sources: PubMed, Embase, and Web of Science. Methods: Following the Preferred Reporting Items for Systematic Reviews and Meta-Analyses (PRISMA), multiple databases were queried for articles published from inception to 2023 describing Tympanic membrane injuries from welding. The publications were screened by two independent viewers. The Joanna Briggs Institute 2017 Critical Appraisal Checklist was used to assess the quality of studies. Results: A total of 227 articles were identified, and 9 full-text articles were included in this review, comprising a total of 18 patients. The patients’ ages ranged from 18 to 75 years. Most commonly, patients were welding overhead in a tight working space, and none of the patients were wearing protective ear equipment in addition to their welding masks. Patients experienced otalgia (n = 10; 55%), hearing loss (n = 11; 65%), vertigo (n = 6; 35%), chronic otorrhea (n = 5; 29%), and facial paralysis (n = 4; 23%). A total of 12 patients (70.6%) required surgery, most requiring debridement of metallic foreign body multiple times, some undergoing surgery up to four years post-injury. Conclusions: Tympanic membrane injuries from welding are often overlooked. They cause hearing loss and facial nerve damage. Following a period of observation, sturdy reconstruction with cartilage grafting is recommended, given the poor vasculature and inflammation after this injury. Full article

Fast high-temperature gas-phase reactions occurring in the limited space of the arc cavity in the submerged arc welding (SAW) process limit the study of specific gas-phase behaviours. A low-temperature experimental method is applied to investigate gas-phase reactions in the reaction of oxy-fluoride slag with Al-Fe-Ni metal powders. The presence of nano-strands in the slag cavities confirms the vaporisation and re-condensation of gasses. Ti is the main element in nano-strands, although some nano-strands also contain Al-Mg-Si-Na oxy-fluoride. Nano-strand end-caps contain Mn-Fe-Si fluoride, and some contain Ni. The Ni in nano-strand end-caps is sourced from the added Ni powder and indicates gas-phase transfer. The Ti in the nano-strands is sourced from the flux. Themochemistry calculations identify KAlF₄, TiF₃, NaAlF₄, SiF₄, AlF₃, SiF₃, and Na in the gas phase. Increased Al reaction results in decreased TiF₃ in the gas phase, likely due to the displacement of Ti from TiF₃, resulting in the gas-phase transfer of Ti from the flux. Comparative diffusion flux calculations support Ti nano-strand formation via the vaporisation of TiF₃ and the re-condensation of Ti. The low-temperature simulation experiment applied here can be used to study the gas reaction behaviour in the reaction of oxy-fluoride flux with metal powders. Full article

In this work, the influences of La₂O₃ addition on the connectivity of the glass network, phase compositions and microstructural evolution of weld slag were investigated through Raman spectrum, X-ray powder diffraction (XRPD), SEM and EBSD technologies. All experimental results indicated that La₂O₃ addition could modify the whole glass network’s connectivity and short-ordered units. According to the Raman spectrum, only 1 wt.% La₂O₃ addition resulted in the occurrence of a unique linking mode of Si-O and Al-O tetrahedrons that was assigned to feldspar phases (albite or anorthite). Further XRPD examination showed that the primary phases were albite and anorthite, which agreed with the Raman results. Moreover, enhanced linkage between Si-O and Al-O tetrahedrons needs a large amount Na⁺ to achieve electric neutrality. This repaired the connectivity of the slag network due to the lack of Na⁺. Additionally, the solubility of La₂O₃ in the slag matrix was limited to about 3 wt.%. Adding further La₂O₃ to this weld slag, the existence form of La₂O₃ retained its original status. Thus, La₂O₃ addition that exceeded 3 wt.% had little effect on the slag connectivity besides providing a phase interface. In conclusion, La₂O₃ addition in weld slag could promote the hardness and the formation of feldspar phases. Feldspar is an extremely fragile silicon aluminate crystal. The factors mentioned above caused the detachability to be enhanced when adding La₂O₃. Full article

In this work, the effects of the mixing water loss capacity of hydrated lime mortars with different dosages were analysed—type O (mix 1:2:9), type N (mix 1:1:6), and type M (mix 1:0.5:4.5), with additions of submerged arc welding (SAW) slag. Infrared thermography tests and optical and scanning electronic microscopy analyses of the mortars were also carried out. The experimental results showed that the mortar samples with additions of SAW slag type M, using low-cost materials, proved to be in economic and technical terms (adhesion strength) the best solution, even more so if a spatter dash layer is used, a fact that increases the adhesion strength even more. Also, the infrared thermographic results revealed that the ability of the mortar paste to yield water to the ceramic substrate in the interface regions is a relevant factor in the adhesion of these coatings. Finally, the analyses by scanning electron microscopy and optical microscopy revealed that the ability to release water to the substrate is related to the hydration of the mortar and its anchoring capacity. Furthermore, the analyses carried out demonstrated that the adhesion of the mortars is influenced and increased with the application of a layer of splashes, as the pores of the substrate become more refined and better filled with the applied mortar. Full article

Defects occurring during the welding process of metal structural components directly affect their overall strength, which is crucial to the load-bearing capacity and durability of the components. This signifies the importance of accurate measurement and assessment of weld strength. However, traditional non-destructive testing methods such as ultrasonic and non-contact camera inspection have certain technical limitations. In response to these issues, this paper analyzes the detection principle of weld strength, revealing that weld defects reduce the effective area of the structural bearing section and cause stress concentration around them. Through repeated experimental data analysis of samples, strain distribution data along the one-dimensional direction caused by defects such as slag inclusion and porosity were obtained. Experimental results show that this method can identify defect types in welds, including slag inclusion, porosity, and unevenness, and accurately measure the location and size of defects with a precision of 0.64 mm, achieving qualitative analysis of weld defects. Additionally, by deploying distributed optical fiber sensors (DOFS) at different vertical distances along the weld direction, the propagation law of stress induced by different types of weld defects on samples was thoroughly analyzed. This further validates the advantages of this method in weld strength detection, including high spatial resolution, high sensitivity, and non-destructive measurement. Full article

The identification of slag inclusion defects in welds is of the utmost importance in guaranteeing the integrity, safety, and prolonged service life of welded structures. Most research focuses on different kinds of weld defects, but branch research on categories of slag inclusion material is limited and critical for safeguarding the quality of engineering and the well-being of personnel. To address this issue, we design a simulated method using ultrasonic testing to identify the inclusion of material categories in austenitic stainless steel. It is based on a simulated experiment in a water environment, and six categories of cubic specimens, including four metallic and two non-metallic materials, are selected to simulate the slag materials of the inclusion defects. Variational mode decomposition optimized by particle swarm optimization is employed for ultrasonic signals denoising. Moreover, the phase spectrum of the denoised signal is utilized to extract the phase characteristic of the echo signal from the water–slag specimen interface. The experimental results show that our method has the characteristics of appropriate decomposition and good denoising performance. Compared with famous signal denoising algorithms, the proposed method extracted the lowest number of intrinsic mode functions from the echo signal with the highest signal-to-noise ratio and lowest normalized cross-correlation among all of the comparative algorithms in signal denoising of weld slag inclusion defects. Finally, the phase spectrum can ascertain whether the slag inclusion is a thicker or thinner medium compared with the weld base material based on the half-wave loss existing or not in the echo signal phase. Full article

The submerged arc welding (SAW) process is operated at high temperatures, up to 2500 °C, in the arc cavity formed by molten oxy-fluoride flux (slag). These high arc cavity temperatures and the complex interaction of gas–slag–metal reactions in a small space below the arc render the study of specific chemical interactions difficult. The importance of gas phase reactions in the arc cavity of the SAW process is well established. A low-temperature (1350 °C) experimental method was applied to simulate and study the vaporisation and re-condensation behaviour of the gas species emanating from oxy-fluoride flux. Energy dispersive X-ray spectroscopy (EDX) analyses and reaction thermochemistry calculations were combined to explain the role of Al as a de-oxidiser element in gas phase chemistry and, consequently, in nano-strand formation reactions. EDX element maps showed that the nano-strands contain elemental Ti only, and the nano-strand end-caps contain Co-Mn-Fe fluoride. This indicates a sequence of condensation reactions, as Ti in the gas phase is re-condensed first to form the nano-strands and the end-caps formed from subsequent re-condensation of Co-Mn-Fe fluorides. The nano-strand diameters are approximately 120 nm to 360 nm. The end-cap diameter typically matches the nano-strand diameter. Thermochemical calculations in terms of simple reactions confirm the likely formation of the nanofeatures from the gas phase species due to the Al displacement of metals from their metal fluoride gas species according to the reaction: yAl + xMF_y ↔ xM + yAlF_x. The gas–slag–metal equilibrium model shows that TiO₂ in the flux is transformed into TiF₃ gas. Formation of Ti nano-strands is possible via displacement of Ti from TiF₃ by Al to form Al-fluoride gas. Full article

The article presents the influence of heat treatment on the kinetics of transformations in lean duplex LDX2101 steel and a weld made of standard duplex 2209 material, which was welded by manual metal arc welding. Changes in the microstructure, hardness, and magnetic phase content were analyzed after heat treatment was conducted at a temperature of 800 °C for a period ranging from 15 to 1440 min. Light and scanning microscopy, Vickers hardness measurements, and magnetic phase content measurements using a ferritoscope were used for the research. In the LDX2101 steel, the presence of δ-ferrite and γ austenite was identified and additional Cr₂N nitrides were observed in the heat-affected zone. After heat treatment, the decomposition of δ ferrite into γ₂ austenite and Cr₂N nitrides was observed in both areas. In the case of weld made by the coated electrode in 2209 grade, a ferritic–austenitic microstructure with allotriomorphic austenite (γ_A), Widmanstätten austenite (γ_W), and idiomorphic austenite (γ_I) and δ-ferrite area with “bee swarms” of fine precipitations of chromium nitrides Cr₂N and non-metallic inclusions (NMIs) of slag, formed during the welding process, are observed in the as-welded state. After heat treatment, the presence of the χ phase (after 15 min of annealing) and the σ phase (after 120 min of annealing) was additionally identified. The kinetics of intermetallic phase evolution in welds made from 2209 material were presented. The obtained results of hardness measurements and metallographic tests were correlated, which allowed for a quick check of the precipitation processes on the used element. Full article

The physical phenomena of submerged arc welding (SAW) conducted with a 1.6 mm flux-cored wire were investigated using X-ray imaging technique. Three kinds of metal transfer modes were confirmed in this paper, namely the front flux wall-guided droplet transfer, back flux wall-guided droplet transfer, and repelled droplet transfer, of which the corresponding percentages were 47.65%, 45.29%, and 7.06%, respectively. Although the average sizes of the droplets for SAW and FCAW (flux-cored wire welding) were 2.0 mm and 1.9 mm with an average droplet transfer time of 90.3 ms, it required 36.4% more time for the droplet of SAW to finish one metal transfer than it did in FCAW. In addition, the volume of the cavity was not constant but repeated a cycle mode of “expansion and contraction” during the whole process. Thus, the dynamics of the cavity and viscous resistance caused by the flux collectively slowed down the velocity of the droplets from the wire to the weld pool in SAW. Compared with FCAW, a smoother weld without pits and pores was manufactured during the SAW process. Due to the compression effect of the flux, the 14.5 mm average weld width of SAW was 2.9 mm shorter than that of the FCAW. Furthermore, the thickness of slag with a porous structure in SAW was 2.7 times of that in FCAW, indicating that it could provide better protection to the weld of SAW. Full article

This study aims to predict and evaluate the transfer behavior of silicon employing SiO₂-bearing fluxes during submerged arc welding. Unlike previous studies that only focused on chemical reactions in the weld pool zone, this research investigates the elemental behavior of silicon subjected to essential reaction zones in a submerged arc welding process. The proposed method is compared with the traditional thermodynamic equilibrium models, enhancing the understanding of silicon transfer behavior in the submerged arc welding process. It is demonstrated that relying solely on thermodynamics within the weld pool zone is inadequate for accurately predicting the extent of silicon transfer level since the loss of silicon during the droplet zone and the improvement in oxygen content in the molten droplet are not considered, resulting in an overestimation of the ΔSi level. Finally, the limitations of the traditional elemental transfer quantification method and corresponding corrective suggestions are proposed. Full article

The detection of weld defects by using X-rays is an important task in the industry. It requires trained specialists with the expertise to conduct a timely inspection, which is costly and cumbersome. Moreover, the process can be erroneous due to fatigue and lack of concentration. In this context, this study proposes an automated approach to identify multi-class welding defects by processing the X-ray images. It is realized by an intelligent hybridization of the data augmentation techniques and convolutional neural network (CNN). The proposed data augmentation mainly performs random rotation, shearing, zooming, brightness adjustment, and horizontal flips on the intended images. This augmentation is beneficial for the realization of a generalized trained CNN model, which can process the multi-class dataset for the identification of welding defects. The effectiveness of the proposed method is confirmed by testing its performance in processing an industrial dataset. The intended dataset contains 4479 X-ray images and belongs to six groups: cavity, cracks, inclusion slag, lack of fusion, shape defects, and normal defects. The devised technique achieved an average accuracy of 92%. This indicates that the approach is promising and can be used in contemporary solutions for the automated detection and categorization of welding defects. Full article

The scope of this work is to improve the SAW process understanding and present an improved description of the SAW process in terms of gas-slag-metal reactions with alloy powder and Al powder additions. The scope does not include the materials properties of the weld metal. The latter may easily be optimised in the future by changing the weld metal chemistry once the process reactions of different element powders in SAW are understood. Aluminium as de-oxidiser element was applied to SAW to lower the oxygen partial pressure in the process. The results show the Al-Ni-Cr-Co-Cu alloyed weld metal total oxygen content was reduced to 257 ppm O, compared to the base case weld metal at 499 ppm O, made with the same flux and no metal powder additions. Thus, the aluminium that was added as a de-oxidiser element to the SAW process effectively lowered the original flux-induced partial oxygen pressure, both in the arc cavity and at the interface of the molten flux–weld pool phases. This partial oxygen pressure lowering effect of Al also prevents oxidation of Cr, preventing loss of Cr to the slag. Carbon steel was alloyed to 3.9% Al, 4.8% Ni, 4.9% Cr, 4.8% Co, 4.7% Cu at 62% Al yield, 76% Ni yield, 77% Cr yield, 75% Co yield, 74% Cu yield. SEM (scanning electron microscope) work on the three-dimensional (3D) post-weld slag sample show dome cavities with 3D rounded structures embedded in the dome cavity walls, as well as shards and nano-strands on the dome cavity walls. The 3D structures indicate vapour formation and re-condensation of oxy-fluorides. The novel application of the EERZ (effective equilibrium reaction zone) model simulates the mass transfer effects in the SAW process. This model is novel because it is the first model used to calculate the gas-slag-metal phase chemistry changes in SAW as a function of welding time. The novel SAW process modification of adding Al de-oxidiser powder with alloying element powders of the unique combination of Co-Cr-Co-Ni-Al was successfully applied. The results confirm that the gas phase and its reactions must be included in the interpretation and modelling of SAW process metallurgy. Full article
