The authors present an algorithm for determining the stiffness of the bone tissue for individual ranges of bone density. The paper begins with the preparation and appropriate mechanical processing of samples from the bovine femur and their imaging using computed tomography and then processing DICOM files in the MIMICS system. During the processing of DICOM files, particular emphasis was placed on defining basic planes along the sides of the samples, which improved the representation of sample geometry in the models. The MIMICS system transformed DICOM images into voxel models from which the whole bone FE model was built in the next step. A single voxel represents the averaged density of the real sample in a very small finite volume. In the numerical model, it is represented by the HEX8 element, which is a cube. All voxels were divided into groups that were assigned average equivalent densities. Then, the previously prepared samples were loaded to failure in a three-point bending test. The force waveforms as a function of the deflection of samples were obtained, based on which the global stiffness of the entire sample was determined. To determine the stiffness of each averaged voxel density value, the authors used advanced optimization analyses, during which numerical analyses were carried out simultaneously, independently mapping six experimental tests. Ultimately, the use of genetic algorithms made it possible to select a set of stiffness parameters for which the error of mapping the global stiffness for all samples was the smallest. The discrepancies obtained were less than 5%, which the authors considered satisfactory by the authors for such a heterogeneous medium and for samples collected from different parts of the bone. Finally, the determined data were validated for the sample that was not involved in the correlation of material parameters. The stiffness was 7% lower than in the experimental test. Full article

The role of forests is increasing because of rapid land use changes worldwide that have implications on ecosystems and the carbon cycle. Therefore, it is necessary to obtain accurate information about forests and build forest inventories. However, it is difficult to assess the internal structure of the forest through 2D remote sensing techniques and fieldwork. In this aspect, we proposed a method for estimating the vertical structure of forests based on full-waveform light detection and ranging (FW LiDAR) data in this study. Voxel-based tree point density maps were generated by estimating the number of canopy height points in each voxel grid from the raster digital terrain model (DTM) and canopy height points after pre-processing the LiDAR point clouds. We applied an unsupervised classification algorithm to the voxel-based tree point density maps and identified seven classes by profile pattern analysis for the forest vertical types. The classification accuracy was found to be 72.73% from the validation from 11 field investigation sites, which was additionally confirmed through comparative analysis with aerial images. Based on this pre-classification reference map, which is assumed to be ground truths, the deep neural network (DNN) model was finally applied to perform the final classification. As a result of accuracy assessment, it showed accuracy of 92.72% with a good performance. These results demonstrate the potential of vertical structure estimation for extensive forests using FW LiDAR data and that the distinction between one-storied and two-storied forests can be clearly represented. This technique is expected to contribute to efficient and effective management of forests based on accurate information derived from the proposed method. Full article

The estimation of forest biomass by remote sensing is constrained by different uncertainties. An important source of uncertainty is the border effect, as tree crowns are not constrained by plot borders. Lidar remote sensing systems record the canopy height within a certain area, while the ground-truth is commonly the aboveground biomass of inventory trees geolocated at their stem positions. Hence, tree crowns reaching out of or into the observed area are contributing to the uncertainty in canopy-height–based biomass estimation. In this study, forest inventory data and simulations of a tropical rainforest’s canopy were used to quantify the amount of incoming and outgoing canopy volume and surface at different plot sizes (10, 20, 50, and 100 m). This was performed with a bottom-up approach entirely based on forest inventory data and allometric relationships, from which idealized lidar canopy heights were simulated by representing the forest canopy as a 3D voxel space. In this voxel space, the position of each voxel is known, and it is also known to which tree each voxel belongs and where the stem of this tree is located. This knowledge was used to analyze the role of incoming and outgoing crowns. The contribution of the border effects to the biomass estimation uncertainty was quantified for the case of small-footprint lidar (a simulated canopy height model, CHM) and large-footprint lidar (simulated waveforms with footprint sizes of 23 and 65 m, corresponding to the GEDI and ICESat GLAS sensors). A strong effect of spatial scale was found: e.g., for 20-m plots, on average, 16% of the CHM surface belonged to trees located outside of the plots, while for 100-m plots this incoming CHM fraction was only 3%. The border effects accounted for 40% of the biomass estimation uncertainty at the 20-m scale, but had no contribution at the 100-m scale. For GEDI- and GLAS-based biomass estimates, the contributions of border effects were 23% and 6%, respectively. This study presents a novel approach for disentangling the sources of uncertainty in the remote sensing of forest structures using virtual canopy modeling. Full article

In this paper, we investigate the performance of six data structures for managing voxelised full-waveform airborne LiDAR data during 3D polygonal model creation. While full-waveform LiDAR data has been available for over a decade, extraction of peak points is the most widely used approach of interpreting them. The increased information stored within the waveform data makes interpretation and handling difficult. It is, therefore, important to research which data structures are more appropriate for storing and interpreting the data. In this paper, we investigate the performance of six data structures while voxelising and interpreting full-waveform LiDAR data for 3D polygonal model creation. The data structures are tested in terms of time efficiency and memory consumption during run-time and are the following: (1) 1D-Array that guarantees coherent memory allocation, (2) Voxel Hashing, which uses a hash table for storing the intensity values (3) Octree (4) Integral Volumes that allows finding the sum of any cuboid area in constant time, (5) Octree Max/Min, which is an upgraded octree and (6) Integral Octree, which is proposed here and it is an attempt to combine the benefits of octrees and Integral Volumes. In this paper, it is shown that Integral Volumes is the more time efficient data structure but it requires the most memory allocation. Furthermore, 1D-Array and Integral Volumes require the allocation of coherent space in memory including the empty voxels, while Voxel Hashing and the octree related data structures do not require to allocate memory for empty voxels. These data structures, therefore, and as shown in the test conducted, allocate less memory. To sum up, there is a need to investigate how the LiDAR data are stored in memory. Each tested data structure has different benefits and downsides; therefore, each application should be examined individually. Full article

In the computer vision field, many 3D deep learning models that directly manage 3D point clouds (proposed after PointNet) have been published. Moreover, deep learning-based-techniques have demonstrated state-of-the-art performance for supervised learning tasks on 3D point cloud data, such as classification and segmentation tasks for open datasets in competitions. Furthermore, many researchers have attempted to apply these deep learning-based techniques to 3D point clouds observed by aerial laser scanners (ALSs). However, most of these studies were developed for 3D point clouds without radiometric information. In this paper, we investigate the possibility of using a deep learning method to solve the semantic segmentation task of airborne full-waveform light detection and ranging (lidar) data that consists of geometric information and radiometric waveform data. Thus, we propose a data-driven semantic segmentation model called the full-waveform network (FWNet), which handles the waveform of full-waveform lidar data without any conversion process, such as projection onto a 2D grid or calculating handcrafted features. Our FWNet is based on a PointNet-based architecture, which can extract the local and global features of each input waveform data, along with its corresponding geographical coordinates. Subsequently, the classifier consists of 1D convolutional operational layers, which predict the class vector corresponding to the input waveform from the extracted local and global features. Our trained FWNet achieved higher scores in its recall, precision, and F1 score for unseen test data—higher scores than those of previously proposed methods in full-waveform lidar data analysis domain. Specifically, our FWNet achieved a mean recall of 0.73, a mean precision of 0.81, and a mean F1 score of 0.76. We further performed an ablation study, that is assessing the effectiveness of our proposed method, of the above-mentioned metric. Moreover, we investigated the effectiveness of our PointNet based local and global feature extraction method using the visualization of the feature vector. In this way, we have shown that our network for local and global feature extraction allows training with semantic segmentation without requiring expert knowledge on full-waveform lidar data or translation into 2D images or voxels. Full article

In the last decade, full-waveform airborne laser scanning (ALS_FW) has proven to be a promising tool for forestry applications. Compared to traditional discrete airborne laser scanning (ALS_D), it is capable of registering the complete signal going through the different vertical layers of the vegetation, allowing for a better characterization of the forest structure. However, there is a lack of ALS_FW software tools for taking greater advantage of these data. Additionally, most of the existing software tools do not include radiometric correction, which is essential for the use of ALS_FW data, since extracted metrics depend on radiometric values. This paper describes and presents a software tool named WoLFeX for clipping, radiometrically correcting, voxelizing the waves, and extracting object-oriented metrics from ALS_FW data. Moreover, extracted metrics can be used as input for generating either classification or regression models for forestry, ecology, and fire sciences applications. An example application of WoLFeX was carried out to test the influence of the relative radiometric correction and the acquisition scan angle (1) on the ALS_FW metric return waveform energy (RWE) values, and (2) on the estimation of three forest fuel variables (CFL: canopy fuel load, CH: canopy height, and CBH: canopy base height). Results show that radiometric differences in RWE values computed from different scan angle intervals (0°–5° and 15°–20°) were reduced, but not removed, when the relative radiometric correction was applied. Additionally, the estimation of height variables (i.e., CH and CBH) was not strongly influenced by the relative radiometric correction, while the model obtained for CFL improved from R² = 0.62 up to R² = 0.79 after applying the correction. These results show the significance of the relative radiometric correction for reducing radiometric differences measured from different scan angles and for modelling some stand-level forest fuel variables. Full article

A wealth of Full Waveform (FW) LiDAR (Light Detection and Ranging) data are available to the public from different sources, which is poised to boost extensive applications of FW LiDAR data. However, we lack a handy and open source tool that can be used by potential users for processing and analyzing FW LiDAR data. To this end, we introduce waveformlidar, an R package dedicated to FW LiDAR processing, analysis and visualization as a solution to the constraint. Specifically, this package provides several commonly used waveform processing methods such as Gaussian, Adaptive Gaussian and Weibull decompositions and deconvolution approaches (Gold and Richard-Lucy (RL)) with users’ customized settings. In addition, we also developed functions to derive commonly used waveform metrics for characterizing vegetation structure. Moreover, a new way to directly visualize FW LiDAR data is developed by converting waveforms into points to form the Hyper Point Cloud (HPC), which can be easily adopted and subsequently analyzed with existing discrete-return LiDAR processing tools such as LAStools and FUSION. Basic explorations of the HPC such as 3D voxelization of the HPC and conversion from original waveforms to composite waveforms are also available in this package. All of these functions are developed based on small-footprint FW LiDAR data but they can be easily transplanted to the large footprint FW LiDAR data such as Geoscience Laser Altimeter System (GLAS) and Global Ecosystem Dynamics Investigation (GEDI) data analysis. It is anticipated that these functions will facilitate the widespread use of FW LiDAR and be beneficial for better estimating biomass and characterizing vegetation structure at various scales. Full article

Airborne full-waveform LiDAR (ALS_FW) is able to register forest structure properties, essential for fire prevention, in more detail than airborne discrete LiDAR (ALS_D). However, few studies have analyzed ALS_FW methodological parameters (i.e., voxel size and assignation value) due to the complexity and lack of processing tools. In this paper we analyze the influence of the pulse density and ALS_FW methodological parameters on the ALS_FW metrics, as well as the characterization of understory vegetation through ALS_FW. Results show that the influence of pulse density on ALS_FW metrics may be modelled and the differences reduced by modifying ALS_FW methodological parameters. Additionally, the potential of ALS_FW for characterizing the mean height (R² = 0.949) and volume (R² = 0.951) of the understory vegetation was also proved. Full article

Accurate acquisition of forest structural parameters, which is essential for the parameterization of forest growth models and understanding forest ecosystems, is also crucial for forest inventories and sustainable forest management. In this study, simultaneously acquired airborne full-waveform (FWF) LiDAR and hyperspectral data were used to predict forest structural parameters in subtropical forests of southeast China. The pulse amplitude and waveform shape of airborne FWF LiDAR data were calibrated using a physical process-driven and a voxel-based approach, respectively. Different suites of FWF LiDAR and hyperspectral metrics, i.e., point cloud (derived from LiDAR-waveforms) metrics (DPC), full-waveform (geometric and radiometric features) metrics (FW) and hyperspectral (original reflectance bands, vegetation indices and statistical indices) metrics (HS), were extracted and assessed using correlation analysis and principal component analysis (PCA). The selected metrics of DPC, FW and HS were used to fit regression models individually and in combination to predict diameter at breast height (DBH), Lorey’s mean height (H_L), stem number (N), basal area (G), volume (V) and above ground biomass (AGB), and the capability of the predictive models and synergetic effects of metrics were assessed using leave-one-out cross validation. The results showed that: among the metrics selected from three groups divided by the PCA analysis, twelve DPC, eight FW and ten HS were highly correlated with the first and second principal component (r > 0.7); most of the metrics selected from DPC, FW and HS had weak relationships between each other (r < 0.7); the prediction of H_L had a relatively higher accuracy (Adjusted-R² = 0.88, relative RMSE = 10.68%), followed by the prediction of AGB (Adjusted-R² = 0.84, relative RMSE = 15.14%), and the prediction of V had a relatively lower accuracy (Adjusted-R² = 0.81, relative RMSE = 16.37%); and the models including only DPC had the capability to predict forest structural parameters with relatively high accuracies (Adjusted-R² = 0.52–0.81, relative RMSE = 15.70–40.87%) whereas the usage of DPC and FW resulted in higher accuracies (Adjusted-R² = 0.62–0.87, relative RMSE = 11.01–31.30%). Moreover, the integration of DPC, FW and HS can further improve the accuracies of forest structural parameters prediction (Adjusted-R² = 0.68–0.88, relative RMSE = 10.68–28.67%). Full article

The accurate estimation of individual tree level aboveground biomass (AGB) is critical for understanding the carbon cycle, detecting potential biofuels and managing forest ecosystems. In this study, we assessed the capability of the metrics of point clouds, extracted from the full-waveform Airborne Laser Scanning (ALS) data, and of composite waveforms, calculated based on a voxel-based approach, for estimating tree level AGB individually and in combination, over a planted forest in the coastal region of east China. To do so, we investigated the importance of point cloud and waveform metrics for estimating tree-level AGB by all subsets models and relative weight indices. We also assessed the capability of the point cloud and waveform metrics based models and combo model (including the combination of both point cloud and waveform metrics) for tree-level AGB estimation and evaluated the accuracies of these models. The results demonstrated that most of the waveform metrics have relatively low correlation coefficients (<0.60) with other metrics. The combo models (Adjusted R² = 0.78–0.89), including both point cloud and waveform metrics, have a relatively higher performance than the models fitted by point cloud metrics-only (Adjusted R² = 0.74–0.86) and waveform metrics-only (Adjusted R² = 0.72–0.84), with the mostly selected metrics of the 95th percentile height (H₉₅), mean of height of median energy (HOME_μ) and mean of the height/median ratio (HTMR_μ). Based on the relative weights (i.e., the percentage of contribution for R²) of the mostly selected metrics for all subsets, the metric of 95th percentile height (H₉₅) has the highest relative importance for AGB estimation (19.23%), followed by 75th percentile height (H₇₅) (18.02%) and coefficient of variation of heights (H_cv) (15.18%) in the point cloud metrics based models. For the waveform metrics based models, the metric of mean of height of median energy (HOME_μ) has the highest relative importance for AGB estimation (17.86%), followed by mean of the height/median ratio (HTMR_μ) (16.23%) and standard deviation of height of median energy (HOME_σ) (14.78%). This study demonstrated benefits of using full-waveform ALS data for estimating biomass at tree level, for sustainable forest management and mitigating climate change by planted forest, as China has the largest area of planted forest in the world, and these forests contribute to a large amount of carbon sequestration in terrestrial ecosystems. Full article
