Fibre-reinforced composites (FRCs) are already well established in several industrial sectors such as aerospace, automotive, plant engineering, shipbuilding and construction. The technical advantages of FRCs over metallic materials are well researched and proven. The key factors for an even wider industrial application of FRCs are the maximisation of resource and cost efficiency in the production and processing of the textile reinforcement materials. Due to its technology, warp knitting is the most productive and therefore cost-effective textile manufacturing process. In order to produce resource-efficient textile structures with these technologies, a high degree of prefabrication is required. This reduces costs by reducing the number of ply stacks, and by reducing the number of extra operations through final path and geometric yarn orientation of the preforms. It also reduces waste in post-processing. Furthermore, a high degree of prefabrication through functionalisation offers the potential to extend the application range of textile structures as purely mechanical reinforcements by integrating additional functions. So far, there is a gap in terms of an overview of the current state-of-the-art of relevant textile processes and products, which this work aims to fill. The focus of this work is therefore to provide an overview of warp knitted 3D structures. Full article

This paper presents a method to include unmodeled dynamics of load or a robot’s end-effector into algorithms for collision detection or general understanding of a robot’s operation context. The approach relies on the application of a previously developed modification of the Dynamic Time Warping algorithm, as well as a universally applicable algorithm for identifying kinematic parameters. The entire process can be applied to arbitrary robot configuration, and it does not require identification of dynamic parameters. The paper addresses the two main categories of contact tasks with unmodelled dynamics, which are determined based on whether the external contact force has a consistent profile in the end effector or base coordinate. Conclusions for representative examples analysed in the paper are applicable to tasks such as load manipulation, press bending, and crimping for the first type of forces and applications such as drilling, screwdriving, snap-fit, bolting, and riveting assembly for the latter category. The results presented in the paper are based on realistic testing with measurements obtained from an industrial robot. Full article

The growth of the aeronautical sector leads to the growth of polymer composites application, creating new demand for components applications in complex dimensions and shapes. Regarding different methods of draping 2D fabric into a 3D format, the concern is to keep the fabric properties and characteristics, since fiber orientation is modified after draping. For that purpose, this study aims to evaluate the drapability capacity of 2D dry fibrous fabrics (plain, twill, satin, non-crimp-fabric 0/90, and ±45) into a complex geometry, i.e., spherical indent. The energy required to drape fabric is composed of fabric deformation mechanisms (shear and bending), which were used together with microscopic deformation analysis to determine the appropriate fabric architectures with the highest malleability. Both NCF fabrics presented high energy and roughness on the fabric surface due to the folding effect of stitching. On the other hand, plain and twill weave fabrics required lower energy to drape but demonstrated higher fiber misalignment and deformation. The satin warp/weft relation favored shear and bending mechanisms, presenting better uniformity in load distribution, symmetry on drape capability, lower deformation degree, and lower fiber misalignment. Despite the intermediate load and energy required for drape, ANOVA and optimization methods confirmed that satin fabric showed better malleability behavior for complex geometries applications. Full article

Tendons and ligaments are complex tissues that are necessary for human movement. Injuries occur very commonly and treatment quite often requires implants. Such implants must be adapted to the biological and structural composition of human tendons and ligaments. Thus, the objective is to realize graded, biomimetic tendon and ligament implants that are long-term resorbable. First, basic woven fabrics are fabricated from biocompatible silk fibroin yarns. Starting from the basic fabrics, gradient fabrics, with three different weave zones, are then developed and produced. In addition, fabrics with variable width and lateral warp yarn offset are fabricated on the basis of open reed weaving (ORW) technology on a modified shuttle narrow weaving loom. Meso-scale finite element models are developed in order to support the design of the gradient weaves. First, TexGen software is used to create a close to reality fabric geometry. Models are then converted into beam element models using a Python script. Results of real and virtual tensile tests show a clear relationship between the crimp of the warp yarns in the fabric structures and the resulting elongations. The additional ORW yarn system influences the stiffness. The tensile behavior of experiments and simulation agree very well, so the models are suitable for further development of woven implants. Full article

The current research is focused on the design and development of auxetic woven structures. Finite element analysis based on computational modeling and prediction of axial strain as well as Poisson’s ratio was carried out. Further, an analytical model was used to calculate the same parameters by a foldable zig-zag geometry. In the analytical model, Poisson’s ratio is based on the crimp percentage, bending modulus, yarn spacing, and coefficient of friction. In this yarn, properties and fabric parameters were also considered. Experimental samples were evaluated for the actual performance of the defined auxetic material. Auxetic fabric was developed with foldable strips created in a zig-zag way in the vertical (warp) direction. It is based on the principle that when the fabric is stretched, the unfolding of the folds takes place, leading to an increase in transverse dimensions. Both the analytical and computational models gave close predictions to the experimental results. The fabric with foldable strips created in a zig-zag way in the vertical (warp) direction produced negative Poisson’s ratio (NPR), up to 8.7% of axial strain, and a maximum Poisson’s ratio of −0.41 produced at an axial strain of around 1%. The error percentage in the analytical model was 37.14% for the experimental results. The computational results also predict the Poisson’s ratio with an error percentage of 22.26%. Such predictions are useful for estimating the performance of auxetic woven structures in composite reinforcement. The auxetic structure exhibits remarkable stress-strain behavior in the longitudinal as well as transverse directions. This performance is useful for energy absorption in composite reinforcement. Full article

This work developed novel jute-yarn, non-crimp, unidirectional (UD) preforms and their composites, with three different types of warp jute yarns of varying linear densities and twists in the dry UD preforms, in order to present a possible solution to the detrimental effects of higher yarn twists and crimp at the warp–weft yarn interlacements of traditional, woven, preform-based composites on their mechanical properties. In the developed UD preforms, warp jute yarns were placed in parallel by using a wooden picture-frame pin board, with the minimal number of glass weft yarns to avoid crimp at the warp–weft yarns interlacements, which can significantly enhance the load-bearing ability of UD composites compared to traditional, woven, preform composites. It was found that an optimal combination of jute warp yarn linear densities and twists in the UD preforms is important to achieve the best possible mechanical properties of newly developed UD composites, because it encourages a proper polymer-matrix impregnation on jute fibres, leading to excellent fibre–matrix interface bonding. Composites made from the 25 lb/spindle jute warp yarn linear density (UD25) exhibited higher tensile and flexural properties than other UD composites (UD20, UD30). All the UD composites showed a much better performance compared to the traditional woven preform composites (W20), which were obviously related to the higher crimp and yarn interlacements, less load-carrying capacity, and poor fiber–matrix interfaces of W20 composites. UD25 composites exhibited a significant enhancement in tensile modulus by ~232% and strength by ~146%; flexural modulus by 138.5% and strength by 145% compared to W20 composites. This reveals that newly developed, non-crimp, UD preform composites can effectively replace the traditional woven composites in lightweight, load-bearing, complex-shaped composite applications, and hence, this warrants further investigations of the developed composites, especially on long-term and dynamic-loading mechanical characterizations. Full article

The aim of this study was to investigate the distribution of crimp in new jacquard fabric structures (in which one-layer and two-layer weaves are combined) in the fabric width and to create a method of crimp prediction. It was established that crimp was around 18.80% and changed within the limits of errors, i.e., a range of only ~4%, in the fabric width. It can therefore be said that the warp crimp was constant in the fabric width. Because the warp crimp of jacquard fabric changed insignificantly (within the limits of errors), it can be stated that the fabric-setting parameters and structural solutions were chosen and matched correctly, and such fabric can be woven on any jacquard weaving loom. Full article

As promising fibrous reinforcements in the thick composites manufacturing, 3-dimensional warp interlock fabrics (3DWIFs) are recognised more and more in the industry for their outstanding mechanical properties compared to the 2D laminates. The present work shows the influence of the fabric’s architecture on the tensile behaviour of 3DWIFs. Five kinds of 3D fabrics with different interlock structures have been designed according to the main category of binding warp yarn evolution. These five 3DWIFs, containing both binding and stuffer warp yarns and produced with the same warp and weft densities, are experimentally tested via uniaxial tensile tests. The experimental results of the different 3DWIFs have been compared to find the optimal solution based on several mechanical performances. Fabric structures have an impact on tensile properties both in the warp and weft directions. Furthermore, other influential factors, for example, the yarn crimps during the weaving process and the crimp angles of binding warp yarns in 3DWIFs, are investigated and discussed in the paper. The influence of the total crimp angles related to the binding path on the tensile properties of 3DWIFs via the inter yarns friction is summarised. Full article

Composite industry has long been seeking practical solutions to boost laminate through-thickness strengths and interlaminar shear strengths (ILSS), so that composite primary structures, such as stiffeners, can bear higher complex loadings and be more delamination resistant. Three dimensional (3D) woven fabrics were normally employed to render higher transverse and shear strengths, but the difficulty and high expense in producing such fabrics make it a hard choice. Based on a novel idea that the warp yarns that interlock layers of the weft yarns might provide adequate fiber crimps that would allow the interlaminar shear or radial stresses to be transferred and borne by the fibers, rather than by the relatively weaker matrix resin, thus improving the transverse strengths, this work provided a two point five dimensional (2.5D) approach as a practical solution, and demonstrated the superior transverse performances of an economical 2.5D shallow-bend woven fabric (2.5DSBW) epoxy composites, over the conventional two dimensional (2D) laminates and the costly 3D counterpart composites. This approach also produced a potential candidate to fabricate high performance stiffeners, as shown by the test results of L-beams which are common structural components of any stiffeners. This study also discovered that an alternative structure, namely a 2.5D shallow-straight woven fabric (2.5DSSW), did not show any advantages over the two control structures, which were a 2D plain weave (2DPW) and a 3D orthogonal woven fabric (3DOW) made out of the same carbon fibers. Composites of these structures in this study were conveniently fabricated using a vacuum-assisted resin infusion process (VARI). The L-beams were tested using a custom-made test fixture. The strain distribution and failure mode analysis of these beams were conducted using Digital Image Correlation (DIC) and X-ray Computed Tomography Scanning (CT). The results demonstrated that the structures containing Z-yarns or having high yarn crimps or waviness, such as in cases of 3DOW and 2.5DSBW, respectively, were shown to withstand high loadings and to resist delamination, favorable for the applications of high-performance structural composites. Full article

Glass warp-knitted fabrics have been widely used as complex structural reinforcements in composites, such as wind turbine blades, boats, vehicles, etc. Understanding the mechanical behavior and formability of these textiles is very necessary for the simulation of forming processes before manufacturing. In this paper, the shear deformation mechanics of glass warp-knitted non-crimp fabrics (WKNCF) were experimentally investigated based on a picture frame testing apparatus equipped to a universal testing machine. Three commercially available fabrics of WKNCFs were tested for four cycles by the picture frame method. The aim was to characterize and compare the shear behavior of relatively high areal density fabrics during preform processing for composites. The energy normalization theory was used to obtain the normalized shear force from the testing machine data; then, the shear stress against the shear angle was fitted by cubic polynomial regression equations. The results achieved from the equations demonstrated that the in-plane shear rigidity modulus was associated with the shear angle. The effect of the shearing cycles and stitching pattern on shear resistance was also analyzed. Full article
