With the increasing penetration of distributed generation and the diversification of electrical equipment, distribution networks face issues like three-phase unbalance and harmonic currents, while the voltage stability and inertia of the grid-connected system also decrease. A certain amount of energy storage is needed in a Distribution Static Synchronous Compensator (DSTATCOM) to manage power quality and actively support voltage and inertia in the network. This paper first addresses the limitations of traditional $dq0$ compensation algorithms in effectively filtering out negative-sequence twice-frequency components. An improved $dq0$ compensation algorithm is proposed to reduce errors in detecting positive-sequence fundamental current under unbalanced three-phase conditions. Second, considering the impedance ratio characteristics of the distribution network, while reactive power voltage regulation is common, active power regulation is more effective in high-resistance distribution networks. A grid-forming model-based active and reactive power coordinated voltage regulation method is proposed. This method uses synchronous control to establish a virtual three-phase voltage internal electromotive force, forming a comprehensive compensation strategy that combines power quality improvement and active voltage support, exploring the potential of energy storage DSTATCOM applications in distribution networks. Finally, simulation and experimental results demonstrate the effectiveness of the proposed control method. Full article

Virtual synchronous generator (VSG) control has positive effects on the stability of microgrids. In practical power systems, both single-phase loads and three-phase unbalanced loads are present. The four-leg inverter is an alternative solution for the power supply of unbalanced loads and grid connections. The traditional VSG control strategy still faces challenges when using a four-leg inverter to provide a symmetrical voltage and stable frequency in the load power supply and pre-synchronization. This paper proposes a VSG-based control strategy along with a pre-synchronization method for four-leg inverters. An improved VSG control strategy is put forward for four-leg inverters. The improved virtual impedance control and power calculation methods are integrated into the control loop to suppress the voltage asymmetry and frequency ripples. Building on the improved VSG control strategy, a pre-synchronization control approach is proposed to minimize the amplitude and phase angle discrepancies between the inverter output voltage and the power grid voltage. In addition, an optimized design method for control parameters is presented to improve VSG dynamic performance. A hardware prototype of the four-leg inverter is built; the results show that the voltage unbalance ratio can be reduced by 89%, and the response time can be shortened by 50%. Full article

Ternary organic solar cells (OSCs) have attracted intensive studies due to their promising potential for attaining high-performing photovoltaics, whereas there has been an opening challenge in minimizing the open circuit voltage (V_oc) loss while retaining the optimal carrier extraction in the multiple mixture absorbers. Here, we systemically investigate a ternary absorber comprised of two acceptors and a donor, in which the resultant V_oc and fill factor are varied and determined by the ratios of acceptor components as a result of the unbalance of non-radiative recombination rates and charge transport. The transient absorption spectroscopy and electroluminescence techniques verify two distinguishable charge-transfer (CT) states in the ternary absorber, and the mismatch of non-radiative recombination rates of those two CT states is demonstrated to be associated with the V_oc deficit, whilst the high-emissive acceptor molecule delivers inferior electron mobility, resulting in poor charge transport and a subpar fill factor. These findings enable us to optimize the mixture configuration for attaining the maximal-performing devices. Our results not only provide insight into maximizing the photovoltage of organic solar cells but can also motivate researchers to further unravel the photophysical mechanisms underlying the intermolecular electronic states of organic semiconductors. Full article

There has been an increasing number of renewable energy sources introduced into the distribution system to decrease the dependence on single power sources and relieve their effects related to global warming caused by power consumption. When greatly increasing renewable energy in the power system, the renewable energy connected to the power grid must be coupled with corresponding energy-storage technologies. This mechanism not only effectively improves the power floating problem but also more efficiently re-dispatches the power output. The purpose of this paper is to deal with the optimal sizing and location issue of the photovoltaic generation system and the battery energy storage system, which are proposed in order to improve the power loss, bus voltage profile, and voltage unbalance for the actual unbalanced loading distribution system of a large-scale chemical factory. The power loss, construction cost of the solar power and the energy storage systems, voltage variation ratio and voltage unbalance ratio will be treated as part of the objective function of the optimal problem. These variables are subject to various operating constraints and the voltage variation limit of the system when the photovoltaic generation and battery energy storage systems are operated. Furthermore, a refined genetic algorithm, which possesses an auto-selective crossover and mutation scheme, is proposed and applied in this paper in order to solve the optimization problem. Moreover, the simulation results are expected to demonstrate the superiority of the proposed algorithm. Full article

This study aimed to propose individual phase voltage regulation strategies using the sparrow search algorithm (SSA) in the IEEE 8500-node large-scale unbalanced distribution network with high photovoltaic (PV) penetration. The proposed approach is capable of individual phase regulation, which coordinates the on-load tap changer (OLTC), voltage regulator (VR), switched capacitor bank (SCB), and volt–var setting controlled by a smart inverter to improve voltage variation and unbalance. Consequently, the change time of VRs, the switched times of SCBs, and the individual phase voltage magnitude and unbalance ratio are considered in the fitness function for the SSA. The simulation scenarios fully consider the unbalanced load conditions and PV power output patterns, and the numerical results demonstrate that the voltage variation and unbalance are clearly improved, by 15% and 26%, respectively. The fitness values, operation times of OLTC, VR, and SCB, and the settings of the volt–var controlled smart inverter are also optimized by the SSA. The outcomes of this study are helpful for distribution system operators in formulating voltage control strategies corresponding to different system conditions. Full article

In isolated areas such as islands with small power grids, the BESS (Battery energy storage system) can supply the standard voltage and frequency to the power system to achieve 100% of renewable sharing. In addition, the installation of additional BESS may be required in the microgrid due to technical limitations such as redundant operation and manufacturer specifications. Thus, the BESSs in a microgrid can be split into main and sub BESSs which play a role as the main source and auxiliary services, respectively. Generally, the ratio of unbalance current in microgrid system tends to be high, because of inherently unbalanced single phase load distribution. However, because the capacity of BESS is calculated under balanced conditions, the PCS (Power conversion system) of BESS may stop protecting its switching device from a single phase overcurrent in actual operation. From this perspective, this paper proposes that the sub BESSs perform dual current control to supply the unbalanced current instead of the main BESS. In the simulation result of the proposed method, the current unbalance rate of the main ESS has been reduced by about 26%. Through the proposed control scheme, it is possible to prevent an unexpected single phase overload of the main BESS in the microgrid. Full article

Voltages of electric double-layer capacitor (EDLC) modules vary rather wider than traditional secondary batteries. Although EDLCs should desirably be cycled in a voltage range as wide as possible to achieve a high energy utilization ratio, the wide voltage variation of EDLC modules impairs the performance of DC–DC converters. To address such issues, previous works reported series-parallel reconfiguration techniques, which are roughly divided into balance- and unbalance-shift circuits. However, conventional balance-shift circuits are not applicable to modules comprising odd number cells, impairing modularity. Unbalance-shift circuits, on the other hand, unavoidably cause cell voltage imbalance that reduces energy utilization ratio. This paper proposes a novel series-parallel reconfigurable EDLC module with cell voltage equalization capability. The proposed reconfigurable EDLC module is applicable to any number of cells, realizing good modularity. Furthermore, all cells in the proposed module can be charged and discharged uniformly without generating cell voltage imbalance, achieving an improved energy utilization ratio compared with conventional techniques. A five-cell module prototype was built for experimental verification. While the module voltage varied between 1.04 and 2.83 V, all cells discharged from 2.5 to 0.3 V. The result is equivalent to a 98.6% energy utilization ratio. Full article

Penetration of equipment such as photovoltaic power generations (PV), heat pump water heaters (HP), and electric vehicles (EV) introduces voltage unbalance issues in distribution systems. Controlling PV and energy storage system (ESS) outputs or coordinated EV charging are investigated for voltage unbalance compensation. However, some issues exist, such as dependency on installed capacity and fairness among consumers. Therefore, the ideal way to mitigate unbalanced voltages is to use grid-side equipment mainly. This paper proposes a voltage unbalance compensation based on optimal tap operation scheduling of three-phase individual controlled step voltage regulators (3ϕSVR) and load ratio control transformer (LRT). In the formulation of the optimization problem, multiple voltage unbalance metrics are comprehensively included. In addition, voltage deviations, network losses, and coordinated tap operations, which are typical issues in distribution systems, are considered. In order to investigate the mutual influence among voltage unbalance and other typical issues, various optimization problems are formulated, and then they are compared by numerical simulations. The results show that the proper operation of 3ϕSVRs and LRT effectively mitigates voltage unbalance. Furthermore, the results also show that voltage unbalances and other typical issues can be improved simultaneously with appropriate formulations. Full article

Voltage profile is one of many aspects that affect power quality in low-voltage distribution feeders. Weak grids have a typically high line impedance which results in remarkable voltage drops. Distribution grids generally have a high R/X ratio, which makes voltage regulation with reactive power compensation less effective than in high-voltage grids. Moreover, these networks are more susceptible to unbalance and harmonic voltage disturbances. This paper proposes an enhanced coordinated control of active and reactive power injected in a distribution grid for voltage regulation. Voltage drop mitigation was evaluated with power injection based on local features, such loads and disturbances of each connection. In order to ensure disturbances rejection like harmonic components in the grid voltages, a repetitive vector-control scheme was used. The injection of coordinated active and reactive power with the proposed control algorithm was verified through simulations and experiments, demonstrating that it is a promising alternative for voltage regulation in weak and low-voltage networks subject to inherent harmonic distortion. Full article

Voltage variations of electric double-layer capacitors (EDLCs) are rather wider than those of traditional rechargeable batteries, and an energy utilization ratio of EDLCs is dependent on cells’ voltage variation ranges. To satisfactorily utilize EDLCs’ energies, voltages of EDLC modules should be within a certain range, while cells need to be charged and discharged over the wide voltage range. To this end, various kinds of series-parallel reconfiguration techniques based on balance- and unbalance-shift circuits have been proposed, but conventional techniques can only be applied to modules consisting of even number cells, impairing the design flexibility and scalability. With the unbalance-shift circuits, cell voltages are unavoidably mismatched due to unequal currents, resulting in reduced energy utilization ratios. This article proposes a novel series-parallel reconfiguration technique with voltage equalization capability for EDLC modules. The proposed technique can be applied to any number of cells, improving design flexibility and scalability. Furthermore, since the proposed circuit behaves as a switched capacitor converter, in which all cells are virtually connected in parallel, cells are equally charged and discharged without causing voltage imbalance, realizing the improved energy utilization ratio. A prototype for an EDLC module comprising four cells, each with a rated charging voltage of 2.5 V, was built and experimentally tested. The module voltage varied in the range of 3.2–5.0 V, while all cells were uniformly discharged down to as low as 0.8 V, achieving the energy utilization ratio of 90%. Full article
